27” Dot Chandelier
Type: Quantity:Project:
Note: SKU#:
Description
Each of Dot’s 24 arms ends in a shallow reflector with its own
center metal dot. A ring of LEDs behind the dots bounces
light off the reflector’s interior surface evenly and in all
directions, without shadows or glare.
Features
• Available in two finishes: Etched Gold and Polished Chrome
• Includes 42” length adjustable stem kit and 12’ wire length
• Fixture can accept up to four 24” additional stem sections
Maximum stem length: 11’6”
• Replaceable light source
• Driver located in canopy housing
• Hang straight swivel
• Damp location rated
6.6"
16.8 cm
2.5"
6.4 cm
Specifications
• Color Rendering Index: 90 CRI
• LED color temperature: 3000K
• Input Voltage: 120 VAC 50/60Hz
• Wattage: 40w
• Delivered lumens: 2000lm
• Dimming: TRIAC dimmable
• Fixture weigth: 20.9 lb. (9.5 kg)
• For recommended dimmers and downloadable IES & LM 79
files, see blackjacklighting.com
Custom
•Consultorderingguidebelowforcustomoptions
DOT-27C-
12T 30K
adjustable
29.0” to 55.0”*
73.7cm to 139.7cm
4.9"
12.4 cm
26.5"
67.3 cm
26.5"
67.3 cm
ORDERING GUIDE CUSTOM OPTIONS
Family Size/Type Finish Volts/Dimming Color Temp.
DOT 27C 30K12T
27C 27” Pendant
EG Etched Gold
PC Polished Chrome
12T 120VAC,
Triac Dimming
30K 3000K
OPTIONAL ACCESSORIES
24” Additional Stem
Model No: 92002-24- EG (Etched Gold)
Model No: 92002-24- PC (Polished Chrome)
Sloped Ceiling Swivel (0-90degrees)
Model No: 92004-EG (Etched Gold)
Model No: 92004-PC (Polished Chrome)
Example: DOT-27C-PC-12T-30K
(30K Standard)(12T Standard)
We reserve the right to change,
modify or upgrade our products without notice.
© 2019 Blackjack Lighting LLC
Blackjacklighting.com
1547 Barclay Blvd.
Buffalo Grove IL, 60089
