Black & Decker DCM900, DCM300 User Manual

10-Cup

Drip Coffeemakers (English See Pg. ??) Cafetera para 10 tazas (Consulte lá pagina ??) Cafetière de 10 tasses (Fraçais à la page ??)

Series DCM300 Séries Series DCM900 Séries

(DCM903WH Shown)

SAVE THIS USE AND CARE BOOK

LEASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO

CONSERVER CE GUIDE D’ENTRETIEN ET D’UTILISATION

U.S.A. 1-800-231-9786

QUESTIONS?

MEXICO 9-1-800-70128

PREGUNTAS?

CANADA 1-800-465-6070

DES QUESTIONS?

IMPORTANT / IMPORTANTE /IMPORTANT

WASH CARAFE BEFORE FIRST USE!

LAVE LA JARRA ANTES DEL PRIMER USO!

LAVER LA CARAFE AVANT LA

PREMIÈRE UTILISATION!

IMPORTANT SAFEGUARDS

When using electrical appliances, in order to reduce the risk of fire, electric shock, and/or injury to persons, basic safety precautions should always be followed, including the following:

■ Please read all instructions.

■ Do not touch hot surfaces. Use handles or knobs.

■ To protect against fire, electric shock and injury to persons, do not

immerse cord, plug, or coffeemaker base in water or other liquid.

■ To prevent fire or electric shock, do not remove bottom cover from coffeemaker base. There are no user-serviceable part inside. Repair should be done by authorized service personnel only.

■ Close supervision is necessary when any appliance is used by or near children.

■ Allow to cool before putting on or taking off parts and before cleaning the coffeemaker.

■ Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Return the appliance to the nearest Black & Decker (U.S.) Inc., Household Appliance Company-Owned or Authorized Service Center for examination, repair, or adjustment.

■ The use of an accessory not evaluated for use with this coffeemaker may result in fire, electric shock, or injury to persons.

■ Do not use outdoors.

■ Do not let cord hang over edge of table or counter or touch

hot surfaces.

■ Do not place on or near a hot gas or electric burner or in a hot oven.

■ Do not use coffeemaker for other than intended use.

■ Keep lid on carafe while serving coffee.

■ The carafe is designed for use with this coffeemaker. It must never

be used on a range top or in a microwave oven.

■ Do not set a hot carafe on a wet or cold surface.

■ Do not use a cracked carafe or a carafe with a loose or

weakened handle.

■ Do not clean carafe with cleansers, steel wool pads, or other abrasive material.

■ Remember to place carafe on the “Keeps Hot” Plate before brewing and when using the automatic timer on clock models.

■ Do not pour liquid other than water or the cleaning solution specified in this manual into the water reservoir. (See “Mineral Deposits and Cleaning”)

■ Do not move entire unit when carafe contains hot liquid.

1 Water Reservoir Lid 2 Filter Basket 3 10-Cup Level Mark on Handle 4 Carafe 5 “Keeps Hot” Plate (Under Carafe) 6 Power “On” Light (Red) 7 Brew Later Light (Green) 8 Clock/Control Panel 9 Carafe Lid 10 Drip Stop (Under Basket) 11 Water Reservoir

DCM903WH Shown

POLARIZED PLUG

This appliance has a polarized plug—one blade is wider than the other. To reduce the risk of electric shock, this plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse it. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature by modifying the plug in any way.

TAMPER RESISTANT SCREW

This appliance is equipped with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no consumer serviceable parts inside. Repair should be done only by authorized service personnel.

SAVE THESE INSTRUCTIONS

■ Do not operate in the presence of explosive and/or flammable fumes.

■ This appliance is intended FOR HOUSHOLD USE ONLY and not for

commercial or industrial use.

NOTE: It is not necessary to set the clock before brewing.

1. When you plug in the Coffeemaker. The Clock will flash 12:00 a.m. and contunue flashing until either the Up or Down Buttons are pressed (Figure A).

2. Push and hold the Up or Down Button until the current time of day, a.m. or p.m., is reached.

3. To move forward or backward one minute at a time, push and

release the Up or Down Button until the desired time is reached.

BEFORE BREWING COFFEE

1. Brew 10 cups of water by following the instructions under “Brewing Coffee - With or Without Clocks”, but do not add coffee grounds to the paper filter.

2. When all the water has brewed into the Carafe, turn the Coffeemaker off, wait 10 minutes, discard the water then repeat steps 1 and 2.

3. Wash and dry the Filter Basket, Carafe, and Carafe

Lid.

BREWING COFFEE

1. Fill the Carafe with cold water to the level for the desired number of cups. Open the Water Reservoir Lid and pour the water into the Water Reservoir.

SETTING THE CLOCK

Figure A

●●

Up Down

How To Use

2. Remove the Filter Basket and place a standard cupcake-style paper coffee filter in it.

3. Put coffee grounds in the filter, using 1 level tablespoon of drip grind coffee for each cup (5 oz.) of brewed coffee.

NOTE: Use more or less grounds per cup to suit your taste. When brewing 2-4 cups, use slightly more grounds per cup (20 tablespoons maximum).

4. Shake the Filter Basket to spread the grounds, and place it back in the Coffeemaker. Be sure the Filter Basket is pushed all the way into the unit.

5. Place the Carafe on the “Keeps Hot” Plate, making sure the Carafe Lid is on the Carafe.

6. Press the ON/OFF Button. A red Power “On” Light will glow showing the unit is brewing and the “Keeps Hot” plate will automatically come on. Let all brewed coffee drip from the Filter Basket before removing the Carafe.

7. Always keep the Carafe Lid on the Carafe when pouring. To keep coffee hot, place the Carafe back on the “Keeps Hot” Plate when not serving.

8. The “Keeps Hot” Plate will remain on for two hours then will shut off automatically. If you wish to turn the Coffeemaker off sooner, depress the ON/OFF Button and the red Power “On” Light will turn off.

9. If you’d like to extend the “Keeps Hot” after the auto shut-off, press the ON/OFF Button to turn the “Keeps Hot” Plate on for two more hours.

NOTE: The amount of coffee in the Carafe may be slightly less than the amount of water placed in the Water Reservoir, since some water is absorbed by the coffee grounds during brewing.
