Model # 900149: Page 1
Bottom Loading
Bottled Water Dispenser
Model # 900149
USER MANUAL
PN O-035 © 2009 Primo Water Corporation
TO REDUCE THE RISK OF INJURY AND
PROPERTY DAMAGE, USER MUST READ
THIS MANUAL BEFORE ASSEMBLING,
INSTALLING & OPERATING DISPENSER.
SAVE THIS MANUAL FOR
FUTURE USE
Model # 900149: Page 2
SAFETY PRECAUTIONS
To reduce risk of injury and property damage, user must read this entire
manual before assembling, installing & operating dispenser.
Failure to execute the instructions in this manual can cause personal injury
or property damage.
This product dispenses water at very high temperatures. Failure to use
properly can cause personal injury.
When operating this dispenser, always exercise basic safety precautions,
including the following:
• Prior to use, this dispenser must be properly assembled and installed in accordance with
this manual.
• This dispenser is intended for water dispensing only. Do NOT use other liquids. Do NOT
use for other purposes. Never use any other liquid in the dispenser other than known and
microbiologically safe bottled water.
• For indoor use only. Keep water dispenser in a dry place away from direct sunlight. Do NOT
use outdoors.
• Install and use only on a hard, flat and level surface.
• Do NOT place dispenser into an enclosed space or cabinet.
• Do NOT operate dispenser in the presence of explosive fumes.
• Position back of dispenser no closer than 4 inches from wall and permit free airflow
between wall and dispenser. There must be at least 4 inches clearance on the sides of the
dispenser to permit airflow.
• Use only properly grounded outlets.
• Do not use an extension cord with your water dispenser.
• Always grasp plug and pull straight out from outlet. Never unplug by pulling on power cord.
• Do NOT use dispenser if cord becomes frayed or otherwise damaged.
• To protect against electric shock, do NOT immerse cord, plug, or any other part of cooler in
water or other liquids.
• Ensure dispenser is unplugged prior to cleaning.
• Never allow children to dispense hot water without proper and direct supervision. Unplug
unit to prevent unsupervised use by children.
• Service should be performed only by a certified technician. Please contact us at
866-429-7566 for assistance.
TABLE OF CONTENTS
Safety Precautions …………………………………………… 2
Key Information for Future Use ……………………………. 3
Specifications ………………………………………………… 4
Parts & Features …………………………………………….. 4
Assembly ……………………………………………………… 5
Installation ……………………………………………………. 5
Operation …………………………………………………….. 5
Proper Care & Cleaning ……………………………………. 9
Troubleshooting ……………………………………………… 11
Limited Warranty ……………………………………………… 12
KEY INFORMATION FOR FUTURE USE
Please register your dispenser immediately at
www.primowater.com.
For future support please record your serial number (located on
label on back of dispenser) and date purchased. Staple your
receipt to manual.
You will need this information to obtain warranty service.
Product Bottom Loading
Bottled Water Dispenser
Model Number 900149
Serial ID Number
Date of Purchase
Model # 900149: Page 3
Model # 900149: Page 4
SPECIFICATIONS
Power Supply 5 AMPs
Refrigerant Type R-134A
Cold Water Power 125 Watts
Cold Capacity / Hour 1.0 Gallons
Cold Temp Range 39!F – 59!F
Hot Water Power 425 Watts
Hot Capacity / Hour 1.0 Gallons
Hot Temp Range 149!F – 199!F
Dimensions 40.5 inches H x 12.6 inches W x 15.0
inches D
Net Weight 35.3 lbs.
PARTS & FEATURES
Energy Saving Switch - Cold
Front Back
LED Nightlights
Bottle Tray (Inside)
Bottle Probe (Inside Cabinet)
Hot Water Control
Hot Water Release
Hot Water Tap
Cold Water Tap
Drip Tray
1
2
3
4
5
6
7
8
9
11
Drain Plug
Carry Handle
Power Cord
1
2
3
4
5
6
7
8
9
13
15
10
14
12
13
14
Cold Water Control
12
15
Door
11
Energy Saving Switch - Hot
10
