BW-2500
PREMIER
USER INSTRUCTIONS
CONGRATULATIONS on your purchase of the PREMIER
remote vehicle alarm. You now own the most reliable security
system available today, utilizing the latest state of the art technology. It is American made, designed and engineered by leading
experts in the security industry.
The PREMIER comes with two 2-button code learning remote
transmitters, flashing L.E.D., dual electronic sensor,and many
additional features. It can be programmed as a manual or passive system.A number of these safety and convenience features
can be programmed into your system either by the installing
dealer, or in some cases yourself (explained below).With minimum care and upkeep, this alarm will give you many years of
service and protection. Read the following information carefully.It
will help you get the best from your system.
A) MANUAL OPERATION
1) TO ARM – Press the left button.You will hear 1 chirp
and the L.E.D.will flash slowly 10 seconds after button is
pressed.This indicates your system is armed.
2) TO DISARM – Press the left button.You will hear 2
chirps and the L.E.D.will no longer flash indicating the sys
tem is disarmed. If doors are not open before 30 seconds,
alarm will re-arm itself.
B) PASSIVE OPERATION
1) TO ARM – If your installing dealer has installed the
PREMIER as a passive system, the alarm will arm
automatically approximately 30 seconds after the last door
is closed. (Note: you can also arm immediately by pressing
the left button as in #1 above).
2) TO DISARM – Disarm system same as in #2 above.
3) VALET – Your dealer installed a valet (push button)
switch in a convenient location in the dashboard area.To
activate the valet, push for 5 seconds prior to turning off
the engine.The L.E.D. will stay on (non-flashing) while the
vehicle is in Valet.You can now leave the vehicle without
arming the system.While in valet, with the alarm inactive,
you can still lock/unlock your doors with the remote transmitters. See section C.To deactivate from the valet mode,
turn on the ignition and press the valet switch for 5 seconds.
C) DOOR LOCK AND UNLOCK
1) If your vehicle has electronic (automatic) door locks,
and your dealer connected them to the alarm, the
PREMIER will also lock when arming and unlock when
the system is disarmed in either manual or passive operation.
2) Your system can be programmed by the dealer not to
lock in the passive mode. In this case your system will arm
passively, but you must press the left button to lock the
vehicle.
3) Your door locks can also be programmed by your deal
er to lock when the ignition is turned on and to unlock
when the ignition is turned off.
If you have questions,ask your dealer to explain these very convenient features to you.
D) AUDIO-VISUAL WARNING INDICATORS –
When disarming, if you hear 3 chirps (instead of the normal
2) and the L.E.D.is flashing rapidly, it means either an entry
violation was attempted or your vehicle was bumped hard
enough to cause the alarm to trigger (check your vehicle to
make sure everything is working and there is no damage).
E) REMOTE PANIC – An important safety feature on your
PREMIER system is a remote panic which will trigger
your alarm a substantial distance away. Press left button for
3 seconds until siren sounds.To stop the siren, press the
left button.
F) STARTER INTERRUPT – As added protection, the
PREMIER has a built-in starter interrupt.When the
system is armed, the vehicle cannot be jump started, hot
wired, or started with a key.This makes it extremely tough
on any theft attempt.When you use your transmitter to
disarm the system, the vehicle can then be started normally.
(Continued on Reverse Side)
Please Keep For Future Reference
TO USE THE CODE LEARNING
SEQUENCE FOLLOW THIS PROCEDURE:
1. Turn the ignition switch ON/OFF 3 times, leave
ignition ON the 3rd time.The SIREN will chirp
once and the Door Locks (if connected) will
LOCK.
2. Within 5 SECONDS, press and HOLD the Valet
Switch for 5 seconds, the SIREN will Chirp 3
Times and the L.E.D. will turn SOLID.The System
is now in Code Learning Mode.
(Continued on Reverse Side)
Page 2
3. Press Button #1 of either transmitter for Car #1
operation, the system will respond with either 1
or 2 Siren Chirps.The system has now learned the
transmitters code. For a two car operation, follow
the steps 1 and 2 for second vehicle using button #2 of transmitter.
Turn OFF the ignition switch.
The system is now ready to be tested.
12753 Moore Street
Cerritos, California 90703
Note: The valet switch is also an emergency
override switch. If you lose or damage your re-mote
transmitter, or if there is a malfunction in the system,
you can still use your vehicle even if armed, utilizing
the following procedure. Open the door (the siren
will sound and the starter interrupt will be in effect),
turn ignition switch to “on”position, and press the
push button switch to “on” as well (your dealer will
show you where the switch is on or near the dash).
The siren will stop and the starter interrupt mode
overridden, allowing you to start the vehicle. See your dealer as
soon as possible to replace transmitter or correct any malfunction.
G) AUTOMATIC RESET – If your alarm is set-off, it will
automatically rearm itself after the cycle is completed.
H) TEMPORARY CHIRP DELETE – The PREMIER
alarm system is designed to chirp when the alarm is
armed or disarmed.There may be times when the chirp
sound is inconvenient (late at night for example).You can
temporarily stop the chirp by pressing the right button
immediately preceding the press on the left button when
arming or disarming.This eliminates the chirp that time
only. Each time you wish the chirp eliminated, the above
procedure must be used.
I) DOME LIGHT TURN ON – If you have an interior
light, the PREMIER can be set to turn it on temporarily when the disarm button is pressed.This allows you to
see in and around the vehicle as you approach it.
J) FAULTY SENSOR BY PASS – If a sensor malfunc-
tions, it will be bypassed automatically, and not stop the use
of the alarm.Therefore your vehicle is still protected.
However, bring your vehicle into your dealer as soon as
possible to fix the problem.
K) AUXILIARY FEATURES
1) MULTI-CAR USE – The PREMIER remote
transmitters can be programmed to work with control
modules of other PREMIER alarms. For example, you
can use the left button to send appropriate signals to your
car, and the right button to use for the PREMIER
alarm in a second car.
Ask your dealer about this feature.
window roll-up and more.These are acces-
sories available from your BLACK WIDOW dealer who
will explain how these accessories will work on your vehicle.
L) PROGRAMMABLE MULTI-TONE SIREN –
Your BW-2500 PREMIER comes with a Multi-tone siren which
can be programmed to sound from 1 to 6 tones. On the top of
the siren is a rubber grommet, underneath which are 6 jumper
contacts.You can program the siren by removing the rubber
grommet and removing or adding jumper contacts.Your dealer
can show you how to program your siren, as well as all the
other BLACK WIDOW accessories available to you.
ACCESSORIES AVAILABLE FOR YOUR
BLACK WIDOW BW-2500 PREMIER:
MAS-2 Radar Field Disturbance Sensor
BWS-500 Battery Back-Up
RAS-101 Remote Auto Start
TR-100 Trunk Release Module
WRM-2 Window Roll-Up Module
BWS-390 Leather Transmitter Case
PDL-50 Power Door Lock Actuator
LIMITED LIFETIME WARRANTY
The Black Widow Division of DLC, Inc. warrants to the original purchaser that the vehicle alarm system purchased will be free from
defects in workmanship.
If it is determined that a defect exists, at our option, we will repair
defective parts or replace the system. If product is defective within
one (1) year from date of purchase, item will be repaired or replaced
at no cost to original purchaser. If product is defective after one (1)
year from date of purchase, ship defective unit prepaid to Black
Widow Division, DLC, Inc. along with $20.00 U.S. ($30.00 Canadian)
cashier’s check or money order to cover cost of handling.
Proof of purchase by the original owner must accompany
warranty request before service is rendered.
This warranty covers normal use. It does not cover damage from
alteration, misuse, abuse, accident, improper installation or maintenance.Warranty does not cover transmitter batteries or cases.This
warranty gives you specific legal rights and you may have rights which
vary from state to state. If you have any questions, contact your
authorized Black Widow dealer.
DLC/U.S.A.
12753 Moore Street
Cerritos, California 90703
2) AUTOMATIC TRUNK OPENER –
The 2nd channel (right button) can be programmed to open the trunk (if the vehicle has
automatic trunk release), and other quick
release accessories.
3) ADDITIONAL USES – The 3rd channel (pressing left & right buttons at the same
time) can control remote starter, automatic
