Black & Decker Le4 Instruction Manual [ar]
AR PT FR EN
www.blackanddecker.ae
LE4
ENGLISH
4
1
3
5
6
2
7
8
2
Fig.1
ENGLISH
Fig.2
4 5
9
3
ENGLISH
Intended use
Your BLACK+DECKER™ torch has been
designed for providing illumination. This
tool is intended for professional and private,
non professional users.
Safety instructions
General power tool safety warnings
Warning! Read all safety warnings
and all instructions. Failure to
follow the warnings and
instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference. The term "power tool" in all of the
warnings listed below refers to your mains
operated (corded) power tool or battery
operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
c. Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools. Unmodified
plugs and matching outlets will reduce
risk of electric shock.
b. Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if
your body is earthed or grounded.
c. Do not expose power tools to rain or wet
conditions. Water entering a power tool
will increase the risk of electric shock.
d. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock.
e. When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric
shock.
f. If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of electric
shock.
3. Personal safety
a. Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment
of inattention while operating power tools
may result in serious personal injury.
b. Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing
protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the
switch is in the o-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your
finger on the switch or energising power
tools that have the switch on invites
accidents.
d. Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a
rotating part of the power tool may result
in personal injury.
4
ENGLISH
e. Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g. If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of
dust collection can reduce dust-related
hazards.
4. Power tool use and care
a. Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
was designed.
b. Do not use the power tool if the switch
does not turn it on and o. Any power
tool that cannot be controlled with the
switch is dangerous and must be
repaired.
c. Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive
safety measures reduce the risk of
starting the power tool accidentally.
d. Store idle power tools out of the reach of
children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may aect the power tools
operation. If damaged, have the power
tool repaired before use. Many accidents
are caused by poorly maintained power
tools.
f. Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
g. Use the power tool, accessories and tool
bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations dierent from those intended
could result in a hazardous situation.
5. Battery tool use and care
a. Recharge only with the charger specified
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with
another battery pack.
b. Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c. When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws, or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together
may cause burns or a fire.
d. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from
the battery may cause irritation or burns.
5
ENGLISH
6. Service
a. Have your power tool serviced by a
qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool
is maintained.
Additional power tool safety warnings
Warning! Additional safety
warnings for torches
• Never attempt to remove or replace any
parts other than those specified in this
manual.
• Do not operate without the lens in place
or with a damaged lens.
• Never look directly into the light or shine
the light into another persons eyes.
Warning! Fire hazard.Do not
operate worklight or charger near
flammable liquids or in gaseous or
explosive atmospheres. Internal sparks may
ignite fumes causing personal injury.
• Do not expose light or charger to wet or
damp areas. Do not expose light or
charger to rain or snow.
• Do not wash light or charger with water
or allow water to get inside light or
charger. Do not submerge light in water
at any time.
Caution! When not in use, place
tool on its side on a stable surface
where it will not cause a tripping
or falling hazard. Some tools with large
battery packs will stand upright on the
battery pack but may be easily knocked
over.
Residual risks
Additional residual risks may arise when
using the tool which may not be included in
the enclosed safety warnings. These risks
can arise from misuse, prolonged use etc.
Even with the application of the relevant
safety regulations and the implementation
of safety devices, certain residual risks can
not be avoided. These include:
• Injuries caused by touching any
rotating/moving parts.
• Injuries caused when changing any parts,
blades or accessories.
• Injuries caused by prolonged use of a
tool. When using any tool for prolonged
periods ensure you take regular breaks.
• Impairment of hearing.
• Health hazards caused by breathing dust
developed when using your tool
(example:- working with wood, especially
oak, beech and MDF.)
Labels on tool
The following pictograms are shown on the
tool:
Warning! To reduce the risk of injury,
the user must read the instruction
manual.
Additional safety instructions for
batteries and chargers
Batteries
• Never attempt to open for any reason.
• Do not expose the battery to water.
• Never view directly with optical
instruments into the light source.
6
• Do not store in locations where the
temperature may exceed 40 °C.
ENGLISH
• Charge only at ambient temperatures
between 10 °C and 40 °C.
• Charge only using the charger provided
with the tool.
• When disposing of batteries, follow the
instructions given in the section
"Protecting the environment".
Do not attempt to charge damaged
batteries.
Chargers
• Use your BLACK+DECKER charger only
to charge the battery in the tool with
which it was supplied. Other batteries
could burst, causing personal injury and
damage.
• Never attempt to charge
non-rechargeable batteries.
• Have defective cords replaced
immediately.
• Do not expose the charger to water.
• Do not open the charger.
• Do not probe the charger.
The charger is intended for indoor
use only.
Read the instruction manual before
use.
Electrical safety
This tool is double insulated;
therefore no earth wire is
required. Always check that the
power supply corresponds to the voltage
on the rating plate.
• If the supply cord is damaged, it must be
replaced by the manufacturer or an
authorised Black & Decker Service
Centre in order to avoid a hazard.
Features
1. Pivot
2. Pivoting 24 - LED adjustable lamp
3. Carrying handle
4. On/o button (Fixed 9 - LED lamp)
5. On/o button
(Pivoting 24 - LED adjustable lamp)
6. Fixed 9 - LED lamp
7. Battery lead
8. Charger
9. Charging indicator
Use
Warning! Let the tool work at its
own pace. Do not overload.
Charging the battery
The battery needs to be charged before first
use and whenever it fails to produce
sucient power on jobs that were easily
done before.
The battery may become warm while
charging; this is normal and does not
indicate a problem
Warning: Do not charge the battery at
ambient temperatures below 10 °C or above
40 °C. Recommended charging
temperature: approx. 24 °C.
Note: The charger will not charge a battery
if the cell temperature is below
approximately 0 °C or above 40 °C.
The battery should be left in the charger
and the charger will begin to charge
automatically when the cell temperature
warms up or cools down.
• To charge the unit. Plug into a power
supply(AC power),The red charge
indicator (9) shows that the lamp is
charging successfully.
7
ENGLISH
Leaving the battery in the charger
The charger and battery pack can be left
connected with the LED glowing
indefinitely. The charger will keep the
battery pack fresh and fully charged.
Switching on and o (Fig 2)
• To switch the fixed 9 - LED lamp (6) on
press the switch (4).
• To switch the fixed 9 - LED lamp (6) off
depress the switch (4).
• To switch the pivoting 24 - LED
adjustable lamp (2) on press the switch
(5).
• To switch the pivoting 24 - LED
adjustable lamp (2) depress the switch
(5).
The pivoting 24 - LED adjustable lamp
For your convienience, the pivoting 24 LED adjustable lamp (2) can be pivoted into
a range of positions (Fig1)
Maintenance
Your BLACK+DECKER tool has been
designed to operate over a long period of
time with a minimum of maintenance.
Continuous satisfactory operation depends
upon proper tool care and regular cleaning.
Your charger does not require any
maintenance apart from regular cleaning.
Warning! Before performing any
maintenance on the tool, unplug
the charger before cleaning it.
• Regularly clean the ventilation slots in
your tool using a soft brush or dry cloth.
• Regularly clean the motor housing using
a damp cloth.
• Do not use any abrasive or
solvent-based cleaner.
Technical Data
LE4
Input voltage VdC 220-240
Power input W 4
Net weight kg 1.4
Protecting the environment
Separate collection. This product must
not be disposed of with normal
household waste.
Should you find one day that your
Black+Decker product needs replacement,
or if it is of no further use to you, do not
dispose of it with other household waste.
Make this product available for separate
collection.
• Black+Decker provides a facility for
recycling Black+Decker products once
they have reached the end of their
working life. This service is provided free
of charge. To take advantage of this
service please return your product to any
authorised repair agent who will collect
them on our behalf.
• You can check the location of your
nearest authorised repair agent by
contacting your local Black+Decker
oce at the address indicated in this
manual. Alternatively, a list of authorized
Black+Decker repair agents and full
details of our after-sales service and
contact are available on the Internet at:
www.2helpU.com.
8
Warranty
Black+Decker is confident of the quality of
its products and offers an outstanding
warranty.
This warranty statement is in addition to and
in no way prejudices your statutory rights.
The warranty is valid within Middle East &
Africa regions.
If a Black+Decker product becomes
defective due to faulty materials,
workmanship or lack of conformity, within
24 months from the date of purchase,
Black+Decker warranty to replace defective
parts, repair products subjected to fair wear
and tear or replace such products to ensure
minimum inconvenience to the customer
unless:
The product has been subjected to
The product has sustained damage
Repairs have been attempted by
To claim on the warranty, you will need to
submit proof of purchase to the seller or an
authorised repair agent. You can check the
location of your nearest authorised repair
agent by contacting your local
Black+Decker oce at the address
indicated in this manual.
Alternatively, a list of authorised
Black+Decker repair agents and full details
of our after-sales service and contacts are
available on the Internet at:
www.2helpU.com.
The product has been used for
trade, professional or hire
purposes;
misuse or neglect;
through foreign objects,
substances or accidents;
persons other than authorised
repair agents or Black+Decker
service staff.
ENGLISH
9
FRANÇAIS
4
1
3
5
6
2
7
10
8
Fig.1
FRANÇAIS
Fig.2
4 5
9
11
Loading...
