Black & Decker TS2020, TS2000 User Manual
Sandwich Maker / Grill
First Use Safety Recommendation
Please read through this booklet for safe and efficient use of the appliance.
We urge you to read the "Hint's" section and also follow all detailed
instructions even if you are familiar with using this appliance.
Keep this guide handy for future reference.
English Page 02
Farsi Page 13
Arabic Page 19
TS2000 / TS2020
English
IMPORTANT SAFEGUARDS
While using electrical appliances, in order to reduce the risk of fire, electric shock,
and/or injury to persons, basic safety precautions should be followed, including the
following:
• Read all instructions carefully, even if you are familiar with the appliance.
• To protect against the risk of electric shock, DO NOT IMMERSE the appliance,
cord set or plug in water or other liquids.
• To clean, wipe the exterior with a damp cloth.
• Close supervision is necessary when any appliance is used near children. Never
leave an appliance unattended when in use.
• If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
• Switch off and remove the plug from the power outlet when not in use before
assembling or disassembling parts, cleaning or carrying out any maintenance of
the appliance.
• Do not operate the appliance if it's damage in any manner. Return the complete
appliance to your nearest authorized service facility for examination, electrical
repair, mechanical repair or adjustments to avoid any hazard.
• The use of attachments or accessories not recommended or sold by this
appliance manufacturer may result in fire, electric shock or personal injury.
• Do not let the cord hang over the edge of a table, counter, or touch hot surfaces.
• Avoid touching hot surfaces, use handles and knobs.
• Do not operate or place any part of this appliance on or near any hot surfaces
(such as gas or electric burner or in a heated oven).
• Do not abuse the cord. Never carry the appliance by the cord or yank it to
disconnect it from the outlet; instead, grasp the plug and pull to disconnect.
• When using an extension cord with your appliance, make sure the extension cord
is correctly wired, and rated for its use.
• This product is intended for household use only.
• Do not attempt to repair the appliance yourself; instead, take it to your Black &
Decker-owned or Authorized Service Centre for repair.
SAVE THESE INSTRUCTIONS
-2-
English
Parts Identification
1. Power indicator
2. Temperature indicator
3. Clamp
4. Lower plate
5. Upper plate
6. Cut and Seal Triangular Plate (TS2000)
7. Grill Plate (TS2020)
3
6
1
2
3
3
7
5
4
5
4
-3-
English
Intended Use
Your Black and Decker Sandwich Maker /
Grill has been designed for toasting
sandwiches or grilling food as described in
this manual.
This appliance is intended for indoor
consumer use only.
Safety Instructions
Warning! When using mains-powered
appliances, basic safety precautions,
including the following, should always be
followed to reduce the risk of fire, electric
shock, personal injury and material
damage.
Read all of this manual carefully
before using the appliance.
Using your appliance
• Always take care when using the
appliance.
• Do not use the appliance outdoors.
• Never pull the power supply cord to
disconnect the plug from the socket.
Keep the power supply cord away from
heat, oil and sharp edges.
• Disconnect the appliance from the power
supply when not in use, before fitting or
removing parts, maintenance and before
cleaning.
• Do not allow the cord set to hang over
bench tops.
• Surfaces may be hot during use and
during the cool down period.
• The intended use is described in this
manual. The use of any accessory or
attachment or the performance of any
operation with this appliance other than
those recommended in this instruction
manual may present a risk of personal
injury.
• Retain this manual for future reference.
• Always route the cord carefully to avoid a
tripping hazard.
• Never operate an appliance directly
below the socket-outlet it is connected
to.
• Do not operate or place any part of this
appliance on or near any hot surface,
such as a gas or electric burner or in a
heated oven.
• When using an extension cord with your
appliance, make sure the extension cord
is correctly wired and rated for its use.
Safety of others
• Do not allow children or any person
unfamiliar with these instructions to use
the appliance.
-4-
English
English
• Do not allow children or animals to come
near the work area or to touch the
appliance or power supply cord.
• Close supervision is necessary when the
appliance is used near children.
• Never leave an appliance unattended
when in use.
• Do not allow the cord set to hang over
bench tops.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
After use
• Switch off and remove the plug from the
socket before leaving the appliance
unattended and before changing,
cleaning or inspecting any parts of the
appliance.
• When not in use, the appliance should
be stored in a dry place. children should
not have access to stored appliances.
Inspection and repairs
• Before use, check the appliance for
damaged or defective parts. Check for
breakage of parts, damage to switches
and any other conditions that may affect
its operation.
• Do not use the appliance if any part is
damaged or defective.
• Have any damaged or defective parts
repaired or replaced by an authorized
repair agent.
• Before use, check the power supply cord
for signs of damaged, ageing and wear.
• Do not use the appliance if the power
supply cord or main plug is damaged or
defective.
• If the supply cord is damaged, it must be
replaced by the manufacturer or its
service agent or a similarly qualified
person in order to avoid a hazard.
• Do not cut the power supply cord and do
not attempt to repair it yourself.
• Never attempt to remove or replace any
parts other than those specified in this
manual.
• Do not attempt to repair the appliance.
Take it to your nearest Black & Decker owned or authorized Services Centre for
repair.
Electrical Safety
This product must be earthed.
Always check that the power supply
corresponds to the voltage on the rating
plate.
Extension cables & class 1 product
If an extension lead is required a 3 core
cable must be used as your appliance is
earthed and of class 1 construction.
-5-
English
• Up to 30m ( 100ft ) can be used without
loss of power.
• Power plugs must match the outlet.
Never modify the plug in anyway. Do not
use any adapter plugs with earthed
(class 1) appliances. Unmodified plugs
and matching outlets will reduce the risk
of electric shock.
Use
Preheating
• Place the appliance on a suitable
surface.
• Plug the appliance in.
• The red power indicator (1) and the green
temperature indicator (2) will light up.
• Wait for the green temperature indicator
to go out. This indicates the unit is at the
correct temperature and is ready to use.
Toasting
• Place the slice of buttered bread onto
the lower plates (5), with the buttered
side down.
• Add the required filling and place another
piece of buttered bread on top, with the
buttered side up.
• Repeat for the second sandwich.
• Close the cooking plates by slowly
lowering the upper plate.
• Use the clamp (3) to keep the plates
closed.
• After approx. 2-3 minutes, the
sandwiches will be ready. The time may
vary depending on your taste and the
type of bread and filling.
Warning! Do not use force to close the
cover or to apply the clamp. If necessary,
remove some filling.
Grilling
• Lightly brush both grill plates with butter,
margarine or cooking oil to prevent food
sticking to the plates.
• Ensure the unit is at the correct cooking
temperature (green light out).
• Open the grill and add the food to the
lower plate.
• Close the grill by slowly pressing the
cover down.
• If possible use the clamp to lock the
cover in place.
• Avoid thick foods as these will prevent
the unit closing.
The cooking time will vary depending upon
the food type and thickness.
• Check food regularly to avoid burning.
Cleaning and Maintenance
Warning! Before cleaning and maintenance,
remove the plug from the socket and allow
the appliance to cool.
• Wash the plates using warm soapy water
and dry well.
• Wipe the exterior with a damp cloth. Do
not use any abrasive or solvent-based
cleaner.
Warning! Do not immerse the appliance in
water or any other liquid.
Technical Data
TS2000/TS2020
Voltage 220-240V
Power 750W
Weight 1.3Kg
-6-
