Your Black & Decker appliance is intended for
chopping and blending food.
Do not use this appliance for any other purpose.
This product is intended for indoor household use
only.
Read this entire manual
carefully before using the
appliance.
Safety instructions
Warning! When usin
g mainspowered appliances, basic safety
precautions, including the
following, should always be
followed to reduce the risk of fire,
electric shock and personal
injury.
The intended use is described in
this manual. The use of any
accessory or attachment or the
performance of any operation
with this appliance other than
those recommended in this
instruction manual may present a
risk of personal injury.
Retain this manual for future
reference.
English
Using your appliance
Always take care when using the
appliance.
Never pull the power supply cord
to disconnect the plug from the
socket. Keep the power supply
cord away from heat, oil and
sharp edges.
Do not place the appliance on or
near heat sources or in a heated
oven.
Do not use the appliance
outdoors.
Always protect the motor unit
from water or excessive humidity.
If the power supply cord is
damaged during use, disconnect
the appliance from the power
supply immediately. Do not touch
the power supply cord before
disconnecting from the power
supply.
Disconnect the appliance from
the power supply when not in
use, before fitting or removing
parts and before cleaning.
Never let the appliance operate
unattended.
3
English
Never reach into the jar with your
fingers or an object while the
appliance is running.
Only remove the jar after you
have switched the appliance off
and any moving parts have
stopped.
Do not touch the cutting blades.
Keep any loose clothing or long
hair away from the feeding tube
and any moving parts.
Care shall be taken when
handling the sharp cutting blades,
emptying the bowl and during
cleaning.
Do not let the cord hang over the
edge of a table, counter, or touch
hot surfaces.
Guide the power supply cord
neatly so it does not hang over
the edge of a worktop and cannot
be caught accidentally or tripped
over.
Safety of others
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved. Children shall
not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision.
Children should be supervised to
ensure that they do not play with
the appliance.
After use
Remove the plug from the socket
before leaving the appliance
unattended and before changing,
cleaning or inspecting any parts
of the appliance.
When not in use, the appliance
should be stored in a dry place.
Children should not have access
to stored appliances.
4
Inspection and repairs
Switch off the appliance before
cleaning, changing accessories
or approaching parts which move
in use
Before use, check the appliance
for damaged or defective parts.
Check for breakage of parts,
damage to switches and any
other conditions that may affect
its operation.
Do not use the appliance if any
part is damaged or defective.
Do not use the appliance if the
blade is damaged.
Have any damaged or defective
parts repaired or replaced by an
authorised repair agent.
Before use, check the power
supply cord
for signs of damage,
ageing and wear.
Do not use the appliance if the
power supply cord or mains plug
is damaged or defective.
English
If the power supply cord or mains
plug is damaged or defective it
must be repaired by an
authorised repair agent in order
to avoid a hazard. Do not cut the
power supply cord and do not
attempt to repair it yourself.
Never attempt to remove or
replace any parts other than
those specified in this manual.
Electrical safety
Before use, check the mains
voltage corresponds to the voltage
on the rating plate.
This appliance is double
insulated in accordance with
EN 60335-2-14; therefore
no earth wire is required.
To avoid the risk of electric
shock, do not immerse the cord,
plug or motor unit in water or
other liquid.
Check that the supply voltage
shown on the rating plate of the
appliance matches that of your
electrical system. Any connection
error will invalidate the guarantee.
5
English
Mains plug replacement
If a new mains plug needs to be fitted:
Safely dispose of the old plug
Connect the brown lead to the live terminal of
the new plug
Connect the blue lead to the neutral terminal
If the product is class I (earthed), connect the
green/yellow lead to the earth terminal
Warning! If your product is class II double
insulated (only 2 wires in the cord set), no
connection is to be made to the earth terminal
Follow the fitting instructions supplied with
good quality plugs
Any replacement fuse must be of the same
rating as the original fuse supplied with the
product
Assembly
Use
1. Place the appliance on a flat, stable surface.
2. Place the assembled blade into the bowl.
3. Place the ingredients into the bowl.
4. Place the bowl lid onto the bowl. Lock it in
place by turning it clockwise.
5. Place the assembled bowl (3) on to the
chopper body (5). Lock it in place by turning
it clockwise.
6. Connect it to the electricity supply.
7. Press and hold the on button (4) to start the
appliance.
The appliance should be disconnected
from the mains supply before removing
from the bowl.
The appliance will not operate without
the bowl lid fitted.
The appliance should be disconnected
from the mains supply before assembly.
1. Wash all detachable parts (see chapter
‘Maintenance and cleaning’).
Extra care should be taken when
handling or assembling the blades.
2. Place the blade (2) into the bowl (3), ensure
it is placed on to the spindle in the bottom of
the bowl.
3. Place the lid (1) on to the bowl. Lock it in
place by turning it to the lock position
4. Place the assembled bowl (3) on to the
chopper body (5). Lock it in place by turning
it clockwise.
6
.
Do not operate the appliance without
the blade fitted.
The chopper should be run in 15 second (max)
pulses and should not be run for longer than 60
seconds (4 consecutive pulses). After a
continuous run of 60 seconds (4 consecutive 15
second pulses), the chopper should be allowed to
cool for at least 2 minutes before further use.
Useful advice
Place the appliance on a clean, flat work
surface.
Note: Do not exceed the maximum capacity of
350 ml.
When chopping is complete disconnect the
appliance from the power socket.
Once the blades have come to a
stop, lift the bowl from the chopper body.
Remove the lid
position
the ingredients into a suitable container.
buy turning it to the unlock
. Remove the blades then pour
complete
Recommended run time
Food Run Time
(Seconds)
Onion 10 100g cut into
Garlic 15 100g whole peeled
Ginger 15 100g cut into
Carrot 15 100g cut into
Almonds 25 150g. Run for an
Meat 20 200g cut in to 2cm
Comments
quarters
cloves
thumb sized
pieces
thumb sized
pieces
additional 10
seconds if powder
is required.
cubes
Maintenance & cleaning
Switch the appliance off, remove the plug from
the power socket and wait until the blade has
stopped rotating.
The appliance is easier to clean if you do so
immediately after use.
Do not use abrasive cleaning agents, scourers,
acetone, alcohol etc. to clean the appliance.
All removable parts can be cleaned with a
cleaning brush in warm water with some
washing-up liquid and rinse them under the
tap.
English
Remove the dirty parts from the motor unit.
Clean the motor unit with a damp cloth.
Never immerse the motor unit in water nor rinse it
under the tap.
Protecting the environment
Separate collection. This product must not
be disposed of with normal household
waste.
Should you find one day that your Black & Decker
product needs replacement, or if it is of no further
use to you, do not dispose of it with household
waste. Make this product available for separate
collection.
Separate collection of used
products and packaging allows
materials to be recycled and used
again. Reuse of recycled
materials helps prevent
environmental pollution and
reduces the demand for raw
materials.
Local regulations may provide for separate
collection of electrical products from the
household, at municipal waste sites or by the
retailer when you purchase a new product.
Black & Decker provides a facility for recycling
Black & Decker products once they have
reached the end of their working life. This
service is provided free of charge. To take
advantage of this service, please return your
product to any authorised repair agent who will
collect them on our behalf.
7
English
You can check the location of your nearest
authorised repair agent by contacting your local
Black & Decker office at the address indicated
in this manual. Alternatively, a list of authorized
Black & Decker repair agents and full details of
our after-sales service and contacts are
available on the Internet at: www.2helpU.com.
Technical data
Voltage 220 – 240 Volts
Supply 50 – 60 Hz
Power consumption 120 W
Weight 0.85 kg
Guarantee
Black & Decker is confident of the quality of its
products and offers an outstanding guarantee.
This guarantee statement is in addition to and in
no way prejudices your statutory rights.
The guarantee is valid within the territories of the
Member States of the European Union and the
European Free Trade Area.
If a Black & Decker product becomes defective
due to faulty materials, workmanship or lack of
conformity, within 24 months from the date of
purchase, Black & Decker guarantees to replace
defective parts, repair products subjected to fair
wear and tear or replace such products to ensure
minimum inconvenience to the customer unless:
The product has been used for trade,
professional or hire purposes;
The product has been subjected to misuse
or neglect;
The product has sustained damage through
foreign objects, substances or accidents;
Repairs have been attempted by persons
other than authorised repair agents or Black
& Decker service staff.
To claim on the guarantee, you will need to
submit proof of purchase to the seller or an
authorised repair agent. You can check the
location of your nearest authorised repair agent
by contacting your local Black & Decker office at
the address indicated in this manual.
Alternatively, a list of authorised Black & Decker
repair agents and full details of our after-sales
service and contacts are available on the Internet
at: www.2helpU.com.
8
Italiano
1. Coperchio
2. Lama
3. Tazza
4. Pulsante di accensione
5. Base tritatutto
9
Loading...
+ 19 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
