Black & Decker DE755, DE755B User Manual
Please Read and Save this Use and Care Book
Por favor lea este instructivo antes de usar el producto
Veuillez lire et conserver ce guide d’entretien et d’utilisation
Accessories/Parts (USA/Canada)
Accesorios/Partes (EE.UU/Canadá)
Accessoires/Pièces (É.-U./Canada)
1-800-738-0245
USA/Canada 1-800-231-9786
Mexico 01-800-714-2503
www.blackanddecker.com
IMPORTANT / IMPORTANTE /
IMPORTANT
WASH CARAFE BEFORE FIRST USE!
LAVE LA JARRA ANTES
DEL PRIMER USO
LAVER LA CARAFE AVANT
LA PREMIÈRE UTILISATION!
Models
Modelos
Modèles
❑
DE755B
❑
DE755
12-Cup Coffeemaker
Cafetera de 12 tazas
Cafetière de 12 tasses
2
1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and/or injury
to persons, including the following:
❑
Read all instructions.
❑
Do not touch hot surfaces. Use handle or knobs.
❑
To protect against electric shock, do not place cord, plug or appliance
in water or other liquids.
❑
Close supervision is necessary when any appliance is used by or near
children.
❑
Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts and before cleaning the appliance.
❑
Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
the appliance to the nearest authorized service facility for examination,
repair, or adjustment. Or, call the appropriate toll-free number on the
cover of this manual.
❑
The use of an accessory not evaluated for use with this appliance may
cause injuries.
❑
Do not use outdoors.
❑
Do not let cord hang over the edge of table or counter, or touch hot
surfaces.
❑
Do not place on or near a hot gas or electric burner or in a heated oven.
❑
Do not use this appliance for other than intended use.
❑
Keep the lid on the carafe when in use.
❑
Scalding may occur if the lid is removed during the brewing cycles.
❑
The carafe is designed for use with the appliance. It must never be used
on a range top.
❑
Do not set a hot carafe down on a wet or cold surface.
❑
Do not use the carafe if the glass is cracked or has a loose or weakened
handle.
❑
Do not clean the carafe with abrasive cleansers, steel wool, or other
abrasive material.
❑
Do not use this appliance for anything other than its intended use.
❑
Scalding may occur if the lid is removed during the brewing cycles.
SAVE THESE INSTRUCTIONS.
POLARIZED PLUG (120V Models Only)
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way.
If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning : This appliance is equipped with a tamper-resistant screw to prevent
removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt
to remove the outer cover. There are no user-serviceable parts inside. Repair should
be done only
by authorized service personnel.
ELECTRICAL CORD
a) A short power-supply cord (or detachable power-supply cord) is to be provided
to reduce the risk resulting from becoming entangled in or tripping over
a longer cord.
b) Longer detachable power-supply cords or extension cords are available and
may be used if care is exercised in their use.
c) If a long detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the detachable power-supply cord
or extension cord should be at least as great as the electrical rating
of the appliance,
2) If the appliance is of the grounded type, the extension cord should be
a grounding-type 3-wire cord, and
3) The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or tripped over.
Note: If the power supply cord is damaged, it should be replaced by qualified
personnel or in Latin America by an authorized service center.
4
How to Use
This appliance is intended for household use only.
Getting Started
1. Remove all stickers, packing material, and literature.
2. Wash all parts as instructed in the Care and Cleaning section.
3. Pour water up to 12-cup level mark in the water reservoir.
Brew it through as instructed in "BREWING", but do not add coffee grounds to the permanent
filter. When done, turn off the coffeemaker and discard the water from the carafe.
BREWING
1. Lift one piece water reservoir and brew basket lid. Use water markings on carafe to fill
water reservoir with water.
2. Place the permanent gold-tone filter into the brew basket. Add ground coffee, (we
recommend a heaping tablespoon for every cup). Close the cover. Make sure permanent
gold-tone filter is secured in place.
3. Place carafe on the "Keep Hot" plate and plug in the unit.
4. Press "ON/OFF" and the indicator light located on the right corner of the control panel will
turn on. For delayed brewing, see "SETTING THE CLOCK/TIMER & AUTO-BREW". You
don’t have to set the clock if you want to brew coffee right away.
5. Replace the carafe on the "Keep Hot" plate when not serving to keep coffee hot.
6. Press "ON/OFF" to turn off unit.
The coffeemaker will keep coffee warm for 2 hours before it automatically shuts off.
Sneak-A-Cup® Interrupt Feature
You can pour a cup of coffee while coffee is brewing without leaking from the brew basket.
When finished pouring coffee, place the carafe under brew basket. The brewing process
continues.
Important: To avoid possible overflow after removing the carafe, be sure to replace the carafe
under the brew basket within 30 seconds or less.
SETTING THE CLOCK/TIMER & AUTO-BREW
Plug in unit, clock flashes 12:00 a.m. until correct time is set. The coffeemaker works without
setting the clock.
1. To set current time of day: Press the HOUR button, little dot in the top left corner of the
display indicates "p.m." time. Press the MIN button. Once set, clock continues to keep
time unless coffeemaker is unplugged or a power failure occurs. To reset, press either the
hour or minutes until desired time is reached.
2. To set the Auto Brew time: Press the PROG button and the light in the upper right corner
of the display button starts flashing, indicating it is being programmed. Press the HOUR,
then MIN buttons to set the time you’d like coffee to automatically begin brewing (for
example 7:15 a.m.). Watch for the "p.m." indicator dot at the top left of the digital display.
When finished, press the AUTO button. The AUTO light will stop flashing and will stay on
to show the timer is activated.
3. Prepare the coffeemaker for brewing as instructed in "BREWING" but don’t turn
on the unit.
4. To check your pre-set auto time, press PROG and it will display. When the clock returns
to the current time of day, press AUTO to reactivate the timer. To automatically brew
coffee again at the same pre-set auto-on time, prepare coffeemaker for brewing again
and press the AUTO button.
Note: The Auto Brew function can be canceled at any time by pressing the AUTO button
a second time. The AUTO light goes out. After 2 hours , coffeemaker will automatically
shut off.
3
Product may vary slightly from what is illustrated.
†1.One piece water reservoir and brew basket lid (Part # DE755B-03)
2. Water spreader
3. Guide
4. Water reservoir
5. Water level window
6. Control Panel
7. “Keep Hot” plate
†8.12-cup/60 oz. (1774 ml) carafe with lid (Part # DE755B-02)
†9.Removable brew basket (Part #DE755B-01)
†10. Permanent gold-tone filter (Part # PF75)
†Consumer replaceable/removable parts
CONTROL PANEL
6
5
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service personnel.
CLEANING
1. Be sure the unit is off and cooled. Open the one piece water reservoir and brew basket
lid, remove the brew basket (lift straight up), and discard the grounds. Clean as follows:
brew basket, permanent gold-tone filter, carafe, and carafe lid are all top rack dishwashersafe; or they may be hand washed in warm, sudsy water. See below for carafe care. The
coffeemaker’s exterior, control panel area and "Keep Hot" plate may be cleaned with a
soft damp cloth. Do not use abrasive cleansers or scouring pads. Never immerse the
coffeemaker in water.
2. To clean inside of one piece water reservoir and brew basket lid,
open. Wipe surfaces with a damp cloth, then close the one piece
water reservoir and brew basket lid (A).
Carafe Care
A damaged carafe may result in possible burns from a hot liquid.
To avoid breaking:
• Do not allow all liquid to evaporate from the carafe while on the "Keep Hot" plate or heat
the carafe when empty.
• Discard the carafe if chipped, cracked, or damaged in any manner.
• Never use abrasive scouring pads or cleansers; they will scratch and weaken the glass.
• Do not place the carafe on or near a gas or electric burner, in a heated oven, or in
a microwave oven.
• Avoid rough handling and sharp blows.
Mineral Deposits and Clogging
Mineral deposits left by hard water can clog your coffeemaker. Cleaning is recommended
every 3 months. Excessive steaming or a prolonged brewing cycle is a sign that a cleaning is
needed. The frequency of flushing out deposits is affected by your usage and water hardness.
During cleaning, more steaming occurs than when brewing coffee and may emit spurts of
steam.
1. Pour white vinegar into water reservoir up to 6-cup level on water level window. Add
water up to 12-cup line.
2. Put a paper filter in the brew basket or permanent gold-tone filter and close the one piece
water reservoir and brew basket lid. Set empty carafe on the "Keep Hot" plate.
3. Turn on coffeemaker and let half the cleaning solution brew into carafe (till water level
goes down to around "5"). Turn off coffeemaker and let it soak for at least 15 minutes to
soften the deposits.
4. Turn on coffeemaker and brew remaining cleaning solution into carafe.
5. Turn off coffeemaker, empty carafe and discard soiled filter.
6. Fill reservoir with water to 12-cup line, replace empty carafe, then turn on coffeemaker for
a complete brew cycle to flush out remaining cleaning solution. You may have to repeat
this to eliminate the vinegar smell/taste.
7. Wash the brew basket and carafe as instructed in "CLEANING".
A
Cuando se utilizan aparatos eléctricos, siempre se debe respetar ciertas
medidas de seguridad a fin de reducir el riesgo de un incendio, un choque
eléctrico y (o) lesiones a las personas, incluyendo las siguientes:
❑
Por favor lea todas las instrucciones.
❑
No toque las superficies calientes. Utilice las asas o las perillas.
❑
A fin de protegerse contra el riesgo de un choque eléctrico, no coloque
el aparato de manera que el cable, el enchufe o el mismo aparato entre
en contacto con agua o cualquier otro líquido.
❑
Todo aparato eléctrico utilizado en la presencia de menores de edad o
por ellos mismos requiere la supervisión de un adulto.
❑
Desconecte el aparato de la toma de corriente cuando no esté en
funcionamiento y antes de limpiarlo. Espere que el aparato se enfríe
antes de instalar o retirar las piezas y antes de limpiarlo.
❑
No se debe utilizar ningún aparato eléctrico que tenga el cable o el
enchufe averiado, que presente un problema de funcionamiento o que
esté dañado. Devuelva el aparato al centro de servicio autorizado más
cercano para que lo examinen, reparen o ajusten. Si el producto llegase
a fallar dentro del período de la garantía, llame gratis al número
apropiado que aparece en la cubierta de este manual para obtener
información relacionada al servicio de mantenimiento del aparato.
❑
El uso de un accesorio no evaluado para ser utilizado con este aparato
podría ocasionar lesiones personales.
❑
Este aparato no se debe utilizar a la intemperie.
❑
No permita que el cable cuelgue del borde de la mesa o del mostrador
ni que entre en contacto con las superficies calientes.
❑
No coloque el aparato sobre ni cerca de las hornillas de gas o eléctricas
ni adentro de un horno caliente.
❑
El aparato se debe de utilizar únicamente con el fin previsto.
❑
La jarra debe permanecer tapada cuando está en uso.
❑
Existe el riesgo de quemaduras si uno retira la tapa durante los ciclos
de colado.
❑
La jarra está diseñada para ser utilizada con este aparato. Jamás se
deberá utilizar sobre la estufa.
❑
Nunca coloque una jarra caliente sobre una superficie fría ni húmeda.
❑
No utilice la jarra si el vidrio se encuentra rajado o si el asa está débil.
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD
Loading...
