use and care manual
manual de uso y cuidado
BL1350
PLEASE READ AND SAVE THIS USE AND CARE BOOK.
IMPORTANT SAFEGUARDS.
When using electrical appliances, always follow basic safety precautions to reduce the
risk of fire, electric shock, and/or injury, including the following:
• Read all instructions.
• To protect against risk of electrical shock, do
not put blender base, cord or plug in water or
other liquid.
• Close supervision is necessary when any
appliance is used by or near children.
• Unplug from outlet when not in use, before
assembly/disassembly and before cleaning.
• Avoid contacting moving parts.
• Do not operate any appliance with a
damaged cord or plug or after the appliance
malfunctions or is dropped or damaged
in any manner. Contact Customer Service
for examination, repair or electrical or
mechanical adjustment by calling the
appropriate toll-free number listed in this
manual. This appliance has important
markings on the plug blade. The attachment
plug or entire cordset (if plug is molded
onto cord) is not suitable for replacement. If
damaged, the appliance must be replaced.
• The use of attachments, including canning
jars, not recommended or sold by the
appliance manufacturer may cause a risk of
injury to persons.
• Do not use outdoors.
• Do not let cord hang over the edge of table or
counter, or touch hot surfaces.
• Keep hands and utensils out of container
while blending to reduce the risk of severe
injury to persons or damage to the blender. A
scraper may be used but must be used only
when the blender is not running.
• Blades are sharp. Handle carefully.
• To reduce the risk of injury, never place
cutter assembly blades on base without the
jar properly attached.
• Always operate blender with cover in place.
• Do not blend hot liquids.
• Do not use appliance for other than
intended use.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• Do not place on or near a hot gas or electric
burner or in a heated oven.
• Do not operate with damaged blades.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to fit into a polarized outlet only one way.
If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician.
Do not attempt to modify the plug in any way.
TAM PER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-
resistant screw to prevent removal of the outer cover.
To reduce the risk of fire or electric shock, do not
attempt to remove the outer cover. There are no userserviceable parts inside. Repair should be done only by
authorized service personnel.
ELECTRICAL CORD
1) A short power-supply cord is provided to reduce the risk
resulting from becoming entangled in or tripping over a
longer cord.
2) Extension cords are available and may be used if care
is exercised in their use.
3) If an extension cord is used,
a) The marked electrical rating of the extension cord
should be at least as great as the electrical rating of
the appliance,
b) If the appliance is of the grounded type, the extension
cord should be a grounding-type 3-wire cord, and
c) The cord should be arranged so that it will not drape
over the countertop or tabletop where it can be pulled
on by children or tripped over.
Note: If the power cord is damaged, please call our
Customer Service line listed in these instructions.
2
Congratulations on your purchase of the BLACK+DECKER™ Infuser 3-in-1 Digital
Blending System!
From delicious smoothies to creamy soups, the PowerCrush blender’s powerful motor
and unique QuadPro blade design work together to ensure superior blending and
crushing results—for home or on the go.
GETTING TO KNOW YOUR
INFUSER 3-IN-1 DIGITAL BLENDING SYSTEM
3
8
9
10
4
15
2
1
5
11
12
16
6
7
13
14
1. Tamper (Part# BL1350-01)
2. Infuser Filter (Part# BL1350-02)
3. Pour Spout
4. Blending Jar (Part # BL1350-03)
5. On/Off button
6. Digital Control Panel
7. Blender Base
8. Ingredient/Tamper Slot
Product may vary slightly from what is illustrated.
9. Dual-opening lid (Part# BL1350-04)
10. Handle
11. Blade Assembly (Part# BL1130-04)
12. Jar Base (Part# BL1350-05)
13. Non-skid Rubber Feet
14. Cord Storage (under base)
15. Single Serve Lid (Part# BL1550-03)
16. Single Serve Jar (Part# BL1550-04)
3
HOW TO USE
This product is for household use only.
GETTING STARTED
• Remove all packing material, any stickers, and the plastic band around
the power plug.
• Remove and save literature.
• Please visit www.prodprotect.com/applica to register your warranty.
• Wash all removable parts as instructed in CARE AND CLEANING
section of this manual.
BLENDING JAR ASSEMBLY
1. Turn blending jar upside down and place flat on
counter top or work surface.
2. Place the blade assembly in bottom opening of the jar
with blades down. (A)
Caution: Blades are sharp. Handle carefully.
3. Place the jar base onto the blending jar and rotate
clockwise until tight. It is important to tighten to avoid
leaking while blending
4. Turn assembled jar right side up.
5. Place the dual-opening lid on blender jar.
6. Uncoil power cord from storage area under the blender
base.
7. Place the jar assembly on blender base (B) and twist
clockwise to lock.
8. Blender is now ready for use.
INSTALLING INFUSER INTO
BLENDING JAR
1. Put together Blending Jar assembly as above.
2. Place the infuser filter all the way down into the base
of the jar, fitting together the slots on the bottom rim
of the filter with the ridges on the inside bottom of the
blending jar. (C)
3. Place the dual-opening lid on blender jar.
4. Open the Ingredient/Tamper Slot and insert the tamper. (D)
5. Blender with infuser is now ready for use.
C
D
4
USING YOUR INFUSER
Important: Appliance should always have lid in place when in use.
Caution: Do not place blender jar onto base when motor is running.
Caution: Do not blend hot liquids.
1. Make sure appliance is OFF.
2. Place Infuser Filter all the way down into the base of the Blending Jar.
3. Place lid on jar; make sure pour spout is closed.
4. Pour desired amount of water into the Ingredient/Tamper Slot.
Caution: Do not fill past the Max Fill Line
5. Place ingredients to be infused into the filter through the Ingredient/
Tamper Slot.
6. Place Tamper into the Ingredient/Tamper Slot.
7. Plug power cord into outlet. Press ON/OFF button. LED should turn a
solid color to signify the blender is in standby mode. After 60 seconds
the unit will automatically power off if no buttons are pressed. The LED
will blink slowly when the blender is in use.
Note: When in use, do not leave blender unattended. Keep one hand on the
Tamper at all times.
8. Select the Infuse function.
Note: There is no need to select a speed since the Infuse function has a
preprogrammed speed.
9. When blending, push ingredients down into the blade
with the tamper to ensure all ingredients are blended
properly.
10. Remove the tamper to add ingredients while the
blender is running. Drop ingredients through the
opening (E).
Important: Do not remove the lid while the blender is
running.
11. When finished, press ON/OFF to stop blending. Make sure blades have
completely stopped before attempting to remove the blending jar from
the base (refer to TROUBLESHOOTING for any issues).
12. Unplug the blender.
13. To remove the jar: grasp the handle and twist counter-clockwise, then
lift up.
14. Remove the tamper, close the Ingredient/Tamper Slot, open the pour
spout, and serve.
Note: Do not remove the Infuser Filter before serving.
15. Always unplug the appliance when not in use.
E
5
USING YOUR BLENDER (WITHOUT INFUSER)
Important: Appliance should always have lid in place when in use.
Caution: Do not place blender jar onto base when motor is running.
Caution: Do not blend hot liquids.
1. Make sure appliance is OFF.
2. Place ingredients to be blended into jar. For best results, add ingredients
in the following order:
a. Liquids
b. Powders
c. Soft foods
d. Hard foods
e. Ice cubes last
Tip: When using frozen fruits it is not necessary to also add ice.
3. Place lid on jar; make sure the pour spout and ingredient slot are closed.
4. Plug power cord into outlet. Press ON/OFF button. LED should turn a
solid color to signify the blender is in standby mode. After 60 seconds
the unit will automatically power off if no buttons are pressed. The LED
will blink slowly when the blender is in use.
Note: When in use, do not leave blender unattended. When using hard foods,
such as ice or cheese, keep one hand on the lid to keep blender in place.
5. Select the speed that best suits your desired task. (See SPEED CHART)
Important: Do not hold speed button. Simply press the desired speed,
watch, and press ON/OFF when the desired consistency is achieved.
Holding the button for longer than 30 seconds will cause the blender to shut
off. Unit must be shut off to reset.
6. When blending thick mixtures, such as smoothies and milkshakes, use
the PULSE/Ice Crush button for several seconds, then release. Repeat to
mix ingredients and then run continuously until food has reached desired
consistency. Releasing pulse stops the blending and the unit returns to
STANDBY. You may use a spatula or utensil to move ingredients and thick
mixtures around in the blender jar, but only after stopping the blender.
Turn the blender OFF before using a utensil.
7. Open the
is running. Drop ingredients through the opening. (F).
Important: Do not remove the lid while the blender is running.
8. When finished, press ON/OFF to stop blending. Make
sure blades have completely stopped before attempting
to remove the blending jar from the base(refer to
TROUBLESHOOTING for any issues).
9. Press ON/OFF to power off and unplug the blender.
10. To remove the jar: grasp the handle and twist counter-clockwise, then
lift up.
ingredient slot
to add ingredients while the blender
F
6
11. Open pour spout to serve.
Note: Unit will auto shutoff after 60 seconds without use.
12. Always unplug the appliance when not in use.
USING THE PREPROGRAMMED FUNCTIONS
• Fill the assembled blender jar with the desired ingredients.
• Place the dual-opening lid on the jar.
• Place the jar on the base.
• Press desired preprogrammed button. The blender will automatically mix
and blend the following recipes with the press of a button:
- Smoothie: 30 seconds to blend fruits and vegetables to a smooth
consistency.
- Infuse: Create infused water in seconds.
- Shake/Mix: Create thick, smooth and creamy frozen treats or use to
combine other ingredients together.
USING THE SINGLE SERVE JAR
Note: Do not blend hot liquids in the single serve jar.
1. Place the single serve jar on a flat surface with the open end facing up.
Fill the jar with ingredients. Do not fill ingredients past the max fill line.
Note: For best results, add ingredients in the following order:
A. Frozen ingredients
b. Fresh ingredients
c. Yogurts
d. Powders
e. Leafy greens
f. Liquids
2. Place blade assembly in the jar opening with blades down.
3. Place jar base onto jar and rotate clockwise until it is tight. It is
important to tighten to prevent leaking during blending.
4. Turn single serve jar upside down, place on the blender base, and twist
clockwise to lock.
5. Select speed 1 or use pulse/ice crush to blend to desired consistency.
6. Once blending has finished, remove the single serve jar by twisting
counter-clockwise then lifting off the base. Turn the jar over and place it
on a flat surface.
Note: Always make sure blades have stopped moving before removing jar.
Important: If the jar gets stuck on the blending base or begins to loosen
from the jar base, follow these steps:
A. Unplug the unit
B. Turn the jar clockwise to tighten jar onto the jar base
7
7. Remove the jar base from the single serve jar by turning
counterclockwise. Then carefully remove blade assembly
8. Place the single serve lid on the single serve jar and enjoy your delicious
drinks on-the-go.
Caution: Blades are sharp. Handle carefully.
BLENDING TIPS AND TECHNIQUES
• Cut food into pieces no larger than 3⁄4" for use in the blender.
• When preparing foods that have several different kinds of ingredients,
always add liquid ingredients first when using the full size jar and last
when using the single serve jar.
• When ingredients splatter onto the sides of the jar or the mixture is
very thick, press the ON/OFF button to turn appliance off. Remove the
lid and use a rubber spatula to scrape down the sides of the jar and to
redistribute the food, pushing food toward the blades. Replace the lid and
continue blending.
• When making bread crumbs or blending dry goods, make sure blending
jar and blade assembly are completely dry.
• The PULSE/ICE CRUSH function is helpful when short bursts of power
are needed, such as when preparing thick smoothies or milkshakes. Do
not use pulse for more than 10 seconds at a time. Release the PULSE/ICE
CRUSH button regularly, allow the blender to rest briefly, then continue.
• Do not run blender for longer than 1 ½ minutes at a time.
• Do not use if blender jar is chipped or cracked.
• It is helpful to begin the blending process on the lowest speed and then
increase to a higher speed, if necessary.
• To stop blending at any time, press the ON/OFF button.
• Always operate the blender with the lid on the jar.
• Do not store foods in the blending jar.
• Do not overfill the blender (the blender is more efficient with less rather
than more).
DO NOT USE BLENDER TO BLEND:
• Hot Liquids
• Large pieces of frozen foods
• Tough foods such as raw turnips, sweet potatoes and potatoes
• Bones
• Hard salami, pepperoni
• Boiling liquids (cool for 5 minutes before place in blending jar)
• Egg whites
• Dough
• Meats
8
SPEED AND FUNCTION CHART
Function Food Type Speed Setting
1 Stir
Mix
Crumb
2 Chop
Whip
Blend
3 Dressings
Batters
Dips
Pulse/Ice Crush Pulse
Ice
Prepare salad dressings.
Mix ingredients for baked goods.
Make crumbs: cookie, cereal, bread.
Blend in the single serve jar.
Chop fruits, vegetables.
Whip whipped cream or butter.
Blend smoothies, sauces
Puree fruits and vegetables.
Blend milkshakes and malts.
Grind hard cheeses and coconut.
Pulse to desired consistency.
Crush ice to snow texture.
30 Second
Smoothie
Infuse Infused Water Preset function
Mix/Shakes Mix
Smoothies Preset function
Preset function
Milkshakes
CARE AND CLEANING
This product contains no user serviceable parts. Refer service to qualified
service personnel.
1. Before cleaning, turn off and unplug the appliance.
2. To remove the jar: grasp the handle and twist counter-clockwise, then lift
up.
3. Remove jar base by turning it counterclockwise until loose.
4. Remove the blade assembly.
Caution: Blades are sharp. Handle carefully.
5. Remove lid.
6. Wash removable parts by hand or in the dishwasher. Place the jar on the
bottom rack and the rest of the parts on the top rack only.
CLEANING TIPS
• For quick cleanup, combine 1 cup hot water and a drop of liquid dish soap
in the blending jar.
• Cover and blend on Speed 2 for about 30 seconds.
• Discard liquid and rinse thoroughly.
9
Important:
• Do not place the jar parts in boiling liquids.
• Do not immerse the base in liquid. Wipe the base with a damp cloth and
dry thoroughly.
• Remove stubborn spots by rubbing with a damp cloth and nonabrasive
cleaner.
Note: If liquids spill onto the base, wipe with a damp cloth and dry thoroughly.
Do not use rough scouring pads or cleansers on parts or finish.
TROUBLESHOOTING
Problem
LED blinking
quickly
(100 msec/time)
Blender stops/
goes into
STANDBY mode
Possible Cause Solution
Blender overheated or
button held longer
than 30 seconds.
Blending time exceeds
2.5 minutes.
Unit must be reset. Unplug to
reset. Let unit cool for at least
20 minutes.
Re-select appropriate speed
setting to start blender.
RECIPES
CLASSIC SMOOTHIE
Servings: 6
Serving Size: 8 oz.
4 cups apple juice
4 medium bananas, cut into 2 pieces
4 cups frozen whole strawberries
Place ingredients in blender in order shown above. Cover and blend for 15
seconds, or until smooth.
Tip: Substitute orange juice for apple juice
EASY FROZEN MARGARITA
Servings: 6
1/2 cup orange flavored liquor
1 cup tequila
1 (6 oz.) can frozen limeade mix
4 cups ice cubes
Place ingredients in blender with liquids first and ice last; cover. Blend on
AUTO setting 1. Serve with lime wedges if desired.
10
Loading...
