Coffeematic
®
Drip Coffeemakers
SAVE THIS USE AND CARE BOOK
1-800-231-9786
QUESTIONS? Please call us TOLL FREE
?
MODELS DCM12WH, DCM12WL, DCM94WH
IMPORTANT:
PLEASE WASH
CARAFE BEFORE
FIRST USE!
12
10
8
6
4
2
When using electrical appliances, in order to reduce the risk of fire,
electric shock and/or injury, basic safety precautions should always be
followed, including the following:
PLEASE READ ALL INSTRUCTIONS.
■ Use only for its intended use.
■ Do not touch hot surfaces. Use handles or knobs.
■ To protect against fire, electric shock, or injury, do not place cord, plug
or Coffeemaker base in water or other liquid.
■ Do not remove the bottom cover from the Coffeemaker. There are no
user-serviceable parts inside. Any repairs should be done by authorized personnel only.
■ Close supervision is necessary when any appliance is used by or near
children.
■ Unplug when Coffeemaker is not in use and before cleaning. Allow to
cool before putting on or taking off parts and before cleaning the
Coffeemaker.
■ Be sure there is water in the reservoir before brewing.
■ Do not operate if this appliance or the electrical cord or plug is dam-
aged or after the appliance malfunctions or has been damaged in any
manner. Return the Coffeemaker to the nearest authorized service
facility for examination, repair, or adjustment.
■ To avoid an electrical overload, do not operate another high-wattage
appliance on the same circuit with this Coffeemaker.
■ The use of an accessory not recommended or approved for operation
with this Coffeemaker may result in fire, electric shock, or injury.
■ Do not use outdoors.
■ Do not let cord hang over the edge of table or counter, or come in
contact with hot surfaces.
■ Do not place Coffeemaker or Carafe on or near a hot gas or electric
burner or in a heated oven.
■ Do not store anything directly on top of the Coffeemaker.
■ Keep the lid on the serving carafe when in use.
■ Use the “Keeps Hot” plate only. Do not heat the Carafe on a range top
or in a microwave oven.
■ Do not set a hot carafe down on a wet or cold surface.
2
IMPORTANT SAFEGUARDS
■ Do not use the Carafe if the glass is cracked or has a loose or
weakened handle.
■ Do not remove Carafe from “Keeps Hot” plate while liquid is dripping
from basket. Allow basket to cool before removing it from the
Coffeemaker.
■ Do not clean the Carafe with cleansers, steel wool, or other abrasives.
■ Do not pour liquid other than water or the cleaning solution specified
in this manual into the water reservoir.
■ Remember to place the empty Carafe on the “Keeps Hot” plate before
brewing.
■ Do not operate any electric appliance in the presence of explosive
and/or flammable fumes or liquids.
■ This product is intended FOR HOUSEHOLD USE ONLY and not for commercial or industrial use.
POLARIZED PLUG The Coffeematic
®
Drip Coffeemaker has a
polarized plug — one blade is wider than
the other. As a safety feature, this plug will
fit into a polarized outlet only one way. If the
plug does not fit fully into the outlet, reverse
it and try again. If it still does not fit, contact
an electrician. Do not attempt to defeat this
safety feature.
TAMPER-RESISTANT This appliance is equipped with a tamper-
SCREW resistant screw to prevent removal of the
outer cover. To reduce the risk of fire or
electric shock, do not attempt to remove the
outer cover. There are no consumer serviceable parts inside. Repair should be done
only
by authorized service personnel (see
pages 10-11 for a list of Black & Decker
Company-Owned Service Centers).
3
SAVE THESE INSTRUCTIONS
Before the first use, remove all stickers,
packing material, and literature.
Clean the Carafe, Filter Basket, Water
Spreader, and Carafe Lid by washing in hot,
sudsy water — rinse thoroughly.
Brew 10 (model DCM94WH) or 12 (model
DCM12WH or model DCM12WL) cups of
fresh water through the system as instructed in the BREWING COFFEE instructions,
but do not add coffee grounds.
How To Use
PREPARATION
FOR USE
4
1. Water Reservoir with Cup Level Markings
2. Flip-Up Reservoir Cover
3. Water Spreader
4. Paper Filter (not included)
5. Filter Basket
6. Carafe Serving Lid
7. 12-Cup Carafe (Models DCM12WH
and DCM12WL Shown)
8. “Keeps Hot” Plate
9. On/Off Control
1
3
4
6
2
5
7
8
9
5
BREWING COFFEE
1. Remove the Water Spreader and
place a paper coffee filter into the
Filter Basket. Add drip grind coffee to
the filter corresponding to the amount
of coffee to be brewed (usually one
heaping tablespoon for every two
cups. Adjust to suit your taste). When
brewing 2-4 cups, use slightly more
grounds per cup. Replace the Water
Spreader over the Filter Basket.
2. Use the Carafe to fill the Water
Reservoir with cold water to the
desired cup level. Close the Flip-Up
Reservoir Cover.
3. Place the Filter Basket (with Water
Spreader) over the empty Carafe,
(Figure A) then sit the Carafe on the
“Keeps Hot” plate.
4. Slide the Control to “On.” You will
see a red square in the display. The
“Keeps Hot” plate comes on automatically when brewing begins.
5. Let all the brewed coffee drip from
the Basket. Remove the Basket and
Spreader and set it aside. Place the
Serving Lid on the Carafe. (Figure B)
6. Place the Carafe on the “Keeps
Hot” plate when not serving to keep
coffee hot. The “Keeps Hot” plate will
remain warm until the unit is turned
off by sliding the Control to “Off”.
7. DO NOT pour brewed coffee back
into the Water Reservoir to reheat it.
Reheat coffee in a saucepan on a
range or in a microwave-safe container in a microwave oven. Do not put
the Carafe in a microwave oven.
Figure B
Figure A
CARING FOR YOUR
CARAFE
To clean your Coffeemaker after brewing coffee, be sure the unit is OFF and has cooled.
Discard the paper filter and grounds, and
clean as follows:
Filter Basket, W
ater Spreader, Carafe, and
Carafe Serving Lid are all top rack dishwasher-safe; or, they may be hand washed in hot,
sudsy water.
NOTE: Since the white Filter Basket and
Water Spreader are prone to staining, you
may want to wash them well with soap and
water after each use.
The Coffeemaker’
s exterior and “Keeps Hot”
plate may be cleaned with a damp cloth. Do
not use abrasive cleansers or scouring pads.
Never immerse the Coffeemaker in water.
The Carafe capacity for the DCM12WH and
DCM12WL is 12 cups; for the DCM94WH, it is
10 cups (Figure C). A damaged Carafe may
result in possible burns from hot liquid. To
avoid breaking the Carafe:
• Do not let all liquid evaporate from the
Carafe while on the “Keeps Hot”
plate, or heat the Carafe when empty.
• Discard the Carafe if damaged in any
manner. A chip or crack could result
in breakage.
• Never use abrasive scouring pads or
cleansers, they will scratch the glass.
• Do not place the Carafe on or near a
hot gas or electric burner, in a heated
oven, or in a microwave oven.
• Avoid rough handling and sharp
blows.
6
CLEANING YOUR
COFFEEMAKER
Figure C
DCM94WH
Carafe
DCM12WH and
DCM12WL Carafe
Mineral deposits left by hard water can clog
your Coffeemaker. It is necessary to regularly clean your Coffeemaker to flush out
these deposits. Excessive steaming or a
prolonged brewing cycle are signs that a
cleaning is needed.
Clean your Coffeemaker approximately
every 1-3 months. The frequency of cleaning required is affected by your specific
usage and water hardness. You may have to
clean the Coffeemaker more or less often.
During cleaning, more steaming occurs than
when brewing coffee.
1. Fill the Water Reservoir half way with
white vinegar and add cold water up to the
10-cup line (model DCM94WH) or 12-cup
line (model DCM12WH or DCM12WL).
2. Put an empty paper filter in the Filter
Basket, place the Water Spreader over the
basket, and place the Basket over the
empty Carafe. Set the empty Carafe securely onto the “Keeps Hot” plate.
3. Turn the Coffeemaker on.
4. Let half the cleaning solution brew into
the Carafe, then turn the Coffeemaker off to
soak.
5. Allow the Coffeemaker to remain off for at
least 15 minutes to soften the deposits.
6. Turn the Coffeemaker on again to brew
the remaining cleaning solution into the
Carafe.
7. Turn the Coffeemaker off; discard the
cleaning solution and the soiled Filter.
7
MINERAL DEPOSITS
AND CLOGGING
ELECTRICAL CORD
8. Fill the Reservoir with cold water to the
10-cup line (model DCM94WH) or the 12cup line (model DCM12WH or DCM12WL);
replace the empty Basket, Water Spreader,
and Carafe.
9. Turn on the Coffeemaker for a complete
brew cycle to flush out the remaining cleaning solution.
10. Wash the Filter Basket, Water Spreader,
and Carafe as instructed in “Cleaning Your
Coffeemaker” (see page 6).
The cord length of this Drip Coffeemaker
was selected to reduce safety hazards that
may occur with a longer cord. If more cord
length is needed, an extension cord with a
polarized plug may be used. It should be
rated not less than 10 amperes, 120 Volts,
and have Underwriters Laboratories listing.
A properly rated extension cord may be purchased from a Black & Decker (U.S.) Inc.,
Household Appliance Company-Owned or
Authorized Service Center. When using a
longer cord, be sure it does not drape over
a working area or dangle where it could be
pulled on or tripped over. Handle cord carefully for longer life; avoid jerking or straining
it at outlet and appliance connections.
8
Service, if necessary, must be performed by
a Black & Decker (U.S.) Inc., Household
Appliance Company-Owned or Authorized
Service Center. The Service Center nearest
you can be found in the yellow pages of
your phone book under “Appliances-SmallRepairing.” For your convenience, a complete listing of our Company-Owned Service
Centers is listed on pages 10-11.
If mailing or shipping your Coffeemaker,
pack it carefully in a sturdy carton with
enough packing material to prevent damage. Be sure to empty water from the reservoir and Carafe before packing. You may
use original packaging as long as you’ve
include packing material suitable for shipping. Include a note describing the problem
to our Service Center and be sure to give
your return address. We also suggest that
you insure the package for your protection.
Consumer-replaceable parts and accessories are available at Black & Decker
(U.S.) Inc., Household Appliance
Company-Owned or Authorized Service
Centers. To order a replacement Carafe by
phone (or any other replacement part such
as the brew basket, water spreader, or
serving lid), call toll free, 1-800-258-6003.
9
SERVICE OR REPAIR
10
BLACK AND DECKER COMPANY-OWNED SERVICE CENTERS
ALABAMA
BIRMINGHAM — 2412 Green Springs, Hwy., 35209
205-942-0538
MOBILE — 3831 Airport Blvd., 36608 205-343-6624
ALASKA
ANCHORAGE — 910 West International Airport Rd., 99518
907-563-4664
ARIZONA
MESA — 535 South Dobson Rd., Suite 7, 85202
602-461-1074
PHOENIX — 4501 N. 7th Ave., 85013 602-279-6414
TUCSON — 4845 E. Speedway Blvd., 85712 602-323-3388
ARKANSAS
LITTLE ROCK — 519 W. Seventh St., 72201 501-372-3040
CALIFORNIA
ANAHEIM — 540 South State College Blvd., 92806
714-772-4050
CHULA VISTA — 309 Broadway, 91911 619-420-6350
CONCORD — 1500 Monument Blvd., #C2, 94520
510-682-4880
FRESNO — 5412 North Blackstone Ave., 93710 209-435-0810
LONG BEACH — 2011 South St., 90805 310-422-5825
LOS ANGELES — 4820 South Eastern Ave., Suite “L” 90040
213-720-1834
RIVERSIDE — 6215 Magnolia Ave., Suite B, 92506
714-787-9700
SACRAMENTO — 2033 Fulton Ave., 95825 916-972-9090
SAN DIEGO — 9270 Clairmont Mesa Blvd., 92123
619-279-2011
SAN JOSE — 1185 South Bascom Ave., 95128 408-293-7350
SAN LEANDRO — 15206 East 14th St., 94578 510-276-1610
VAN NUYS — 14920 Victory Blvd., 91411 818-787-5531
COLORADO
DENVER — 1171 South Federal Blvd., Box 19220, 80219
303-922-8325
CONNECTICUT
HARTFORD — 662 Silas Deane Hwy., 06109 203-563-5800
ORANGE — 481 Boston Post Rd., 06477 203-795-3583
DISTRICT OF COLUMBIA
COLMAR MANOR, MD — 4153 Bladensburg Rd., 20710
301-779-3808
FALLS CHURCH, VA — 344 W. Broad St., 22046
703-533-7313
FLORIDA
FT. LAUDERDALE — 799 East Oakland Pk. Blvd., 33334
305-566-5102
FT. MYERS — 5224 Bank St., 33907 813-278-1188
JACKSONVILLE — 920 Cassat Ave., 32205 904-781-2253
MIAMI — 13345 North West Seventh Ave., 33168
305-681-6658
MIAMI — 12233 South Dixie Hwy., 33156 305-232-9497
ORLANDO — 3807 East Colonial Dr., 32803 407-894-7011
ST. PETERSBURG — 5635 49th St. North, 33709
813-525-0273
TAMPA — 3432 West Kennedy Blvd., 33609 813-872-8317
WEST PALM BEACH — 310 South Military Trail, 33415
407-689-3247
GEORGIA
ATLANTA (South) — 5330 Old National Hwy., 30349 404-762-8844
SMYRNA — 2550 Cobb Parkway South, 30080 404-956-0869
STONE MOUNTAIN — 5723 Memorial Dr., 30083 404-292-4714
HAWAII
HONOLULU — Unit No. 106, Sand Island Access Rd., 96819
808-847-7447
ILLINOIS
CHICAGO (Lincolnwood) — 6710 North Crawford Ave., 60646
708-673-0923
DES PLAINES — 1277 South Elmhurst Rd., 60018 708-364-5220
LISLE — 2950 Ogden Ave., Unit H, 60532 708-717-1075
MOLINE — 4433 23rd Ave., 61265 309-762-3000
OAK LAWN — 6343 W. 95th St., 60453 708-423-7212
WAUKEGAN, — 39 S. Greenbay Rd., 60085 703-249-4390
INDIANA
EVANSVILLE — 307 First Ave., Crescent Ctr., 47710 812-425-4269
HAMMOND — 7103 Kennedy Ave., 46323 219-845-5100
INDIANAPOLIS (Speedway) — 5999 Crawfordsville Rd., 46224
317-243-8308
IOWA
DES MOINES — 3427 Merle Hay Rd., 50310 515-270-1340
KANSAS
WICHITA — 155 South West St., 67213 316-943-1271
KENTUCKY
LOUISVILLE — 5211 Preston Hwy., 40213 502-968-7100
LOUISIANA
BATON ROUGE — 11859 Florida Blvd., 70815 504-272-8111
HARVEY — 2500 Lapalco Blvd., 70058 504-366-8676
METAIRIE (New Orleans) — 3504 North Causeway Blvd., 70002
504-837-2550
SHREVEPORT — 7710-7714 Jewella Rd., 71108 318-688-1553
MARYLAND
BALTIMORE — 4712 Erdman Ave., 21205 410-485-5550
BALTIMORE — 29-31 Cranbrook Rd., Cockeysville, 21030
410-666-5966
COLMAR MANOR (Wash. D.C.) — 4153 Bladensburg Rd., 20722
301-779-3808
PASADENA — 8220 Ritchie Hwy., 21122 410-647-8456
MASSACHUSETTS
BRIGHTON (Boston) — 12 Market St., 02135 617-782-6264
SEEKONK — 120 Highland Ave., 02771 508-336-6510
MICHIGAN
GRAND RAPIDS — 3040 28th St.,SE, 49512 616-949-8331
LANSING — 3203 W. Saginaw Hwy., 48917 517-323-4181
WARREN — 27035 Van Dyke Blvd., 48093 313-756-6711
WESTLAND — 8067 N. Wayne Rd., 48185 313-427-1520
MINNESOTA
BLOOMINGTON — 9517 Lyndale Ave., South, 55420 612-884-9191
11
MISSOURI
KANSAS CITY — 4324 Main St., 64111 816-531-0629
ST. ANN — 3637 North Lindbergh Blvd., 63074
314-739-4661
ST. LOUIS — 12852 Manchester Rd., 63131 314-821-8740
NEBRASKA
OMAHA — 4225 South 84th St., 68127 402-592-5666
NEVADA
LAS VEGAS — 3411 East Charleston Blvd., 89104
702-641-6555
NEW JERSEY
CHERRY HILL — 1444 East Marlton Pike (Rt. 70), 08034
609-429-2822
LITTLE FALLS — 1189 U.S. Hwy. 46, 07424 201-256-9373
SCOTCH PLAINS — 2520 Route #22 East, 07076 908-233-5665
NEW MEXICO
ALBUQUERQUE — 5617 Menaul Blvd., N.E., 87110
505-884-1002
NEW YORK
ALBANY (Latham) — 836 Troy-Schenectady Rd., 12110
518-785-1867
BUFFALO — 881 West Delavan Ave., 14209 716-884-6220
CENTEREACH L.I. — 2061-63 Middle Country Rd., 11720
516-737-4706
NEW YORK (Elmhurst) — 77-20 Queens Blvd., 11373
718-335-1042
NEW YORK (Manhattan) — 50 West 23rd St., 10010
212-929-6450
NEW YORK (Westbury, L.I.) — 1061 Old Country Rd., 11590
516-997-6140
ROCHESTER — 2969 W. Henrietta Rd., 14623 716-424-1310
SYRACUSE — 3485 Erie Blvd., East, 13214 315-446-3086
NORTH CAROLINA
CHARLOTTE — 3007 East Independence Blvd., 28205
704-374-1779
GREENSBORO — 3716 High Point Rd., 27407 919-852-1300
RALEIGH — 2930 Capital Blvd., 27604 919-878-0357
OHIO
CINCINNATI — 2310 East Sharon Rd., 45241 513-772-3111
COLUMBUS — 3975 East Livingston Ave., 43227
614-237-0461
DAYTON — 2898 South Dixie Drive, 45409 513-298-1951
MAYFIELD HEIGHTS — 5881 Mayfield Rd., 44124
216-449-2770
PARMA HEIGHTS (Cleveland) — 6483 Pearl Rd., 44130
216-842-9100
TOLEDO — 3231 Dorr St., 43607 419-531-8921
OKLAHOMA
OKLAHOMA CITY — 1318 Linwood Blvd., 73106
405-232-7515
TULSA — 3120 S. Sheridan Rd, 74145 918-622-5666
OREGON
PORTLAND — 1640 NW Johnson St., 97209
503-228-8631
PENNSYLVANIA
ALLENTOWN (Whitehall) — 2242 MacArthur Rd., 18052
215-435-9544
EVANS CITY — Cranberry Town Center Plaza, 20808 Rt. 19 N., 16033
412-779-9600
HARRISBURG — 6080 Allentown Blvd., 17112 717-545-0651
LANCASTER — 118 Keller Ave., 17601 717-393-5251
PHILADELPHIA — 9977-81 Bustleton Ave., 19115
215-464-7771
PHILADELPHIA — 333 North 20th St., 19103 215-564-5520
PITTSBURGH — 5437 Baum Blvd., 15232 412-362-2700
WILKES-BARRE — 759 Kidder St., 18702 717-824-5704
PUERTO RICO
GUAYNABO — “C” Street # 14, Rexco Industrial Park, 00922-1924
809-783-3535
RHODE ISLAND
SEEKONK, MA — 120 Highland Ave., 02771 508-336-6510
SOUTH CAROLINA
GREENVILLE — 1557 Laurens Rd., 29607 803-232-3038
TENNESSEE
CHATTANOOGA — Perimeter Place Shopping Ctr., Sp. E,
6231 Perimeter Dr., 37421 615-894-5957
KNOXVILLE — 4118 North Broadway, 37917 615-688-0921
MEMPHIS — 1085 East Brooks Rd., 38116 901-332-3444
NASHVILLE — 4811 Nolensville Rd., 37211 615-833-8277
TEXAS
AMARILLO — 3008 West 6th Ave., 79106 806-373-1531
AUSTIN — 6549 Burnet Rd., 78757 512-459-1133
DALLAS — 2257 Royal Lane, 75229 214-620-8655
EL PASO — 6822 Gateway East, 79915 915-778-9769
FORT WORTH — 721 North Beach St., 76111 817-831-3828
GARLAND — 78 West Centerville Rd., 75043 214-686-9302
HOUSTON — 536 East Tidwell Rd., 77022 713-692-7111
SAN ANTONIO — 500 Culebra Ave., 78201 210-732-1221
WEBSTER — 100 East Nasa Road One, Ste. 75, 77598 713-338-4556
UTAH
SALT LAKE CITY — 1541 S. Third West St., 84115 801-486-5828
VIRGINIA
FALLS CHURCH — 344 W. Broad St., 22046 703-533-7313
HAMPTON — 3416 W. Mercury Blvd., 23666 804-826-9382
NORFOLK — 7631 Sewells Point Rd., 23513 804-480-3333
RICHMOND — 1424 Chamberlayne Ave., 23222 804-649-9245
WASHINGTON
SEATTLE — 421 S. Michigan, 98108 206-763-2010
SPOKANE — N. 7011 Division St., 99208 509-467-8190
TACOMA — 2602 S. 38th St., 98409 206-473-6040
WEST VIRGINIA
CHARLESTON — 1638 Sixth Ave., 25312 304-343-0289
WISCONSIN
MILWAUKEE (Wauwatosa) — 10424 W. Bluemound Rd., 53226
414-453-4240
REV: 8/94
Listed by Underwriters Laboratories Inc.
Copyright © 1990, 1991, 1994 Black & Decker
Printed in U.S.A.
Pub. No. 168638-01-RV03
FULL TWO-YEAR
WARRANTY
Black & Decker (U.S.) Inc. warrants this product
against any defects that are due to faulty material or workmanship for a two-year period after the
original date of consumer purchase or receipt as
a gift. This warranty does not include damage to
the product resulting from accident or misuse.
If the product should become defective within
the warranty period, we will repair it or elect to
replace it free of charge, including free return
transportation, provided it is delivered prepaid to
any Black & Decker (U.S.) Inc., Household
Appliance Company-Owned or Authorized
Service Center. This warranty gives you specific
legal rights, and you may also have other rights
which vary from state to state.
Answers to any questions regarding warranty or
service locations may be obtained by calling toll
free 1-800-231-9786 or by writing:
Consumer Assistance and Information
Black & Decker (U.S.) Inc.
626 Hanover Pike
Hampstead, MD 21074-0618
Loading...
