Black & Decker DE710 User Manual
Please Read and Save this Use and Care Book
Por favor lea este instructivo antes de usar el producto
Veuillez lire et conserver ce guide d’entretien et d’utilisation
12-Cup Coffeemaker
Cafetera de 12 tazas
Cafetière de 12 tasses
IMPORTANT / IMPORTANTE /
IMPORTANT
WASH CARAFE BEFORE FIRST USE!
LAVE LA JARRA ANTES
DEL PRIMER USO
LAVER LA CARAFE AVANT
LA PREMIÈRE UTILISATION!
Model
Modelo
Modèle
❑
DE710
USA/Canada 1-800-231-9786
Mexico 01-800-714-2503
www.blackanddecker.com
Accessories/Parts (USA/Canada)
Accesorios/Partes (EE.UU/Canadá)
Accessoires/Pièces (É.-U./Canada)
1-800-738-0245
2
1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and/or injury to
persons, including the following:
❑ Read all instructions.
❑ Do not touch hot surfaces. Use handle or knobs.
❑ To protect against electric shock, do not place cord, plug or appliance
in water or other liquids.
❑ Close supervision is necessary when any appliance is used by or near
children.
❑ Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts and before cleaning the appliance.
❑ Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
the appliance to the nearest authorized service facility for examination,
repair, or adjustment. Or, call the appropriate toll-free number on the
cover of this manual.
❑ The use of an accessory not evaluated for use with this appliance may
cause injuries.
❑ Do not use outdoors.
❑ Do not let cord hang over the edge of table or counter, touch with hot
surfaces.
❑ Do not place on or near a hot gas or electric burner or in a heated oven.
❑ Keep the lid on the carafe when in use.
❑ The carafe is designed for use with the appliance. It must never be used
on a range top.
❑ Do not set a hot carafe down on a wet or cold surface.
❑ Do not use the carafe if the glass is cracked or has a loose or weakened
handle.
❑ Do not clean the carafe with abrasive cleansers, steel wool, or other
abrasive material.
❑ Do not use this appliance for anything other than intended use.
❑ Scalding may occur if the lid is removed udring the brewing cycles.
SAVE THESE INSTRUCTIONS.
POLARIZED PLUG (120V Models Only)
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way.
If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning : This appliance is equipped with a tamper-resistant screw to prevent
removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt
to remove the outer cover. There are no user-serviceable parts inside. Repair should
be done only by authorized service personnel.
ELECTRICAL CORD
a) A short power-supply cord (or detachable power-supply cord) is to be provided
to reduce the risk resulting from becoming entangled in or tripping over
a longer cord.
b) Longer detachable power-supply cords or extension cords are available
and may be used if care is exercised in their use.
c) If a long detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the detachable power-supply cord or extension
cord should be at least as great as the electrical rating of the appliance,
2) If the appliance is of the grounded type, the extension cord should be a
grounding-type 3-wire cord, and
3) The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or tripped over.
Note: If the power supply cord is damaged, it should be replaced by qualified
personnel or in Latin America by an authorized service center.
4
How to Use
This appliance is intended for household use only.
GETTING STARTED
1. Remove all stickers, packing material, and literature.
2. Wash all parts as instructed in the Care and Cleaning section.
3. Pour water up to 12-cup level mark in the water reservoir.
Brew it through as instructed in "BREWING," but do not add coffee grounds to the
paper filter. When done, turn off the coffeemaker and discard the water from the
carafe.
BREWING
1. Lift one-piece water reservoir and brew basket lid. Use water markings on
carafe to fill water reservoir with water to your desired level.
2. Place a paper filter into the brew basket. Add ground coffee, (we recommend
a heaping tablespoon for every cup). Close the one-piece water reservoir and
brew basket lid.
3. Place carafe on the "Keep Hot" plate and plug in the unit.
4. Press ON/OFF switch.
5. Replace the carafe on the "Keep Hot" plate when not serving to keep
coffee hot.
6. Press "ON/OFF" to turn off unit.
The coffeemaker will keep coffee warm for 2 hours before it automatically
shuts off.
Sneak-A-Cup®Interrupt Feature
You can pour a cup of coffee while coffee is brewing without leaking from the
brew basket. When finished pouring coffee, place the carafe under brew basket.
The brewing process continues.
Important: To avoid possible overflow after removing the carafe, be sure to
replace the carafe under the brew basket within 30 seconds to prevent the basket
from overflowing.
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service
personnel.
CLEANING
1. Be sure the unit is off and cooled. Open the one-piece water reservoir and
brew basket lid, remove the brew basket (lift straight up), and discard the paper
filter/grounds. Clean as follows: brew basket, carafe, and carafe lid are all top
rack dishwasher-safe; or they may be hand washed in warm, sudsy water. See
below for carafe care. The coffeemaker’s exterior, control panel area and
"Keep Hot" plate may be cleaned with a soft damp cloth. Do not use abrasive
cleansers or scouring pads. Never immerse the coffeemaker in water.
3
Product may vary slightly from what is illustrated.
†1. One-piece water reservoir and brew basket lid (Part # DE710-01)
2. Water showerhead (not shown)
3. Water reservoir
4. Water viewer with water marker
5. Cord storage (inside of unit)
6. On/Off switch
7. “Keep Hot” plate
8. Water-fill/brewed-coffee markings
†9. Carafe with lid (Part # DE710-02)
†10. Removable brew basket (not shown) (Part # DE710-03)
†Consumer replaceable/removable parts
CONTROL PANEL
6
5
2. To clean inside, open the one-piece water reservoir and
brew basket lid. Wipe surfaces with a damp cloth, close the
one-piece water reservoir and brew basket lid (A).
Carafe Care
A damaged carafe may result in possible burns from a hot liquid.
To avoid breaking:
• Do not allow all liquid to evaporate from the carafe while on the "Keep Hot"
plate or heat the carafe when empty.
• Discard the carafe if chipped, cracked, or damaged in any manner.
• Never use abrasive scouring pads or cleansers; they will scratch and weaken
the glass.
• Do not place the carafe on or near a gas or electric burner, in a heated oven,
or in a microwave oven.
• Avoid rough handling and sharp blows.
Mineral Deposits and Clogging
Mineral deposits left by hard water can clog your coffeemaker. Cleaning is
recommended every 3 months. Excessive steaming or a prolonged brewing cycle
is a sign that a cleaning is needed. The frequency of flushing out deposits is
affected by your usage and water hardness. During cleaning, more steaming
occurs than when brewing coffee and may emit spurts of steam.
1. Pour white vinegar into water reservoir up to 6-cup level on water viewer.
Add water up to 12-cup line.
2. Put a paper filter in the brew basket and close the cover. Set empty carafe on
the "Keep Hot" plate.
3. Turn on coffeemaker and let half the cleaning solution brew into carafe
(till water level goes down to around "5"). Turn off coffeemaker and let
it soak for at least 15 minutes to soften the deposits.
4. Turn on coffeemaker and brew remaining cleaning solution into carafe.
5. Turn off coffeemaker, empty carafe and discard soiled filter.
6. Fill reservoir with water to 12-cup line, replace empty carafe, then turn on
coffeemaker for a complete brew cycle to flush out remaining cleaning
solution. You may have to repeat this to eliminate the vinegar smell/taste.
7. Wash the brew basket and carafe as instructed in "CLEANING".
Cuando se utilizan aparatos eléctricos, siempre se debe respetar ciertas
medidas de seguridad a fin de reducir el riesgo de un incendio, un choque
eléctrico y (o) lesiones a las personas, incluyendo las siguientes:
❑
Por favor lea todas las instrucciones.
❑
No toque las superficies calientes. Utilice las asas o las perillas.
❑
A fin de protegerse contra el riesgo de un choque eléctrico, no coloque
el aparato de manera que el cable, el enchufe o el mismo aparato entre
en contacto con agua o cualquier otro líquido.
❑
Todo aparato eléctrico utilizado en la presencia de menores de edad o
por ellos mismos requiere la supervisión de un adulto.
❑
Desconecte el aparato de la toma de corriente cuando no esté en
funcionamiento y antes de limpiarlo. Espere que el aparato se enfríe
antes de instalar o retirar las piezas y antes de limpiarlo.
❑
No se debe utilizar ningún aparato eléctrico que tenga el cable o el
enchufe averiado, que presente un problema de funcionamiento o que
esté dañado. Devuelva el aparato al centro de servicio autorizado más
cercano para que lo examinen, reparen o ajusten. Si el producto llegase
a fallar dentro del período de la garantía, llame gratis al número
apropiado que aparece en la cubierta de este manual para obtener
información relacionada al servicio de mantenimiento del aparato.
❑
El uso de un accesorio no evaluado para ser utilizado con este aparato
podría ocasionar lesiones personales.
❑
Este aparato no se debe utilizar a la intemperie.
❑
No permita que el cable cuelgue del borde de la mesa o del mostrador
ni que entre en contacto con las superficies calientes.
❑
No coloque el aparato sobre ni cerca de las hornillas de gas o eléctricas
ni adentro de un horno caliente.
❑
La jarra debe permanecer tapada cuando está en uso.
❑
La jarra está diseñada para ser utilizada con este aparato. Jamás se
deberá utilizar sobre la estufa.
❑
Nunca coloque una jarra caliente sobre una superficie fría ni húmeda.
❑
No utilice la jarra si el vidrio se encuentra rajado o si el asa está débil.
❑
No limpie la jarra con limpiadores abrasivos, con almohadillas de fibra
de metal ni demás limpiadores abrasivos.
❑
El aparato se deberá utilizar únicamente con el fin previsto.
❑
Existe el riesgo de quemaduras si uno retira la tapa durante los ciclos
de colado.
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD
GUARDE ESTAS INSTRUCCIONES.
A
