Black & Decker DCM2075, DCM2000B, DCM2000, DCM2050 User Manual
PLEASE READ AND SAVE THIS USE AND CARE BOOK.
POR FAVOR LEA ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
VEUILLEZ LIRE ET CONSERVER CE GUIDE D’ENTRETIEN ET D’UTILISATION.
IMPORTANT / IMPORTANTE /
IMPORTANT
WASH CARAFE BEFORE FIRST USE!
LAVE LA JARRA ANTES
DEL PRIMER USO
LAVER LA CARAFE AVANT
LA PREMIÈRE UTILISATION!
Série/Serie DCM2000 Series
Accessories/Parts (USA/Canada)
Accesorios/Partes (EE.UU/Canadá)
Accessoires/Pièces (É.-U./Canada)
1-800-738-0245
USA/Canada 1-800-231-9786
Mexico 01-800-714-2503
www.blackanddecker.com
SmartBrew
®
12-Cup Coffeemaker
Cafetera de 12 tazas
Cafetière de 12 tasses
DCM2000.Pub175560RV10 4/28/05 8:36 AM Page 1
2
1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and/or injury to
persons, including the following:
❑
Read all instructions.
❑
Do not touch hot surfaces. Use handle or knobs.
❑
To protect against electric shock, do not place cord, plug or appliance in
water or other liquids.
❑
Close supervision is necessary when any appliance is used by or near
children.
❑
Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts and before cleaning the appliance.
❑
Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return the
appliance to the nearest authorized service facility for examination,
repair, or adjustment. Or, call the appropriate toll-free number on the
cover of this manual.
❑
The use of an accessory not evaluated for use with this appliance may
cause injury.
❑
Do not use outdoors.
❑
Do not let cord hang over the edge of table or counter, or touch hot
surfaces.
❑
Do not place on or near a hot gas or electric burner or in a heated oven.
❑
Keep the lid on the carafe when in use.
❑
The carafe is designed for use with the appliance. It must never be used
on a range top.
❑
Do not set a hot carafe down on a wet or cold surface.
❑
Do not use the carafe if the glass is cracked or has a loose or weakened
handle.
❑
Do not clean the carafe with abrasive cleansers, steel wool, or other
abrasive material.
❑
Do not use appliance for other than its intended use.
SAVE THESE INSTRUCTIONS.
POLARIZED PLUG (120V Models Only)
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way.
If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning : This appliance is equipped with a tamper-resistant screw to prevent
removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt
to remove the outer cover. There are no user-serviceable parts inside. Repair should
be done only
by authorized service personnel.
ELECTRICAL CORD
a) A short power-supply cord (or detachable power-supply cord) is to be provided
to reduce the risk resulting from becoming entangled in or tripping over
a longer cord.
b) Longer detachable power-supply cords or extension cords are available and
may be used if care is exercised in their use.
c) If a long detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the detachable power-supply cord or extension
cord should be at least as great as the electrical rating of the appliance,
2) If the appliance is of the grounded type, the extension cord should be
a grounding-type 3-wire cord, and
3) The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or tripped over.
NOTE: If the power supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in order
to avoid a hazard.
DCM2000.Pub175560RV10 4/28/05 8:36 AM Page 2
4
How to Use
This appliance is intended for household use only.
GETTING STARTED
1. Remove all stickers, packing material, and literature.
Important: For warranty verification, please do not remove line cord sticker.
2. Wash all parts as instructed in the Care and Cleaning section.
3. Pour cold water up to 11-cup level mark in the water reservoir. Brew it through as
instructed in "BREWING", but do not add coffee grounds to the paper filter. When done,
turn off the coffeemaker and discard the water from the carafe.
BREWING
1. Lift the one-piece cover. Use the carafe to fill water reservoir with cold water.
2. Place a paper filter or the permanent gold-tone filter into the brew basket. Add ground
coffee, (we recommend one heaping tablespoon for every 2 cups). Close the cover.
3. Place carafe on the "Keep Hot" plate and plug in the unit.
4. Press "ON" or "ON/OFF" (depending on your model) and the indicator light comes on, or,
for delayed brewing (Clock Models), see "SETTING THE CLOCK/TIMER & AUTO-BREW."
You don’t have to set the clock if you want to brew coffee right away.
5. In the DCM2700 series, when brewing is done, you will hear a series of beeps.
6. Replace the carafe on the “Keep Hot” plate when not serving to keep coffee hot.
7. Press “OFF” or “ON/OFF” (depending on your model) to turn the unit off.
In the DCM2500 series, the coffeemaker will keep coffee warm for 2 hours before it
automatically shuts off.
8. In the DCM2700 series, you may adjust your auto-off time by pressing the auto off button
and holding it to select 1 hr., 2 hr., 3 hr. or 4 hr. for auto-off time. You will hear a long
beep just before the unit automatically shuts off. If you do not select a time, the unit will
automatically shut off in 2 hours.
Sneak-A-Cup
®
Interrupt Feature
You can pour a cup of coffee while coffee is brewing without leaking from the brew basket.
When finished pouring coffee, place the carafe under brew basket. The brewing process
continues.
Important: To avoid possible overflow after removing the carafe, be sure to replace the carafe
under the brew basket within one minute or less.
1. To set current time of day: Press the HOUR button, little dot in the top left corner of the
display indicates "p.m." time. Press the MIN button. Once set, clock continues to keep
time unless coffeemaker is unplugged or a power failure occurs.
2. To set the Auto On time: Press the PROGRAM button and the light near the AUTO ON
button will start flashing indicating it is being programmed. Press the Hour, then Min
buttons to set the time you’d like coffee to automatically begin brewing (for example
7:15 a.m.). Press the HOUR and MIN buttons to 7:15 a.m. Make sure the PM indicator
light is not lit. When finished, press the AUTO ON button. The AUTO ON light will stop
flashing and will stay on to show the timer is activated.
3. Prepare the coffeemaker for brewing as instructed in BREWING but don’t turn the unit on.
4. To check your pre-set auto time, press program and it will display. When the clock returns
to the current time of day, press AUTO ON to reactivate the timer. To automatically brew
coffee again at the same pre-set auto-on time, prepare your coffeemaker for brewing again
and press the AUTO ON button.
Note: The AUTO ON function can be canceled at any time by pressing the AUTO ON
button a second time. The AUTO ON light will go out.
Adjustable Keep Warm/Temperature (DCM2700 series)
To adjust the holding temperature of your brewed coffee, press the KEEP WARM button until
3
Product may vary slightly from what is illustrated.
1. One-piece cover
2. Water spreader
3. Water reservoir
4. Water windows (on both sides)
with cup level markings
5. Cord storage (inside of unit)
6. Control panel (See Series Illus.)
7. "Keep Hot" plate
8. Brewed-coffee markings (not shown)
†9.12-cup/60 oz. (1800 ml) Carafe
(Part # DCM2000-02 (w))
(Part # DCM2000B-02(b))
†10. Hinged carafe lid
(Part # DCM2000-03 (w))
(Part # DCM2000B-03 (b))
†11. Removable brew basket
(Part # 175555-00)
†12. Permanent gold-tone filter
(Certain Models)
(Part # DCM2000-04)
†13. Water filter basket with charcoal filter
(Certain Models)
(Part #DCM2000-05)
† Consumer replaceable
CONTROL PANELS
DCM2000 DCM2500 DCM2700
DCM2000.Pub175560RV10 4/28/05 8:36 AM Page 4
12
10
8
6
4
2
6
5
you reach your desired selection which ranges from 1 (warm heat) to 7 (very hot). If you do
not adjust the temperature, the coffeemaker will remain at setting 4 (hot).
Water Filter (Certain models)
1. Some models include a water filter to reduce chlorine or impurities in your water. It is
recommended to change the charcoal filter approximately once a month, depending on
the hardness of the water in your area and your use.
2. Lift the cover and pull the water filter basket out by its handle (A).
Press the tab on the water filter basket, remove the old filter (B),
replace it with a new filter, and snap the water filter basket closed.
3. Press the water filter basket back into the well at the bottom of the
reservoir.
Care and Cleaning
CLEANING
1. To clean your coffeemaker, be sure the unit is off and cooled. Open
the cover, remove the brew basket, and discard the paper filter/
grounds. Clean as follows: brew basket, permanent gold-tone filter
(certain models), carafe, carafe lid, and the water filter basket (certain
models) are all top rack dishwasher-safe; or they may be hand
washed in warm, sudsy water. See below for carafe care. The
coffeemaker’s exterior, control panel area and “Keep Hot” plate may
be cleaned with a soft damp cloth. Do not use abrasive cleansers or
scouring pads. Never immerse the coffeemaker in water.
2. To clean inside of reservoir cover, open the one-piece cover allowing
it to rest in the open position. Pull water spreader out from under the
guide, wipe surfaces with a damp cloth, then place water spreader
under guide and close the cover (C).
Caring For Your Carafe
A damaged carafe may result in possible burns from a hot liquid. To avoid breaking:
• Do not allow all liquid to evaporate from the carafe while on the “Keep Hot” plate or heat
the carafe when empty.
• Discard the carafe if chipped, cracked, or damaged in any manner.
• Never use abrasive scouring pads or cleansers, they will scratch and weaken the glass.
• Do not place the carafe on or near a gas or electric burner, in a heated oven, or in a
microwave oven.
•Avoid rough handling and sharp blows.
Mineral Deposits and Clogging
Mineral deposits left by hard water can clog your coffeemaker. Cleaning is recommended
every 3 months.
1. Pour white vinegar into the water reservoir up to the 6-cup level on the water window.
Add cold water up to the 10-cup line.
2. Put a paper filter in the brew basket or permanent gold-tone filter (certain models) and
close the cover. Set the empty carafe on the “Keep Hot” plate.
3. Turn on the coffeemaker and let half the cleaning solution brew into the carafe (till water
level goes down to around “5”). Turn off the coffeemaker and let it soak for at least
15 minutes to soften the deposits.
4. Turn on the coffeemaker and brew the remaining cleaning solution into the carafe.
5. Turn off the coffeemaker; empty the carafe and discard the soiled filter.
6. Fill the reservoir with cold water to the 11-cup line, replace the empty carafe, then turn
on the coffeemaker for a complete brew cycle to flush out the remaining cleaning
solution. You may have to repeat this to eliminate the vinegar smell/taste.
7. Wash the brew basket and carafe as instructed in “Cleaning.”
A
C
B
Cuando se utilizan aparatos eléctricos, siempre se debe respetar ciertas
medidas de seguridad a fin de reducir el riesgo de un incendio, un choque
eléctrico y (o) lesiones a las personas, incluyendo las siguientes:
❑
Por favor lea todas las instrucciones.
❑
No toque las superficies calientes. Utilice las asas o las perillas.
❑
A fin de protegerse contra el riesgo de un choque eléctrico, no coloque
el aparato de manera que el cable, el enchufe o el mismo aparato entre
en contacto con agua o cualquier otro líquido.
❑
Todo aparato eléctrico utilizado en la presencia de menores de edad
o por ellos mismos requiere la supervisión de un adulto.
❑
Desconecte el aparato de la toma de corriente cuando no esté en
funcionamiento y antes de limpiarlo. Espere que el aparato se enfríe
antes de de instalar o retirar las piezas y antes de limpiarlo.
❑
No se debe utilizar ningún aparato eléctrico que tenga el cable o el
enchufe averiado, que presente un problema de funcionamiento o que
esté dañado. Devuelva el aparato al centro de servicio autorizado más
cercano para que lo examinen, reparen o ajusten. También puede llamar
gratis al número apropiado que aparece en la cubierta de este manual.
❑
El uso de un accesorio no evaluado para ser utilizado con este aparato
podría ocasionar lesiones personales.
❑
Este aparato no se debe utilizar a la intemperie.
❑
No permita que el cable cuelgue del borde de la mesa o del mostrador
ni que entre en contacto con las superficies calientes.
❑
No coloque el aparato sobre ni cerca de las hornillas de gas o eléctricas
ni adentro de un horno caliente.
❑
La jarra debe permanecer tapada cuando está en uso.
❑
La jarra está diseñada para ser utilizada con este aparato. Jamás se
deberá utilizar sobre la estufa.
❑
Nunca coloque una jarra caliente sobre una superficie fría ni húmeda.
❑
No utilice la jarra si el vidrio se encuentra rajado o si el asa está débil.
❑
No limpie la jarra con limpiadores abrasivos, con almohadillas de fibra
de metal ni demás limpiadores abrasivos.
❑
El aparato se deberá utilizar únicamente con el fin previsto.
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD
GUARDE ESTAS INSTRUCCIONES.
DCM2000.Pub175560RV10 4/28/05 8:36 AM Page 6
12
Loading...
