THERMAL PROGRAMMABLE
12-CUP* COFFEE MAKER
CAFETERA TÉRMICA PROGRAMABLE
DE 12 TAZAS*
CAFETIÈRE PROGRAMMABLE AVEC
CARAFE ISOTHERME DE 12 TASSES*
CM2045
Should you have any questions or concerns about your new product, please call our Customer Service Line at
We want you to have a 5-star experience!
1-800-465-6070 (U.S. and Canada). Please do not return to the store.
¡Deseamos que disfrute de una experiencia de 5 estrellas!
Si usted tiene alguna inquietud o pregunta con su producto, por favor llame a nuestra línea de servicio al cliente una
atención inmediata 1-800-465-6070 (EE.UU/Canadá) 01-800-714-2503 (México). No devuela a la tienda.
Nous voulons que vous ayez une expérience 5 étoiles!
Si vous avez des questions ou des préoccupations à propos de votre nouveau produit, veuillez
communiquer avec notre Service à la clientèle au 1 800 465-6070 (États-Unis et Canada).
Veuillez ne pas rapporter le produit au magasin.
*One cup equals approximately 5 oz. (varies by brewing technique)
*Una taza equivale a aproximadamente 5 onzas. (varía de acuerdo al método de preparación utilizado)
*Une tasse équivaut à environ 115 g (5 oz; varie selon la technique de brassage)
1
CONTENTS
Please Read and Save this Use and Care Book.
Important Safeguards
Getting to know your Coffee Maker
Product Benefits
Getting to know your Control Panel
Before Brewing
Programming your Coffee Maker
4 Elements to Brew the Perfect Cup
Tips for a Perfect Cup of Coffee
Brewing Coffee
Care and Cleaning
Troubleshooting
Warranty and Customer
Service Information
RISK OF FIRE OR ELECTRIC SHOCK. DO NOT OPEN.
The lightning symbol refers to “dangerous voltage”; the exclamation symbol refers
to maintenance instructions. See below.
Warning: To reduce the risk of fire or electric shock, do not remove the cover of the
coffeemaker. There are no user-serviceable parts inside. Repair should be done by
authorized service personnel only.
WARNING
3
4
5
6
7
7-8
9
10
11-12
12
14
15
IMPORTANT SAFEGUARDS.
When using electrical appliances, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and/or injury, including the following:
• Read all instructions.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against fire, electric shock and injury to
persons do not immerse cord, plugs or appliance in
water or other liquid.
• Close supervision is necessary when any appliance
is used by or near children.
• Unplug from outlet when either the appliance or
display clock is not in use, and before cleaning. Allow
to cool before putting on or taking off parts, and
before cleaning the appliance.
• Do not operate any appliance with a damaged cord
or plug, or after the appliance malfunctions or has
been damaged in any manner. Contact Consumer
Support at the number listed in this manual.
• The use of accessory attachments not
recommended by the appliance manufacturer may
result in fire, electric shock or injury to persons.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter,
or touch hot surfaces.
• Do not place on or near a hot gas or electric
burner, or in a heated oven.
• To disconnect, turn the unit OFF, then remove plug
from wall outlet.
• Do not use this appliance for other than
intended use.
• Keep lid on the carafe when in use.
• Scalding may occur if the lid is removed during the
brewing cycles.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
• Never fill the water reservoir past the 12-Cup
marking.
• The carafe is designed to hold 12 cups (60 ounces)
of coffee. Do not overfill.
• The carafe should never be tilted backwards.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG (120V models only)
This appliance has a polarized plug
(one blade is wider than the other). To
reduce the risk of electric shock, this
plug is intended to fit into a polarized
outlet only one way. If the plug does not
fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified
electrician. Do not attempt to modify the
plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped
with a tamper-resistant screw to prevent
removal of the outer cover. To reduce
the risk of fire or electric shock, do not
attempt to remove the outer cover.
There are no user-serviceable parts
inside. Repair should be done only by
authorized service personnel.
ELECTRICAL CORD
a) A short power-supply cord is provided
to reduce the risks resulting from
becoming entangled in or tripping
over a longer cord.
b) Extension cords are available and may
be used if care is exercised in their use.
c) If an extension cord is used:
1) The marked electrical rating of the
extension cord should be at least as
great as the electrical rating of the
appliance;
2) If the appliance is of the grounded
type, the extension cord should be
a grounding-type 3-wire cord; and
3) The cord should be arranged
so that it will not drape over the
counter top or tabletop where it
can be pulled on by children or
tripped over.
Note: If the power cord is damaged,
please contact the warranty department
listed in these instructions.
2 3
GETTING TO KNOW YOUR COFFEE MAKER
PRODUCT BENEFITS
Fresh Brew Timer
After the brew cycle is complete,
the clock will convert to a
1
countdown timer starting at 120
minutes and countdown until it
reaches 01 minute remaining.
slows to extract the maximum
flavor from the coffee grounds.
Regular strength is indicated by the
STRONG light being off.
Sneak-A-Cup
™
Feature
Can’t wait for the full pot of coffee
Stainless Steel Thermal Carafe
6
The large capacity 12-cup doublewalled vacuum-sealed stainless
steel thermal carafe keeps coffee
2
hot and fresh for hours.
to finish brewing? Use the Sneak-ACup™ feature, which stops the flow
of coffee into your carafe, to grab a
cup before brewing ends. Replace
the carafe back in the coffeemaker
within 20 seconds to prevent brew
3
7
Reusable filter
The reusable filter reduces waste with
no need for paper filters.
basket overflow.
Perfect Pour
™
Spout
The thermal carafe features a
Washable Brew Basket
8
The washable brew basket can easily
be removed and washed after brewing,
and is top rack dishwasher safe.
specially designed Perfect Pour
spout for no more drips.
Easy View Water Window
™
The water window shows the
4
Vortex™ Showerhead
This technology provides even
amount of water in the reservoir for
easy and accurate filling.
saturation of the coffee grounds for
optimal water flow for maximum
flavor.
Auto Clean
After every 60 brews or when the
™
System
machine senses calcification build-
5
1. Lid
2. Reusable filter (Part # CM2045-01)
3. Washable brew basket
(Part # CM2046-01 )
4. Carafe lid (Part # CM2046-03)
5. 12-cup stainless steel
thermal carafe (Part # CM2046-02)
9
6. Vortex™ Showerhead
7. Water reservoir
8. Easy-view water window
9. Control panel
Brew Later
The programmable Brew Later
delay start allows you to set the
24-hour timer to brew coffee at the
selected time, day or night.
Digital Clock
The LCD display features a
programmable digital clock.
Auto-Shutoff
Once the brewing cycle is complete,
the coffeemaker will automatically
shut off for peace of mind.
Brew Strength Selector
You may choose between regular
or strongly flavored coffee to suit
your personal taste. If you press
up, the word “CLEAN” should scroll
across the display three times,
alerting you that it is time to run
Auto Clean
™
to automatically descale your coffeemaker. This helps
to maintain your brewer and coffee
quality.
IMPORTANT PRO TIP:
To help coffee stay at brewed
temperature, warm the carafe
before brewing by filling it
with and then discarding hot
tap water.
the STRONG button; the light
Product may vary slightly from what is illustrated.
goes on and the brewing process
4 5
GETTING TO KNOW YOUR CONTROL PANEL
Digital Clock with
LCD Display
Strong display
When showing,
indicates that the
strong mode is set.
Hour Button
Use to program the
clock
(see “Programming”
section)
Clean Button
For the auto clean
function
Brew Later Button
Use to program
(see “Programming”
section)
Power Button
Lighted button turns
the unit ON or OFF.
PM indicator
Shows when the clock
is set past noon.
Brew Later display
When showing,
indicates that the
Brew Later function
is set.
Minute Button
Use to program the
clock
(see “Programming”
section)
Strong button
Use to program
(see “Programming”
section)
BEFORE BREWING
1. To register your product, go to www.prodprotect.com/blackanddecker
2. Carefully unpack your coffeemaker, removing all packaging materials, labels, and/or
stickers from your coffeemaker.
3. Remove the plastic band around the power plug using scissors
4. Clean your coffeemaker thoroughly before using for the first time. Wash the thermal
carafe and washable brew basket in warm, soapy water. Rinse and dry, then place
back into your coffeemaker.
5. Clean the inside of your coffeemaker by running two full brewing cycles with water
only, no coffee.
a. Pour fresh, cold water into the water reservoir up to the 12-cup MAX
mark, then place carafe onto the carafe plate.
b. Plug cord into standard electrical outlet.
c. Push the ON-OFF / Power Button to immediately brew water through
the coffeemaker without adding coffee.
d. Once the cycle is finished, discard water.
e. Turn off appliance, unplug and allow to cool down for 15 minutes
before repeating.
PROGRAMMING YOUR COFFEE MAKER
Setting the Digital Clock
1. Plug the coffeemaker into a standard electrical outlet.
2. The digital clock display flashes “12:00”.
3. To set the time, press the HR button until the correct hour appears on the
display. The “PM” symbol will appear in the upper right corner of the digital
display for PM time settings.
4. Press the MIN button to select minutes.
Note: If the unit is unplugged or power interrupted, the time will need to
be reset, as will the Brew Later delay start time.
Setting the Brew Later Delay Start for the first time
The programmable Brew Later delay start allows you to set the 24-hour timer
to brew coffee at the selected time, day or night. To activate the Auto Brew
timer, follow these steps
1. After the digital clock is set, press the BREW LATER button. The programmed
clock time will begin to flash.
2. BREW LATER displays and flashes.
3. Clock shows last BREW LATER time programmed (if no time has been
programmed, or unit has been unplugged, BREW LATER time defaults to 12:00)
6 7
:
4. Use HR and MIN buttons to set BREW LATER time (while BREW LATER display
is blinking)
5. After 3 seconds with no button pressed, BREW LATER time is set.
6. When the BREW LATER function is set, BREW LATER is displayed (not
flashing), and unit will begin brewing at the BREW LATER time.
If BREW LATER function has been previously set:
The programmable Brew Later delay start allows you to set the 24-hour timer
to brew coffee at the selected time, day or night. To activate the Auto Brew
timer, follow these steps
1. Press BREW LATER button to check the BREW LATER time. “BREW LATER”
will flash once per second, and the clock will display the BREW LATER time for
3 seconds
2. After 3 seconds, clock reverts to current time, and “BREW LATER” is
illuminated (no flashing)
Note: To override the BREW LATER function, press the Power button to
cancel. Unit begins brewing immediately
Note: Even though BREW LATER is disabled, the BREW LATER time will still
be stored unless unit is unplugged
:
4 ELEMENTS TO BREW THE PERFECT CUP
Water
Quality
A great cup of coffee starts with
fresh, filtered water. Since water
represents more than 98% of
brewed coffee, it is just as important
as the coffee quality itself. The
water you use should taste like
fresh, good-quality drinking
water, have an odorless aroma,
and contain no visible impurities.
Filtered water will limit impurities
and excessive minerals that can
detrimentally impact coffee flavor
and machine performance.
A truly fresh cup of coffee only
comes from freshly ground coffee
beans. In fact, once a coffee bean
is broken or ground, its flavor
will begin to degrade over time.
Maximize the freshness of your
coffee by grinding coffee beans
just prior to brewing.
Coffee
Freshness
Even
Saturation
Even saturation of your coffee
grounds is vital for ensuring proper
flavor and extraction. Some coffee
makers simply drip water down the
center of the brew basket, which
leads to over-extraction in the
center of the coffee grounds and
under-extraction on the perimeter.
This coffeemaker features a
Showerhead, providing even
saturation of the coffee grounds for
optimal water flow and maximum
flavor.
Vortex™
Proper
Proportion
It is important to use the proper
coffee-to-water ratio to produce a
finished brew that isn’t too strong
or weak. We recommend using 1
tablespoon of ground coffee for
every 1 cup of brewed coffee. You
may adjust this proportion to suit
your individual taste, or try the
Brew Strength Selector to
customize your flavor!
8 9
TIPS FOR A PERFECT CUP OF COFFEE
• To maximize the freshness
of your coffee, grind
whole coffee beans just
before brewing.
• Fill the carafe with hot tap water
and empty before brewing,
which will warm up the carafe
and help keep coffee at the
brewed temperature.
USING THE CARAFE
A. Lid in the closed/locked position.
Press button on handle before
pouring.
B. Lid in the unlocked position.
C. Lid removed.
Note: When brewing half a carafe or
less of coffee, be sure to prewarm
the carafe. See tip on page 10.
A
• Always use fresh, cold, clean
water in your coffee maker. The
water you use should have an
odorless aroma and contain no
visible impurities.
• Use spring water or filtered
water, not distilled water
which lacks the minerals
necessary to bind to elements
of coffee.
• A clean coffee maker is
always important. Regular
cleaning is required for the
best tasting coffee.
• Always keep the lid on your
thermal carafe after brewing.
The carafe is double-wall
insulated and vacuum sealed to
help keep your coffee hot and
fresh for hours.
• Use the strong setting for best
flavor when brewing less than 4
cups of coffee.
• Always store your coffee in a cool,
dry place. Once coffee has been
opened, keep it tightly sealed in
an airtight container.
• Do not refrigerate or freeze
your daily supply of coffee,
as contact with moisture
will cause the coffee to
deteriorate.
• Never re-use your coffee grounds.
After brewing, the desirable
coffee flavors have been
extracted and only the bitter
flavors remain.
• Brewed coffee should be enjoyed
immediately! Allowing coffee to
sit too long and reheating coffee
will impact the flavor.
• Smell the aroma of your freshly
brewed coffee, and remember
that every sip is meant to be
savored and enjoyed!
Note: Coffee may run over if lid is
not correctly in place on carafe.
Note: The carafe should never be
tilted backwards.
BREWING COFFEE
Note: You don’t need to set the
clock to brew coffee right away.
1. Open cover of coffeemaker. Fill
water reservoir with cold water. (D)
Filtered water will limit impurities
and excessive minerals that can
detrimentally impact coffee flavor
and machine performance.
2. Use lines on the easy viewing water
window as a guide. Do not fill past
12 MAX line.
3. Insert the reusable filter or place a
basket shaped paper filter into the
brew basket. Add ground coffee (we
suggest 1 tablespoon per cup). Put
brew basket in place.
B
C
D
10 11
4. Place empty carafe on the carafe
plate and plug cord into a standard
outlet.
5. To set the Brew Later delay start,
brew strength selector, follow the
instructions in the “Programming”
section.
6. Press power button once to
begin brewing. (E)
7. The Sneak-A-Cup™ feature allows
you to pour a cup of coffee before
the brewing cycle is complete.
The carafe must be placed
back into the coffeemaker within
20 seconds to prevent overflow.
Replacing the carafe will restart the
brewing process.
8. Brew timer count down from 120
minutes will begin when
brewing cycle is complete.
9. Press button on handle to pour coffee.
10. To turn off the coffeemaker at any time press the power button. (E)
11. When coffee grounds are cool, carefully remove and throw away used grounds
and filter.
12. Clean the thermal carafe and washable brew basket according to the
instructions in the CARE AND CLEANING section.
E
CARE AND CLEANING
Cleaning your coffee maker, following the directions below is recommended
after every use. This product contains no user serviceable parts.
Cleaning
1. Make sure your coffeemaker is unplugged and cool.
2. Open the coffeemaker cover. Remove the brew basket and permanent filter.
Throw away the coffee grounds.
3. Wash the permanent filter, brew basket and carafe in a dishwasher or by hand
in warm water with dish soap.
4. Wipe the outside of the coffeemaker, carafe plate, and power cord with a soft,
damp cloth.
5. To clean the inside of the cover, open the cover and leave in the open position;
wipe surfaces with a damp cloth.
Note: Do not use abrasive cleansers or scouring pads, and never immerse the
coffeemaker in water.
COFFEE MAKER PART CLEANING INSTRUCTIONS
Housing
Carafe plate
Power Cord
Carafe and carafe lid
Washable Brew Basket
Wipe with a soft, damp cloth.
Wash by hand in warm soapy
water
DESCALING WITH THE AUTO CLEAN™ FUNCTION
With regular use, minerals and hard water can clog your coffee maker. A full
cleaning with vinegar is recommended once a month. To notify you that it
is time to descale with vinegar, after 60 brew cycles or when calcification is
sensed, “CLEAN” should scroll across the display three times. The “CLEAN”
word will continue to blink before each brew until the descaling process
is completed. If the machine is extremely calcified it may require multiple
cleaning cycles to clear the “CLEAN” warning.
1. Pour white vinegar into the water reservoir up to the 5-cup mark on the water
window. Add cold water up to the 12-cup mark.
2. Put a basket-shaped paper filter in the brew basket and close the cover. Set the
empty carafe on the carafe plate.
3. Press the CLEAN button to start the Auto Clean™ function. The entire cleaning
process will take 45-60 minutes to complete.
4. During the Auto Clean™ process, the coffee maker will:
- Brew 5 cups of the vinegar/water mixture first
- Pause for about 30 minutes
- After the pause, it will brew the remainder of the vinegar/water mixture
5. Once the process is complete, empty the carafe and discard the paper filter.
6. Fill the water reservoir with cold water to the 12-cup line: replace the empty
carafe on the carafe plate and then turn ON the coffeemaker for a complete
brewing cycle to flush out the remaining vinegar/water mixture. You may want
to repeat this step to completely remove the vinegar smell and taste
7. Wash the brew basket and carafe as shown in CARE AND CLEANING.
8. If your machine is heavily calcified, the “CLEAN” warning may remain activated
after cleaning. In this case, repeat cleaning.
12 13
TROUBLESHOOTING
NEED HELP?
PROBLEM POSSIBLE CAUSE SOLUTION
Coffee maker does
not turn on.
Coffee maker
is leaking.
The brew basket
overflows.
Coffee sediment in
brewed cup of coffee.
The coffee maker
brews slowly.
Coffee maker does
not complete brewing
(water left in tank).
Coffee is not hot
enough.
Coffee maker is not
plugged in.
Water reservoir may be
overfilled.
Cover may not be
correctly placed on
carafe
Carafe may not be
correctly placed on the
carafe plate
The carafe has been
removed for longer than
20 seconds when using
the Sneak-A-Cup™ feature.
Excessive amount of
coffee is used.
The paper filter and/or
the brew basket are not
properly placed.
The coffee maker needs
cleaning.
The coffee maker is
heavily calcified.
Low brew volumes (under
four cups of coffee) and/
or the carafe is cold.
Make sure appliance
is plugged into a
working outlet.
Make sure water
reservoir has not
been filled beyond
the 12-cup MAX line.
Make sure cover is
correctly placed and
tightened on carafe
Make sure carafe is
placed correctly on the
carafe plate.
Make sure to replace
the carafe within 20
seconds during the
brewing cycle.
Reduce the amount
of coffee used to
eliminate brew basket
overflows.
Insert basket-shaped
paper filter into brew
basket and insert
basket properly into
holder.
Follow the instructions
in the “Descaling
With the Auto Clean™
Function” section.
Follow the instructions
in the “Descaling
With the Auto Clean™
Function” section.
Multiple cleaning cyles
may be required.
Pre-heat carafe before
brewing with hot tap
wa ter.
For service, repair or any questions regarding your appliance, please call
our Customer Service Line at 1-800-465-6070. Please DO NOT return the
product to the place of purchase. Also, please DO NOT mail product back to
manufacturer, nor bring it to a service center. You may also want to consult
the website listed on the cover of this pamphlet.
Warranty Information
(Applies only in the United States and Canada)
What does it cover?
• Any defect in material or workmanship provided; however, Spectrum
Brands’ liability will not exceed the purchase price of product.
For how long?
• Two years from the date of original purchase with proof of such purchase.
What will we do to help you?
• Provide you with a reasonably similar replacement product that is either new
or factory refurbished.
How do you get service?
• Save your receipt as proof of date of sale.
• Visit the online service website at www.prodprotect.com/blackanddecker, or
call toll-free
• If you need parts or accessories, please call
How does state law relate to this warranty?
• This warranty gives you specific legal rights. You may also have other rights
that vary from state to state or province to province.
What does your warranty not cover?
• Damage from commercial use
• Damage from misuse, abuse or neglect
• Products that have been modified in any way
• Products used or serviced outside the country of purchase
• Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of the unit
• Consequential or incidental damages (Please note, however, that some
states do not allow the exclusion or limitation of consequential or incidental
damages, so this limitation may not apply to you.)
Are there additional warranty exclusions?
• This warranty shall not be valid where it is contrary to U.S. and other
applicable laws, or where the warranty would be prohibited under any
economic sanctions, export control laws, embargos, or other restrictive
trade measures enforced by the United States or other applicable
jurisdictions. This includes, without limitation, any warranty claims
implicating parties from, or otherwise located in, Cuba, Iran, North Korea,
Syria and the disputed Crimea region.
1-800-465-6070
, for general warranty service.
1- 800-738-0245
.
If additional assistance is needed, please contact our consumer service team at
1-800-465-6070.
14 15
Loading...
