ENGLISH

English

Intended use

Your Black and Decker sandwich maker/healthy grill has been designed for making toasted sandwiches and grilling food as described in this manual. Do not use this appliance for any other purpose. This product is intended for household use only.

Safety instructions Warning! When using mains-powered appliances, basic

safety precautions, including the following, should always be followed to reduce the risk of fire, electric shock, personal injury and material damage.

X Read all of this manual carefully before using the

appliance.

X The intended use is described in this manual. The use

of any accessory or attachment or the performance of any operation with this appliance other than those recommended in this instruction manual may present a risk of personal injury.

X Retain this manual for future reference.

Using your appliance

X Do not touch hot surfaces. Keep your hands away from

the funnel (6).

X Always take care when using the appliance. X Never pull the power supply cord to disconnect the plug

from the socket. Keep the power supply cord away from heat, oil and sharp edges. Do not allow the power supply cord to hang over the edge of your work top or table.

X Always place the appliance on a level surface with

adequate free space on all sides.

X Do not place the appliance below a socket outlet. Do not

place the appliance on a wet or slippery surface. Do not place the appliance on or near heat sources or in a heated oven.

X Do not use the appliance near flammable or explosive

materials.

X Do not use the appliance outdoors. X Always protect the appliance from water or excessive

humidity.

X Do not move the appliance when in use. X Operate the appliance only with dry hands. X Do not use the appliance if you have bare feet. X If the power supply cord is damaged during use,

disconnect the appliance from the power supply immediately. Do not touch the power supply cord before disconnecting from the power supply.

X Disconnect the appliance from the power supply when

not in use, before fitting or removing parts and before cleaning.

X Allow the appliance to cool before cleaning.

Safety of others

X Do not allow children or any person unfamiliar with

these instructions to use the appliance.

X Do not allow children or animals to come near the work

area or to touch the appliance or power supply cord. Close supervision is necessary when the appliance is used near children.

X This appliance is not intended for use by persons

(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

X Children must be supervised to make sure that they do

not play with the appliance.

After use

X Switch off and remove the plug from the socket before

leaving the appliance unattended and before changing, cleaning or inspecting any parts of the appliance.

X When not in use, the appliance should be stored in a dry

place. Children should not have access to stored appliances.

Inspection and repairs

X Before use, check the appliance for damaged or

defective parts. Check for breakage of parts, damage to switches and any other conditions that may affect its operation.

X Do not use the appliance if any part is damaged or

defective.

X Have any damaged or defective parts repaired or

replaced by an authorised repair agent.

X Before use, check the power supply cord for signs of

damage, ageing and wear.

X Do not use the appliance if the power supply cord or

mains plug is damaged or defective.

X If the supply cord is damaged, it must be replaced by the

manufacturer or an authorised Black & Decker Service Centre in order to avoid a hazard.

X Never attempt to remove or replace any parts other than

those specified in this manual.

Electrical safety

This product must be earthed. Always check that the power supply corresponds to the voltage on the rating plate.

If the supply cord is damaged, it must be replaced by the manufacturer or an authorised Black & Decker Service Centre in order to avoid a hazard.

To avoid the risk of electric shock, do not immerse the cord, plug or appliance in water or other liquid.

ENGLISH

Extension cables & class 1 product

If an extension lead is required a 3 core cable must be used as your appliance is earthed and of class 1 construction.

X Up to 30m (100ft) can be used without loss of power. X Power plugs must match the outlet. Never modify the

plug in anyway. Do not use any adapter plugs with earthed (Class 1) appliances. Unmodified plugs and matching outlets will reduce the risk of electric shock.

Features

1. Temperature indicator

2. Power indicator

3. Drip tray

Figs A - C

4. Lower plate

5. Upper plate

6. Funnel

Before first use

X Remove all packaging from the appliance. X Clean the appliance before first use.

Use

Warning! Always place the appliance on a flat, clean and

non-slip surface before operating it.

Warning! Do not leave the unit unattended while in use.

Preheating

Do not touch hot parts. The plates (4 & 5) and the funnel (6) will become hot during use.

X Place the appliance on a suitable surface. X Connect the plug to a power socket; the red power

indicator (2) will light up.

When the unit reaches the correct cooking temperature the green temperature indicator (1) will light. This indicates that the unit is at the correct temperature and is ready for use.

Toasting

X Preheat the plates as described above. X Open the appliance and place a slice of buttered bread

onto the lower plate (4), with the buttered side down.

X Add the required filling and place another piece of

buttered bread on top, with the buttered side up.

X If required repeat for a second sandwich. X Make sure that the drip tray (3) is located within the

aperture below the funnel (6). This will make sure that all excess oil/fat is contained.

X Close the cooking plates by carefully lowering the upper

plate (5).

Warning! The contents of a toasted sandwich may be very hot.

X After approx. 2-3 minutes, the sandwiches will be ready.

The time may vary depending on your taste, the type of bread and the filling.

Grilling

X Preheat the plates as described above. X Open the appliance and lightly brush both cooking

plates (4 and 5) with butter, margarine or cooking oil to prevent the food sticking to the cooking plates.

X Make sure that the unit is at the correct cooking

temperature (green light (1) is on).

X Make sure that the drip tray (3) is located within the

aperture below the funnel. This will make sure that all excess oil/fat is contained.

X Open the appliance and add the food to the lower

cooking plate (4).

X Close the cooking plates by carefully lowering the upper

plate (5). Note: Avoid thick foods as these will prevent the unit from closing properly. Note: The cooking time will vary depending upon the food type and thickness.

X Check the food regularly to avoid burning.

Cleaning and maintenance

Warning! Before cleaning and maintenance, switch the

appliance off, remove the plug from the socket and allow the appliance to cool. Warning! Do not immerse the appliance, the cord set or the plug in water or any other liquid.

X Wipe the exterior with a damp cloth. X Do not use scouring pads. X If necessary, use a mild detergent to remove spots. Do

not use any abrasive or solvent based cleaner.

Protecting the environment

Separate collection. This product must not be disposed of with normal household waste.

Should you find one day that your Black & Decker product needs replacement, or if it is of no further use to you, do not dispose of it with household waste. Make this product available for separate collection.

Separate collection of used products and packaging allows materials to be recycled and used again. Reuse of recycled materials helps prevent environmental pollution and reduces the demand for raw materials.

ENGLISH

Local regulations may provide for separate collection of electrical products from the household, at municipal waste sites or by the retailer when you purchase a new product.

Black & Decker provides a facility for the collection and recycling of Black & Decker products once they have reached the end of their working life. To take advantage of this service please return your product to any authorised repair agent who will collect them on our behalf.

You can check the location of your nearest authorised repair agent by contacting your local Black & Decker office at the address indicated in this manual. Alternatively, a list of authorised Black & Decker repair agents and full details of our after-sales service and contacts are available on the Internet at: www.2helpU.com.

Technical data

TS75

Voltage Vac 230 Power input W 800 Weight (empty) kg 1.7

EC declaration of conformity

TS75 – TYPE 1

Black & Decker declares that these products conform to:

EN60335, 2006/95/EC

The undersigned is responsible for compilation of the

technical file and makes this declaration on behalf of

Black & Decker

X The product has been used for trade, professional or

hire purposes.

X The product has been subjected to misuse or neglect. X The product has sustained damage through foreign

objects, substances or accidents.

X Repairs have been attempted by persons other than

authorised repair agents or Black & Decker service staff.

To claim on the guarantee, you will need to submit proof of purchase to the seller or an authorised repair agent. You can check the location of your nearest authorised repair agent by contacting your local Black & Decker office at the address indicated in this manual. Alternatively, a list of authorised Black & Decker repair agents and full details of our aftersales service and contacts are available on the Internet at:

www.2helpU.com Please visit our website www.blackanddecker.co.uk to

register your new Black & Decker product and to be kept up to date on new products and special offers. Further information on the Black & Decker brand and our range of products is available at www.blackanddecker.co.uk.

Kevin Hewitt

Director of Consumer Engineering

Spennymoor, County Durham DL16 6JG,

United Kingdom

02-11-2008

Guarantee

Black & Decker is confident of the quality of its products and offers an outstanding guarantee. This guarantee statement is in addition to and in no way prejudices your statutory rights. The guarantee is valid within the territories of the Member States of the European Union and the European Free Trade Area.

If a Black & Decker product becomes defective due to faulty materials, workmanship or lack of conformity, within 24 months from the date of purchase, Black & Decker guarantees to replace defective parts, repair products subjected to fair wear and tear or replace such products to make sure of the minimum inconvenience to the customer unless:
