Black & Decker UCM6 User Manual

10-Cup Programmable Coffeemaker

Cafetera programable de 10 tazas

Cafetière programmable de 10 tasses

Please Read and Save this Use and Care Book Por favor lea este instructivo antes de usar el producto Veuillez lire et conserver ce guide d’entretien et d’utilisation

Model Modelo Modèle

❑

UCM6

USA/Canada 1-800-231-9786 Mexico 01-800-714-2503

www.applicaconsumerproductsinc.com

Accessories/Parts (USA/Canada) Accesorios/Partes (EE.UU/Canadá) Accessoires/Pièces (É.-U./Canada) 1-800-738-0245

for a chance to WIN $100,000!

Registre su producto en la Internet en el sitio Web www.prodprotect.com/applica

y tendrá la oportunidad de GANAR $100,000!

Inscrivez votre produit en ligne à l'adresse www.prodprotect.com/applica

et courez la chance de GAGNER 100 000 $!

IMPORTANT / IMPORTANTE /

IMPORTANT

WASH CARAFE BEFORE FIRST USE!

LAVE LA JARRA ANTES

DEL PRIMER USO

LAVER LA CARAFE AVANT

LA PREMIÈRE UTILISATION!

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

❑

Read all instructions.

❑

Do not touch hot surfaces. Use handle or knobs.

❑

To protect against electric shock, do not place cord, plug or appliance in water or other liquids.

❑

Close supervision is necessary when any appliance is used by or near children.

❑

Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.

❑

Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has been damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair, or adjustment. Or, call the appropriate toll-free number on the cover of this manual.

❑

The use of an accessory not evaluated for use with this appliance may cause injuries.

❑

Do not use outdoors.

❑

Do not let cord hang over the edge of table or counter, or touch hot surfaces.

❑

Do not place on or near a hot gas or electric burner or in a heated oven.

❑

Keep the lid on the carafe when in use.

❑

The carafe is designed for use with the appliance. It must never be used on a range top.

❑

Do not clean the carafe with abrasive cleansers, steel wool, or other abrasives material.

❑ Do not set a hot carafe down on a wet or cold surface. ❑ Do not use the carafe if the glass is cracked or has a loose or weakened

handle.

❑ Do not clean the carafe with abrasive cleansers, steel wool, or other abrasive

material.

❑

Do not use this appliance for other than intended use.

❑

To disconnect, turn any control to off, then remove plug from wall outlet.

❑

Scalding may occur if the lid is removed during the brewing cycles.

SAVE THESE INSTRUCTIONS.

POLARIZED PLUG (120V Models Only)

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW Warning : This appliance is equipped with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside.

Repair should be done only by authorized service personnel.

ELECTRICAL CORD

a) A short power-supply cord (or detachable power-supply cord) is to be provided

to reduce the risk resulting from becoming entangled in or tripping over a longer cord.

b) Longer detachable power-supply cords or extension cords are available and

may be used if care is exercised in their use.

c) If a long detachable power-supply cord or extension cord is used,

1) The marked electrical rating of the detachable power-supply cord or extension cord should be at least as great as the electrical rating of the appliance,

2) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord, and

3) The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.

Note: If the power supply cord is damaged, it should be replaced by qualified personnel or in Latin America by an authorized service center.

How to Use

This product is for household use only.

GETTING STARTED

1. Remove all stickers, packing material, and literature.

2. Wash the carafe, carafe lid and brew basket in warm sudsy water—rinse thoroughly. These parts are also top rack, dishwasher safe.

CLEANING BEFORE FIRST USE

Cycle the unit once with water to help remove any sediment.

1. Open lid and pour cold water into water reservoir up to the

10-cup level mark on the water window (A). Do not overfill.

2. Close the reservoir lid.

3. Follow steps (8-10) in "Brewing Coffee" (Do not use ground coffee or a paper filter).

4. When cycle is finished discard water from the carafe.

SETTING THE CLOCK

To set the current time of day:

1. Plug in the coffeemaker. The display indicates 12:00 a.m. until the time is set. a. Press the HOUR button until you see the correct P.M. hour. b. Press the MIN button to select the correct minutes. The clock is set and will continue

to keep correct time.

Note: Unplugging the unit will reset the clock to 12:00.

BREWING COFFEE

You do not have to set the clock or program the coffeemaker to brew coffee.

1. Open water reservoir lid.

2. Use the carafe to fill the water reservoir with cold water. Watch water window for the desired level.

3. Close the reservoir lid.

4. Press brew basket release button to expose brew basket (B).

5. Insert a cone-shaped #4 paper filter into the brew basket.

6. Add ground coffee into filter (we recommend one heaping tablespoon for every two cups).

7. Swing brew basket assembly closed until it snaps into place.

8. Place the carafe into the coffeemaker.

9. Plug in the coffeemaker.

10. Press button above the brew strength desired (STRONG/

MED/MILD) (C). A steady light illuminates above the strength chosen indicating the coffeemaker is ON. The light remains on until the brewing process is completed. When brewing is completed, unit sounds a series of 3 "beeps" and the chosen brew light flashes until the coffeemaker is turned off or until it shuts itself off after 2 hours automatically sounding

4 "beeps." For delayed brewing see section "Programming the Coffeemaker for Auto Brew."

Important: Do not swing open brew basket while brewing.

11. Replace the carafe on the "Keep Hot" plate when not serving to keep coffee hot. Note: The coffeemaker shuts off automatically after 2 hours, or you may press the "OFF"

button to instantly turn off the coffeemaker. At any time prior to auto shutoff, pressing the "OFF" button and then the "ON" button will reset the auto-off mode to 2 hours.

Product may vary slightly from what is illustrated.



















†1.Water reservoir with flip up lid (Lid - Part# CM-UCM6-003)

2. Brew basket release button

3. Water window with red ball indicator

†4.Removable brew basket (inside)(Part# CM-UCM6-001)

5. Carafe lid

†6.10-Cup/50 oz. (1479 ml) carafe (Part# CM-UCM6-002)

7. Cord storage (back of unit)

8. "Keep Hot" plate

9. Control panel

† Consumer replaceable/removables parts

1. Brew selectors/ON buttons

2. Brew/ON indicator lights

3. HOUR button

4. PM indicator

5. Digital clock/timer display

6. MIN button

7. AUTO indicator light

8. AUTO button

9. PROG button

10. OFF button

CONTROL PANEL





















SNEAK-A-CUP® INTERRUPT FEATURE

You can pour a cup of coffee while coffee is brewing without leaking from the brew basket. When finished pouring coffee, place the carafe under brew basket. The brewing process

continues. Important: To avoid possible overflow after removing the carafe, be sure to replace the

carafe under the brew basket within one minute or less.

Programming the Coffeemaker for Auto Brew (D)

Be sure clock is set for the current time of day see "SETTING THE CLOCK."

1. To preset the coffeemaker to begin brewing at a certain time first follow steps (1-9) in "BREWING COFFEE."

2. To program the coffeemaker for Auto Brew:

a. Press the PROG button then press the HOUR, then MIN buttons until desired brew

time is reached. Be sure to watch for the P.M. indicator in the digital display.

b. Press PROG button again, the auto time is set.

3. Press the AUTO button. The auto light illuminates, indicating the timer is activated.

4. To check your preset auto brewing time, press PROG and view display. When you release the PROG button, the clock displays the current time of day.

5. Press button above the brew strength desired (STRONG/MED/MILD). Follow steps 10 and 11 in "BREWING COFFEE."

6. To automatically repeat brewing at the same preset auto-on time, prepare your coffeemaker for brewing again and press the AUTO button. The AUTO light illuminates.

Note: The auto-brew function can be cancelled at any time by pressing the OFF button. The AUTO light goes out.

Care and Cleaning

This product contains no user serviceable parts. Refer service to qualified service personnel. Caution: The control panel is not waterproof. Do not overexpose the control panel to water.

Water may cause permanent damage and make the coffeemaker inoperable.

CLEANING

1. Be sure the unit is unplugged and cooled.

2. Press the brew basket release button.

3. Remove the brew basket by lifting the basket straight up.

4. Discard the paper filter with the grounds.

5. Clean parts as follows:

• Brew basket, carafe and lid are all top rack dishwasher safe; or they may be hand washed in warm, sudsy water.

• Wipe the exterior and the "Keep Hot" plate with a soft damp cloth. Do not use abrasive cleansers or scouring pads. Never immerse the coffeemaker in water.

6. Insert brew basket back into place (E) and swing closed.

CARING FOR YOUR CARAFE

A damaged carafe may result in possible burns from a hot liquid. To avoid breaking:

• Do not allow all liquid to evaporate from the carafe while on the "Keep Hot" plate or heat the carafe when empty.

• Discard the carafe if damaged in any manner. A chip or crack could result in breakage.

• Never use abrasive scouring pads or cleansers, they will scratch and weaken the glass.

• Do not place the carafe on or near a hot gas or electric burner, in a heated oven, or in a microwave oven.

• Avoid rough handling and sharp blows.

MINERAL DEPOSITS AND CLOGGING

Mineral deposits left by hard water can clog your coffeemaker. Excessive steaming or a prolonged brewing cycle are signs that a cleaning is needed. Cleaning is recommended every 3 months.

1. Pour white vinegar into the water reservoir up to the 4-cup level on the water window. Add fresh water up to the 6-cup line, and close the reservoir lid.

2. Press brew basket release button to expose brew basket.

3. Put a new paper filter in the brew basket, swing the basket closed and be sure it latches. Set the empty carafe on the "Keep Hot" plate.

4. Turn the coffeemaker on and let half the cleaning solution brew into the carafe. Turn the coffeemaker off and let it soak for at least 15 minutes to soften the deposits.

5. Turn the coffeemaker on and brew the remaining cleaning solution into the carafe.

6. When the cleaning solution has finished brewing, discard the paper filter, empty the carafe and rinse with clean water.

7. Refill the reservoir with cold water to the 10-cup line, replace the empty carafe, put a paper filter in the brew basket, then turn on the coffeemaker and run another brew cycle to flush out the remaining cleaning solution.

8. Wash the brew basket and carafe and carafe lid as instructed in "Care and Cleaning."
