Black & Decker CM5000BCKT User Manual

MILL & BREW™

12-CUP PROGRAMMABLE COFFEE MAKER

CAFETIÈRE PROGRAMMABLE DE 12 TASSES

use & care manual

guide d’utilisation et d’entretien

CM5000BCKT

CONTENTS

Important Safeguards

Getting to know your Mill & Brew™ Coffee Maker

Mill & Brew™ Coffee Maker Product Benefits

Getting to know your Control Panel

Before Brewing

Programming your Mill & Brew™ Coffee Maker

4 Elements to Brew the Perfect Cup

Tips for a Perfect Cup of Coffee

Brewing Coffee

Care and Cleaning

3–4

7–8

11–12

13–14

Troubleshooting

Warranty and Customer Service Information

Please Read and Save this Use and Care Book.

IMPORTANT SAFEGUARDS.

When using electrical appliances, basic safety precautions should always be followed including the following:

• Read all instructions.

• Do not touch hot surfaces. Use handles or knobs.

• To protect against fire, electric shock and injury to persons do not immerse cord, plugs or appliance in water or other liquid.

• Close supervision is necessary when any appliance is used near children.

• Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.

• Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Contact the consumer service number listed in this manual.

• The use of any accessory not evaluated for use with this appliance may result in fire, electric shock or injury to persons

• Do not use outdoors.

• Do not let cord hang over edge of table or counter, or touch hot surfaces.

• Do not place on or near a hot gas or electric burner, or in a heated oven.

• To disconnect, turn the unit OFF, then remove plug from wall outlet.

• Do not use this appliance for other than intended use.

• Keep lid on the carafe when in use.

• Scalding and/or burns may occur if the integrated grinder lid is removed during the brewing cycle.

• Check the grinder basket for presence of foreign objects before using.

• Only coffee beans and coffee grounds should be placed into the grinder basket.

• CAUTION: To prevent injury when utilizing the Sneak-a-Cup™ feature, replace carafe within 20 seconds of removing during the brewing process.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

POLARIZED PLUG (120V models only)

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to ﬁt into a polarized outlet only one way. If the plug does not ﬁt fully into the outlet, reverse the plug. If it still does not ﬁt, contact a qualiﬁed electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped

with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of ﬁre or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside. Repair should be done only by authorized service personnel.

ELECTRICAL CORD

1. A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord.

2. Extension cords may be used if care is exercised in their use.

3. If a long detachable extension cord is used: a) The marked electrical rating of the power cord or extension cord should be at least as great as the electrical rating of the appliance. b) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord. c) The cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over. Note: If the power cord is damaged, please contact the warranty department

listed in these instructions.

GETTING TO KNOW YOUR MILL & BREW™ COFFEE MAKER

1. Control panel

2. Lift latch

3. Lid

4. Water reservoir cover

5. Easy viewing water window

Product may vary slightly from what is illustrated.

6. Duralife™ glass carafe

(Part# CM5000-01 )

7. “Keep hot” carafe plate

8. Coffee scoop

(Part# CM5000-02 )

GETTING TO KNOW YOUR MILL & BREW™ COFFEE MAKER

1. 2-in-1 grinder and permanent filter basket

(Part# CM5000-03)

2. Washable brew basket

(Part# CM5000-04)

3. Lift latch

4. Grinder lid

5. Removable showerhead (press highlighted tabs to remove)

(Part# CM5000-05)

MILL & BREW™ COFFEE MAKER PRODUCT BENEFITS

Fresh Brew Timer

After the brew cycle is complete, the time since brewed will be displayed in 1-minute increments. This information will be in place of the digital clock during keep warm.

2-in-1 Grinder and Permanent Filter Basket

Whole coffee beans are ground and brewed in the same grinder assembly, allowing for fast brewing and easy clean-up.

Eco-Friendly Permanent Filter

The high-performance Bronze Tone permanent ﬁlter eliminates the need for paper ﬁlters and minimizes any coffee staining appearance.

Washable Brew Basket

The washable brew basket can easily be removed and washed after brewing, and is top rack dishwasher safe.

Removable Showerhead

The coffeemaker’s showerhead is removable for easy cleaning.

Brew Strength Selector

Customize the ﬂavor of your coffee by selecting from three brew strength settings: regular, strong, or bold.

Sneak-A-Cup™

Can’t wait for the full pot of coffee to ﬁnish brewing? Sneak-A-Cup™ of coffee before brewing using this great feature, which stops the ﬂow of coffee into your carafe. Replace the carafe back in the coffee maker within 20 seconds to prevent brew basket overﬂow.

Grind Select

Cycles through optimal grind settings (4, 6, 8, 10, 12) correlating with the number of cups to be brewed, or turns the grinder OFF for brewing pre-ground coffee.

Duralife™ Glass Carafe

Durable construction provides an extended carafe life. Water level markings make for easy ﬁlling and pouring.

Auto Brew

The programmable Auto Brew delay start allows you to set the 24-hour timer to brew coffee at the selected time, day or night.

Digital Clock with Backlighting

The LCD display features a programmable digital clock and backlighting for easy-viewing in low light conditions.

Adjustable Auto-Shutoff

This feature allows you to select automatic shutoff times from 0-2 hours in 30 minute increments. The “Keep Hot” carafe plate will be activated until the automatic shutoff time is reached.

Non-stick “Keep Hot” Carafe Plate

This feature allows you to keep your carafe of coffee hot after brewing until the selected auto-shutoff time has been reached.

Easy Viewing Water Window

The water window shows the amount of water in the reservoir for easy and accurate ﬁlling.

Cord Storage

Keep excess cord out of the way and your countertop neat with simple cord storage.

GETTING TO KNOW YOUR CONTROL PANEL

Indicates the delay start timer is set

Brew

strength

settings

Indicates if the whole bean grinder function has been turned OFF ( ) or ON ( )

Clock / Backlit LCD Display Power: Turns the unit ON or OFF. Auto: Turns on the Auto

Brew delayed start. Program: Auto Brew, press and

release button once. Keep Warm, press and hold.

Hour: Use to program the clock (see “Programming” section).

Minute: Use to program the clock (or cycle through different keep warm settings when in that program mode to adjust “Keep Warm” time.)

Optimal grind setting correlating with the number of cups to be brewed

Grind: Cycles through optimal grind settings (4, 6, 8, 10, 12) correlating with the number of cups to be brewed. Also, turns the grinder OFF ( )for brewing pre-ground coffee.

Strong: Use to select the Brew Strength setting (3 levels)

No bars = regular (default setting) 1 bar ( ) = strong 2 bars ( ) = bold

BEFORE BREWING

• Please go to www.prodprotect.com/applica to register your warranty and for information about replaceable parts.

1. Carefully unpack your coffeemaker, removing all packaging materials, labels, and/or stickers from your coffeemaker.

2. Clean your coffeemaker thoroughly before using for the first time. Wash the Glass Carafe, Washable Brew Basket, 2-in-1 Grinder and Permanent Filter Basket, and Removable Showerhead in warm, soapy water. Rinse and dry, then place back into your coffeemaker.

3. Clean the inside of your coffeemaker by running two full brewing cycles with water only, no coffee.

a. Pour fresh, cold water into the water reservoir up to the 12-cup MAX mark, then place carafe on the warming plate.

b. Plug cord into standard electrical outlet. c. Press the GRIND button until you reach the symbol to turn the grinder

OFF ( ) d. Push the ON-OFF / Power Button to immediately brew water through

the coffeemaker without adding coffee. e. Once the cycle is ﬁnished, discard water and rinse out the 2-in-1

Grinder and Permanent Filter Basket. f. Turn off appliance, unplug and allow to cool down for 15 minutes

before repeating.

PROGRAMMING YOUR MILL & BREW™ COFFEE MAKER

Note: The ﬁrst button press illuminates the backlit display and any subsequent presses will perform the programming.

Setting the Digital Clock

1. Plug the coffeemaker into a standard electrical outlet.

2. The digital clock display flashes “12:00”.

3. To set the time, press the HR button until the correct hour appears on the display. The “PM” symbol will appear in the upper right corner of the digital display for PM time settings.

4. Press the MIN button to select minutes.

Note: If the unit is unplugged or power interrupted, the time will need to be reset, as will the Auto Brew delay start time.

Setting the Auto Brew Delay Start

The programmable Auto Brew delay start allows you to set the 24-hour timer to brew coffee at the selected time, day or night. To activate the Auto Brew timer, follow the steps on the next page

PROGRAMMING YOUR MILL & BREW™ COFFEE MAKER

1. After the digital clock is set, press the PROG button. The timer icon ( ) will begin to flash and display will read 12:00.

2. Press the HR button and then MIN button to select the time you would like automatic brewing to begin (for example: 7:30 AM). Make sure the PM light is not on, if needed.

3. The timer display will flash several times then switch back to the current time of day.

4. Press and release the AUTO button to activate the delay start time that was just programmed. The timer icon ( ) will remain solid, indicating Auto Brew is activated.

5. When the time of day matches the programmed Auto Brew set time, your coffeemaker will activate the brew cycle.

6. To cancel the Auto Brew function, press the AUTO button until the timer icon ( ) disappears.

Note: To check the preset Auto Brew time, press PROG button and the preset Auto Brew time is displayed. Press AUTO button to reactivate the timer.

Setting the Adjustable Auto-off, Keep Warm Time

This feature allows you to select automatic shutoff times from 0-2 hours in 30 minute increments. The “Keep Hot” carafe plate will be activated until the automatic shutoff time is reached.

1. Press and hold PROG button for 3 seconds. This will show the default (120 minutes) keep warm time setting.

2. Press the MIN button to toggle through the keep warm settings (00, 30, 60, 90, 120). The values correlate to length of time (in minutes) the keep warm will remain on after brewing.

3. Press the PROG button to lock in the keep warm setting.

Note: To check the time Auto Brew is set for without making changes, press the PROG button to display the Auto Brew time, then press the AUTO button.”

Setting the Brew Strength Selector

The Brew Strength Selector customizes the ﬂavor of your coffee by selecting from three brew strength settings.

1. Press the STRONG button to cycle through the different Brew Strength settings (3 levels).

a. No bars = regular (default setting) b. 1 bar ( ) = strong c. 2 bars ( ) = bold

4 ELEMENTS TO BREW THE PERFECT CUP

Water Quality

A great cup of coffee starts with fresh, quality water. Since water represents more than 98% of brewed coffee, it is just as important as the coffee quality itself. The water you use should taste like fresh, good-quality drinking water, have an odorless aroma, and contain no visible impurities.

Grind Selection

The particle size of the coffee grind is vital for ensuring proper ﬂavor and extraction. A coffee grind that is too coarse will allow water to pass through too quickly without proper extraction. A coffee grind that is too ﬁne will lead to over-extraction and produce a bitter taste. Your Mill & Brew coffee maker comes with a Grind setting to select the optimal grind, correlating with the number of cups to be brewed and ensuring proper grind size for this type of coffee maker.

™

Coffee Freshness

A truly fresh cup of coffee only comes from freshly ground coffee beans. In fact, once a coffee bean is broken or ground, its ﬂavour will begin to degrade over time. Your Mill & Brew maximizes the freshness of your coffee by grinding the coffee beans just prior to brewing.

™

coffee maker

Proper Proportion

It is important to use the proper coffee-to-water ratio to produce a ﬁnished brew that isn’t too strong or weak. When using whole coffee beans or pre-ground coffee, we recommend using 1 tablespoon for every 1 cup of brewed coffee. This proportion may be adjusted to suit your individual taste, or try the Brew Strength Selector to customize your ﬂavour!

TIPS FOR A PERFECT CUP OF COFFEE

• To maximize the freshness of your coffee, use the integrated grinder to grind your coffee beans just before brewing.

• When brewing whole bean coffee, use the Grind setting to select the optimal grind, correlating with the number of cups to be brewed and ensuring proper grind size.

• The coffee grinder is intended for coffee beans only. Do not grind other food products or spices in the coffee grinder.

• Always use fresh, cold, clean water in your coffee maker. The water you use should have an odorless aroma and contain no visible impurities.

• Use spring water or ﬁltered water, not distilled water which lacks the minerals necessary to bind to elements of the coffee bean.

• A clean coffee maker is always important. Regular cleaning is required for the best tasting coffee.

• Always store your coffee in a cool, dry place. Once coffee has been opened, keep it tightly sealed in an airtight container.

• Do not refrigerate or freeze your daily supply of coffee, as contact with moisture will cause the coffee to deteriorate.

• Never re-use your coffee grounds. After brewing, the desirable coffee ﬂavors have been extracted and only the bitter ﬂavors remain.

• Brewed coffee should be enjoyed immediately! Allowing coffee to sit too long and reheating coffee will impact the ﬂavor.

• Smell the aroma of your freshly brewed coffee, and remember that every sip is meant to be savored and enjoyed!
