FULL ONE-YEAR WARRANTY (Applies only in U.S. and Canada)
Applica warrants this product against any defects that are due to faulty material or workmanship
for a one-year period after the original date of consumer purchase. This warranty does not
include damage to the product resulting from accident, misuse, or repairs performed by
unauthorized personnel. If the product should become defective within the warranty period, or
you have questions regarding warranty or service, call Consumer Assistance and Information toll
free at: 1-800-231-9786.
This warranty gives you specific legal rights and you may also have other rights which vary from
state to state or province to province.
Product may vary slightly from what is illustrated.
El producto puede variar ligeramente del ilustrado.
Le produit peut différer légèrement de celui illustré.
UN AÑO COMPLETO DE GARANTIA (Este párrafo no se aplica a E.U.A. ni a Canadá)
Applica garantiza este producto contra cualquier defecto originado por fallas en los materiales o
en la mano de obra por un período de un año a partir de la fecha original de compra. Esta
garantía no es válida cuando: a) el producto se utilice en condiciones distintas a las normales, b)
el producto no se opere de acuerdo con el instructivo de uso que le acompaña, c) el producto
sea alterado o reparado por personas no autorizadas. Si el producto resulta con defectos dentro
del período de garantía, lo repararemos o reemplazaremos según sea necesario, sin costo
alguno. Para que esta garantía sea válida debe presentar el producto con su recibo de compra
y/o la tarjeta de registro correspondiente. Esta garantía le otorga derechos específicos, y usted
podría tener otros que pueden variar en su país. Si tiene alguna pregunta, comuníquese con una
sucursal o centro de servicio más cercano autorizado por Black & Decker.
Nota: Usted podrá encontrar partes, componentes, consumibles y accesorios en los centros de
servicio autorizados. Esta garantía incluye los gastos de transportación que se deriven de su
cumplimiento dentro de su red de servicio.
GARANTIE COMPLÈTE DE UN AN (Valable aux É.-U. et au Canada seulement)
Applica garantit le produit pour un an à compter de la date d’achat, contre tout vice de matière
ou de fabrication. La garantie ne couvre pas les dommages causés par un accident, une
mauvaise utilisation ou des réparations effectuées par des personnes non autorisées. Advenant
le fonctionnement irrégulier du produit dans les délais prescrits, ou pour toute question relative à
la garantie ou au service, communiquer sans frais avec le service à la clientèle au numéro
suivant : 1 800 231-9786.
Les modalités de la présente garantie donnent des droits légaux spécifiques. L’utilisateur peut
également se prévaloir d’autres droits selon l’état ou la province qu’il habite.
Séries DF200-DF251 Series
READ AND SAVE THIS USE AND CARE BOOK
POR FAVOR LEA ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO
LIRE ET CONSERVER CE GUIDE D’ENTRETIEN ET D’UTILISATION
*
?
U.S.A./CANADA 1-800-231-9786
MEXICO 01-800-714-2499
http://www.applicaconsumerproductsinc.com
FryMate™Deep Fryers (English, page 2)
Ollas de freír FryMate
™
(Español, página 10)
Friteuses FryMate
mc
(Français, à la page 19)
Applica Consumer Products, Inc.
3
쐅
GROUNDED PLUG (Certain Models Only)
As a safety feature, this product is equipped with a grounded plug, which will only fit into
a three prong outlet. Do not attempt to defeat this safety feature. Improper connection of
the grounding conductor may result in the risk of electric shock. Consult a qualified
electrician if you are in doubt as to whether the outlet is properly grounded.
POLARIZED PLUG (Detachable Cord Models Only)
This appliance has a polarized plug — one blade is wider than the other. To reduce the
risk of electric shock, this plug will fit into a polarized outlet only one way. If the plug does
not fit fully into the outlet, reverse it. If it still does not fit, contact a qualified electrician.
Do not attempt to defeat this safety feature by modifying the plug in any way.
DETACHABLE POWER CORD (Certain Models Only)
In models with a magnetic detachable power cord, be sure the cord is properly
attached by aligning the DOT on the plug to the DOT on the unit, before plugging in. A
breakaway/detachable power cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. The use of an extension cord is
not recommended. However, if it is absolutely necessary, be sure that the cord is (1) No.
14 AWG minimum size and rated no less than 1875 watts; (2) UL Listed; (3) as short as
possible (long cords can overheat, as well as trip circuit breakers); (4) not used for
operating more than one appliance at a time.
2
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
Read all instructions, labels, and warnings before operating.
■ This appliance uses hot oil; it is very important to be sure the unit is placed
on a safe, dry, level surface while the oil is hot. Make sure the cord is not
loose or hanging where it may be tripped on.
■ DO NOT MOVE THE DEEP FRYER WHEN OIL IS HOT OR DURING COOKING.
■ Always use oven mitts or pot holders when touching handles or knobs. Do
not touch hot surfaces.
■ To protect against a risk of electric shock, do not immerse the unit, the cord,
or plug in water or other liquid.
■ Close supervision is necessary when any appliance is used by or near
children.
■ Unplug from outlet when not in use and before cleaning. Be sure to turn the
unit OFF before disconnecting. Allow to cool before putting on or taking off
parts and before cleaning.
■ Do not leave the appliance unattended when in use.
■ Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or is dropped or damaged in any manner. Return the
appliance to the nearest authorized service facility for examination, repair, or
electrical or mechanical adjustment. Or, call the appropriate toll-free number
listed on the cover of this manual.
■ Do not use outdoors.
■ The use of attachments not recommended or sold by the appliance
manufacturer may cause fire, electric shock, or injury.
■ Do not allow cord to touch hot surfaces or hang over the edge of table or
counter.
■ Do not place on or near a hot gas or electric burner or in a heated oven.
■ Do not operate in the presence of explosive and/or flammable fumes. Do not
place flammable materials in or close to the Fryer such as paper, cardboard,
or plastic.
■ Do not place oversized foods into the Fryer as they may create a fire.
■ Do not clean with metal scouring pads or any abrasive materials. Pieces can
break off the pad and touch electrical parts resulting in a risk of electrical
shock.
■ Be sure Basket Handle is properly locked in place before removing Basket.
■ Always attach plug to appliance first, then plug cord into electrical outlet. To
disconnect, grasp plug and remove from outlet. Do not yank on cord.
■ This appliance is intended for household use only, not for commercial or
industrial use. Use for anything other than intended will void the warranty.
씊
씉
씈
쐈
쐉
Removable Lid with Viewing Window
Vent
Charcoal & Mesh Filters (under Vent)
Drip Tray
Removable Cooking Pot
Basket
MIN/MAX Fill Marks (Inside Pot)
Easy-Lift Grips
On/Off
쐅 Power Light
쐈 Heating Light
쐉 Temperature Control Lever
씈 30-Minute Timer (Certain Models Only)
씉 Lid Release
씊 Handle Release/Lock Button
WARNING: To reduce the risk of personal injury, NEVER PUT ICE INTO HOT OIL! Always
close the Lid when cooking. DO NOT lower the food Basket until the Lid is closed.
5
Care and Cleaning
IMPORTANT: Always UNPLUG the unit and allow it to COOL COMPLETELY before cleaning!
NOTE: You do not have to change the oil after each use. Oil can be re-used until it gets
dark or there is visible debris (such as batter or bits of food) in it.
1. Be sure oil is completely cool before removing the Cooking Pot by lifting up and out
(see B). Pour the oil off into large cans for re-use or disposal (such as large coffee
cans with lids). For longer life, store oil for reuse in the refrigerator.
2. Open the Lid and pull straight up to remove it. Remove the Drip Tray which catches oil
and condensation from the Lid (see Call Out illustration). The Lid, Drip Tray, Cooking
Pot, and Basket can be completely immersed and soaked in soapy water then
washed by hand. The Cooking Pot is also dishwasher-safe — however, it must be
placed vertically in the dishwasher to avoid damaging the non-stick finish. Slip the
Drip Tray back in place before replacing the Lid. To reattach the Lid, tilt it slightly
forward and slip the Tabs of the Lid into the Notches of the unit. Lower the Lid down.
3. If washing by hand, use a sponge or nylon pad with liquid detergent. Do not use any
abrasive cleaners, coarse cleansers, or metal pads as they may damage the nonstick coated surface. Be careful not to bang the Pot as any dents can affect future
performance. After washing, dry the Cooking Pot, Basket & Handle, and Lid
completely before re-use. Over time and repeated use, there may be some fat buildup
in the Pot and on the Basket. This is normal.
4.
DO NOT IMMERSE THE UNIT.
Wipe it with a damp
sponge or cloth and dish detergent. Never spray or
apply cleaners directly onto the Lid or Cooking Pot.
Dry thoroughly with a soft cloth.
Changing the Charcoal & Mesh Filters
These filters are intended to help cut down on frying
odors and should always be in place when operating
the fryer. Over time, they will become less effective.
To change the filters, remove the Vent Lid and take
out the 2 filters. (D) Replace with new ones by placing
the white mesh filter in first, then the charcoal filter
4
How To Use
1. For models with a detachable cord, be sure the breakaway/detachable cord is
properly attached to the unit and the Cooking Pot is properly seated with the
MAX/MIN MARKS to the rear of the unit or the Lid will not lock down. Fill the Cooking
Pot with approximately 2 liters of vegetable cooking oil. Do not use olive, peanut,
sunflower, or flavored oils. (See Tips about cooking oils.) Do not go below the MIN
MARK or exceed the MAX FILL MARK inside the Pot.
2. Sit the empty Basket into the Unit, close the Lid. Press the Handle Release to fold the
Basket handle down and lower it into the oil. CAUTION: Always CLOSE THE LID
before lowering the Basket. Plug in the unit and press the On/Off button. The Power
Light will come on. Slide the Temperature Control Lever to the appropriate
temperature for your food. The Heating Light will
come on indicating the unit is preheating.
Preheating the empty Basket will help prevent food
from sticking to it. When the unit reaches its
cooking temperature, the light will go out in about
20-25 minutes.
3. Pull up on the Basket Handle to lock in place (see
A) and let it drain a few seconds. Lift the Lid and fill
the Basket with the appropriate amount of food (C).
DO NOT OVERFILL THE BASKET. Use the charts and
recipes in this book as your guide to determine
food quantities, temperature settings, and time,
along with the graphics printed on the front of the
unit for various foods.
4. For models with Timers, turn the Timer Dial to the
appropriate timing up to 30 minutes. The Timer will
count down the minutes and there will be an
audible signal when time is up, however, the unit will NOT shut off automatically.
When cooking is done, you MUST press the On/Off Button to shut the unit off. The
Power Light will go out.
BEFORE FIRST USE
Pull up on the Basket Handle until it locks horizontally (A). Press the Lid Release and lift
the Basket out of the unit. Remove any instructions, stickers, etc. and lift out the NonStick Cooking Pot (B). Wash the Pot and Basket in warm water and liquid detergent,
rinse, and dry thoroughly. Replace the Cooking Pot in the unit. Wipe the exterior of the
unit including the Lid with a damp sponge or cloth. NEVER IMMERSE THE UNIT IN
WATER. CAUTION:
Do not use the
Fryer under
cabinets or
curtains. Never
leave it unattended
during use. During
first use, you may
detect a slight odor.
This is normal.
A
B
D
C
5. With the LID STILL CLOSED, press the Handle Release button and SLOWLY fold back
the Handle to lower the Basket into the hot oil, then lock the Handle down into the
unit. The Heating Light will cycle on and off indicating that the unit is maintaining the
cooking temperature.
6. Although this appliance has a ThermaGuard™ Base so you won't burn your hand if
accidentally touched, AVOID TOUCHING the exterior of the unit during cooking. Keep
the Lid closed while frying; you may peek into the Viewing Window to check progress
without opening the Lid. It is normal for steam to appear in the Window but it will
clear during cooking if you keep the Window clean after each use.
7. Avoid the Vent and the seam around the Lid during cooking as there may be some
escaping steam.
8. When cooking is done, lift up on the Basket Handle (see A) so that it locks in place
horizontally. Let the food drain 10-15 seconds, then push the Lid Release button and
the Lid will pop open. Carefully lift the Basket out (be sure not to press the Handle
Release button) and turn the food out onto a plate with paper toweling to drain.
Replace the Basket in the unit, close the Lid, and lower the Basket back into the oil to
reheat. Repeat as necessary to cook additional food. When finished, press the On/Off
button and the Power Light will go out.
76
Tips
11. Use a good quality vegetable oil for best results. Do not use butter, bacon fat, lard,
margarine, or olive oil since these oils tend to smoke and/or burn easily.
12. Always be sure Cooking Pot and Basket are thoroughly dry before using.
13. Always keep oil level between the Max and Min levels. Check to be sure oil is at the
correct level before preheating.
14. Whenever possible, let refrigerated foods stand at room temperature for a half hour
before frying. For frozen foods, remove from freezer just before frying and remove
any ice crystals.
15. Dry excess moisture from foods with paper towels before frying to reduce
spattering.
16. Remember to preheat for 20-25 minutes for best results, or until the Heating Light
goes out for the first time.
17. Keep foods a uniform in size and thickness.
18. Do not use plastic utensils in hot cooking oil — they will melt.
19. To help keep the oil from dropping below proper frying temperatures, (1) add food to
oil in small batches, and (2) wait 5-10 minutes before frying additional batches.
10. Experiment with lower temperatures and/or shorter times to help prevent
overbrowning.
11. Always heat Basket in the oil during preheating to help prevent foods from sticking
to the Basket. Raising the Basket and stirring foods once during frying may also help
prevent foods from sticking together.
12. To help minimize batter-dipped foods sticking to the Basket, let foods drain before
adding them to the Basket.
13. Salt foods away from Deep Fryer. Salt causes vegetable oil to spoil more quickly.
14. Experiment with different kinds of potatoes for the best French fry results. The age
and kind of potatoes affect crispness and browning.
15. Soaking cut French fries in cold water for half an hour washes away the starch and
may improve cooked results for better crispness.
16. If oil darkens or smokes, discard and use fresh oil.
17. For longer life of oil after frying, cool the oil and strain it through a sieve lined with a
paper towel. Store in a tightly covered container in a dark, cool location or
refrigerate. Add some fresh vegetable oil to used oil each time you fry.
18. On average, oil can be used 6-8 times. It will need to be changed more often if used
to fry fish or used with heavily batter-dipped foods.
19. If overbrowning is a problem and you are reusing oil or have preheated a long time,
you might want to double check oil temperature with a candy thermometer.
Food Temperature Time Tips
In Minutes
Chicken Tenders, 350°F 4-5 Dip in egg batter. Then roll in
about 6 177°C seasoned bread crumbs.
Chicken Wing Pieces, 350°F 6-8 Coat lightly with seasoned
up to 6 177°C all-purpose flour.
Chicken Drumsticks, 350°F 18-20 Same as for Wings.
Up to 3 177°
Doughnuts, 375°F 3-31⁄2 For quick fast doughnuts, use
refrigerated biscuits 191°C refrigerated biscuits. Just cut out the
3 or 4 at a time center with a 1-inch biscuit cutter.
Then drop 3 in the fry basket. Cook
1-11⁄2 minutes, turn and cook the
other side. Sprinkle with cinnamon
and sugar or confectioners’ sugar
while hot.
Eggplant Sticks, 350°F 2-3 Dip in egg batter, then in seasoned
About 6 177°C bread crumbs.
Fish Fillets, 350°F 7-9 Cut into serving size pieces. Coat
3
⁄4-1” (1.91-2.54cm) 177°C with favorite egg batter, then
thickness, 2-3 pieces crumbs.
Frozen Convenience 350-400°F
—
Follow package directions.
Foods, such as 177-204°C
French Fries, chicken
nuggets, or
mozzarella sticks
French Fries 375°F 6-8 Remember dry potatoes well and do
(Homemade) 191°C not to overload basket.
Thin Size, 1⁄2 lb./227 g
French Fries 350°F 8-11 Dry potatoes well as above.
(Homemade) 177°C
Large Size, 1/2 lb./227 g
Mozzarella Sticks 375°F 30 seconds Dip in egg batter. Roll in flour. Dip in
(3⁄8”/.95 cm) (Homemade) 191°C egg batter, then roll in favorite
Up to 6 sticks at a time breadcrumbs. Allow to dry before
frying. Be careful not to stick with a
fork when removing.
Mushrooms, 350°F 2-3 Dip in egg batter, then in seasoned
Single layer 177°C bread crumbs.
Onion Rings, 375°F 2-3 Allow excess batter to drain off
(Homemade) 191°C rings. Fry about a cup at a time.
About 1 cup at a time
Scallops, 350°F 2-3 Dip in egg batter. Then roll in
Fresh Bay, 177°C seasoned bread crumbs.
1
⁄2 lb./227 g
Shrimp 350°F 4-5 Peel and devein uncooked shrimp.
Large Size, 177°C Dip in Tempura batter. Drain well,
Single layer then fry.
Zucchini Sticks, 350°F 2-3 Dip in egg batter, then in seasoned
Single layer 177°C bread crumbs.
Frying Chart
Need Help?
For service, repair, parts, or any questions regarding your appliance, call the appropriate
“800” number on the cover of this book. Do NOT return the product to the place of
purchase. Do NOT mail the product back to the manufacturer nor bring it to a service
center. You may also want to consult the website listed on the cover of this manual.
NOTE:
If the power supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a hazard.
on top; slide the Vent Lid back in place. Filters are available by calling the “800” number
on the cover of this book.
98
Recipes
Favorite All-Purpose Batter
1
⁄2cup all-purpose flour dash pepper
1
⁄2teaspoon baking powder
1
⁄3cup milk
1
⁄4teaspoon salt 1 egg
1. Combine dry ingredients in large mixing bowl.
2. Beat milk and egg together and add to flour mixture.
3. Stir until fairly smooth.
4. Add food to be coated with batter, such as onion rings or shrimp.
Makes: About 1 cup batter.
Best Egg Batter
1 egg
1 tablespoon milk
3
⁄4-1 cup favorite seasoned bread crumbs
1. Mix egg and milk together.
2. Dip foods (such as fish fillets or mushrooms) into egg mixture.
3. Then roll in bread crumbs.
Makes: Enough for about 1 pound/454 g fish fillets.
Easy Tempura Batter
1 cup all-purpose flour 11⁄3cups ice water
1
⁄4cup cornstarch 1 egg yolk
1
⁄8teaspoon baking soda cornstarch
1. Measure and blend flour, 1/4 cup cornstarch and baking soda in large mixing bowl.
2. Measure ice water and stir in egg yolk. Stir into flour mixture quickly, just until flour mixture is
moistened. (Do not over mix. Batter should be lumpy.)
3. Coat food to be fried with cornstarch, then coat with batter. Drain off excess batter.
Makes: About 2 cups batter.
Note: Batter will be thin.
Extra-Crisp, Twice-Fried French Fries
1
⁄2pound/227g Idaho potatoes
Salt
1. Prepare fryer for cooking per use/care directions, and preheat fryer at 325°F (163°C).
2. Peel and cut potatoes into
1
⁄4-inch (.64cm) pieces.
3. Soak in cold water for
1
⁄2 hour. Then drain and dry on paper toweling.
4. Fry potatoes, a handful at a time, for 4 minutes. Repeat until all are used.
5. After potatoes are fried the first time, put into a large bowl lined with paper towels, and allow
them to stand for
1
⁄2 hour.
6. Increase temperature to 375°F (191°C).
7. Fry all potatoes at once for about 2 minutes.
8. Salt and serve.
Makes: About
1
⁄2 pound/227g extra crisp fries.
Special Cake Dougnuts
2 eggs 2 teaspoons baking powder
1 cup sugar 1 teaspoon baking soda
2 tablespoons shortening, melted
1
⁄2teaspoon salt
3
⁄4cup buttermilk
1
⁄2teaspoon cinnamon
3
1
⁄2cup all-purpose flour
1. Prepare fryer for cooking per use/care directions, and preheat fryer at 375°F (191°C).
2. In a large mixing bowl, combine eggs, sugar, shortening. Stir in buttermilk.
3. In a separate bowl, combine flour, baking powder, baking soda, salt and cinnamon. Add to egg
mixture and mix until smooth. Dough will be sticky.
4. Turn dough onto a well-floured board. Turn to lightly cover with flour. Roll out dough gently to
about
1
⁄2-inch/1.27 cm thickness.
5. Cut dough with floured, 3-inch/7.6 cm doughnut cutter. Place 3 doughnuts into fry basket, and
lower into preheated oil. Fry 2-2
1
⁄2 minutes total, or until browned. Turn doughnuts after 1 minute.
Remove from fry basket and place on absorbent paper toweling. Repeat with remaining donuts.
6. To make doughnut holes, add 6 to fry basket and fry 1
1
⁄2 minutes total, turning halfway through.
7. Serve doughnuts and doughnut holes plain, sugared or glazed.
Makes: 2 dozen (3-inch/7.6 cm) doughnuts and 2 dozen donut holes.
To Make Sugar Doughnuts:
While doughnuts are warm, shake 1-2 doughnuts at a time, or 3-4
doughnut holes at a time, in bag with confectioners’ sugar, granulated sugar or a mixture of
cinnamon and sugar.
To Make Glazed Doughnuts:
Add 2 tablespoons boiling water gradually to 1 cup confectioners’
sugar. Mix thoroughly. Add additional water if necessary,
1
⁄4 teaspoon at a time. Dip warm
doughnuts into the warm glaze.
Loading...
