ENGLISH

Intendeduse

Your Black & Decker blender has been designed for blending,
mixing and crushing of solid and liquid food and beverage
ingredients.
This product is intended for household use only.

Safetyinstructions

u Warning! When using mains-powered appliances, basic

safety precautions, including the following, should always

be followed to reduce the risk of re, electric shock and

personal injury.

u Read this entire manual carefully before using the appliance.
u The intended use is described in this manual. The use of

any accessory or attachment or the performance of any
operation with this appliance other than those recommended
in this instruction manual may present a risk of personal
injury.

u Retain this manual for future reference.

Usingyourappliance

u Switch off and unplug the appliance before changing

accessories or approaching parts which move when in use.

u Make sure that the appliance is switched off before

connecting to or disconnecting from the power supply.

u Always take care when using the appliance
u Do not use the appliance outdoors.
u Do not operate the appliance if your hands are wet.
u Do not operate the appliance if you are barefoot.
u Do not touch moving parts. Keep long hair and loose

clothing out of the way of the moving parts.

u Guide the power supply cord neatly so it does not hang

over the edge of a worktop and cannot be caught
accidentally or tripped over.

u Never pull the power supply cord to disconnect the plug

from the socket. Keep the power supply cord away from
heat, oil and sharp edges.

u Switch off and wait for the motor to stop running before

disconnecting the appliance from the power supply.

u Never detach any part or accessory while the appliance is

still connected to the power supply. Always disconnect the

appliance from the power supply rst.

u If the power supply cord is damaged during use,

disconnect the appliance from the power supply
immediately. Do not touch the power supply cord before
disconnecting from the power supply.

u Disconnect the appliance from the power supply when not

in use, before tting or removing parts and before

cleaning.

u Always disconnect the appliance from the power supply if

it is left unattended.

u Do not try to disassemble or repair this appliance.

Always return it to the manufacturer, its Service Agent or

similarly qualied persons in order to avoid a hazard.

Safety of others

u Do not allow children or any person unfamiliar with these

instructions to use the appliance.

u Do not allow children or animals to come near the work

area or to touch the appliance or power supply cord.

u Close supervision is necessary when the appliance is

used near children.

u This appliance is not intended for use by persons

(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.

u Children must be supervised to make sure that they do not

play with the appliance.

u This unit must be attended in use
u Do not allow children to use the appliance without

supervision.

Beforerstuse

u Before using the appliance for the rst time ensure all

packaging is removed.

u Clean all parts before use.

Afteruse

u Remove the plug from the socket and let the appliance

cool down before leaving it unattended and before
changing, cleaning or inspecting any parts of the appliance.

u When not in use, the appliance should be stored in a dry

place.

u Children should not have access to stored appliances.

Inspection and repairs

u Before use, check the appliance for damaged or defective

parts. Check for breakage of parts and any other
conditions that may affect its operation.

u Do not use the appliance if any part is damaged or defective.
u Have any damaged or defective parts repaired or replaced

by an authorised repair agent.

u Before use, check the power supply cord for signs of

damage, ageing and wear.

u Do not use the appliance if the power supply cord or

mains plug is damaged or defective.

u If the power supply cord or mains plug is damaged or

defective it must be repaired by an authorised repair agent

in order to avoid a hazard. Do not cut the power supply

cord and do not attempt to repair it yourself.

u Never attempt to remove or replace any parts other than

those specied in this manual.

4

ENGLISH

Electrical safety

This appliance is double insulated in accordance

#

with EN 60335; therefore no earth wire is required.
Always check that the power supply corresponds to
the voltage on the rating plate.

To avoid the risk of electric shock, do not immerse

!

the cord plug or motor unit in water or other liquid.

Overview

This appliance includes some or all of the following features.

1. Speed control switch

2. Blade assembly

3. Jug

4. Lid

5. Pouring hole cover

Assembly(g.A)

Warning! Before assembly, make sure that the appliance is
switched off and unplugged.

Assemblingthejug(g.A)

u Place the seal (9) on the blade assembly (2).
u Position the blade assembly in the underside of the jug (3).
u Rotate the blade assembly counterclockwise to lock it into

place.

Warning! Do not overtighten the blade assembly.

u Place the lid (4) on the jug.
u Turn the lid (4) clockwise until it locks into place.
u Place the pouring hole cover (5) in the lid (4).

Warning! Take care when emptying the jug and when
handling the blades as they are very sharp.

u For longer operation, turn the speed control switch (1) to

position 1 (low speed) or 2 (high speed). To switch off, turn
the switch to position 0.

Warning! Do not operate the appliance continuously for more

than 2 minutes. After operating the appliance
continuously for 2 minutes, let it cool down for at
least 10 minutes before operating it again.

Blending

Before tting the lid (4) add the ingredients. The ingredients

can be topped up by inserting them through the pouring hole.

Warning! Never operate the appliance without the lid.

Warning! Take care when emptying the jug and when

handling the blades as they are sharp.

u Set the unit up for blending as described above.
u Open the pouring hole or remove the lid (4).
u Add the required ingredients into the jug (3).

Warning! Do not exceed the MAX level (1.4 litres).

u Fit the lid and pouring hole cover onto the jug.
u Operate the appliance as described above. It is

recommended to start at low speed, then change to high
speed if necessary.

u Turn the jug counterclockwise and lift it off the motor unit.
u Remove the lid.
u Pour the ingredients out.

Afteruse

u Remove the jug from the appliance.
u Remove the lid from the jug.
u Pour the ingredients out.

Hintsforoptimumuse

Fittingandremovingthejug(g.A)

u Position the jug (3) on the motor unit, aligning the lugs (6)

with the recesses (7).

u Fix the jug by turning it clockwise until the lugs (6) engage

in the slots (8).

u To remove the jug, turn the jug counter-clockwise and take

if off.

Use

Warning! Always place the unit on a at, clean and non-slip

surface before operating it.

Switching on and off

u In order to briey switch on, turn the speed control switch

(1) to position P. To switch off, release the switch.

Operating times
Blender

 Time(s) Speed Maximumquantity

Liquids 25-35 1-2 1.4 l
Semi liquids 15-20 1 1 l

Cleaning and maintenance

Warning! Be careful when cleaning the blades as they are

sharp.

Warning! Before cleaning and maintenance, switch the
appliance off and unplug it.

u Always clean the appliance immediately after use.
u Wipe the motor unit with a damp cloth. Do not immerse

the motor unit or blender base in water. Wash the other
parts in warm water and dry carefully.

5

ENGLISH

u If necessary, the blade assembly can be removed and

cleaned separately.

u Do not use abrasives or chemical cleaners on any part

this appliance.

u Do not wash any parts of the appliance in a dishwasher.
u Do not attempt to sharpen the blades as this could

damage them.

Protecting the environment

Separate collection. This product must not be

Z

disposed of with normal household waste.

Should you nd one day that your Black & Decker product

needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product
available for separate collection.

Separate collection of used products and packaging

z

allows materials to be recycled and used again.
Re-use of recycled materials helps prevent
environmental pollution and reduces the demand for
raw materials.

Local regulations may provide for separate collection of
electrical products from the household, at municipal waste
sites or by the retailer when you purchase a new product.

Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.

You can check the location of your nearest authorised repair

agent by contacting your local Black & Decker ofce at the

address indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com

Technical data
BL355

Voltage V 230
Power input W 350
Weight kg 2

EC declaration of conformity

BL355

Black & Decker declares that these products conform to:

2006/95/EC, EN 60335

The undersigned is responsible for compilation of the technical

le and makes this declaration on behalf of Black & Decker.

_

Director of Consumer Engineering

Spennymoor, County Durham DL16 6JG,

Kevin Hewitt

United Kingdom

23-6-2009

Guarantee

Black & Decker is condent of the quality of its products and

offers an outstanding guarantee. This guarantee statement is
in addition to and in no way prejudices your statutory rights.
The guarantee is valid within the territories of the Member
States of the European Union and the European Free Trade
Area.

If a Black & Decker product becomes defective due to faulty
materials, workmanship or lack of conformity, within 24 months
from the date of purchase, Black & Decker guarantees to
replace defective parts, repair products subjected to fair wear
and tear or replace such products to ensure minimum
inconvenience to the customer unless:

u The product has been used for trade, professional or hire

purposes;

u The product has been subjected to misuse or neglect;
u The product has sustained damage through foreign

objects, substances or accidents;

u Repairs have been attempted by persons other than

authorised repair agents or Black & Decker service staff.
To claim on the guarantee, you will need to submit proof of
purchase to the seller or an authorised repair agent. You can
check the location of your nearest authorised repair agent by

contacting your local Black & Decker ofce at the address

indicated in this manual. Alternatively, a list of authorised
Black & Decker repair agents and full details of our after-sales
service and contacts are available on the Internet at:

www.2helpU.com

Please register at our website www.blackanddecker.co.uk to
be kept up to date on new products and special offers.
Further information on the Black & Decker brand and our
range of products is available at www.blackanddecker.co.uk
