BLACK & DECKER DCM100 User Manual

Please Read and Save this Use and Care Book Veuillez lire et conserver ce guide d’entretien et d’utilisation

Models Modèles

❑

DCM100BC

❑

DCM100WC

12-Cup Programmable Coffeemaker

Cafetière programmable de 12 tasses

USA/Canada 1-800-231-9786

www.applicaconsumerproductsinc.com

IMPORTANT /IMPORTANT

WASH CARAFE BEFORE FIRST USE!

LAVER LA CARAFE AVANT

LA PREMIÈRE UTILISATION!

Accessories/Parts (USA/Canada) Accessoires/Pièces (É.-U./Canada) 1-800-738-0245

for a chance to WIN $100,000!

For US residents only

Inscrivez votre produit en ligne à l'adresse www.prodprotect.com/applica

et courez la chance de GAGNER 100 000 $!

Aux résidents du É.-U seulement

* Filters not included. * Filtres non compris.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock and/or injury to persons, including the following:

❑

Read all instructions.

❑

Do not touch hot surfaces. Use handles or knobs.

❑

To protect against fire, electric shock and injury to persons do not immerse cord, plugs or appliance in water or other liquid.

❑

Close supervision is necessary when any appliance is used by or near children.

❑

Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.

❑

Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or adjustment. Or, call the appropriate toll-free number on the cover of this manual.

❑

The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock or injury to persons.

❑

Do not use outdoors.

❑

Do not let cord hang over edge of table or counter, or touch hot surfaces.

❑

Do not place on or near a hot gas or electric burner, or in a heated oven.

❑

To disconnect, turn any control to OFF, then remove plug from wall outlet.

❑

Do not use this appliance for other than intended use.

❑

Keep lid on the carafe when in use.

❑

Scalding may occur if the lid is removed during the brewing cycles.

POLARIZED PLUG (120V Models Only)

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW Warning: This appliance is equipped with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside.

Repair should be done only by authorized service personnel.

ELECTRICAL CORD

a) A short power-supply cord (or detachable power-supply cord) is to be provided

to reduce the risk resulting from becoming entangled in or tripping over a longer cord.

b) Longer detachable power-supply cords or extension cords are available and

may be used if care is exercised in their use.

c) If a long detachable power-supply cord or extension cord is used,

1) The marked electrical rating of the detachable power-supply cord or extension cord should be at least as great as the electrical rating of the appliance,

2) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord, and

3) The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.

Note: If the power supply cord is damaged, it should be replaced by qualified personnel or in Latin America by an authorized service center.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

Product may vary slightly from what is illustrated.

1. One-piece water reservoir and brew basket cover

2. Water showerhead

3. Guide

4. Water reservoir

5. Water level window

6. Control panel

7. “Keep Hot” carafe plate †8. 12-cup/60 oz. (1774 ml) carafe with brew-thru lid

(Part # DCM100B-01 (black), DCM100W-01 (white)) †9. Removable filter basket (Part # DCM100B-02 (black & white)) †Consumer replaceable/removable parts

How to Use

This product is for household use only.

GETTING STARTED

• Remove all packing material, and any stickers from the product.

• Remove and save literature.

• Wash all removable parts as instructed in CARE AND CLEANING section of this manual.

• Open water reservoir/brew basket cover and pour fresh cold water up to 12-cup level mark into the water reservoir (B).

• Place empty 8-12 cup basket style paper filter into removable filter basket.

• Place basket into brew basket with the handle to the

right (C).

• Close water reservoir/brew basket cover.

• Place lid on carafe.

• Place empty carafe on the “Keep Hot” carafe plate.

• Pull power cord out from power cord holder in back of coffeemaker and plug into standard electrical outlet.

• Brew water through appliance following the BREWING COFFEE instructions, without adding coffee grounds. This removes any dust or residue that may remain in the system during the manufacturing process.

• Discard the water from the carafe and paper filter from filter basket.

• Turn off the appliance, unplug and allow it to cool down.

ADJUSTING THE POWER CORD LENGTH

You can adjust the length of the power cord to suit your needs. To increase the length of the power cord, simply grasp the cord (not the plug) at

the rear of the coffeemaker and gently pull down and out of the slot, away from the coffeemaker.

To decrease the length of the power cord, simply feed any excess cord into the slot at the rear of the coffeemaker.

Lift the cord and lock it into the slot when cord is at desired length.

SETTING THE CLOCK

1. Plug appliance into standard electrical outlet.

2. The digital clock display flashes 12:00 (D). Note: You must set the clock in order to use the delayed

brewing feature.



















12:00

3. To change the time: Press HOUR (HR) button until the

correct time appears (E).

Note: When the time passes noon, a small light appears in the top left corner of the digital display under the P.M. to let you know you are in P.M. time. If the P.M. indicator is not lit, the time is set to A.M.

4. Repeat with the MIN button (F). (If minute setting is

not changed within 5 seconds, the clock will revert to default time and selection of hour and minute must be repeated.)

Tip: Hold each button down to make the hours and minutes change rapidly after a short delay. To change the time in 1 minute increments, press and release the button.

Note: If the unit is unplugged or power is interrupted even momentarily, the time may need to be reset.

BREWING COFFEE

It is not necessary to set the clock to brew coffee unless you wish to use delayed brewing.

1. Open water reservoir/brew basket cover.

2. Fill water reservoir with desired amount of cold tap water using water markings on side of reservoir. Do not exceed the 12-cup maximum level (G).

Caution: Be careful not to exceed the 12-cup maximum level, to avoid water running out the overflow hole in the back of the coffeemaker.

3. Place an 8-12 cup basket style paper filter into the

removable filter basket, making sure filter is centered in filter basket.

4. Add desired amount of ground coffee.

5. Insert filter basket into brew basket following directions in GETTING STARTED.

6. Close brew basket/ water reservoir cover.

7. Place brew-thru lid on empty carafe. Note: Coffee may overflow if brew-thru lid is not properly aligned.

8. Place empty carafe on the “Keep Hot” carafe plate.

9. Plug cord into standard electrical outlet.

10. Press I/O button (H); power light is illuminated.

Brewing begins OR, to delay brewing, you may set the auto function (see for DELAYED BREWING).

11. When coffee stops flowing into carafe, the brew cycle

is complete.

12. Once coffee grounds have cooled carefully open reservoir/brew basket cover and using filter basket handle, remove and discard used grounds and paper filter. Close reservoir/brew basket cover.

13. The coffeemaker will keep brewed coffee hot for 2 hours and then automatically turn off.

14. To turn off the coffeemaker press the I/O button.

15. Unplug appliance when not in use.

SNEAK-A-CUP® INTERRUPT FEATURE

The Sneak-A-Cup® interrupt feature allows you to pour a cup of coffee from the carafe while the coffee is still brewing. When the carafe is removed, the brewing process is paused. Simply replace the carafe on the carafe plate within 30 seconds and brewing will resume.

Note: If the carafe is not replaced within 30 seconds the brew basket may overflow.

DELAYED BREWING

1. Follow steps 1 through 9 under BREWING COFFEE.

2. Make sure clock has been set to correct time of day (see SETTING THE

CLOCK).

3. Press the PROG button; the AUTO light blinks.

4. To select the time for delayed brewing: Press HOUR (HR) button until the

correct time appears on the display. Repeat with the MIN button within 5 seconds. (If minute setting is not changed within 5 seconds, the clock will revert to default time and selection of hour and minute must be repeated.)

5. Press the PROG button again. The delayed brewing time is set.

6. Press the AUTO button to activate the delayed brewing. The AUTO light is

displayed on the digital display screen.

7. To check the preset auto time, press PROG button and it will display the time

selected for delay brewing to begin. (The AUTO light will blink until the AUTO button is pressed.)

8. To cancel the AUTO brew, press the I/O button twice. All lights will turn off.

COFFEE BREWING TIPS

• Stir coffee in carafe before serving to evenly distribute the flavor.

• Coffee that is poured during brewing cycle may vary in strength from the

finished brew.

• Not sure how much coffee to use? Begin by using 1 level scoop of medium

grind coffee for each cup of coffee to be brewed.

• Never reuse coffee filters; they absorb flavors from the brewed coffee and will

give the newly brewed coffee a stale flavor. They may also tear and allow grinds to drip into the newly brewed coffee.

• Open coffee grounds are best stored in the refrigerator in a tightly sealed

container. Once opened, coffee should be used within 1 month.

• If filled carafe is left on the hot plate, be sure to remove the coffee grounds from
