BLACK & DECKER DCM2160 User Manual

Please Read and Save this Use and Care Book Por favor lea este instructivo antes de usar el producto Veuillez lire et conserver ce guide d’entretien et d’utilisation

Models Modelos Modèles

❑

DCM2160W

❑

DCM2160B

12-Cup Programmable Coffeemaker

Cafetera programable de 12 tazas

Cafetière programmable de 12 tasses

USA/Canada 1-800-231-9786 Mexico 01-800-714-2503

www.applicaconsumerproductsinc.com

IMPORTANT / IMPORTANTE /

IMPORTANT

WASH CARAFE BEFORE FIRST USE!

LAVE LA JARRA ANTES DEL PRIMER USO

LAVER LA CARAFE AVANT

LA PREMIÈRE UTILISATION!

Accessories/Parts (USA/Canada) Accesorios/Partes (EE.UU/Canadá) Accessoires/Pièces (É.-U./Canada) 1-800-738-0245

for a chance to WIN $100,000!

For US residents only

Registre su producto en la Internet en el sitio Web www.prodprotect.com/applica

y tendrá la oportunidad de GANAR $100,000!

Solamente para los residentes de EE.UU

Inscrivez votre produit en ligne à l'adresse www.prodprotect.com/applica

et courez la chance de GAGNER 100 000 $!

Aux résidents du É.-U seulement

* Filters not included. * No incluye los filtros. * Filtres non compris.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock and/or injury to persons, including the following:

❑

Read all instructions.

❑

Do not touch hot surfaces. Use handles or knobs.

❑

To protect against fire, electric shock and injury to persons do not immerse cord, plugs or appliance in water or other liquid.

❑

Close supervision is necessary when any appliance is used by or near children.

❑

Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.

❑

Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or adjustment. Or, call the appropriate toll-free number on the cover of this manual.

❑

The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock or injury to persons.

❑

Do not use outdoors.

❑

Do not let cord hang over edge of table or counter, or touch hot surfaces.

❑

Do not place on or near a hot gas or electric burner, or in a heated oven.

❑

To disconnect, turn any control to OFF, then remove plug from wall outlet.

❑

Do not use this appliance for other than intended use.

❑

Keep lid on the carafe when in use.

❑

Scalding may occur if the lid is removed during the brewing cycles.

SAVE THESE INSTRUCTIONS.

POLARIZED PLUG (120V Models Only)

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW Warning: This appliance is equipped with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside.

Repair should be done only by authorized service personnel.

ELECTRICAL CORD

a) A short power-supply cord (or detachable power-supply cord) is to be provided

to reduce the risk resulting from becoming entangled in or tripping over a longer cord.

b) Longer detachable power-supply cords or extension cords are available and

may be used if care is exercised in their use.

c) If a long detachable power-supply cord or extension cord is used,

1) The marked electrical rating of the detachable power-supply cord or extension cord should be at least as great as the electrical rating of the appliance,

2) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord, and

3) The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.

Note: If the power supply cord is damaged, it should be replaced by qualified personnel or in Latin America by an authorized service center.

Product may vary slightly from what is illustrated.

1. One-piece water reservoir and brew basket cover

2. Water showerhead

3. Water reservoir

4. Water windows (on both sides) with cup level markings

5. Cord storage (inside of unit)

6. Control panel

7. “Keep Hot” plate

†8. 12-cup/60 oz. (1774 ml) carafe (Part # DCM2160W-02(w)) (Part# DCM2160B-02(b))

†9. Carafe lid (Part #DCM2160W-03(w)) (Part #DCM2160B-03(b))

†10. Removable filter basket (Part #DCM2160W-01(w)) (Part #DCM2160B-01(b))

† Consumer replaceable/removable parts





















Control Panel

1. LCD display Shows:

• Current time of day

• Preset auto brew cycle

2. AUTO light (in LCD display): Lights up when auto brew function is activated.

3. Power light: Lights up to indicate that the unit is turned on and the “Keep Hot” plate is heated.

4. MIN button: Sets desired minutes.

5. AUTO button: Activates the auto brew function.

6. ON/OFF button: Turns the unit on and off.

7. PROG button: Press to select Delayed Brew mode.

8. HOUR button: Sets desired hours.

9. PM light (in LCD display): Lights up to indicate PM hours.

POWER

6:00



















SETTING THE CLOCK

1. Plug appliance into standard electrical outlet.

2. The digital clock display flashes 12:00 (F). Note: You must set the clock in order to use the Delayed

Brewing feature.

3. To set the time: Press HOUR button until the correct

hour appears (G).

Note: When the time passes Noon a small light appears in the top left corner of the digital display under the PM signage to let you know you are in P.M. time. If the P.M. indicator is not lit, the time is A.M.

4. Repeat with the MIN button (H). (If minute setting is not

changed within 5 seconds, the clock will revert to default time and the selection of hour and minute will have to be repeated.)

Tip: Hold the button down to make the hours and minutes change rapidly after a short delay. To change the time in 1 minute increments, press and release the MIN button.

Note: If the unit is unplugged or power is interrupted even momentarily, the time will need to be reset.

BREWING COFFEE

It is not necessary to set the clock to brew coffee unless you want to use Delayed Brewing.

1. Open water reservoir/brew basket cover.

2. Fill water reservoir with cold tap water up to the desired

water marking on the side of reservoir. Caution: Be

careful not to exceed the 12-cup maximum level, to avoid water running out the overflow hole in the back of the coffeemaker (J).

3. Place an 8 to 12 cup basket style paper filter in the removable filter basket, make sure that it is properly centered in the brew basket.

4. Add your desired amount of ground coffee.

5. Insert brew basket into brew basket holder following directions in GETTING STARTED.

6. Close brew basket/ water reservoir cover securely.

7. Place brew- thru cover on empty carafe following directions in GETTING

STARTED.

Note: Coffee may overflow if brew-thru lid is not properly aligned.

8. Place empty carafe on the “Keep Hot” plate.

9. Plug cord into standard electrical outlet.

POWE

POWER

12:00

POWE

How to Use

This product is for household use only.

GETTING STARTED

1. Remove all packing material, and any stickers from the product.

2. Remove and save literature.

3. Wash all removable parts as instructed in the Care and Cleaning section.

4. Open water reservoir/brew basket cover and pour in

fresh cold water up to the #12-cup level mark. Caution:

Be careful not to exceed the 12-cup maximum level, to avoid water running out the overflow hole in the back of the coffeemaker (C).

5. Place empty 8 to 12 cup basket style paper filter into removable filter basket.

6. Place basket into brew basket with the handle to the

right (D).

7. Close water reservoir/brew basket cover securely.

8. To replace brew-thru lid cover on empty carafe insert small hole on left side of cover handle into projection on carafe cover holder. Press U-shaped projection on right side of cover handle down to click into position on right side of cover holder (E).

9. Place empty carafe on the “Keep Hot” plate.

10. Pull power cord out from power cord holder in back of coffeemaker and plug into standard electrical outlet.

11. Brew water through appliance following the “Brewing Coffee” instructions without adding coffee grounds. This removes any dust or residue that may have remained in the coffeemaker during the manufacturing process.

12. When brewing is complete, discard the water from the carafe and paper filter from filter basket.

13. Turn off the coffeemaker; unplug it and allow it to cool down.

ADJUSTING THE POWER CORD LENGTH

• You can adjust the length of the power cord to suit your needs.

• To increase the length of the power cord, simply grasp the cord (not the plug)

in the rear of the coffeemaker and gently pull down and out of the slot away from the coffeemaker.

• To decrease the length of the power cord, simply feed any excess cord into the

slot in the rear of the coffeemaker.

• Lift the cord and lock it into the slot when cord is at desired length.

• Do not reuse coffee grounds; the best flavors are extracted during the first brewing.

• If carafe filled with coffee is left on the “Keep Hot” plate, be sure to remove the coffee grounds from the filter basket as soon as they have cooled slightly. This will keep the coffee from developing a bitter taste.

• For a special occasion, whip some heavy cream with 1 or 2 tablespoons of hazel nut, chocolate or almond liqueur. Use to top off each cup of coffee.

• Add a 2-inch piece of vanilla bean to the sugar bowl. You’ll be surprised at how good it tastes.

• Keep your coffeemaker very clean; you’ll be pleased with the flavor.

• For iced coffee, brew the coffee with twice the normal amount of grounds. The ice dilutes the coffee flavor.

• Make coffee ice cubes from left over coffee and brew your coffee at its normal strength.

• Remember when pouring hot liquid into a glass, always put a spoon in the glass before adding the hot liquid. This will prevent glass from breaking.

Care and Cleaning

This product contains no user serviceable parts. Refer service to qualified service personnel.

Cleaning

1. To clean your coffeemaker, be sure the unit is off and cooled. Open the cover, remove the brew basket, and discard the paper filter/grounds. Clean as follows: brew basket, carafe and carafe lid are all top rack dishwasher-safe; or they maybe hand washed in warm, sudsy water. See below for carafe care. The coffeemaker’s exterior, control panel area and “Keep Hot” plate may be cleaned with a soft damp cloth. Do not use abrasive cleansers or scouring pads. Never immerse the coffeemaker in water.

2. To clean inside the reservoir cover, open the one-piece cover allowing it to rest in the open position. Pull showerhead, clean showerhead with a damp cloth, then place water spreader under guide and close the cover.

Caring for Your Carafe

A damaged carafe may result in possible burns from a hot liquid. To avoid breaking:

• Do not allow all liquid to evaporate from the carafe while it is stationed on the “Keep Hot” plate, or heat the carafe when it is empty.

• Discard the carafe if it is chipped, cracked, or damaged in any manner.

• Never use abrasive scouring pads or cleansers, they will scratch and weaken the glass.

• Do not place the carafe on or near a gas or electric burner, in a heated oven, or in a microwave oven.

• Avoid rough handling and sharp blows.

10. Press ON/OFF button; power light is illuminated..

Brewing begins OR to delay brewing set the auto function. (See below for Delayed Brewing.) (K).

11. When coffee stops flowing into carafe the brew cycle is complete.

12. Once coffee grounds have cooled, carefully open reservoir/brew basket cover and lift the filter basket by

its handle, remove and discard used grounds and paper filter. Close open reservoir/brew basket cover.

13. The coffeemaker will keep brewed coffee hot for 2 hours and then turn off automatically.

14. To turn off the coffeemaker, press the ON/OFF button.

15. Unplug appliance when not in use.

SNEAK-A-CUP® INTERRUPT FEATURE

The Sneak-A-Cup® feature allows you to pour a cup of coffee from the carafe while the coffee is brewing. When the carafe is removed, the brewing process is paused. Simply replace the carafe on the “Keep Hot” plate within 30 seconds and brewing will resume automatically.

Note: If the carafe is not replaced within 30 seconds the brew basket may overflow.

DELAYED BREWING:

1. Follow steps 1 through 9 under Brewing Coffee.

2. Make sure clock has been set to correct time of day.

3. Press the PROG button; the AUTO light blinks.

4. To select the time for delayed brewing: Press HOUR button until the correct

hour appears on the display. Repeat with the MIN button within 5 seconds. (If minute setting is not changed within 5 seconds the clock will revert to default time and selection of hour and minute will have to be repeated.)

5. Press the PROGRAM button again. The delayed brewing time is set.

6. Press the AUTO button to activate the delayed brewing. The AUTO button light

is displayed on the digital display screen.

7. To check the preset auto time, press PROG button and it will display the time

selected for delayed brewing to begin. (The AUTO light will blink until the AUTO button is pressed.)

8. To cancel the AUTO brew, press the ON/OFF button twice. All lights are off.

COFFEE BREWING TIPS

• Stir coffee in carafe before serving to evenly distribute the flavor.

• Coffee that is poured during brewing cycle may vary in strength from the

finished brew.

• Not sure how much coffee to use. Begin by using 1 level scoop of medium

grind coffee for each cup of coffee to be brewed.

• Never reuse coffee filters; they absorb flavors from the brewed coffee and will

give the newly brewed coffee a stale flavor. They may also tear and allow grinds to drip into the freshly brewed coffee.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE SOLUTION

Coffeemaker does not turn on.

Coffeemaker is leaking.

Brewing takes too long.

Coffee is not brewing.

The coffee maker brews clear water.

The one-piece cover does not close.

Filter basket overows.

Grounds in the brewed coffee.

Coffeemaker is brewing slowly; brewed coffee tastes bad.

Coffeemaker is not plugged in.

Water reservoir may be overlled.

Carafe may not be correctly placed on “Keep Hot” plate.

The coffeemaker might need cleaning.

Water reservoir might be empty.

There may be no coffee grounds in the removable lter basket.

Removable lter basket may not be correctly placed.

Carafe may be improperly placed on the “Keep Hot” plate.

The lter and/or the brew basket are not properly placed.

Coffeemaker needs cleaning; wrong grind being used.

Check to be sure appliance is plugged into a working outlet and the ON/OFF button has been pressed.

Make sure the water reservoir has not been lled beyond the MAX ll line. Make sure carafe is placed correctly on “Keep Hot” plate and is centered under the brew basket.

Follow procedure under “Maintaining Your Coffeemaker.”

Make sure water reservoir has sufcient water to brew desired number of cups of coffee.

Add sufcient amount of coffee grounds to paper lined removable lter basket.

Remove lter basket and replace correctly into brew basket.

Remove carafe and insert so that carafe rests comfortably within the grooves on the “Keep Hot” plate.

Insert paper liner into lter basket and insert basket properly into brew basket.

Follow directions in CARE AND CLEANING. Use only coffee ground for automatic drip coffeemakers.

MINERAL DEPOSITS AND CLOGGING

Mineral deposits left by hard water can clog your coffeemaker. Excessive steaming and/or a prolonged brewing cycle are signs that a cleaning is needed. The frequency of cleaning out deposits is affected by the regularity of usage and water hardness. During cleaning, more steaming occurs than when brewing coffee and may emit spurts of steam. Cleaning is recommended every 60 brewing cycles.

1. Pour white vinegar into water reservoir up to 7-cup line on the water level window. Add water up to 12-cup line.

Caution: Be careful not to exceed the 12-cup maximum level, to avoid water running out the overflow hole in the back of the coffeemaker.

2. Put a paper filter in the brew basket and close the one-piece water reservoir and brew basket cover. Set empty carafe on the "Keep Hot" carafe plate.

3. Turn on coffeemaker and let half the cleaning solution brew into carafe (till water level goes down to around the 6-cup line on the water level window). Turn coffeemaker off and let it soak for at least 15 minutes to soften the deposits.

4. Turn on coffeemaker and brew remaining cleaning solution into carafe.

5. Turn off coffeemaker, empty carafe and discard filter.

6. Fill reservoir with fresh water to 12-cup line, replace empty carafe on the “Keep Hot” carafe plate and then turn on coffeemaker for a complete brew cycle to flush out remaining cleaning solution. You may wish to repeat this step again to eliminate any remaining vinegar smell/taste.

7. Wash the brew basket and carafe as instructed for normal cleaning.

+ 13 hidden pages
