X1550

6 5

ENGLISH

(Original instructions)

7 8

(Original instructions)

ENGLISH

(Original instructions)

Intended use

Your BLACK+DECKER X1550 Iron has been designed to remove creases from fabrics using heat & steam and is not to be used for any other purpose.

This product is intended for consumer use only. Thank you for choosing BLACK+DECKER. We hope that

you will enjoy using this product for many years. For indoor domestic use only. This appliance is not to be used in:

• Staff kitchen areas in shops, ofﬁces and other working

environments;

• Farm Houses;

• By clients in hotels, motels and other residential type

environments;

• Bed and breakfast type environments or any other

non-household type environments.

Safety instructions

Warning! Read all safety warnings and all instructions. Failure to follow the warnings and

instructions listed below may result in electric

shock, ﬁre and/or serious injury.

• Read all of this manual carefully before using the

appliance.

• The intended use is described in this manual. The use of

any accessory or attachment or the performance of any operation with this appliance other than those recommended in this instruction manual may present a risk of personal injury.

• Retain this manual for future reference. Warning! When using mains-powered appliances, basic

safety precautions, including the following, should always be followed to reduce the risk of ﬁre, electric shock and

personal injury and material damage.

• The intended use is described in this manual. The use of

any accessory or attachment or the performance of any operation with this appliance other than those recommended in this instruction manual may present a risk of personal injury.

• Retain this manual for future reference.

Using your appliance

• Make sure that the temperature control dial is set to the

minimum before connecting to or disconnecting from the power supply.

• The power cord should be arranged such that it will not

drape over the edge of counters or table tops where it could be pulled by children or tripped over.

• Never operate an appliance directly below the

socket-outlet it is connected to.

• Always take care when using the appliance.

• Do not use the appliance outdoors.

• Do not operate the appliance if your hands are wet. Do

not operate the appliance if you are barefoot.

• Guide the power supply cord neatly so it does not hang

over the edge of a worktop and cannot be caught accidentally or tripped over.

• Never pull the power supply cord to disconnect the plug

from the socket. Keep the power supply cord away from

heat, oil and sharp edges.

• If the power supply cord is damaged during use,

disconnect the appliance from the power supply immediately. Do not touch the power supply cord before disconnecting from the power supply.

• Disconnect the appliance from the power supply when

not in use and before cleaning.

• The iron must not be left unattended while it is connected

to the supply mains.

• The plug must be removed from the socket-outlet before the water reservoir is ﬁlled with water.

• The ﬁlling aperture must not be opened during use.

• The iron must be used and rested on a stable surface

• When placing the iron on its stand, ensure that the

surface on which the stand is placed is stable.

• The iron is not to be used if it has been dropped, if there

are visible signs of damage or if it is leaking

• Keep the iron and its cord out of reach of children less

than 8 years of age when it is energized or cooling down.

Safety of others

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not

play with the appliance.

• Do not allow children or any person unfamiliar with these

instructions to use the appliance.

• Do not allow children or animals to come near the work

area or to touch the appliance or power supply cord.

• Close supervision is necessary when the appliance is

used near children.

After use

• Switch off and remove the plug from the socket before leaving the appliance unattended and before changing,

cleaning or inspecting any parts of the appliance.

• When not in use, the appliance should be stored in a dry

place. Children should not have access to stored appliances.

(Original instructions)

ENGLISH

Inspection and repairs

• Before use, check the appliance for damaged or defective parts. Check for breakage of parts, damage to

switches and any other conditions that may affect its operation.

• Do not use the appliance if any part is damaged or

defective.

• Have any damaged or defective parts repaired or

replaced by an authorised repair agent.

• Before use, check the power supply cord for signs of damage, ageing and wear.

• Do not use the appliance if the power supply cord or

mains plug is damaged or defective.

• If the power supply cord or mains plug is damaged or

defective it must be repaired by an authorised repair agent in order to avoid a hazard. Do not cut the power supply cord and do not attempt to repair it yourself.

• Never attempt to remove or replace any parts other than those speciﬁed in this manual.

Additional safety instructions for irons

Warning! Do not place near a hot Gas or electric oven.

• Always route the cord carefully to avoid a tripping

hazard.

• Do not use the appliance near water.

• Do not place the appliance near heat sources or directly

under cabinets. Do not use the appliance in the

presence of explosive or ﬂammable materials.

• The water inlet cover must not be opened during use.

• Steam may escape from the soleplate.

• Surfaces may be hot during use and during the cool

down period.

• Set the temperature control dial to the minimum position

before plugging in or out.

• Let the appliance cool down before leaving it unattended

and before cleaning or inspecting any parts of the appliance.

• The power supply cord should not touch the hot

soleplate during use or during the cool down period.

• Do not touch the soleplate until it has cooled down.

• Wait until the appliance has cooled down before

emptying the water tank as the water may still be hot.

• Do not immerse the appliance, cord set or plug in

liquids.

• Always disconnect the appliance from the supply before ﬁlling, emptying, cleaning, or carrying out any

maintenance on the appliance.

• This product is designed to remove creases from fabrics

using heat & steam and is not to be used for any other purpose.

• The iron must not be left unattended while it is

connected to the supply mains

• The plug must be removed from the socket-outlet before the water reservoir is ﬁlled with water.

• The iron must be used and rested on a stable surface.

• When placing the iron on its stand, ensure that the

surface on which the stand is placed is stable

• The iron is not to be used if it has been dropped, if there

are visible signs of damage or if it is leaking.

Electrical safety

Before use, check that the mains voltage corresponds to the

voltage on the rating plate.

This product must be earthed. Always check that the mains voltage corresponds to the voltage on the rating plate

• Appliance plugs must match the outlet. Never modify the

plug in any way.

• Do not use any adapter plugs with earthed (Class 1) appliances. Unmodiﬁed plugs and matching outlets will

reduce the risk of electric shock.

• To avoid the risk of electric shock, do not immerse the cord, plug or motor unit in water or other liquid.

Extension cables & class 1 product

• A 3 core cable must be used as your tool is earthed and

of class 1 construction.

• Up to 30m (100 ft) can be used without loss of power.

• If the supply cord is damaged, it must be replaced by the manufacturer or an authorised BLACK+DECKER Service

Centre in order to avoid a hazard.

Labels on Appliance

The following pictograms along with the date code are shown on the tool:

Warning! Hot surface.

Anti Calc

Anti Drip

Steam Shot

Spray

ENGLISH

Vertical steam

Self Clean

(Original instructions)

Features

1. Soleplate

2. Spray nozzle

3. Water inlet cover

4. Variable steam button/Self clean button

5. Spray button

6. Steam burst button

7. Power cord

8. Indicator light

9. Temperature dial

Before ﬁrst use

• Remove any sticker, protective foil or storage cover from

the soleplate.

• Heat up the iron to maximum temperature and iron over

a piece of damp cloth for several minutes on the purpose of removing any residue on the soleplate.

Note: It is normal that a strange odour will eminate from the

unit for the ﬁrst time it is used.

Assembly

Warning! Before assembly, make sure that the appliance is

switched off and unplugged.

Filling the water tank (Fig. A)

In order to be able to use the steam function, you will ﬁrst need to ﬁll the water tank with water.

• Unplug the Iron and take it to a water outlet

• Lift the water inlet cover (3).

• Hold the appliance at an angle.

• Fill the appliance with water to the required amount via water outlet, or using a ﬁlling jug.

• Close the water inlet cover (3).

Warning! Never ﬁll above the maximum ﬁlling level indicated on the appliance. Normal tap water can be used,

but if you live in a hard water area the use of distilled water is recommended. Do not use chemically de-scaled water.

Use

Warning! Do not leave the appliance unattended while it is

connected to the power supply and during the cool down period.

• Connect plug to outlet and turn temperature dial to your desired setting, which is dependant on the fabric of the

garment (Fig.B).

• The indicator light (8) will be illuminated. Refer 'IRONING TIPS' in this manual.

• Once soleplate has reached its preset temperature, the indicator light will be off, then you can set the steam

button to your desired steam output or dry position and begin ironing.

Warning! Do not touch the hot soleplate at any time before cooling down!

• Press spray button (5) a couple of times to moisten the laundry if necessary, before spraying make sure that

there is enough water in water tank.

• The steam burst function can be used at max temperature, to remove stubborn creases.

• The iron has an anti-drip function: if ironing garments for a long time, the soleplate temperature will fall off, the iron

will stop producing steam automatically and no water droplets can emit from the soleplate.

• The steam burst can also be applied when holding the iron in a vertical position, so this is useful for removing creases from hung clothes, curtains, etc.

Self-clean function

The unit should be cleaned regularly according to hardness of water and frequency of use.

• Fill the water tank and set the temperature selector to Max position.

• Connect to power supply, the indicator light will be illuminated, make sure Steam button is in the Dry position, then place iron upright as shown in ﬁgure.D

Warning! never pour white vinegar or other liquid cleaners for eliminating calcium into water tank!

• Once the indicator light is off, disconnect the plug, hold the iron over the sink and turn steam button to SELF CLEAN position (Fig.C) with a little force. Steam and

boiling water will come out of the soleplate while ensuring

impurities and ﬂakes are ﬂushed out.

• Release the button as soon as the water in the water

tank is used up.

Auto-decalciﬁcation feature

There is a decalciﬁcation box inside the appliance, which is

able to absorb insoluble calcium ion and emit soluble natrium

ions so that water can be softened, and calcium build up will

be greatly reduced.

Note: In order to keep soleplate smooth, never iron over any metal material such as zips, etc.

Ironing tips

• Always check ﬁrst whether a label with ironing

instructions is attached to the article.

(Original instructions)

ENGLISH

• Follow these ironing instructions in any case.

• The iron heats up quicker than it cools down, therefore,

you should start ironing articles requiring the lowest

temperature, such as those made of synthetic ﬁbre.

• If the fabric consists of various kinds of ﬁbres, you must

always select the lowest ironing temperature to iron the

composition of those ﬁbres.

• Silk and other fabrics that are likely to become 'shiny'

should be ironed on the inner side.

• To prevent staining do not spray water straight on silk or

other delicate fabrics.

• Velvet and other textures that rapidly become shiny

should be ironed in one direction with light pressure applied. Always keep the iron moving at all times.

• Pure woollen fabrics (100% wool) may be ironed with

the iron set at the steam position. Preferably set steam

button to the maximum position and use a dry cloth as a

mat.

Note: when ironing woolen fabrics, shining of the fabric may occur. So it is suggested that you should turn the article

inside out and iron the reverse side.

Cleaning and maintenance & storage

Warning! Before cleaning and maintenance, switch the

appliance off and remove the plug from the socket. Warning! Do not immerse the appliance or the cord set or

the plug in water or any other liquid.

• Wipe the exterior with a damp cloth.

• Do not use scouring pads.

• If necessary, use a mild detergent to remove spots. Do

not use any abrasive or solvent based cleaner. Do not use chemical based de-scaling agents.

• Store your appliance in a cool dry area.

Mains plug replacement

If a new mains plug needs to be ﬁtted:

• Safely dispose of the old plug.

• Connect the brown lead to the live terminal of the new

plug.

• Connect the blue lead to the neutral terminal.

• If the product is class l (earthed), connect the green /

yellow lead to the earth terminal.

Warning! If your product is class ll double insulated (only 2

wires in the cord set), no connection is to be made to the

earth terminal.

Follow the ﬁtting instructions supplied with good quality

plugs. Any replacement fuse must be of the same rating as the

original fuse supplied with the product.

Protecting the environment

Separate collection. This product must not be

disposed of with normal household waste.

Should you ﬁnd one day that your BLACK+DECKER product needs replacement, or if it is of no further use to you, do not dispose of it with other household waste. Make this product

available for separate collection.

• BLACK+DECKER provides a facility for recycling

BLACK+DECKER products once they have reached the end of their working life. This service is provided free of charge. To take advantage of this service please return your product to any authorised repair agent who will collect them on our behalf.

• You can check the location of your nearest authorised

repair agent by contacting your local BLACK+DECKER

ofﬁce at the address indicated in this manual. Alternatively, a list of authorized BLACK+DECKER repair

agents and full details of our after-sales service and contact are available on the Internet at: www.2helpU.com.

Technical data

X1550

Voltage/supply V

Power consumption W 1600 - 2000 Weight kg 0.950

220 - 240

Warranty

BLACK+DECKER is conﬁdent of the quality of its products

and offers an outstanding warranty. This warranty statement is in addition to and in no way

prejudices your statutory rights.

The warranty is valid within the territories of the Member States of the European Union and the European Free Trade

Area. If a BLACK+DECKER product becomes defective due to

faulty materials, workmanship or lack of conformity, within 24 months from the date of purchase, BLACK+DECKER warranty to replace defective parts, repair products subjected

to fair wear and tear or replace such products to ensure minimum inconvenience to the customer unless:

The product has been used for trade, professional or hire

purposes;

The product has been subjected to misuse or neglect; The product has sustained damage through foreign

objects, substances or accidents;

Repairs have been attempted by persons other than

authorised repair agents or BLACK+DECKER service staff.

To claim on the warranty, you will need to submit proof of

purchase to the seller or an authorised repair agent. You can check the location of your nearest authorised repair agent by

contacting your local BLACK+DECKER ofﬁce at the address

indicated in this manual.

Alternatively, a list of authorised BLACK+DECKER repair

agents and full details of our after-sales service and contacts are available on the Internet at: www.2helpU.com.

FRANÇAIS

6 5

(Traduction des instructions d'origine)

7 8

(Traduction des instructions d'origine)

FRANÇAIS

(Traduction des instructions d'origine)

Usage prévu

Votre Fer BLACK + DECKER X1550 a été conçu pour éliminer les plis de tissus en utilisant la chaleur et la vapeur

d'eau et ne doit pas être utilisé à d'autres ﬁns. Ce produit est destiné à un usage domestique uniquement. Merci d'avoir choisi BLACK+DECKER. Nous espérons que

vous proﬁterez de ce produit pendant de nombreuses années.

Pour usage domestique en intérieur uniquement.

Cet appareil ne doit pas être utilisé dans:

• dans une cuisine pour les employés d'une boutique, de bureaux et d'autres environnements professionnels ;

• dans les fermes ;

• par les clients d'hôtels, motels et autres environnements de type résidentiel ;

• dans les chambres d'hôtes ou tout autre environnement non résidentiel.

Consignes de sécurité

Avertissement ! Lisez toutes les consignes de sécurité et toutes les instructions. Le

non-respect de toutes les instructions peut

entrainer un choc électrique, un incendie et/ou des blessures graves.

• Lisez attentivement ce manuel dans son intégralité avant d'utiliser l'appareil.

• L'usage prévu est décrit dans le présent manuel.

L'utilisation d'accessoires ou pièces rajoutées et de

l'appareil en lui-même doit se faire uniquement selon les recommandations de ce manuel d'instructions. Dans le cas contraire, il existe un risque de blessure.

• Conservez ce manuel de sorte à pouvoir vous y reporter plus tard.

Avertissement ! Lorsque que vous utilisez des appareils électriques, veuillez toujours respecter les précautions élémentaires de sécurité, entre autres, pour réduire le risque d'incendie, d'électrocution et de blessures corporelles et des dommages matériels.

• L'usage prévu est décrit dans le présent manuel.

L'utilisation d'un accessoire ou une pièce jointe ou

l'exécution de toute opération avec cet appareil autre que ceux recommandés dans ce mode d'emploi peut présenter un risque de blessure

• Conservez ce manuel de sorte à pouvoir vous y reporter plus tard.

Utilisation de votre appareil

• Assurez-vous que le cadran de la commande de

température est réglé sur le minimum avant de le

brancher ou de le débrancher de l'alimentation.

• Le cordon d'alimentation doit être disposé de telle sorte qu'il ne pende pas sur le bord des comptoirs ou des

plateaux de table car les enfants pourraient le tirer ou y trébucher.

• Ne faites jamais fonctionner un appareil directement en

dessous de la prise de courant sur laquelle il est

connecté.

• Utilisez toujours l'appareil avec précaution.

• N'utilisez pas l'appareil à l'extérieur.

• N'utilisez pas l'appareil avec les mains mouillées. Ne manipulez pas l'appareil pieds nus.

• Positionnez correctement le cordon d'alimentation de sorte qu'il ne pende pas sur le bord d'un plan de travail et pour éviter tout accrochage et piétinement accidentels.

• Ne tirez jamais sur le cordon d'alimentation pour débrancher la prise. Maintenez le cordon d'alimentation à l'écart des sources de chaleur, de l'huile et des bords tranchants.

• Si le cordon d'alimentation est endommagé pendant l'utilisation, débranchez immédiatement l'appareil. Ne touchez pas le cordon d'alimentation avant de le débrancher de l'alimentation.

• Débranchez l'appareil de l'alimentation électrique en cas de non utilisation et avant de le nettoyer.

• Le fer à repasser ne doit pas être laissé sans surveillance alors qu'il est branché au secteur.

• Retirez la ﬁche de la prise électrique avant de remplir le réservoir d'eau.

• L'ouverture de remplissage ne doit pas être ouverte pendant l'utilisation.

• Le fer doit être utilisé et posé sur une surface stable

• Lorsque vous déposez le fer à repasser sur son socle, assurez-vous que la surface sur laquelle est placé le support est stable.

• Le fer ne doit pas être utilisée si elle est tombé, s'il présente des dégâts visibles ou en cas de fuite

• Tenez le fer à repasser et son cordon hors de la portée des enfants âgés de moins de 8 ans lorsqu'il est mis sous tension ou entrain de refroidir.

Sécurité d'autrui

• Cet appareil n'est pas prévu pour être utilisé par des personnes (y compris les enfants) présentant des capacités physiques, sensorielles ou mentales réduites, ou manquant d'expérience et de connaissances, sans

surveillance ou sans avoir reçu d'instructions concernant l'utilisation de l'appareil de la part d'une personne

responsable de leur sécurité.

• Les enfants doivent être surveillés pour s'assurer qu'ils ne jouent pas avec l'appareil.

• Ne laissez pas les enfants et les personnes non familiarisées avec ces instructions utiliser cet appareil.

• Ne laissez pas les enfants ou les animaux s'approcher de la zone de travail ou toucher l'appareil ou le cordon d'alimentation.

+ 22 hidden pages
