Black & Decker Cv1205t Instruction Manual

www.blackanddecker.co.uk

5

1

2

3

4

6

UK

Ireland

Australia

New Zealand

1

5

7

8

A

6

C

10

B

9

D

2

E

1

4 11

F

2

3

11

12

G

I

17

14

H

15

16

13

J

19

K

18

L

3

Intended use

Your Black & Decker Dustbuster® hand
held vacuum cleaner has been designed
for light dry vacuum cleaning purposes.
This product is intended for household
use only.

Safety instructions

◆ Warning! When using battery-

powered appliances, basic safety
precautions, including the following,
should always be followed to reduce
the risk of fire, leaking batteries,
personal injury and material damage.

◆ Read this manual carefully before

using the appliance.

◆ The intended use is described in this

manual. The use of any accessory or
attachment or the performance of
any operation with this appliance
other than those recommended in
this instruction manual may present
a risk of personal injury.

◆ Retain this manual for future

reference.

Using your appliance

◆ Do not use the appliance to pick up

liquids or any materials that could
catch fire.

◆ Do not use the appliance near water.

Do not immerse the appliance in
water.

◆ Never pull the charger lead to

disconnect the charger from the
socket. Keep the charger lead away
from heat, oil and sharp edges.

◆ Do not use the appliance if any part

is damaged or defective.

◆ Have any damaged or defective parts

repaired or replaced by an
authorised repair agent.

◆ Regularly check the charger lead for

damage. Replace the charger if the
lead is damaged or defective.

◆ Never attempt to remove or replace

any parts other than those specified
in this manual.

Battery and charger

◆ Never attempt to open the battery.

◆ Do not expose the battery to water.

◆ Do not incinerate the battery.

◆ Do not expose the charger to water.

◆ Do not open the charger.

Electrical safety

Your charger has been designed for a
specific voltage. Always check that the
mains voltage corresponds to the voltage
on the rating plate. Never attempt to
replace the charger unit with a regular
mains plug.

Symbols on the charger

Your charger is double
insulated; therefore no earth
wire is required.

Fail safe isolating transformer.
The mains supply is electrically
separated from the transformer
output.

After use

◆ Unplug the charger before cleaning

the charger or charging base.

◆ When not in use, the appliance

should be stored in a dry place.
Children should not have access to
stored appliances.

Inspection and repairs

◆ Before use, check the appliance for

damaged or defective parts. Check
for breakage of parts, damage to
switches and any other conditions
that may affect its operation.

4

The charger automatically
shuts off if the ambient
temperature becomes too high.
As soon as the ambient
temperature has decreased, the
charger will resume operating.

The charger is intended for
indoor use only.

Features

1. On/off switch

2. Release button

3. Dust bowl

4. Filter cleaning wheel

5. Charging indicator

6. Brush head

Fig. A

7. Crevice tool

8. Brush tool

Installation

Fitting the charging base to the wall
(fig. B)

The charging base can be placed on a
worktop or fitted to the wall to provide a
convenient storage and charging point for
the appliance.

Assembly

◆ Place the appliance on the charging

base as shown.

◆ Plug in the charger. Switch on at the

mains.
The charging indicator (5) will be lit.

◆ Leave the appliance to charge for at

least 16 hours.
Whilst charging, the charger may become
warm. This is normal and does not
indicate a problem. The appliance can be
left connected to the charger indefinitely.
The charging indicator will be lit as long
as the appliance is connected to the
plugged-in charger.

Warning! Do not charge the battery at
ambient temperatures below 4 °C or
above 40 °C.

Fitting the brush head (fig. C)

The brush head (6) allows for vacuuming
on cut pile carpeting. The brush is
particularly useful for picking up hair,
threads, etc.

◆ Insert the brush into the front of the

appliance.

◆ Insert the jack plug (9) into the

connector (10) as shown.

Fitting the accessories (fig. A & D)

These models are supplied with the
following accessories:

– a crevice tool (7) for confined spaces
– a brush tool (8) for furniture and stairs

To fit an accessory, proceed as follows:

◆ Take the accessories from the

appliance.

◆ Insert the appropriate accessory into

the front of the appliance.

Use

◆ Before first use, the battery must be

charged for at least 16 hours.

◆ Place the appliance on the charging

base whenever it is not in use.

Charging the battery (fig. B)

◆ Make sure that the appliance is

switched off. The battery will not be
charged with the on/off switch in the
on position.

Switching on and off (fig. E)

◆ To switch the appliance on, slide the

on/off switch (1) forward.

◆ To switch the appliance off, slide the

on/off switch back.

Optimising the suction force (fig. F)

In order to keep the suction force
optimised, the filter must be cleared
regularly during use.

◆ Rotate the wheel (4) a few turns to

shake out dust clogging the filter

(11).

Cleaning and maintenance

Warning! Regularly clean the filters.

Clearing the brush head

◆ Remove any hair or threads collected

onto the brush . Use a pair of

scissors if necessary.

Cleaning the dust bowl and filters
(fig. G & H)

The filters are re-usable and should be
cleaned regularly.

◆ Press the release button (2) and

remove the dust bowl (3).

◆ Empty the dust bowl.

◆ Remove the filters (11 & 12) by

twisting them clockwise.

◆ Brush any loose dust off the filters.

5

◆ Wash the filters in warm, soapy

water. The bowl can also be washed
if necessary. Do not immerse the
appliance in water.

◆ Make sure the dust bowl and filters

are dry.

◆ Refit the filters (11 & 12) onto the

appliance, twisting them
counterclockwise until they lock into
place.

◆ Refit the dust bowl onto the

appliance. Make sure the dust bowl
clicks into place.

Warning! Never use the appliance
without the filters. Optimum dust
collection will only be achieved with
clean filters and an empty dust bowl.

Cleaning the exhaust filter (fig. I)

◆ Open the lid (13).

◆ Remove the filter (14) from the

recess.

◆ Wash the filter in warm, soapy

water.

◆ Make sure the filter is dry.

◆ Refit the filter (14).

◆ Close the lid.

Replacing the filters

The filters should be replaced every 6 to
9 months and whenever worn or
damaged. Replacement filters are
available from your Black & Decker
dealer (cat. no. VF40).

◆ Remove the old filters as described

above.

◆ Fit the new filters as described

above.

Protecting the environment

Separate collection of used
products and packaging allows
materials to be recycled and
used again. Re-use of recycled
materials helps prevent
environmental pollution and
reduces the demand for raw
materials.

Local regulations may provide for
separate collection of electrical products
from the household, at municipal waste
sites or by the retailer when you
purchase a new product.

Black & Decker provides a facility for the
collection and recycling of Black &
Decker products once they have reached
the end of their working life. To take
advantage of this service please return
your product to any authorised repair
agent who will collect them on our
behalf.

You can check the location of your
nearest authorised repair agent by
contacting your local Black & Decker
office at the address indicated in this
manual. Alternatively, a list of authorised
Black & Decker repair agents and full
details of our after-sales service and
contacts are available on the Internet at:

www.2helpU.com

Battery (fig. J - L)

When disposing of the product,
the battery must be removed as
described below and disposed
of in accordance with local
regulations.

Separate collection. This product
must not be disposed of with
normal household waste.

Should you find one day that your
Black & Decker product needs
replacement, or if it is of no further use
to you, do not dispose of it with
household waste. Make this product
available for separate collection.

6

◆ Preferably discharge the battery by

operating the appliance until the

motor stops.
The battery is located under the back end
of the appliance.

◆ Take the accessories from the

appliance.

◆ Remove the screws (15).

◆ Unlock the tabs (16) holding the

accessory holder in place.

◆ Remove the accessory holder (17).

◆ Remove the screws (18) holding the

battery in place.

◆ Slide the battery (19) backward as

shown.

◆ Remove the battery.

◆ Place the battery in a suitable

packaging to ensure that the
terminals cannot be short-circuited.

◆ Take the battery to your service

agent or a local recycling station.

Warning! Once removed, the battery
cannot be refitted.

Technical data

CV7205T CV9605T

Voltage V 7.2 9.6
Weight kg 1.1 1.3

CV1205T

Voltage V 12
Weight kg 1.7

Charger

Input voltage V
Approx. charging time h 16

230

AC

EC declaration of conformity

CV7205T/CV9605T/CV1205T

Black & Decker declares that these

products conform to:

89/336/EEC, 73/23/EEC, EN 55014,

EN 60335, EN 61000

Level of sound pressure, measured

according to EN 60704-1: < 70 dB(A)

The guarantee is valid within the
territories of the Member States of the
European Union and the European Free
Trade Area.

If a Black & Decker product becomes
defective due to faulty materials,
workmanship or lack of conformity,
within 24 months from the date of
purchase, Black & Decker guarantees to
replace defective parts, repair products
subjected to fair wear and tear or replace
such products to ensure minimum
inconvenience to the customer unless:

◆ The product has been used for trade,

professional or hire purposes;

◆ The product has been subjected to

misuse or neglect;

◆ The product has sustained damage

through foreign objects, substances

or accidents;

◆ Repairs have been attempted by

persons other than authorised repair

agents or Black & Decker service

staff.

To claim on the guarantee, you will need
to submit proof of purchase to the seller
or an authorised repair agent. You can
check the location of your nearest
authorised repair agent by contacting
your local Black & Decker office at the
address indicated in this manual.
Alternatively, a list of authorised
Black & Decker repair agents and full
details of our after-sales service and
contacts are available on the Internet at:

www.2helpU.com

Director of Consumer Engineering

Kevin Hewitt

Spennymoor, County Durham DL16 6JG,

United Kingdom

1-6-2006

Guarantee

Black & Decker is confident of the quality
of its products and offers an outstanding
guarantee. This guarantee statement is
in addition to and in no way prejudices
your statutory rights.

Please visit our website
www.blackanddecker.co.uk to
register your new Black & Decker product
and to be kept up to date on new
products and special offers. Further
information on the Black & Decker brand
and our range of products is available at

www.blackanddecker.co.uk

7

Australia

Black & Decker (Australia) Pty. Ltd. Tel. [phone]
20 Fletcher Road, Mooroolbark,
Victoria, 3138 Fax [phone]

New Zealand

Black & Decker Tel. [phone]
81 Hugo Johnston Drive Fax [phone]
Penrose, Auckland, New Zealand

United Kingdom

Black & Decker Tel. [phone]
210 Bath Road Fax [phone]
Slough, Berkshire SL1 3YD Helpline 01753 574277

90504919 06/06

8
