7-QUART digital slow cooker
olla
digital de cocciÓN leNta
DE 6,6 LITROS DE CAPACIDAD
Mijoteuse NuMérique
DE 6 LITRES (7 PINTES)
Customer Care Line:
USA 1-800-231-9786
Accessories/Parts (USA)
1-800-738-0245
For online customer service
and to register your product, go to
www.prodprotect.com/applica
Service line à la clientèle :
Canada 1-800-231-9786
Accessoires/Pièces (Canada)
1-800-738-0245
Pour accéder au service à la clientèle en
ligne ou pour inscrire votre produit en
ligne, rendez-vous à
www.prodprotect.com/applica
Servicio para el cliente:
México 01-800 714-2503
Accesorios/Partes (EE.UU)
1-800-738-0245
Para servicio al cliente y para
registrar su garantía, visite
www.prodprotect.com/applica
MODEL/MODELO/MODÈLE
❍
SL6470C
1
Please Read and Save this Use and Care Book.
Additional Important Safeguards
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
❍ Read all instructions.
❍ Do not touch hot surfaces. Use handles or knobs.
❍ To protect against electrical shock, do not immerse cord, plug or
appliance in water or other liquid.
❍ Close supervision is necessary when any appliance is used by or near
children.
❍ Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts.
❍ Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Contact
Consumer Service for examination, repair or adjustment.
❍ The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
❍ Do not use outdoors.
❍ Do not let cord hang over edge of table or counter, or touch hot
surfaces.
❍ Do not place on or near a hot gas or electric burner, or in a heated
oven.
❍ Extreme caution must be used when moving an appliance containing
hot oil or other hot liquids.
❍ To disconnect, turn any control to OFF then remove plug from wall
outlet.
❍ Do not use appliance for other than intended use.
❍ Avoid sudden temperature changes, such as adding refrigerated foods
into a heated pot.
❍ This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
❍ Children should be supervised to ensure that they do not play with the
appliance.
CAUTION, HOT SURFACES: This appliance generates heat and
escaping steam during use. Proper precautions must be taken to
prevent the risk of burns, fires, or other injury to persons or damage
to property.
❍ A person who has not read and understood all operating and safety
instructions is not qualified to operate this appliance. All users
of this appliance must read and understand this Owner’s Manual
before operating or cleaning this appliance.
❍ If this appliance falls or accidentally becomes immersed in water,
unplug it from the wall outlet immediately. Do not reach into the
water!
❍ When using this appliance, provide adequate air space above and
on all sides for air circulation. Do not operate this appliance while it
is touching or near curtains, wall coverings, clothing, dishtowels or
other flammable materials.
❍ Do not leave this appliance unattended during use.
❍ If this appliance begins to malfunction during use, immediately
unplug the cord. Do not use or attempt to repair a malfunctioning
appliance!
❍ The cord to this appliance should only be plugged into a 120V AC
electrical wall outlet.
❍ Do not use this appliance in an unstable position.
❍ Never use the Stoneware Liner on a gas or electric cooktop or on
an open flame.
❍ Lift off Glass Lid carefully to avoid scalding, and allow water to drip
into Stoneware Liner.
Caution: To prevent damage or shock hazard, do not cook in Cooking
Base. Cook only in Stoneware Liner provided.
ENGLISH
SAVE THESE INSTRUCTIONS.
This product is for household use only.
2
3
POLARIZED PLUG (120V Models Only)
This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug is intended to fit into a
polarized outlet only one way. If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician.
Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
A short power-supply cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. Do not use an
extension cord with this product.
ELECTRIC POWER
If the electrical circuit is overloaded with other appliances, your appliance
may not operate properly. It should be operated on a separate electrical
circuit from other appliances.
Note: If the power supply cord is damaged, it should be replaced
by qualified personnel or in Latin America by an authorized service.
Product may vary slightly from what is illustrated.
ENGLISH
1. Lid handle
2. Inverted lid handle
† 3. Tempered glass lid (Part # SL5470C-01)
† 4. Removable stoneware liner (Part # SL5470C-02)
5. Cool-touch handles
6. Cooking base
7. Power cord
8. Polarized plug
9. Digital temperature control
Note: † indicates consumer replaceable/removable parts
4
5
DIGITAL TEMPERATURE CONTROL
How to Use
This product is for household use only.
GETTING STARTED
• Remove all packing material, and any stickers from the product.
• Remove and save literature.
• Please go to www.prodprotect.com/applica to register your warranty.
• Wash the stoneware liner and the glass lid as instructed in Care and
Cleaning section of this manual.
• Place the clean, dry stoneware liner into the cooking base.
HOW TO USE
1. Add the ingredients to be cooked into the stoneware
liner (A).
A
2. Place the lid, handle side up, on the stoneware liner
(B).
ENGLISH
1. On / Off button
2. High temperature indicator light
3. Up (▲) button
• To increase cooking time (hours)
4. Warm temperature indicator light
5. Down (▼) button
• To decrease cooking time (hours)
6. Low temperature indicator light
6
7. Hour and minute countdown display
• Minute indicator light comes on when
minutes are displayed
8. Temperature set button
• Changes the temperature setting to:
o Low (4 to 12 hours)
o Warm (2 to 6 hours)
o High (2 to 8 hours)
9. Minute indicator light
B
3. Plug in the appliance. The indicator light below
HIGH blinks; the digital display shows 4.0 (4 hours).
To cook on HIGH for 4 hours, press the ON/OFF
button on the top left of the control panel (C). The
indicator light below HIGH is lit constantly and
cooking begins.
C
Note: The indicator light blinks when the appliance is
plugged in but not turned on.
4. To change the time, press the UP ▲ or DOWN ▼
button on the right of the control panel, before
pressing the ON/OFF button. You can change the
time from 2 to 8 hours (D). When you see the desired
time, press the ON/OFF button; the food starts
cooking.
D
Note: Cook time options are: HIGH 2 to 8 hours;
LOW 4 to 12 hours and WARM 2 to 6 hours.
7
5. To cook on LOW, press the SET button on the lower left
of the control panel; the indicator light below the word
LOW blinks. The digital display changes to 8.0 (8 hours)
(E). Press the ON/OFF button on the top left of the
control panel. The indicator light below LOW becomes
constant and cooking begins.
E
6. To change the time, press the UP ▲ or DOWN ▼ button
on the right of the control panel. You can change the
time from 4 to 12 hours (F). When you see the desired
time, press the ON/OFF button; the food starts
cooking.
Note: When the time goes below 1 hour, the display
F
switches to minutes and counts down from 59 to 0. The
minute light is lit.
7. When cooking time is done, the slow cooker automatically switches to WARM
and the indicator light below WARM comes on and 2.0 (2 hours) is displayed.
Note: Never cook on WARM. This feature is only for keeping cooked foods at
serving temperature.
8. To change the WARM cycle time, press the UP ▲ button on the right of the
control panel.
Note: You can change the time from 2 to 6 hours.
9. At the end of the WARM cycle the unit will beep 5 times.
10. Then the unit and all the indicator lights will automatically shutoff.
Note: The unit can be turned off at any time by pressing the ON/OFF button.
11. Unplug the applicance.
12. Food is ready to serve.
TIPS when using your slow cooker:
• The stoneware liner should always be filled from ½ to ¾, to avoid over and
under cooking.
o When only half full, check for doneness 1 to 2 hours before recommended
cooking time.
o To avoid spillovers, do not fill slow cooker more than ¾ full.
• Always cook with the lid on.
o Do not open lid during first 2 hours of cooking; this allows heat to rise
efficiently.
o Open the lid as little as possible, to assure even cooking.
• If your recipe has a cooking time range, select the even number closest to the
settings on your slow cooker. (For example, if recipe suggests 5 to 7 hours, use
6 hours)
• Most recipes can be cooked on either HIGH or LOW. Many recipes will give the
time for both.
• Important: When the appliance is in use, always use pot holders when
handling the lid or the stoneware liner.
8
Caution: When removing the lid, always lift it away from the body to prevent
getting burnt from the hot steam.
• To save time, fill the stoneware liner the night before and refrigerate. You
may need to add some extra cooking time because the food and stoneware
liner are cold.
• To store the stoneware liner or to place in the refrigerator, invert the lid. It
is easy to use the small lid handle on the bottom of the lid, making it handy
to remove and turn over.
Important: If there is a power outage, the slow cooker will turn off. If this
is discovered quickly, reset the appliance. If you are not sure how long the
slow cooker has not been functioning, discard the food.
HINTS ON INGREDIENTS IN THE SLOW COOKER
DAIRY
• Milk products, especially those low in fat, tend to curdle if cooked too long;
add them toward the end of the cooking time.
• Evaporated milk and condensed soups are great substitutes for milk and
cream.
SOUPS AND STEWS
• Because there is little evaporation, soups and stews require less liquid than
usual.
• If too thick, add additional liquid in last ½ hour of cooking or at serving time.
• Condensed soups and dry soup mixes add great flavor and body to sauces.
MEATS
• The higher the fat content, the less liquid needed. Also, place thickly sliced
onions under fattier meat to keep it above the drippings.
• Browning before cooking in the slow cooker is not necessary; however,
browning meats, lightly coated in flour gives more body and flavor to
sauces. This works for ground meat as well.
• Make sure top of meat does not touch the lid.
• Cooking times are an estimate and will vary depending upon the size of the
meat, the bones and the cut.
Meat with bone in will take longer to cook.
Lean meats and poultry will cook faster.
• Meats slow cooked in liquids develop great flavor with a minimum of effort.
• Use HIGH for more tender cuts of meat; use LOW for tougher cuts.
VEGETABLES
• Place vegetables below or on the sides; they usually take longer to cook
than the meat.
• Vegetables cook well; they develop better flavor and don’t break down as
they would in your oven.
FISH
• Fish cooks quickly; add it for the last 15 minutes.
ENGLISH
9
BEANS
• Do not add dried beans to the slow cooker; cook them first.
• Canned beans are the perfect substitute for dried beans.
SEASONINGS
• Fresh herbs should be added at the end of the cooking cycle. If cooked too
long they lose their color and flavor.
• Dried herbs work well in the slow cooker and can be added at the beginning.
They can become stronger on longer cooking; begin with less and add at end,
if needed.
• Some spices and dried herbs, such as cinnamon sticks, bay leaves and whole
peppercorns can become quite intense with long cooking, so use sparingly.
• If using bay leaves, remember to remove before serving.
Care and Cleaning
Caring For Your Slow Cooker
❍ Avoid sudden, extreme temperature changes. For example, do not place the
hot glass lid or stoneware liner into cold water or onto a wet surface.
❍ Avoid hitting the stoneware liner or glass lid against the faucet or other hard
surfaces.
❍ Do not use stoneware liner or glass lid if chipped, cracked, or severely
scratched.
User Maintenance Instructions
This slow cooker requires little maintenance. It contains no user serviceable
parts.
Do not try to repair it yourself. Any servicing requiring disassembly other than
cleaning must be performed by a qualified appliance repair technician.
Cleaning Your Slow Cooker
Caution: Never immerse cooking base or cord in water or other liquids.
1. Always unplug and allow to cool completely before cleaning.
2. Wash stoneware liner and glass lid in warm, soapy water. If food sticks to
the stoneware liner, fill with warm, soapy water and allow to soak before
cleaning with a plastic scouring pad.
Note: Both stoneware liner and glass lid are dishwasher-safe.
3. Rinse and dry thoroughly.
4. Wipe interior and exterior of the cooking base with a soft, slightly damp cloth
or sponge.
Important: Never use abrasive cleansers or scouring pads to clean the
cooking base, as they may damage the surfaces.
Storing Your Slow Cooker
1. Dry thoroughly before storing.
2. Never wrap the cord tightly around the appliance; keep it loosely coiled.
NEED HELP?
For service, repair or any questions regarding your appliance, call the
appropriate 800 number on cover of this book. Please DO NOT return the
product to the place of purchase. Also, please DO NOT mail product back to
manufacturer, nor bring it to a service center. You may also want to consult the
website listed on the cover of this manual.
TWO-YEAR LIMITED WARRANTY
(Applies only in the United States and Canada)
What does it cover?
• Any defect in material or workmanship provided; however, Applica’s liability
will not exceed the purchase price of product.
For how long?
• Two years from the date of original purchase with proof of such purchase.
What will we do to help you?
• Provide you with a reasonably similar replacement product that is either
new or factory refurbished.
How do you get service?
• Save your receipt as proof of date of sale.
• Visit the online service website at www.prodprotect.com/applica, or call tollfree 1-800-231-9786, for general warranty service.
• If you need parts or accessories, please call 1-800-738-0245.
What does your warranty not cover?
• Damage from commercial use
• Damage from misuse, abuse or neglect
• Products that have been modified in any way
• Products used or serviced outside the country of purchase
• Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of the unit
• Consequential or incidental damages (Please note, however, that some
states do not allow the exclusion or limitation of consequential or incidental
damages, so this limitation may not apply to you.)
How does state law relate to this warranty?
• This warranty gives you specific legal rights. You may also have other rights
that vary from state to state or province to province.
is a trademark of The Black & Decker Corporation,
Towson, Maryland, USA
ENGLISH
10
Made and Printed in People’s Republic of China
11
Loading...
