Black Box VSW-HDMI4X4-B User Manual

4 x 4 HDMI Matrix Switch

Switch (4) HDMI source devices plus IR
to (4) HDMI displays.

Supports 1080p 3D HDMI or DVI formats + IR with RS-232
or IR remote control.

VSW-HDMI4X4-B

Customer

Support

Information

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: w ww.blackbox.com • E-mail : [e-mail]

724-746-5500 | blackbox.com

Trademarks Used in this Manual

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc.

Dolby and Dolby Digital are registered trademarks of Dolby Laboratories Licensing Corporation

HDMI is a registered trademark of HDMI Licensing L.L.C.

Xbox and Windows are registered trademarks of Microsoft Corporation.

Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

Page 2

We‘re here to help! If you have any questions about your application

or our products, contact Black Box Tech Support at 724-746-5500

or go to blackbox.com and click on “Talk to Black Box.”

You’ll be live with one of our technical experts in less than 30 seconds.

724-746-5500 | blackbox.com

FCC and IC RFI Statements

Federal Communications Commission and Industry Canada Radio Frequency Interference
Statements

This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict
accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to
comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules,
which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct the interference.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise emis sion from digital apparatus set out in the Radio
Interference Regulation of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de
la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.

724-746-5500 | blackbox.com

Page 3

724-746-5500 | blackbox.com

NOM Statement

Instrucciones de Seguridad
(Normas Oficiales Mexicanas Electrical Safety Statement)

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca
de una alberca, etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de operación.
Todo otro servicio deberá ser referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato eléctrico
sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en libreros o gabinetes
que impidan el flujo de aire por los orificios de ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros

aparatos (incluyendo amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como

se indique en el aparato.

12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados

sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

Page 4

724-746-5500 | blackbox.com

Safety Information

Safety Information

NOTE: THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS
MANUAL.

1. Save the carton and packing material even if the equipment has arrived in good condition. If you ever need to ship the unit, use only the

original factory packing.

2. Read all documentation before operating your equipment. Retain all documentation for future reference.

3. Follow all instructions printed on unit chassis for proper operation.

4. Do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.

5. Make sure power outlets conform to the power requirements listed on the back of the unit.

6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not likely to be

walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience receptacles, and
the point where they exit.

7. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the means

of grounding of a piece of equipment is not defeated.

8. Voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC voltage is not

covered by any warranty.

9. Power down and disconnect the unit from power voltage before making connections.

10. Never hold a power switch in the “ON” position.

11. Do not use the unit near stoves, heat registers, radiators, or other heat-producing devices.

12. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal flow

of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign matter.

13. Do not remove the cover. Removing the cover will expose you to potentially dangerous voltages. There are no user-serviceable parts inside.

14. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.

15. Non-use periods. The equipment’s power cord should be unplugged from the outlet when left unused for a long period of time.

16. Service information. Equipment should be serviced by qualified service personnel when:

A. The power supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the equipment.

C. The equipment has been exposed to rain.

D. The equipment does not appear to operate normally, or exhibits a marked change in performance.

E. The equipment has been dropped, or the enclosure damaged.

724-746-5500 | blackbox.com

Page 5

724-746-5500 | blackbox.com

Important Safety Instructions

IMPORTANT SAFETY INSTRUCTIONS

To get the best from this product, please read this manual carefully. Keep it in a safe place for future reference.

To reduce the risk of electric shock, do not remove the cover from the unit. No user-serviceable parts inside. Refer servicing to qualified
personnel.

To reduce the risk of fire, do not expose the unit to rain, water, or excessive moisture.

Do not force switched or external connections.

When moving the unit, disconnect the serial port connections first, then the power cable, and finally the interconnecting cables to other devic­es.

Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Use a clean, dry cloth.

Installation of this unit should be in a cool, dry place, away from sources of excessive heat, vibration, dust, moisture, and cold.

WARNING: To prevent electric shock do not use this (polarized) plug with an extension cord, receptacle, or other outlet unless the blades can

be fully inserted to prevent blade exposure. To prevent electric shock, match wide blade of plug to wide slot. Fully insert.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK), NO USER-SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

Page 6

724-746-5500 | blackbox.com

Table of Contents

Table of Contents

1. Specifications ......................................................................................................................................................................... 8

2. Overview ...............................................................................................................................................................................9

2.1 Introduction ...................................................................................................................................................................9

2.2 Features ......................................................................................................................................................................... 9

2.3 What’s Included ............................................................................................................................................................9

2.4 Hardware Description .................................................................................................................................................. 10

2.4.1 Front Panel ........................................................................................................................................................10

2.4.2 Rear Panel ......................................................................................................................................................... 11

3. Installation ........................................................................................................................................................................... 13

3.1 Installation Diagram .................................................................................................................................................... 13

3.2 IR Extender .................................................................................................................................................................. 14

4. Operation ............................................................................................................................................................................ 15

4.1 EDID Setup .................................................................................................................................................................. 15

4.2 Embedded EDID Modes .............................................................................................................................................. 15

4.3 Copy EDID ................................................................................................................................................................... 15

4.4 EDID Status .................................................................................................................................................................. 16

4.5 How to Set Up Fast Speed Start (FSS) Function ........................................................................................................... 17

4.6 Auto Mode Definition ................................................................................................................................................. 17

4.7 Consumer Electronics Control (CEC) Setup.................................................................................................................. 17

4.8 Front-Panel Control Functions .....................................................................................................................................18

4.9 Remote Control ...........................................................................................................................................................18

4.10 IR Remote Custom and Data Codes (NEC Standard) ................................................................................................... 19

5. RS-232 Serial Interface ......................................................................................................................................................... 20

5.1 Connect a PC or Control System .................................................................................................................................20

5.2 RS-232 Protocol Commands ........................................................................................................................................20

6. Troubleshooting ................................................................................................................................................................... 21

6.1 Contacting Black Box...................................................................................................................................................21

6.2 Shipping and Packaging ..............................................................................................................................................21

724-746-5500 | blackbox.com

Page 7

724-746-5500 | blackbox.com

Chapter 1: Specifications

1. Specifications

Controls — IR remote control, IR external port with (1) 3.5-mm earphone jack, Select and Function buttons on front panel,

RS-232 series interface

Digital Audio Support — Multi audio formats 5.1/7.1, MAT (MLP), Dolby Digital, Dolby TrueHD, Dolby Digital Plus, DTS,
DTS-ES 6.1, DTS-HD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)

Digital Video Support — Full HD resolution: 480i, 480p, 720p, 1080i, 1080p

Function Control Key — ALL/OFF/RECALL/ENTER/MEMORY/LOCK/EDID

HDCP/CEC Support — HDCP 2.0 compliant, CEC compliant

HDMI I/O Connector — HDMI Type A, SMD 19-pin female

HDMI Support — HD 1080p @ 60 Hz, H36-bit deep color, 3D (1.4a) formats

Infrared Frequency — 38 kHz

IR External Distance — 1000 feet (300 m) maximum

Preview Output — Supports (1) preview output port simultaneously via Output #1

Safety Approvals — CE, FCC, RoHS

Source Status — Automatically scan sources inputs via LED

Temperature Tolerance — Operating: 32 to 100° F (0 to 38° C)

Video Bandwidth — Double data rates: 340 MHz, total 6.75-Gbps bandwidth

Power — Input: 100–230 VAC, 50/60 Hz;

Output: 12 VDC, 3 A;
Consumption: 3880 mA maximum

Size — 1.75"H (1U) x 9.85"W x 19"D (4.4 x 25 x 48.2 cm)

Weight — 3.08 lb. (1.85 kg)
