Black Box MT1000A-13-R3, MT1000A-85-R3 Quick Start Manual

Download

May 2006

MT1000A-13-R3

MT1000A-85-R3

T1 Fiber Multiplexer

CUSTOMER

SUPPORT

INFORMATION

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com

Quick Start Guide

If you are familiar with the MT1000A, use this guide to prepare it for operation. Perform the following steps.

1. Installing MT1000A

Connecting the Tributary T1 Interfaces

 To connect the balanced T1 interface (RJ-45 connector)

• Connect the RJ-45 connector of the cable to the T1 port.

Connecting the Uplink

 To connect a fiber optic uplink

1. Clean the optical connectors using an approved solvent, and dry thoroughly using optical tissue.

2. Connect to the two optical connectors designated TX (transmit output) and RX (receive input) of the appropriate interface.

3. Pay attention to correct connection of the transmit and receive cables to the corresponding connectors. Avoid sharp bends and twisting of the fiber-optic cables.

Note

For WDM option, only one fiber optic cable per link should be connected.

Installing MT1000A 1

Quick Start Guide MT1000A Installation and Operation Manual

Connecting the Power

Before switching ON this unit and before connecting or disconnecting any other cable, the protective earth terminals of this instrument must be connected to the protective ground conductor of the mains (AC or DC) power

Warning

cord. If you are using an extension cord (power cable) make sure it is grounded as well.

Any interruption of the protective grounding conductor (inside or outside the instrument) or disconnecting the protective earth terminal can make this unit dangerous. Intentional interruption is prohibited.

Connecting the AC/DC Power

The MT1000A is supplied with a Wide Range AC/DC power supply. The widerange AC/DC power supply accepts current from both AC and DC sources. From an AC source, the power supply can receive any voltage in the range of 100 VAC to 240 VAC. From a DC source, the 48 VDC power supply can receive any voltage in the range of 36 to 72 VDC.

This unit is equipped with a standard AC-type 3-prong power input connector located on the unit rear panel. This power input connector can be used for both AC and DC voltage inputs. AC or DC power should be supplied to MT1000A through the 5-feet (1.5m) standard power cable terminated by a standard 3-prong plug.

 To connect MT1000A to AC power:

1. Connect the power cable to the connector on the MT1000A rear panel.

2. Connect the power cable to the electricity outlet.

 To connect MT1000A to 48V DC power:

• Refer to the green Supplement at the end of this manual titled:

DC Power Supply Connection – AC/DC Adaptor (AD) Plug.

Connecting the DC Power

When connecting the DC power, the PWR pin must be connected to the ungrounded line of the central battery (either − or +). The RTN pin must be connected to the grounded line of the central battery. The GND pin must be connected to the protected earth of the building installation.

 To connect MT1000A to 24V DC power:

• Refer to the green Supplement at the end of this manual titled:

DC Power Supply Connection – Terminal Block Connector.

Caution

2 Installing MT1000A

The DC installation procedure must be performed by a qualified technician.

Contents

Chapter 1. Introduction

1.1 Overview..................................................................................................................... 1-1

General ................................................................................................................................1-1

Features................................................................................................................................ 1-1

Application ........................................................................................................................... 1-2

1.2 Physical Description..................................................................................................... 1-2

Physical Characteristics .........................................................................................................1-2

1.3 Functional Description................................................................................................. 1-3

Fiber Optic Link....................................................................................................................1-3

Tributary Interface Characteristics .........................................................................................1-4

Test and Diagnostics Capabilities........................................................................................... 1-5

Alarms and Alarm Indications................................................................................................ 1-5

Management and Monitoring................................................................................................1-6

Power Requirements............................................................................................................. 1-6

1.4 Technical Specifications............................................................................................... 1-7

Chapter 2. Installation and Setup

2.1 Introduction................................................................................................................. 2-1

2.2 Site Requirements & Prerequisites ............................................................................... 2-1

Power................................................................................................................................... 2-1

Tributary Connections...........................................................................................................2-1

Fiber Optic Link Connections................................................................................................2-2

Front and Rear Panel Clearance ............................................................................................2-2

Unit Clearance .....................................................................................................................2-2

Ambient Requirements .........................................................................................................2-2

2.3 Equipment Needed ..................................................................................................... 2-2

2.4 Package Contents ........................................................................................................2-2

2.5 Installation and Setup .................................................................................................. 2-3

Setting the Internal Switches .................................................................................................2-3

2.6 Interfaces and Connections.......................................................................................... 2-6

Connector Location .............................................................................................................. 2-6

Grounding............................................................................................................................ 2-7

Connecting the Power ..........................................................................................................2-7

Chapter 3. Operation

3.1 General ....................................................................................................................... 3-1

3.2 Turning MT1000A On ................................................................................................. 3-1

3.3 Front Panel Indicators and Switches............................................................................. 3-1

3.4 Normal Indications ...................................................................................................... 3-3

3.5 Turning MT1000A Off ................................................................................................. 3-3

Chapter 4. Configuration

4.1 Introduction................................................................................................................. 4-1

Terminal Management Modes...............................................................................................4-1

4.2 Setting Terminal Communication................................................................................. 4-1

MT1000A Installation and Operation Manual i

Table of Contents

Setting the Terminal Communication Parameters ..................................................................4-1

Entering the Terminal Session................................................................................................4-2

4.3 Monitoring the System................................................................................................. 4-4

Monitoring the Status of the Local System .............................................................................4-5

Monitoring the Status of the Remote System..........................................................................4-7

4.4 Monitoring the Physical Ports....................................................................................... 4-7

Monitoring the Status of the Ethernet Port .............................................................................4-8

Monitoring the Status of the Up-Link.....................................................................................4-9

Monitoring the Status of the Channel Port............................................................................. 4-9

4.5 Working with the System Log File .............................................................................. 4-10

Displaying the System Log File ............................................................................................4-10

Clearing the System Log File................................................................................................4-11

4.6 Alarms ....................................................................................................................... 4-11

Displaying System Alarms.................................................................................................... 4-11

Displaying Physical Port Alarms........................................................................................... 4-12

4.7 Configuring the MT1000A .........................................................................................4-13

Configuring redundancy......................................................................................................4-13

Setting the Device Information............................................................................................4-16

Setting the network parameters........................................................................................... 4-17

Setting up the Manager List................................................................................................. 4-18

Setting the Management Access ..........................................................................................4-18

Setting the User Name and Password.................................................................................. 4-19

Configuring the Control Port ...............................................................................................4-20

Resetting the Factory Defaults ............................................................................................. 4-21

Resetting the MT1000A ......................................................................................................4-21

4.8 Configuring the Physical Ports .................................................................................... 4-21

Configuring the Ethernet Port.............................................................................................. 4-21

Configuring the Channels....................................................................................................4-23

Configuring the Up-Links .................................................................................................... 4-23

4.9 Diagnostics ................................................................................................................ 4-24

Setting the E2 Local Loopback Timeout............................................................................... 4-24

Setting Loopbacks in the Local MT1000A............................................................................ 4-25

Setting Loopbacks in the Remote MT1000A........................................................................ 4-26

Displaying Loop Status........................................................................................................ 4-26

4.10 Viewing Hardware and Software Updates.................................................................. 4-27

4.11 Downloading Software .............................................................................................. 4-27

Downloading Software using the TFTP Protocol...................................................................4-27

Downloading Software using the X-Modem Protocol........................................................... 4-29

4.12 Viewing file and file system information ..................................................................... 4-29

Chapter 5. Testing and Diagnostics

5.1 Introduction................................................................................................................. 5-1

5.2 Troubleshooting........................................................................................................... 5-1

5.3 List of Alarms and Events ............................................................................................. 5-3

5.4 Diagnostic Tests ........................................................................................................... 5-4

Local Loopbacks in the MT1000A......................................................................................... 5-5

Remote Loopbacks in the MT1000A ..................................................................................... 5-7

Appendix A. Interface Specifications

Appendix B. MT1000A MIBs

ii MT1000A Installation and Operation Manual

General

Chapter 1 Introduction

1.1 Overview

MT1000A is a second-order multiplexer that combines four T1 (1.544 Mbps) tributary data streams into a single fiber optic link.

The fiber optic interface provides a secure link in hazardous or hostile environments, increases the maximum connection range, and achieves immunity against electrical interference and protection against the harmful effects of ground loops.

Features

The main features of the MT1000A multiplexer are:

• MT1000A multiplexes four T1 channels over a single fiber optic link

• A pair of MT1000A units offers simple connectivity for four T1 channels at

distances of up to 120 km (74.5 miles)

• Redundant power supply

• Optional second fiber optic link for automatic backup

• Operates with multimode or single mode fiber; and single mode over single

fiber in the standalone version (WDM)

• An optional second power supply for power redundancy and fail-safe operation

• Transmits each of the T1 channels independently, so that each T1 channel can have it’s own clock source

• To facilitate system diagnostics, MT1000A features LED status indicators, AIS alarm generation, recognition and dry contact closure upon link failure.

• Setup, control and diagnostics can be performed via ASCII terminal, SNMP management station, or Ethernet link using Telnet or Web-based management interface

• Conforms to ITU G.703, G.823, G.824 and G.955

• Compact 1U high size.

Overview 1-1

Chapter 1 Introduction MT1000A Installation and Operation Manual

Application

Video Conferencing

PBX

Mux

Router

The following diagram illustrates a typical MT1000A configuration:

ASCII terminal linked to supervisory port

Fiber Link

(Optional) Backup Fiber Link

ASCII terminal linked

to supervisory port

Figure 1-1 Typical MT1000A Application

1.2 Physical Description

Video Conferencing

PBX

Mux

Router

Physical Characteristics

MT1000A is a compact unit, intended for installation on desktops or shelves. Unit height is only 1U (1.75"). An optional rack-mount adapter kit enables installation of MT1000A unit in a 19" rack.

The MT1000A front panel provides LED indicators, a control connector and a headset jack, as illustrated in Figure 1-2. For more information about front panel indicators and connectors, refer to Chapter 2.

Power connector/s, fiber optic connectors and T1 interfaces can be accessed via the MT1000A rear panel. For more information about rear panel connectors, refer to Chapter 2.

Figure 1-2 MT1000A Front Panel

1-2 Physical Description

MT1000A Installation and Operation Manual Chapter 1 Introduction

1.3 Functional Description

MT1000A contains the following printed circuit boards:

• One main circuit board that includes four tributary interfaces

• One or two fiber optic interface boards (A and B)

• One or two power supplies (A and B): AC/48 VDC wide-range power supply

or 24VDC power supply.

Fiber Optic Link

Fiber Optic Link Interface Characteristics

The fiber optic interface can be used to provide a secure link in hazardous or hostile environments, increase the maximum connection range, and achieve immunity against electrical interference and protection against the harmful effects of ground loops.

The fiber optic interface complies with the requirements of ITU-T Rec. G.956, and uses a proprietary signaling format that ensures optimum performance. To optimally meet a wide range of system requirements, the fiber optic interface can be ordered for operation over 62.5/125 micron multi-mode fibers (typical attenuation 3.5 dB/km at 850 nm), as well as over low-loss 9/125-micron singlemode fibers (typical attenuation 0.4 dB/km at 1310 nm, and 0.25 dB/km at 1550 nm). Most of the options can be ordered with ST, SC, or FC/PC connectors. In addition, 9/125-micron single mode over a single fiber is also available (with SC connectors only).

Not

The SF3 option uses an SC/APC connector. The FO cable connected to it must therefore be of the same type.

Table 1-1 provides information on the characteristics of the optical sub-system,

including the maximum range over typical fiber optic cable. The maximum range values given in the table assume a 3 dB margin.

Functional Description 1-3

Chapter 1 Introduction MT1000A Installation and Operation Manual

Table 1-1 Fiber Optic Interface Characteristics

Wavelength

[nm]

850 62.5/125

1310 9/125

1310 Transmit/Receive

1310/1550 Transmit/Receive

1550/1310 Transmit/Receive

1550 9/125 single

Fiber Type

[µm]

multimode

single mode

9/125 single mode

mode

Transmitter Type Typical

Laser (VCSEL) -15 -34 4.5 2.8 ST, SC,

Laser -12 -34 47 29.2 ST, SC

Laser [long haul]

Laser [SF3] -12 -27 20 12.4 SC/APC only

Laser WDM [SF1] -12 -34 47 29.2 SC

Laser WDM [SF2] -12 -34 47 29.2 SC

Laser -12 -34 76 47.2 ST, SC,

Laser [long haul]

Receiver Output Power [dBm]

-2 -34 72 44.7 ST, SC,

-1 -34 120 74.5 ST, SC,

Sensitivity

[dBm]

Typical Max. Range

[km miles]

Connector Type

FC/PC

All the fiber optic interface options offer high performance and have a wide dynamic range, which ensures that the receiver does not saturate even when using short fiber optic cables (saturation is caused when the optical power applied to the receiver exceeds its maximum allowed input power, and results in very high bit error rates).

Fiber Optic Link Redundancy Option

MT1000A can be ordered with one or two link interface options. Each interface operates independently, and can be ordered from any of the link options listed above.

In the fiber optic link redundancy option, MT1000A supports fully automatic switching between link A and link B. Link A has priority. Therefore, normally link A is selected for use, and link B is disabled. In case a failure occurs on link A, MT1000A automatically switches to link B and continues providing normal service. After link A returns to normal operation, it is automatically reselected.

Each link interface has its own set of indicators that show the current state of the link. AIS alarm will not appear for the non-active optical link.

Tributary Interface Characteristics

The MT1000A tributary interfaces meet the requirements of ITU-T Rec. G.703. Each tributary port has a 100Ω balanced line interface terminated in an RJ-45 eight-pin connector.

1-4 Functional Description

MT1000A Installation and Operation Manual Chapter 1 Introduction

Line coding is B8ZS or AMI. The nominal balanced interface transmit level is ±3.0 V. The line attenuation is up to 12 dB, and each T1 signal is processed by an adaptive equalizer that compensates for various cable lengths to ensure optimal performance. Phase Locked Loops (PLL) are used to recover the clock signals, and the resulting jitter performance complies with the requirements of ITU-T Rec. G.824.

Each tributary interface has its own set of indicators that show the current state of the tributary link. The user can disable the alarm indications generated by unused interfaces (via internal switch and terminal, see section 2.5). AIS data streams are transmitted instead of failed or unconnected tributary data streams.

Test and Diagnostics Capabilities

MT1000A has comprehensive test and diagnostics capabilities that include local and remote loopbacks on the fiber optic link interface and on each tributary link. The activation is performed by sending a special test sequence through the fiber optic link. An automatic self-test on power-up further enhances maintenance.

For more information on activating loopbacks see Chapter 4.

Alarms and Alarm Indications

MT1000A can detect the following alarm conditions on each T1 and fiber optic interface:

• Loss of input signal

• Loss of frame synchronization

• Reception of alarm indication (AIS) signal, which consists of a continuous

sequence of 1s.

Notes

• When AIS is received, loss of frame synchronization occurs. However, in this case the alarm indicating the loss of frame synchronization is suppressed.

• AIS alarm will not appear for the non-active optical link.

When not all the tributaries are in use, the user can disable the alarm indications related to the unused tributaries.

The response to alarm conditions is as follows:

• AIS is transmitted on each tributary output in the following cases:

 Loss of fiber optic input signal is detected

 AIS is received on the fiber optic input

 Loss of fiber optic frame synchronization.

• For each tributary, an AIS signal is sent instead of the tributary data stream

through the fiber optic link in the following cases:

 Loss of tributary input signal is detected

 AIS is received on the tributary input

 Loss of tributary frame synchronization.

Functional Description 1-5

Chapter 1 Introduction MT1000A Installation and Operation Manual

Front panel indicators display each alarm condition. In addition, a dedicated connector is used to provide major and minor alarm indications, by means of dry contacts.

The major alarm is activated in the following cases:

• MT1000A is not powered, or total power supply failure (e.g., when two power

supplies are installed, failure of both supplies).

• Loss of fiber optic input signals, or loss of fiber optic frame synchronization.

• Loss of tributary input signals, or loss of frame synchronization

• Unable to activate redundancy.

The minor alarm is activated in the following cases:

• Reception of AIS signal on the fiber optic input.

• Reception of AIS signal on tributary inputs.

Management and Monitoring

MT1000A units are equipped with a front panel serial RS-232 management port and an Ethernet management port. The RS-232 port operates at user-selectable rates of 9.6, 19.2, 38.4, 57.6 and 115.2 kbps over a null-modem cable. The Ethernet port operates at a rate of 10 Mbps and can be set to full- or half-duplex.

The management interface supports the following management methods:

• Supervision Terminal–An ASCII terminal connected to the RS-232 port (or a

PC running a terminal emulation program) can be used as a supervision terminal. All software required for the various management functions available through the terminal is contained in the MT1000A.

• SNMP Management–The management interface includes an SNMP agent that

enables SNMP management of the MT1000A, using the UDP-over-SLIP (Serial Link Internet Protocol) protocol. The SNMP agent also enables management by other SNMP-based systems.

• Ethernet Management–A management terminal can be connected to the

MT1000A via an Ethernet connection, using a UTP-CAT5 cable. The 10BaseT Ethernet interface supports a throughput of 10 Mbps. All software required for the various management functions available through the terminal is contained in the MT1000A.

Power Requirements

MT1000A can be ordered with one or two power supplies. Two types of power supplies are available:

• AC/DC wide-range for operation on AC (100 to 240 VAC) or on

DC (40-72 VDC) sources

• DC operation on 24 VDC source.

Each power supply (A and B) can be ordered as one of the above power supply types).

1-6 Functional Description

MT1000A Installation and Operation Manual Chapter 1 Introduction

When two power supplies are installed, they share the load; in case one of the supplies fails or its input power is disconnected, the other power supply continues providing power to MT1000A.

1.4 Technical Specifications

Fiber Optic Interface Characteristics

Applicable Standards

Performance

Connectors

T1 Tributary Interface Characteristics

Applicable Standards

Nominal Line Data Rate

Line Code

Line Impedance

Signal Levels

Transmit Levels

ITU-T Rec. G.956

Refer to Table 1-1

ST, SC, or FC-PC, in accordance with ordered option (SF1/SF2 options only available with SC) (SF3 option only available with SC/APC)

ITU-T Rec. G.703, G.824

1.544 Mbps

B8ZS / AMI

100Ω, balanced

±3.0 V ±20%

Indicators

Technical Specifications 1-7

Receive Levels

Jitter Performance

Connector

0 dB to –12 dB

Per ITU-T Rec. G.824

RJ-45

Loss of input signal for the fiber optic link and for each tributary

Reception of AIS signal for the fiber optic link and for each tributary (loss of frame synchronization alarm suppressed)

TEST (when loopbacks are active)

Power on

Active Receiving link

Chapter 1 Introduction MT1000A Installation and Operation Manual

CONTROL DTE Supervisory Port (Optional)

MNG-ETH

ALARM

Interface

Connector

Data Rate

Physical Interface

Data Rate

Transmission Mode

Connector

Cable Type

Connector

V.24/RS-232, asynchronous DTE interface

9-pin D-type female connector

9.6, 19.2, 38.4, 57.6 and 115.2 kbps

10BaseT

10 Mbps

Full/Half-duplex

Shielded RJ-45

UTP-CAT5

Physical Characteristics

Power Requirements

Connector

Contact Functions

Contact Rating

Height

Width

Depth

Weight

AC/DC Powered Units

9-pin D-type female connector

Set of floating normally-closed/normally-open contacts for major and minor alarm indication

Maximum 1A (at 30 VDC or 30 VAC) through closed contacts

44 mm / 1.75 in (1U)

440 mm / 17.4 in

240 mm / 9.5 in

2 kg / 4.4 lb

100 to 240 VAC, 50 or 60 Hz, 13.5 VA

-or40–72 VDC, 9.5 W

1-8 Technical Specifications

DC Powered Units

Note: MT1000A can support up to two (redundant) power supplies.

24 VDC, 7.5 W

MT1000A Installation and Operation Manual Chapter 1 Introduction

Environment

Operating Temperature

Relative Humidity

0° to 50°C (32° to 122°F)

Up to 90%, non-condensing

Technical Specifications 1-9

Chapter 1 Introduction MT1000A Installation and Operation Manual

1-10 Technical Specifications

Chapter 2 Installation and Setup

2.1 Introduction

MT1000A is delivered completely assembled. It is designed for operation as a desktop unit or for mounting in a 19-inch rack. For instructions of rack mounting, refer to the Rack Mounting Kit for 19 inch Racks guide that comes with the RM kit.

Mechanical and electrical installation procedures for MT1000A are provided in the following sections.

After installing the unit, refer to Chapter 3 for operating instructions and system configuration procedures.

Warning

Power

In case a problem is encountered, refer to Chapter 5 for test and diagnostics instructions.

No internal settings, adjustment, maintenance, or repairs may be performed by either the operator or the user; such activities may be performed only by a skilled technician who is aware of the hazards involved. Always observe standard safety precautions during installation, operation, and maintenance of this product.

2.2 Site Requirements & Prerequisites

AC/DC-powered MT1000A units should be installed within 1.5m (5 feet) of an easily accessible grounded AC outlet capable of furnishing a supply voltage in the range of 100 to 240 VAC or 40–72 VDC.

DC-powered MT1000A units require a 24 VDC power source.

Tributary Connections

Each MT1000A tributary interface has one RJ-45 connector. Appendix A provides the pin allocation for the RJ-45 connector.

The maximum allowable line attenuation between each tributary port and the user's equipment is 12 dB.

Site Requirements & Prerequisites 2-1

Chapter 2 Installation and Setup MT1000A Installation and Operation Manual

Fiber Optic Link Connections

Each fiber optic link interface is terminated in two ST, SC, or FC-PC connectors, in accordance with order. The maximum allowable attenuation depends on the interface option ordered (refer to Table 1-1).

When working with the WDM option, only one fiber optic cable per link should be connected. The two types – SF1 and SF2 – must work opposite each other; SF1 cannot work opposite SF1, and SF2 cannot work opposite SF2.

Front and Rear Panel Clearance

Allow at least 90 cm (36 inches) of frontal clearance for operator access. Allow at least 10 cm (4 inches) clearance at the rear of the unit for interface cable connections.

When planning the routing of fiber optic cables, avoid sharp bends.

Unit Clearance

Allow 1U clearance above MT1000A-E1 for proper ventilation.

Ambient Requirements

The ambient operating temperature of the MT1000A is 0° to 50°C (32° to 122°F), at a relative humidity of up to 90%, non-condensing.

2.3 Equipment Needed

The equipment needed to install the MT1000A is:

• ST, SC or FC/PC fiber optic interface link connector cables

• RJ-45 T1 connector cables (for tributary interface)

• Phillips screwdriver (for installation in 19 inch rack).

2.4 Package Contents

The MT1000A package contains the following:

• MT1000A multiplexer

• CBL-DB9M/DB9F cable

• Two power supply cables

• AC/DC Adaptor (AD) plug

• MT1000A Installation and Operation manual

2-2 Package Contents

MT1000A Installation and Operation Manual Chapter 2 Installation and Setup

2.5 Installation and Setup



To install MT1000A:

1. Set the internal switches.

2. Connect MT1000A’s various interfaces in the order listed here.

This module may include Class A or Class 1 lasers. For your safety:

• Do not look directly into the optical connectors while the module is

Warning

operating. Remember that the MT1000A starts operating as soon as it is powered.

• Do not attempt to adjust the laser drive current.

The use of optical instruments with this product will increase eye hazard. Laser power up to 1 mW at 850 nm and at 1310 nm could be collected by an optical instrument. Use of controls or adjustment or performing procedures other than those specified herein may result in hazardous radiation exposure. WARNING: The laser beam is invisible.

Setting the Internal Switches

Prior to MT1000A installation, check the positions of its internal switches. If necessary, change the settings in accordance with the specific requirements of your application.

Opening MT1000A Case



To open MT1000A and access reach the internal switches:

1. Disconnect all the cables connected to MT1000A.

2. Unscrew the eight screws on the top panel.

3. Unscrew the screws on both side panels.

4. Remove the top cover.

Installation and Setup 2-3

Chapter 2 Installation and Setup MT1000A Installation and Operation Manual

Access to the inside of the equipment is permitted only to qualified and authorized service personnel. To avoid accidental electric shock, always disconnect the unit from the power line and from all the cables before removing the cover.

Warning

Dangerous high voltages are present inside the MT1000A when it is connected to power and/or to the links. Moreover, under external fault conditions, dangerous high voltages may appear on the lines connected to the MT1000A. Any adjustment, maintenance, and repair of the opened instrument under voltage should be avoided as much as possible and, when inevitable, would be carried out only by a skilled technician who is aware of the hazard involved. Capacitors inside the instrument may still be charged even after the instrument has been disconnected form its source of supply.

Caution

The MT1000A contains components sensitive to electrostatic discharge (ESD). To prevent ESD damage, avoid touching the internal components, unless also touching the MT1000A frame.

There are jumpers that are not listed below. They are set by the manufacturer and should not be touched.

Setting the Internal Switches

The internal switches are located on the MT1000A main and interface boards as identified in Figure 2-1. The functions of the switches are described in Table 2-1.



To set the switches:

1. Identify the switch locations, refer to Figure 2-1.

2. Change the settings as required (refer to the following table for settings).

2-4 Installation and Setup

MT1000A Installation and Operation Manual Chapter 2 Installation and Setup

ALARMS MASK

OFF

LINK B

ALARMS MASK

CH1

CH2

CH3

CH4

SW3

OFF ON

INTERFACE BOARD

LINK A INTERFACE BOARD

Figure 2-1 MT1000A Main Board, Internal Settings

Table 2-1. MT1000A Switch Settings

Switches Description Values Factory

Setting

SW3 Tributary Alarms Mask

Along with the software, controls the operation of the alarms and whether they are ignored or processed

SW3-1 sets CH 1

SW3-2 sets CH 2

SW3-3 sets CH 3

SW3-4 sets CH 4

OFF—The decision whether the alarm (of the specific channel) is masked or not is determined by the software setting.

ON—Mask the channel. This channel will not request a relay activation command. The software will indicate the stattus of this channel, but the status cannot be changed via the software.

OFF

Installation and Setup 2-5

Chapter 2 Installation and Setup MT1000A Installation and Operation Manual

Closing the MT1000A Cover

After completing the internal settings, replace the cover on the unit.



To close the cover:

1. Place the top cover on the unit.

2. Insert the screw on both side panels.

3. Insert the eight screws on the top panel

Not

Insert the original cover screws in their positions and tighten carefully. Do not use excessive force.

2.6 Interfaces and Connections

Connector Location

Figure 2-2 shows a typical MT1000A rear panel, and identifies connector locations.

Power

Connector

Connector pin allocations appear in Appendix A.

Optional Backup

Power Supply

Alarm Connector

Fiber Optic Links T1 Tributary Channels

TX RX TX RX

Figure 2-2 Typical MT1000A Rear Panel

Connecting the Tributary Channels

Each tributary interface includes one RJ-45 connector.



To connect the tributary channels:

• Connect each of the tributary cables to the connector(s) corresponding to the

interface in use. Connect to the RJ-45 connectors designated CH1, CH2, CH3 and CH4.

Connecting the Fiber Optic Links

Each fiber optic interface is terminated in two ST, FC or FC/PC connectors, in accordance with the ordered option. The connection to the fiber optic link (A and B) is made using one of two groups of connectors – one for link A and the other for the optional link B. The connector types (ST, SC, FC/PC) depend on the interface option in use.

2-6 Interfaces and Connections

MT1000A Installation and Operation Manual Chapter 2 Installation and Setup



To connect the fiber optic links:

1. Before connecting, clean the optical connectors using an approved solvent and

dry thoroughly using optical tissue.

2. For each fiber optic link interface (A and B), connect two optical cables to the

two optical connectors designated TX (transmit output) and RX (receive input) of the appropriate interface. Pay attention to correct connection of the transmit and receive cables to the corresponding connectors. Avoid sharp bends and twisting of the fiber optic cables.

3. For the WDM option, only one fiber optic cable per link should be connected.

Connecting the Alarm Relays

The ALARM connector is used to connect to the changeover contacts of the major and minor alarm relays.



To connect the alarm relays:

• Connect the cable to the ALARM connector on the rear panel.

Grounding

The connection of the protective ground is accomplished through one of the pins of the power connector, both for the AC and DC versions.

This instrument may become dangerous if damage to the protective (grounding) conductor (inside or outside the instrument) occurs or if disconnecting from the protective ground terminal.

Warning



To ground MT1000A:

• Connect the protective ground terminals of the MT1000A to the protective

ground conductor of the power cord.

Connecting the Power

Figure 2-2 shows a typical rear panel power for an MT1000A unit with a dual AC power supply. When only one power supply unit is installed, the rear panel includes a single power connector.

The wide-range AC/DC power supply inside the MT1000A accepts current from both AC and DC sources. From an AC source, the power supply can receive any voltage in the range of 100 to 240 VAC. From a DC source, the 48 VDC power supply can receive any voltage in the range of 40 to 72 VDC.

Interfaces and Connections 2-7

Chapter 2 Installation and Setup MT1000A Installation and Operation Manual

Before switching on this instrument, the protective earth terminals of the instrument must be connected to the protective ground conductor of the power cord. The power plug may only be inserted in a power outlet provided with a protective earth contact. The protective action must not be negated by

Warning

the use of an extension cord (power cable) without a protective conductor (grounding).

Whenever it is likely that the protection offered by the internal fuses has been impaired, the instrument must be made inoperative and be secured against any unintended operation.

Connecting the AC/DC Power

The MT1000A is supplied with a Wide Range AC/DC power supply. This unit is equipped with a standard AC-type 3-prong power input connector located on the unit rear panel. This power input connector can be used for both AC and DC voltage inputs. AC or DC power should be supplied to MT1000A through the 5feet (1.5m) standard power cable terminated by a standard 3-prong plug.



To connect MT1000A to AC power:



Caution

1. Connect the power cable to the connector on the MT1000A rear panel.

2. Connect the power cable to the electricity outlet.

To connect MT1000A to 48V DC power:

• Refer to the green Supplement at the end of this manual titled:

DC Power Supply Connection – AC/DC Adaptor (AD) Plug.

Connecting the DC Power

To connect MT1000A to 24V DC power:

• Refer to the green Supplement at the end of this manual titled:

DC Power Supply Connection – Terminal Block Connector.

The DC installation procedure must be performed by a qualified technician.

2-8 Interfaces and Connections

Chapter 3 Operation

3.1 General

In this chapter you will find detailed instructions for operating the MT1000A.

The information presented in this chapter includes a description of the MT1000A front panel controls, and operating procedures (turning on, front-panel indications, and turning off).

3.2 Turning MT1000A On



To turn on an MT1000A unit with a single power supply:

1. Connect the power cable to the power connector on the rear panel of the

MT1000A.

2. Connect the power cable to the electricity outlet.

The PWR A indicator lights in green.



To turn on an MT1000A unit with two power supply units:

1. Connect each power cable to a power connector on the rear panel of the

MT1000A.

2. Connect each power cable to the electricity outlet.

The corresponding PWR indicator(s) light in green.

3.3 Front Panel Indicators and Switches

Figure 3-1 shows the front panel of the MT1000A. Table 3-1 lists the functions of

the MT1000A controls, connectors and indicators located on the MT1000A front panel. The index numbers in Table 3-1 correspond to the item numbers in Figure 3-1.

Front Panel Indicators and Switches 3-1

Chapter 3 Operation MT1000A Installation and Operation Manual

Figure 3-1 MT1000A Front Panel

Table 3-1 MT1000A Controls, Connectors and Indicators

NO Control or Indicator Function

1 PWR A indicator ON (green) – Power supply A is turned on and is operating normally.

ON (red) – Power supply A is turned on and a malfunction has been

detected or is not been turned on. In this case, MT1000A continues to operate normally using power supply B (when installed).

2 PWR B indicator ON (green) – Power supply B is turned on and is operating normally.

ON (red) – Power supply B is turned on and a malfunction has been detected or has not been turned on. In this case, MT1000A continues to operate normally using power supply A.

Off – Power supply B is not assembled.

3 ALARM CUT OFF (ACO)

push-button

When this button is pressed, the indication of current alarms is suppressed and only new alarms are indicated.

4 TST indicator ON – The MT1000A is in test condition (local or remote loopback).

5 ON LINE A indicator ON – Link A is active.

OFF – Link A is not active.

6 ON LINE B indicator ON – Link B is active.

OFF – Link B is not active.

7 SYNC LOSS LINK A

ON – Link A bit error rate exceeds 10-6.

indicator

8 SYNC LOSS LINK B

ON – Link B bit error rate exceeds 10-6.

indicator

9 AIS LINK A indicator ON – AIS signal is received on link A.

10 AIS LINK B indicator ON – AIS signal is received on link B.

SYNC LOSS CH1 indicator

ON – The corresponding tributary interface reports loss of input signal.

SYNC LOSS CH2 indicator

SYNC LOSS CH3 indicator

SYNC LOSS CH4 indicator

3-2 Front Panel Indicators and Switches

MT1000A Installation and Operation Manual Chapter 3 Operation

Table 3-1. MT1000A Controls, Connectors and Indicators (Cont.)

NO Control or Indicator Function

AIS CH1 indicator

AIS CH2 indicator

AIS CH3 indicator

AIS CH4 indicator

MNG-ETH connector

MNG-ETH ACT indicator

19A

MNG-ETH LINK indicator

19B

20 CONTROL connector Connection to the optional management interface.

ON – AIS signal is output by the corresponding tributary interface.

Connection to the optional management Ethernet interface.

ON – Data is being transferred on the Ethernet link.

ON – The Ethernet line is "alive".

3.4 Normal Indications

During normal operation:

• The PWR indicators of the active power supply sources light in green.

• The indicator corresponding to the fiber optic link in use (A or B) is lit.

• All the SYNC LOSS, AIS, and TST front-panel indicators are not lit.

3.5 Turning MT1000A Off



To turn off the MT1000A:

• Disconnect the power cable(s) from the electricity outlet.

Turning MT1000A Off 3-3

Chapter 3 Operation MT1000A Installation and Operation Manual

3-4 Turning MT1000A Off

Chapter 4 Configuration

4.1 Introduction

The use of a terminal is optional for configuration, monitoring and maintenance operations.

Terminal Management Modes

The MT1000A provides the following terminal management modes:

• Monitor – A supervisory ASCII ANSI terminal or a PC emulating an ASCII ANSI

terminal connected directly to the MT1000A CONTROL port.

• Ethernet – A PC running terminal emulation software or a management

workstation, connected to the MT1000A via an Ethernet cable. It must be possible to activate Telnet and Web access after setting the IP address.

Up to three users can be active simultaneously, one connected to the terminal and two via telnet or Web. When connected via Telnet or Web, the user is disconnected after 10 minutes of inactivity (no keyboard input on the client computer.)

MT1000A supports several management information bases (MIBs). Refer to

Appendix C for details.

4.2 Setting Terminal Communication

Setting the Terminal Communication Parameters



To set the terminal communication parameters:

1. Connect the terminal to the 9-pin CONTROL connector on the front panel of

the MT1000A over a null-modem cable – CBL-DB9M/ DB9F. If a PC is used, run a terminal emulation program.

2. Set the default parameters of the terminal communication port to a baud rate

of 19,200 bps, 8 bits per character, one stop bit and no parity bit.

3. Disconnect the MT1000A from the mains, and then reconnect it to the mains.

4. Wait until the Test LED starts blinking. This indicates that the device is ready to

learn the baud rate of the terminal.

5. Press <Enter> or <.> at least four times.

Setting Terminal Communication 4-1

Chapter 4 Configuration MT1000A Installation and Operation Manual

MT1000A automatically detects and adapts itself to terminal baud rates of 9,600, 19,200, 38,400, 57,600 and 115,200 bps. After detecting the correct baud rate, the User name prompt is displayed, and the new baud rate is saved in the divide.

If the autodetection fails, the MT1000A CONTROL port uses the last baud rate that was saved in the device.

The MT1000A login screen (see Figure 4-1) is displayed.

MT1000A

USER NAME: PASSWORD:

ESC - clear; & - exit 1 user(s)

Figure 4-1. MT1000A Login Screen

6. Enter your user name. The default user name is USER.

7. Enter your password. The default password for the default user name is 1234.

The MT1000A Main Menu (see Figure 4-2) is displayed.

Entering the Terminal Session

Once you have logged into the system, the MT1000A Main Menu (see Figure 4-2) is displayed.

MT1000A

Main Menu

System Description ... (MT1000A HW Version 0.0 SW Version

3.00)

1. Configuration >

2. Monitoring >

3. Diagnostics >

4. File Utilities >

Please select item <1 to 4>

ESC-prev.menu; !-main menu; &-exit 1 user(s)

For the applicable operation using the terminal, refer to Figure 4-3.

Figure 4-2 Main Menu

4-2 Setting Terminal Communication

MT1000A Installation and Operation Manual Chapter 4 Configuration

1. Configuration

1. System Configuration

2. Monitoring 3. Diagnostics

1. Total Alarms

2. System Monitoring

3. Physical Port Monitoring

Main Menu

1. Local System Status

2. Remote System Status

3. Local System Alarms

4. Remote System Alarms

5. System Log File

6. Clear Log File

1. Local Physical Port Status

1. Management Ethernet

2. Up-Link Status

3. Channels Status

2. Remote Physical Port Status

1. Management Ethernet

2. Up-Link Status

3. Channels Status

3. Local Physical Port Alarms

1. Up-Link Alarms

2. Port Alarms

4. Remote Physical Port Alarms

1. Up-Link Alarms

2. Port Alarms

2. Physical Ports Configuration

1. Loop Status

2. Local Device Loops

1. Loops Setting

2. E2 LLB Timeout

3. Remote Device Loops

1. Loops Setting

2. E2 LLB Timeout

4. File Utilities

1. File System

1. SW Files

2. SWAP SW Files

2. S/W & File Transfer

1. Via TFTP

2. Via X-Modem

1. TFTP File Name

2. TFTP Server IP

3. TFTP Command

1. Redundancy

1. Local Redundancy

2. Remote Redundancy

1. Force Link

2. Redundancy Mode

1. Auto

2. Manual

3. Off

1. Force Link

2. Redundancy Mode

1. Auto

2. Manual

3. Off

1. Local Physical Ports Configuration 2. Remote Physical Ports Configuration

1. Management Port Configuration

1. Duplex Mode

2. Ethernet Alarm Mask

2. Up-Link Configuration

1. Link A Name

2. Link A Alarm Mask

3. Link B Name

4. Link B Alarm Mask

3. Channels Configuration

1. Channel Name

2. Channel Alarm Mask

3. Channel Line Code

4. Channel Line Length

5. Channel Number

2. Management

1. Device Info

1. System Contact

2. System Name

3. System Location

2. Host IP

1. Host IP List

1. IP Address

2. IP Mask 1. Change Access

2. Default Gateway

3. Read Community

4. Write Community

5. Trap Community

3. Manager List

4. Manager Access

1. SNMP

2. Telnet

3. Web

4. Web Trace Refresh

3. Control Port

2. Baud Rate

3. Security Timeout

4. POP Alarms

1. Management Port Configuration

1. Duplex Mode

2. Ethernet Alarm Mask

2. Up-Link Configuration

1. Link A Name

2. Link A Alarm Mask

3. Link B Name

4. Link B Alarm Mask

3. Channels Configuration

1. Channel Name

2. Channel Alarm Mask

3. Channel Line Code

4. Channel Number

4. Local Factory Default

1. All

2. W/O-MNG

1. Change User Name

2. Change Password

1. 9600 bps

2. 19200 bps

3. 38400 bps

4. 57600 bps

5. 115200 bps

5. Reset Device

Setting Terminal Communication 4-3

Figure 4-3 MT1000A Menu Map

Chapter 4 Configuration MT1000A Installation and Operation Manual

4.3 Monitoring the System

You can monitor the following aspects of the MT1000A system:

• Local system status

• Remote system status



To access the monitoring options:

1. From the Main Menu, choose Monitoring.

The Monitoring menu (Figure 4-4) is displayed.

The Total Alarms option displays the total number of alarms that are currently activated.

MT1000A

Monitoring

1. Total Alarms [ ]

2. System Monitoring >

3. Physical Port Monitoring >

Please select item <1 to 3> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-4. Monitoring Menu

2. To monitor the system, choose System Monitoring.

The System Monitoring menu (Figure 4-5) is displayed. This menu is used to monitor various aspects of the system, as described in the sections that follow.

3. To monitor a physical port, choose Physical Port Monitoring.

The Physical Port Monitoring menu (Figure 4-8) is displayed. This menu is used to monitor various aspects of the ports, as described in Monitoring the

Physical Ports on page 4-7.

4-4 Monitoring the System

MT1000A Installation and Operation Manual Chapter 4 Configuration

MT1000A

System Monitoring

1. Local System Status >

2. Remote System Status >

3. Local System Alarms [ ]

4. Remote System Alarms [ ]

5. System Log File [] >

6. Clear Log File

Please select item <1 to 6> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-5. System Monitoring Menu

On the System Monitoring menu, the Remote System Status and Remote System Alarms options are available only when the MT1000A is connected to a remote device.

Monitoring the Status of the Local System



To monitor the status of the local system:

• From the System Monitoring menu, choose Local System Status.

The Local System Status screen (Figure 4-6) is displayed. The fields in the Local System Status Screen are described in Table 4-1.

MT1000A

Local System Status

Device Type > (MT1000A) Service Channel > (Not Exists) Active Link > (LINK_A) Force Link > (LINK_A) Redundancy status > (Available) Redundancy Mode > (AUTO) SW Version (3.00) HW Version (0.00) BOOT Version (1.10 Boot img: 4.76) PS1 Type > (AC) PS1 Status > (OK) PS2 Type > (AC) PS2 Status > (OK) MAC Address (0020d20054dc) IP Address on (172.17.154.64) Sys up time (3 days 05:42:59.50) Alarm Indication > (Major) Test Indication > (Off) >

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Monitoring the System 4-5

Figure 4-6. Local System Status Screen

Chapter 4 Configuration MT1000A Installation and Operation Manual

Table 4-1. Local System Status Values

Field Description

SW Version Version number of the installed software.

HW Version Hardware version number.

BOOT Version The software boot version and the boot manager version installed on

the device.

Active link Identifies the currently active link.

Redundancy status

PS1 Type The type of power supply for Power Supply 1:

PS1 Status The status of Power Supply 1:

PS2 Type The type of power supply for Power Supply 2:

PS2 Status The status of Power Supply 2:

MAC Address The address the device holds when transmitting frames via the

IP Address on The address used when transmitting IP frames via the Ethernet port.

Sys up time System up time.

Alarm Indication Current system status:

Test Indication Indicates whether any tests are currently active in the device:

The redundancy state of the system:

• AUTO

• MANUAL

• OFF.

• AC—AC power supply

• 24VDC—DC power supply

• DC-48V—DC power supply

• NONE—No power supply is installed in this power supply slot.

• OK

• Fault

• Not mounted.

• AC—AC power supply

• 24VDC—DC power supply

• DC-48V—DC power supply

• NONE—No power supply is installed in this power supply slot.

• OK

• Fault

• Not mounted.

Ethernet port.

• Normal—System is functioning normally; no alarms activated

• Major—One or more major alarms are currently activated

• Minor—One or more minor alarms are currently activated.

• ON—Tests are currently active in the device

• OFF—No tests are currently running.

4-6 Monitoring the System

MT1000A Installation and Operation Manual Chapter 4 Configuration

Monitoring the Status of the Remote System



To monitor the status of the remote system:

• From the System menu, choose Remote System Status.

The Remote System Status screen (Figure 4-7) is displayed. The fields in this screen have the same meaning as those in the Local System Status screen, described in Table 4-1.

MT1000A

Remote System Status

Device Type > (MT1000A) Service Channel > (Not Exists) Active Link > (LINK_A) Force Link > (LINK_A) Redundancy status > (Available) Redundancy Mode > (AUTO) SW Version (1.00) HW Version (0.00) PS1 Type > (AC) PS1 Status > (OK) PS2 Type > (AC) PS2 Status > (Fault) Alarm Indication > (Major) Test Indication > (Off) >

Please select item <1 to 0> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-7. Remote System Status Screen

4.4 Monitoring the Physical Ports

You can monitor the following aspects of the physical ports on the MT1000A:

• Management port status

• Up-link status

• Channel status.



To monitor the physical ports:

1. From the Monitoring menu (Figure 4-4), choose Physical Port Monitoring.

The Physical Port Monitoring menu (Figure 4-8) is displayed.

Monitoring the Physical Ports 4-7

Chapter 4 Configuration MT1000A Installation and Operation Manual

MT1000A

Physical Port Monitoring

1. Local Physical Port Status >

2. Remote Physical Port Status >

3. Local Physical Port Alarms [] >

4. Remote Physical Port Alarms [] >

Please select item <1 to 4> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-8. Physical Port Monitoring Menu

The Remote Physical Port Status and Remote Physical Port Alarms options are available only when the MT1000A is connected to a remote device.

2. To display the status of ports on the local device, choose Local Physical Port

Status. To display the status of ports on the remote device, choose Remote Physical Port Status. The Local Physical Port Status menu (Figure 4-9) or

Remote Physical Port Status menu is displayed. The options in the local and remote menus are identical.

MT1000A

Local Physical Port Status

1. Management >

2. Up-Link Status >

3. Channels Status >

Please select item <1 to 3> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-9. Local Physical Port Status Menu

Monitoring the Status of the Ethernet Port



To monitor the status of the Ethernet port:

• From the Local/Remote Physical Port Status menu (Figure 4-9), choose

Management Ethernet.

The Management Ethernet Status screen (Figure 4-10) is displayed.

4-8 Monitoring the Physical Ports

MT1000A Installation and Operation Manual Chapter 4 Configuration

MT1000A

Management Ethernet Status

Link Integrity (No integrity)

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-10. Ethernet Status Screen

The Link Integrity can be one of the following:

• OK—The Ethernet cable has integrity

• No integrity—The Ethernet cable is not connected or some other problem

exists.

Monitoring the Status of the Up-Link



To monitor the status of the up-link:

• From the Local/Remote Physical Port Status menu (Figure 4-9), choose

Up-Link Status.

The Up-link Status screen (Figure 4-11) is displayed.

MT1000A

Up-Link Status

Link A type > (Fiber optic) Link A status > (No alarm) Uplink A mode > (Multi mode) Transmitter type Link A > (Laser) Wave length Link A > (1550 nm) Connector type Link A > (ST) Link B type > (Fiber optic) Link B status > (Signal loss) Uplink B mode > (Multi mode) Transmitter type Link B > (Laser) Wavelength Link B > (1550 nm) Connector type Link B > (ST)

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-11. Up-Link Status Screen

Monitoring the Status of the Channel Port



To monitor the status of the channel port:

• From the Local/Remote Physical Port Status menu (Figure 4-9), choose

Channels Status.

The Channel Port Status screen (Figure 4-12) is displayed.

Monitoring the Physical Ports 4-9

Chapter 4 Configuration MT1000A Installation and Operation Manual

MT1000A

Channel Port Status

Status (No alarm) Line code (B8ZS) Balance mode (Balance)

1. Channel Num > (1)

Please select item <1 to 1> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-12. Channel Port Status Screen

4.5 Working with the System Log File

Displaying the System Log File



To display the system log file:

• From the System Monitoring menu (Figure 4-5), choose System Log File.

The System Log File screen (Figure 4-13) is displayed.

MT1000A

System Log File

Source Alarm Status Time

1 Local Main Link Line AIS occurred Major 2:1:13

| 2 Local Device No connection to remote Off 5:17:11

| 3 Local CH1 LOS Minor 5:19:13

v 4 Local Device Power supply A failure Major 9:1:14

5 Local Device Redundancy is not available Major 13:34:14

6 Remote Device Power supply B failure Major 15:41:12

7 Remote Device Power supply B failure Off 16:22:14

8 Remote CH2 LOS Minor 22:3:14

9 Event Buffer Overflow Event 23:41:14

Please select item <1 to 13

ESC-prev.menu; !-main menu; &-exit 1 user(s)

4-10 Working with the System Log File

Figure 4-13. System Log File Screen

MT1000A Installation and Operation Manual Chapter 4 Configuration

Clearing the System Log File



To remove all entries from the log file:

1. From the System Monitoring menu (Figure 4-5), choose Clear Log File.

A confirmation message appears.

2. Press Y to erase the log file.

4.6 Alarms

MT1000A detects fault conditions and initiates alarms and events to alert the user:

• Alarms (major and minor) have two statuses: ON and OFF. The alarm status

automatically changes to OFF when a fault condition that triggered the alarm is cleared.

• Events have only ON status.

Displaying System Alarms



To display the system alarms:

• From the System Monitoring menu (Figure 4-5), choose Local System Alarms

or Remote System Alarms.

The Local System Alarms screen (Figure 4-14) or Remote System Alarms screen is displayed. The Remote System Alarms screen is similar to the Local System Alarms screen.

MT1000A

Local System Alarms

Source Name Num Severity Status

1. Local DEV PS2 FAIL 2 MAJOR ON

2. Local DEV Remote alarm-DAIS 6 MAJOR ON

Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-14. Local System Alarms Screen

The Local/Remote System Alarms screen only displays alarms that are currently triggered. Alarms that are currently in the OFF status (not activated) are not displayed.

The MT1000A system alarms are described in Chapter 5.

Alarms 4-11

Chapter 4 Configuration MT1000A Installation and Operation Manual

Displaying Physical Port Alarms



To display the physical port alarms:

1. From the Physical Port Monitoring menu (Figure 4-8), choose Local Physical

Port Alarms or Remote Physical Port Alarms.

The Physical Port Alarms menu (Figure 4-15) for the local or remote MT1000A device is displayed.

MT1000A

Physical Port Alarms

1. Up link alarms [ ]

2. Port Alarms [ ]

Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-15. Physical Port Alarms Menu

2. To display the up-link alarms, choose Up link alarms.

The Up Link Alarms screen (Figure 4-16) is displayed.

MT1000A

Up Link Alarms

Source Name Num Severity Status

Local Link B Signal Loss 21 MAJOR ON

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-16. Up Link Alarms Screen

The Up Link Alarms screen only displays alarms that are currently triggered. Alarms that are currently in the OFF status (not activated) are not displayed.

The MT1000A up-link alarms are described in Chapter 5.

3. To display the port alarms, from the Physical Port Alarms menu, choose Port

Alarms.

The Port Alarms screen (Figure 4-17) is displayed.

4-12 Alarms

MT1000A Installation and Operation Manual Chapter 4 Configuration

MT1000A

Port Alarms

Source Name Num Severity Status

Local P-2 Rx AIS 23 MINOR ON

Local P-3 Signal Loss 21 MAJOR ON

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-17. Port Alarms Screen

The Port Alarms screen only displays alarms that are currently triggered. Alarms that are currently in the OFF status (not activated) are not displayed.

The MT1000A port alarms are described in Chapter 5.

4.7 Configuring the MT1000A

The use of a terminal enables you to:

• View the configuration of the E1 and E2 interfaces, to identify whether the

interfaces are in the normal mode or in the looped mode

• Set local loop connections in the local MT1000A at both E1 and E2 interfaces

• Set local loop connections in the remote MT1000A at both E1 and E2

interfaces

• Set the redundancy mode of the E2 interface

• Set the E1 remote loopback connection

• Reset MT1000A to the default configuration (removing loops and switching to

the normal redundancy mode)

Configuring redundancy



To configure the redundancy between the local and remote devices:

1. From the Main Menu (Figure 4-2), choose Configuration.

The Configuration menu (Figure 4-18) is displayed.

Configuring the MT1000A 4-13

Chapter 4 Configuration MT1000A Installation and Operation Manual

MT1000A

Configuration

1. System configuration >

2. Physical ports configuration >

Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-18 Configuration Menu

2. Choose System Configuration.

The System Configuration menu (Figure 4-19) is displayed.

MT1000A

System configuration

1. Redundancy >

2. Management >

3. Control Port >

4. Local Factory Default >

5. Reset Device

Please select item <1 to 6> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-19 System Configuration Menu

When the MT1000A is connected to a new-look remote device, the Redundancy option is shown in the menu; otherwise, the Local Redundancy option is shown instead.

3. If the MT1000A is connected to a remote device, choose Redundancy.

The Redundancy menu (Figure 4-20) is displayed.

MT1000A

Redundancy

1. Local redundancy >

2. Remote redundancy >

Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-20. Redundancy Menu

4. To configure redundancy on the local MT1000A, choose Local Redundancy.

The Local Redundancy menu (Figure 4-21) is displayed.

4-14 Configuring the MT1000A

MT1000A Installation and Operation Manual Chapter 4 Configuration

MT1000A

Local Redundancy

1. Force Link (Link A)

2. Redundancy Mode > (Auto)

Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-21. Local Redundancy Menu

5. Choose the link for which you want to set redundancy. Choose Force Link to

toggle the selected Main Link between Link A and Link B.

6. Choose Redundancy Mode to set the mode to use.

The Redundancy Mode menu (Figure 4-22) is displayed.

MT1000A

Redundancy mode (Auto)

1. Auto

2. Manual

3. Off

Please select item <1 to 3> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Not

Figure 4-22. Redundancy Mode Menu

7. Choose the redundancy mode you want to use:

 Auto—When the selected Main Link (for example, Link A) fails,

MT1000A will automatically switch over to the backup Main Link (for example, Link B)

 Manual—When the selected Force Link fails, the system switches to the

backup link. The backup link remains in use, even if the Force Link returns to service.

 Off—Turns off redundancy. When the selected Main Link fails,

MT1000A will not change over to the backup Main Link.

This completes the setup of redundancy for the local device.

8. To configure redundancy for the remote MT1000A, from the Redundancy

menu (Figure 4-20), choose Remote Redundancy.

The Remote Redundancy menu appears. This menu is identical to the Local Redundancy menu (Figure 4-21).

9. To configure the remote redundancy, refer to the above procedure describing

how to configure local redundancy.

You can set the mode for the remote device, which will then perform redundancy according to the status of its links.

Configuring the MT1000A 4-15

Chapter 4 Configuration MT1000A Installation and Operation Manual

Setting the Device Information

Each MT1000A unit can be configured to hold information about the unit, such as its location and a name to easily identify the unit on the network.



To set device information:

1. From the System Configuration menu (Figure 4-19), choose Management.

The Management menu (Figure 4-23) is displayed.

MT1000A

Management

1. Device Info >

2. Host IP >

3. Manager List []>

4. Manager Access >

Please select item <1 to 4> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-23. Management Menu

2. Choose Device Info.

The Device Info menu (Figure 4-24) is displayed.

MT1000A

Device Info

System Description ... (MT1000A Hw Version 0.0 SW Version 30)

1. System Contact ... ()

2. System Name ... ()

3. System Location ... ()

Please select item <1 to 3>

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-24. Device Info Menu

The System Description line identifies the device, along with the current hardware and software version numbers.

3. To define a system contact person, choose System Contact and then enter the

name, phone and/or other details you want to save in this field.

4. To specify a name to identify the MT1000A device, choose System Name and

then enter the name. It is easier to identify the device by a name than by its IP address.

5. To specify a system location, choose System Location and then enter the

location of the MT1000A unit.

4-16 Configuring the MT1000A

MT1000A Installation and Operation Manual Chapter 4 Configuration

Setting the network parameters

When you integrate the MT1000A into your network, you will need to set the network parameters of the MT1000A.



To set the network parameters:

1. From the Management menu (Figure 4-23), choose Host IP.

The Host IP menu (Figure 4-25) is displayed.

MT1000A Host IP

1. Host IP List >

2. Default Gateway ... (172.17.161.1)

3. Read Community ... (public)

4. Write Community ... (public)

5. Trap Community ... (public)

Please select item <1 to 5> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-25. Host IP Menu

2. Choose Host IP List.

The Host IP List menu (Figure 4-26) is displayed.

MT1000A Host IP List

1. IP Address ... (172.17.161.93)

2. IP Mask ... (255.255.255.0)

> Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-26. Host IP List Menu

3. To set the IP address of the MT1000A unit, choose IP Address and then enter

the IP address.

4. To set the IP Mask, choose IP Mask and then enter the IP mask.

5. To set the default gateway, from the Host IP menu (Figure 4-25), choose

Default Gateway and then enter the IP address of the gateway.

6. From the Host IP menu, choose Read Community and then set the read

community. This field is used by SNMP. Specify a string of eight characters.

7. From the Host IP menu, choose Write Community and then set the read

community. This field is used by SNMP. Specify a string of eight characters.

8. From the Host IP menu, choose Trap Community and then set the read

community. This field is used by SNMP. Specify a string of eight characters.

Configuring the MT1000A 4-17

Chapter 4 Configuration MT1000A Installation and Operation Manual

Setting up the Manager List

By default, any remote management terminal is allowed to change the configuration of the MT1000A. You may enhance the security of the site by limiting remote management to specific management terminals or nodes. The Manager List lists the network nodes from which management may take place.



To define the manager list:

1. From the Management menu (Figure 4-23), choose Manager List.

The Manager List screen (Figure 4-27) is displayed.

MT1000A Manager List

mngNum mngIP mngMask 1 0.0.0.0 NO | 2 0.0.0.0 NO | 3 0.0.0.0 NO v 4 0.0.0.0 NO 5 0.0.0.0 NO

1. Change cell ... (0.0.0.0)

ESC-prev.menu; !-main menu; &-exit 1 user(s)

2. The list contains 10 entries. Press D to move down the list; press U to move up

the list. Press L to select the previous field; press R to select the next field.

3. To change the value of a field, select the field (it will appear highlighted), then

choose Change Cell and then enter the new value.

When the mngMask field is set to Yes, a trap is sent to this agent.

Setting the Management Access



To set the management access:

1. From the Management menu (Figure 4-23), choose Manager Access.

The Manager Access menu (Figure 4-28) is displayed.

MT1000A Manager Access

1. Telnet >

2. SNMP >

3. Web >

4. Web Trace Refresh (seconds)[1-255] ... (10)

Please select item <1 to 4> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-27. Manager List Screen

4-18 Configuring the MT1000A

Figure 4-28. Manager Access Menu

MT1000A Installation and Operation Manual Chapter 4 Configuration

2. Choose the method to use for management access:

 SNMP (the management terminal connects to the MT1000A via SNMP

connection)

 Telnet (the management terminal connects to the MT1000A via Telnet

connection)

 Web (the management terminal connects to the MT1000A via Web

connection)

The menu shown in the following figure is displayed. The title of the menu indicates which management access option is being configured. While the Telnet menu is shown in the figure, the menu options are the same for all management access modes.

MT1000A Telnet

1. Disable

2. Enable

3. Managers only

Please select item <1 to 3> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-29. Telnet Menu

3. Choose Enable to enable this access mode; choose Disable to disable this

access mode. Choose Managers only to provide management access only to those users whose IP addresses appear in the Manager List.

4. When the Web management access method is selected, set the Web Trace

Refresh (1-155 seconds) in the Manger Access menu. This option is available only when Web access is enabled.

Setting the User Name and Password

To enhance security, you can specify a user name and password to control access to the MT1000A management functions.



To set user name and password:

1. From the System Configuration menu (Figure 4-19), choose Control Port.

The Control Port menu (Figure 4-30) is displayed.

MT1000A Control Port

1. Change Access >

2. Baud Rate > (19200bps)

3. Security Timeout (10min)

4. POP Alarms > (OFF)

Please select item <1 to 4> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Configuring the MT1000A 4-19

Figure 4-30. Control Port Menu

Chapter 4 Configuration MT1000A Installation and Operation Manual

2. Choose Change Access.

The Change Access menu (Figure 4-31) is displayed.

MT1000A Change Access

1. Change User Name ... (user)

2. Change Password ... ()

> Please select item <1 to 2>

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-31. Change Access Menu

3. To change the user name, choose Change User Name and then enter the new

user name.

4. To change the password, choose Change Password and then enter the new

password. The new password may contain up to eight characters.

Configuring the Control Port

The control port is used to connect a console terminal to the MT1000A device.



To configure the control port:

1. From the Control Port menu (Figure 4-30), choose Baud Rate.

The Baud Rate menu (Figure 4-32) is displayed.

MT1000A

Baud Rate (9600bps)

1. 9600 bps

2. 19200 bps

3. 38400 bps

4. 57600 bps

5. 115200 bps

Please select item <1 to 5> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-32. Baud Rate Menu

2. Choose the baud rate that matches your management terminal device.

3. From the Control Port menu, choose Security Timeout, and then enter a

timeout value in minutes. This value is the number of minutes of management inactivity after which the MT1000A automatically disconnects from the management session. To reconnect, press <Enter> on the management terminal and then log in again.

4. Choose POP Alarms to toggle POP Alarms ON or OFF. When POP Alarms is

ON, new alarms appear at the bottom of the terminal screen. Regardless of the POP Alarms setting, the alarms are written to the log file.

4-20 Configuring the MT1000A

MT1000A Installation and Operation Manual Chapter 4 Configuration

Resetting the Factory Defaults

You can reset all of the local MT1000A configuration parameters to their default settings, or you can reset all parameters except for the management settings (IP addresses)



To reset parameters to the factory defaults:

1. From the System Configuration menu (Figure 4-19), choose Local Factory

Default.

The Factory Default menu (Figure 4-33) is displayed.

MT1000A

Factory Default

1. All

2. W/O-MNG>

Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-33. Factory Default Menu

2. To reset all parameters to the factory default, choose All.

3. To reset all parameters except for the management information to the factory

default, choose W/O-MNG.

A confirmation message is displayed.

4. Enter Y (Yes) to confirm the reset operation.

Resetting the MT1000A



To reset the MT1000A:

1. From the System Configuration menu (Figure 4-19), choose Reset Device.

A confirmation message is displayed.

2. Enter Y (Yes) to reset the device.

4.8 Configuring the Physical Ports

Configuring the Ethernet Port



To configure the Ethernet port:

1. From the Configuration menu (Figure 4-18), choose Physical Ports

Configuration.

The Physical Ports Configuration menu (Figure 4-34) is displayed.

Configuring the Physical Ports 4-21

Chapter 4 Configuration MT1000A Installation and Operation Manual

MT1000A

Physical ports configuration

1. Local Physical Ports Configuration >

2. Remote Physical Ports Configuration >

Please select item <1 to 2>

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-34. Physical Ports Configuration Menu

The Remote Physical Ports Configuration option is shown only when a remote MT1000A device is connected.

2. Choose Local Physical Ports Configuration or Remote Physical Ports

Configuration.

The Local Physical Ports Configuration screen (Figure 4-35) or Remote Physical Ports Configuration screen is displayed. The Remote Physical Ports Configuration screen is identical to the Local Physical Ports Configuration screen.

MT1000A

Local Physical Ports Configuration

1. Management Port Configuration >

2. Up Links Configuration >

3. Channels Configuration >

Please select item <1 to 3> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-35. Local Physical Ports Configuration Menu

3. Choose Management Port Configuration.

The Management Port Configuration screen (Figure 4-36) is displayed.

MT1000A

Management Port Configuration

1. Duplex Mode (Full)

2. Ethernet alarm mask (On)

Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

4. Choose Duplex Mode to toggle through the available modes:

4-22 Configuring the Physical Ports

Figure 4-36. Management Port Configuration Screen

MT1000A Installation and Operation Manual Chapter 4 Configuration

 Full (Full-duplex mode)

 Half (Half-duplex mode).

5. Choose Ethernet alarm mask to toggle the Ethernet alarm on or off.

Configuring the Channels



To configure the channels:

1. From the Local/Remote Physical Ports Configuration menu (Figure 4-35),

choose Channels Configuration.

The Channels Configuration screen (Figure 4-37) is displayed.

MT1000A

Channels Configuration

1. Channel name ... ( )

2. Channel alarm mask (Off)

3. Channel line code (B8ZS)

4. Channel line length (0-133 ft)

5. Channel Number (1)

Please select item <1 to 4> ESC-prev.menu; !-main menu; &-exit 1 user(s)

2. Choose Channel Number and then enter the number of the channel you want

to configure.

3. If you would like to specify a name to help identify the channel, choose

Channel name and then enter the name (a text string).

4. Choose Channel alarm mask to toggle the alarm for this channel on or off.

5. Choose Channel line code to toggle the line code. Note that changing the line

coding for one channel changes it for all four channels. The following line codes are available:

 B8ZS

 AMI

6. To change the channel line length value, choose Channel line length and then

choose the desired value.

Configuring the Up-Links



To configure the up-links:

1. From the Local/Remote Physical Ports Configuration menu (Figure 4-35),

choose Up-Link Configuration.

The Up-Link Configuration screen (Figure 4-38) is displayed.

Figure 4-37. Channels Configuration Screen

Configuring the Physical Ports 4-23

Chapter 4 Configuration MT1000A Installation and Operation Manual

MT1000A

Up-link Configuration

1. Link A name ... ( )

2. Link A alarm mask (Off)

3. Link B name ... ( )

4. Link B alarm mask (Off)

Please select item <1 to 4> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-38. Up-Link Configuration Screen

2. If you would like to specify a name to easily identify Link A, choose Link A

name and then enter a name for the link.

3. Choose Link A alarm mask to toggle the alarm for Link A on or off.

4. If you would like to specify a name to easily identify Link B, choose Link B

name and then enter a name for the link.

5. Choose Link B alarm mask to toggle the alarm for Link B on or off.

4.9 Diagnostics

Setting the E2 Local Loopback Timeout

The E2 local loopback (LLB) timeout can be set for the local device and the remote device.



To set the E2 LLB local loopback timeout on the local MT1000A:

1. From the Main Menu (Figure 4-2), choose Diagnostics.

The Diagnostics menu (Figure 4-39) is displayed.

MT1000A

Diagnostics

1. Loop Status >

2. Local Device Loops >

3. Remote Device Loops >

Please select item <1 to 3> ESC-prev.menu; !-main menu; &-exit 1 user(s)

The Remote Device Loops option is displayed only if a remote device is connected to the MT1000A.

4-24 Diagnostics

Figure 4-39. Diagnostics Menu

MT1000A Installation and Operation Manual Chapter 4 Configuration

2. Choose Local Device Loops.

The Local Device Loops Menu (Figure 4-40) is displayed.

MT1000A

Local Device Loops

1. Loops Setting [] >

2. Uplink LLB timeout (min) ... (5)

Please select item <1 to 2> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-40. Local Device Loops Menu

3. Choose Uplink LLB Timeout and then enter the timeout in minutes. The value

you specify is the duration of the E2 LLB loopback test. Specify a value as follows:

 0 (forever)

 1-255 (test runs for the specified number of minutes).



To set the E1 LLB local loopback timeout on the remote MT1000A:

1. From the Diagnostics menu (Figure 4-39), choose Remote Device Loops.

The Remote Device Loops menu is displayed. This menu is the same as the Local Device Loops menu (Figure 4-40). Set the loopback as described above for the setting the timeout on the local MT1000A.

Setting Loopbacks in the Local MT1000A



To set loopbacks in the local MT1000A:

1. From the Local Device Loops menu (Figure 4-40), choose Loops Setting.

The Loops Setting screen (Figure 4-41) is displayed.

MT1000A

Loops Setting

Port Loop status Uplink LLB Channel 1 No loop Channel 2 No loop Channel 3 No loop Channel 4 No loop

1. No loop

2. LLB

3. RLB

> Please select item <1 to 3> ESC-prev.menu; !-main menu; &-exit 1 user(s)

Diagnostics 4-25

Figure 4-41. Loops Setting Screen

Chapter 4 Configuration MT1000A Installation and Operation Manual

2. Highlight the Loop status field of the channel you want to change.

3. Enter the loopback status you want to set:

 No loop—No loopback on the channel

 LLB—Local loopback on the channel or uplink

 RLB—Remote loopback on the channel.

See Chapter 5 for definitions of local channel and uplink loopbacks in the remote MT1000A.

The loopback test begins running immediately after a loopback has been set.

Setting Loopbacks in the Remote MT1000A



To set loopbacks in the remote MT1000A:

1. From the Diagnostics menu, choose Remote Device Loops.

The Remote Device Loops menu is displayed. This menu is the same as the Local Device Loops menu (Figure 4-40).

2. From the Remote Device Loops menu, choose Loops Setting.

The Loops Setting screen (Figure 4-41) is displayed.

3. Highlight the Loop status field of the channel you want to change.

4. Enter the loopback status you want to set:

 No loop—No loopback on the channel

 LLB—Local loopback on the channel or uplink

 RLB—Remote loopback on the channel.

See Chapter 5 for definitions of local channel and uplink loopbacks in the remote MT1000A.

The loopback test begins running immediately after a loopback has been set.

Caution

Setting the uplink local loopback in the remote MT1000A disconnects the link, and as such, is irreversible. To remove this loopback, connect a terminal to the remote unit or shut down the power to the remote unit. If you set the Uplink LLB timeout on the remote MT1000A, the loopback test will stop after the specified timeout period.

Displaying Loop Status



To display the current status of loops you have configured in the system:

1. Open the Diagnostics menu (Figure 4-39).

2. Choose Loop Status.

The status of all loops currently configured on the local MT1000A is displayed.

4-26 Diagnostics

MT1000A Installation and Operation Manual Chapter 4 Configuration

4.10 Viewing Hardware and Software Updates



To view the last MT1000A hardware and software updates:

1. From the Main Menu (Figure 4-2), choose Monitoring.

The Monitoring menu (Figure 4-4) is displayed.

2. Choose System Monitoring.

The System Monitoring menu (Figure 4-5) is displayed.

3. Choose Local System Status to display the status of the local MT1000A, or

choose Remote System Status to display the status of the remote MT1000A.

The Local System Status screen (Figure 4-6) is displayed. The first line of information in the screen displays the current hardware and software version numbers.

4.11 Downloading Software

Whenever a new software release is available, you should download it onto the MT1000A. The MT1000A stores up to two versions of the software – each one is a separate partition. You can choose which partition to boot from.

Software can be downloaded using the TFTP or X-Modem protocol.

Downloading Software using the TFTP Protocol



To download a new software revision via TFTP:

1. From the Main Menu (Figure 4-2), choose File Utilities.

The File Utilities menu (Figure 4-42) is displayed.

MT1000A

File Utilities

1. File System >

2. S/W &File Transfer >

Please select item <1 to 2>

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-42. File Utilities Menu

2. Choose S/W & File Transfer.

The S/W & File Transfer menu (Figure 4-43) is displayed.

Downloading Software 4-27

Chapter 4 Configuration MT1000A Installation and Operation Manual

MT1000A

S/W & File Transfer

1. Via TFTP >

2. Via X-Modem

Please select item <1 to 2>

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-43. S/W & File Transfer Menu

3. Choose Via TFTP.

The Via TFTP menu (Figure 4-44) is displayed.

Not

The Via TFTP option is available only if the local MT1000A has been assigned an IP address.

MT1000A

Via TFTP

Transfer Status > (No operation) Transfer Error > (No Error)

1. TFTP File Name (File Name)

2. TFTP Server IP (0.0.0.0)

3. TFTP Command

Please select item <1 to 3>

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-44. Via TFTP Menu

4. Choose TFTP Server IP and enter the IP address of the server from which you

want to download the new software file.

5. Choose TFTP File Name and enter the name of the file you want to

download.

6. Choose TFTP Command.

The download process begins.

The Transfer Status field indicates the current status of the download:

 No operation (no TFTP transfer is in process)

 Connecting (initiating a TFTP connection)

 Transferring data (TFTP data transfer is in process)

 Ended timeout (the download was terminated because the Retry Timeout

or Total Timeout was exceeded)

 Ended OK (the file was successfully downloaded)

 Error (the download was terminated because an error occurred).

4-28 Downloading Software

MT1000A Installation and Operation Manual Chapter 4 Configuration

Downloading Software using the X-Modem Protocol



To download a new software version via X-Modem:

1. Open the S/W & File Transfer menu (Figure 4-43).

2. Choose Via X-Modem.

The download process begins as soon as the remote computer starts the upload process. Note that you need to run an X-Modem application on the remote computer to invoke the upload.

4.12 Viewing file and file system information



To view information about the file system:

1. From the File Utilities menu (Figure 4-42), choose File System.

The File System menu (Figure 4-45) is displayed.

MT1000A

File System

1. SW Files [] >

2. SWAP SW Files

Please select item <1 to 2>

ESC-prev.menu; !-main menu; &-exit 1 user(s)

2. Choose SW Files.

The SW Files screen (Figure 4-46) is displayed, showing information about the active and backup software partitions as well as the boot version.

Figure 4-45. File System Menu

Viewing file and file system information 4-29

Chapter 4 Configuration MT1000A Installation and Operation Manual

MT1000A

SW Files

Software active version 1.00 Software active partition 0 Code size 190 Date 01-01-02 Software backup version 0.00n00 Software backup partition 1 Code size 0 Date 0-0-0 Boot version 2.20 Boot mng version 4.00

ESC-prev.menu; !-main menu; &-exit 1 user(s)

Figure 4-46. SW Files Screen



To change the software boot partition:

1. Open the File System menu (Figure 4-45).

2. To swap the active and backup software partitions, choose SWAP SW Files.

The MT1000A reboots off the other partition.

3. After the system has come up, display the SW Files screen to verify that the

change took place.

4-30 Viewing file and file system information

Chapter 5 Testing and Diagnostics

5.1 Introduction

This chapter includes a description of the MT1000A diagnostic tests and troubleshooting procedures.

5.2 Troubleshooting

In case a problem occurs, check the displayed indications and refer to Section 3-2 and Table 3-1 for their interpretation.

Identify the trouble symptoms and perform the actions listed under Corrective Measures in the order given in Table 5-1, until the problem is corrected.

Table 5-1 Troubleshooting Chart

Trouble Symptoms Probable Cause Corrective Measures

The MT1000A does not respond

Defective Power Supply Disconnect the power from both ends and replace

Defective MT1000A Replace the MT1000A.

One of the PWR indicators lights in red.

No power Check that both ends of the power cable are properly

connected. If power cable is properly connected, but the power supply still does not respond, then the power supply is defective (see below).

If the MT1000A is powered from a DC power source, check the polarity of the power connections.

with another power supply.

Defective power supply Turn the respective power supply off for at least 10

minutes, and then turn it on again.

If the PWR indicator is still red, have the MT1000A repaired as soon as possible.

Troubleshooting 5-1

Chapter 5 Testing and Diagnostics MT1000A Installation and Operation Manual

Table 5-1. Troubleshooting Chart (Cont.)

Trouble Symptoms Probable Cause Corrective Measures

The SYNC LOSS indicator of the fiber optic link lights.

External problem Activate the local loopback on the MT1000A. Check

that the SYNC LOSS and AIS indicators of the fiber optic link in use turn OFF.

If the indicators turn off, check the fiber optic interface connections, the fiber optic transmission path to the remote unit, and the remote unit.

Defective MT1000A Replace the MT1000A.

The AIS indicator of the fiber optic link lights.

1. External The remote equipment connected to the fiber optic link of the MT1000A sends an AIS sequence. Check the remote equipment.

2. Defective MT1000A

Activate the local loopback on the MT1000A. Check that the SYNC LOSS and AIS indicators of the fiber optic link in use turn OFF. If one of the indicators remains lit, replace the MT1000A.

None of the units connected to a local MT1000A receive the remote equipment.

External problem Activate the local loopback on the MT1000A. Check

that all the SYNC LOSS and AIS indicators turn OFF, and that the equipment connected to the local tributaries receive their own transmissions. If the indicators turn OFF, the problem is external. Troubleshoot the remote unit, and the fiber optic transmission path.

Defective

Replace the MT1000A.

MT1000A

Only one of the units connected to a local MT1000A does not

1. Equipment problem Check the equipment connected to the local tributary, and its cable connections. Check the remote tributary equipment.

receive the remote equipment.

2. Defective MT1000A Activate the fiber optic link local loopback in the local MT1000A. Check that any previously lit alarm indicators related to the tributary turn OFF.

If the indicator turns OFF, the problem is external; if the indicator remains lit, replace the MT1000A.

No menus are available. Incomplete downloading

of new FLASH version

Turn the MT1000A ON and proceed to download the new FLASH version again.

5-2 Troubleshooting

MT1000A Installation and Operation Manual Chapter 5 Testing and Diagnostics

5.3 List of Alarms and Events

The MT1000A alarms are described in Table 5-2.

Table 5-2. MT1000A System Alarms

Message on terminal Description Severity

CDP fail A failure has occurred in

the CDP.

FLASH problem A problem occurred in the

device FLASH device. Could not save user configuration.

PS1 FAIL Power supply A has failed. Major

PS2 FAIL Power supply B has failed. Major

Redundancy not available Unable to activate

redundancy between the uplinks. This alarm occurs only if the redundancy mode is set to AUTO or MANUAL.

Remote alarm-DAIS Received a Demux AIS. Major

Remote connection FAIL A managment connection

could not be established with the remote device.

Major

Table 5-3. MT1000A Port and Up-Link Alarms

Message on terminal Description Severity

ETH Integrity fail The managment port is

not connected.

Incorrect Tributary Freq There is a problem with

the tributary frequency.

Looped Loop detected on the

uplinks.

Loss of frame Loss of frames on the

uplinks.

Rx AIS Received AIS on the

uplinks or the channels.

Signal Loss Signal loss detected on

uplinks or channels.

Major

Minor

Major

List of Alarms and Events 5-3

Chapter 5 Testing and Diagnostics MT1000A Installation and Operation Manual

The MT1000A events are described in Table 5-4.

Table 5-4. MT1000A Events

Event Description

BUFFER OVERFLOW The log file overran the last events.

PASSWORD SWITCH ON User changes access password.

SW DOWNLOAD FAIL Software download failed.

SW DOWNLOAD OFF Software download process finished.

SW DOWNLOAD ON Software download is in process.

Uplink switch A->B Switched from uplink A to uplink B – reason unknown.

Uplink switch A->B:LOOPED Switched from uplink A to uplink B – loop detected in uplink A.

Uplink switch A->B:LOSS Switched from uplink A to uplink B – LOSS in uplink A.

Uplink switch A->B:OOF Switched from uplink A to uplink B – out of frames in uplink A.

Uplink switch A->B:USER Switched from uplink A to uplink B – user request.

Uplink switch B->A Switched from uplink B to uplink A – reason unknown.

Uplink switch B->A:LOOPED Switched from uplink B to uplink A – loop detected in uplink B.

Uplink switch B->A:LOSS Switched from uplink B to uplink A – LOSS in uplink B.

Uplink switch B->A:OOF Switched from uplink B to uplink A – out of frames in uplink B.

Uplink switch B->A:USER Switched from uplink B to uplink A – user request.

5.4 Diagnostic Tests

MT1000A supports the following types of loopback connections:

• Loopbacks toward the local MT1000A

• Loopbacks toward the remote MT1000A.

The test functions are controlled by the management software. During all loopbacks, the TST indicator lights up on the units that participate in the loopback path.

The available loopback functions are described in the following paragraphs.

5-4 Diagnostic Tests

MT1000A Installation and Operation Manual Chapter 5 Testing and Diagnostics

Local Loopbacks in the MT1000A

You can set two types of local loopback connections in the MT1000A unit:

• T1 local, which is set for each T1 interface separately from a terminal.

• Fiber optic link local, which can be set from a terminal.

T1 Local Loopback in the MT1000A

The T1 local loopback returns the T1 transmit signal to the output of the receive path. Simultaneously, an unframed all-ones signal is sent to the MUX. Figure 5-1 shows the T1 local loopback connection.

This test checks the operation of the connections to the equipment attached to the local tributary interfaces.

Diagnostic Tests 5-5

Figure 5-1 T1 Local Loopback in the MT1000A

Chapter 5 Testing and Diagnostics MT1000A Installation and Operation Manual

Fiber Optic Link Local Loopback in the MT1000A

The fiber optic local loopback returns the transmit signal of the active fiber optic link interface to the input of the receive path. Simultaneously, the local MT1000A sends an unframed all-ones signal to the fiber optic link. Figure 5-2 shows the fiber optic link local loopback connection.

When this loopback is activated, the equipment connected to the local MT1000A tributary must receive its own transmission.

This test checks the operation of the local MT1000A, and the connections to the equipment attached to the tributary interfaces.

5-6 Diagnostic Tests

Figure 5-2 Fiber optic Link Local Loopback in the MT1000A

MT1000A Installation and Operation Manual Chapter 5 Testing and Diagnostics

Remote Loopbacks in the MT1000A

You can set two types of remote loopback connections in the MT1000A unit:

• T1 remote, which is set for each T1 interface separately, from the terminal.

• Fiber optic link remote, which can be set from the terminal.

T1 Remote Loopback in the MT1000A

The T1 remote loopback returns the transmitted Demuxed T1 to the receiver Mux. Simultaneously, the MT1000A sends an unframed all-ones signal to the T1 link.

Figure 5-3 shows the T1 remote loopback connection.

This test checks the operation of the local MT1000A and the connection to the remote MT1000A unit.

Figure 5-3 T1 Remote Loopback in the MT1000A

Diagnostic Tests 5-7

Chapter 5 Testing and Diagnostics MT1000A Installation and Operation Manual

Fiber Optic Remote Loopback in the MT1000A

The fiber optic remote loopback returns the received signal of the active fiber optic link interface to the input of the transmit path. Simultaneously, the remote MT1000A sends an unframed all-ones signal to the input of the Demux.

Figure 5-4 shows the fiber optic remote loopback connection.

This test checks the operation of the local MT1000A and the connection to the remote MT1000A.

Figure 5-4 Fiber Optic Remote Loopback in the MT1000A

5-8 Diagnostic Tests

Appendix A Interface Specifications

A.1 Tributary Connectors

Each tributary interface has one RJ-45 eight-pin connector. Connector wiring is listed in Table A-1.

Table A-1. RJ-45 Tributary Connector, Pin Functions

Pin Designation Direction Function

1 RD(T) Input Receive Data (tip)

2 RD(R) Input Receive Data (ring)

4 TD(T) Output Transmit Data (tip)

5 TD(R) Output Transmit Data (ring)

3, 6, 7, 8 - N/A Not connected

Tributary Connectors A-1

Appendix A Interface Specifications MT1000A Installation and Operation Manual

A.2 Alarm Connector

The MT1000A ALARM connector is a 9-pin female connector, which includes the contacts of the major and minor alarm relays. Figure A-1 shows the pin functions. The relay positions are shown in the non-energized (alarm active) state.

ALARM

CONN ECTOR

MINOR ALARM RELAY

MAJOR ALARM RELAY

A-2 Alarm Connector

Figure A-1. ALARM Connector Wiring

MT1000A Installation and Operation Manual Appendix A Interface Specifications

A.3 Control Connector

The optional MT1000A supervisory port has a standard RS-232 DTE interface. The physical interface is a 9-pin female connector, designated CONTROL. Connector wiring is given in Table A-2.

Table A-2. CONTROL DTE Connector, Pin Functions

Pin Line Direction Remarks

1 Data Carrier Detect (DCD) To MT1000A

2 Receive Data (RD) To MT1000A

3 Transmit Data (TD) From MT1000A

4 Data Terminal Ready (DTR) From MT1000A

5 Signal Ground (SIG) Common signal reference and DC power supply ground

6 Data Set Ready (DSR) To MT1000A (Not used)

7 Request to Send (RTS) From MT1000A

8 Clear to Send (CTS) To MT1000A

9 Ring Indicator (RI) To MT1000A (Not used)

A.4 MNG-ETH Connector

One LAN Ethernet RJ-45 connector is mounted on the MNG-ETH module. The pinout is shown in Table A-3.

Table A-3. Ethernet RJ-45 Connector Pin Assignment

Pin Designation Function Direction

1 RX+ Receive – positive lead Input

2 RX- Receive – negative lead Input

3 TX+ Transmit – positive lead Output

6 TX- Transmit – negative lead Output

4, 5, 7, 8 - Not connected -

MNG-ETH Connector A-3

Appendix A Interface Specifications MT1000A Installation and Operation Manual

A.5 Power Connectors

The power connector used for the AC/DC power supply is a standard square 3-prong female connector.

For information on the DC power connector, refer to the two supplements at the end of this manual: DC Power Supply Connection - Terminal Block Connector

Supplement and the DC Power Supply Connection - AC/DC Adaptor (AD) Plug Supplement.

A-4 Power Connectors

Appendix B MT1000A MIBs

A MIB (Management Information Base) is a database of managed objects. The MIB contains the data regarding the network elements being controlled and monitored. Each characteristic of the element to manage is defined as an object in the MIB. The MIB is a hierarchical tree structure that acts as the repository for defined objects. Each object has an object name, a type, syntax, an access code (read-write, read-only, not-accessible, and write-only), and a status (mandatory, optional, obsolete).

MT1000A supports appropriate groups (tables) of MIB II (SNMP standard MIB) and some other MIBs, as shown in Table B-1.

Table B-1. MT1000A MIBs

MIB Notes Tables

RFC1213 MIB-11 system

if at ip icmp udp snmp

RFC1573 New Interface Table –

RFC1406 NG Partially supported dsx1ConfigTable

B-1

Appendix B MT1000A MIBs MT1000A Installation and Operation Manual

B-2

Index

—A—

AC/DC connections, 2-8 AIS, 1-5 alarm connector

specifications, 1-8

alarm relays

connector, 2-7

alarms, 1-5, 4-11

connector, A-2 physical port, 4-12 port, 5-3 system, 4-11, 5-3 Up-Link, 5-3

applications, 1-2 automatic switching, 1-4

fiber optic interface, 2-7 ground, 2-7 power supply, 2-7 tributary, 2-1 tributary channels, 2-6

connector

alarms, A-2 control, A-3 Ethernet, A-3 locations, 2-6 power, A-4

control connectors, A-3 control DTE supervisory port

specifications, 1-8

control port

configuring, 4-20 Control Port menu, 4-19

—B—

Baud Rate menu, 4-20 boards, 1-3

—C—

Change Access menu, 4-20 changing software boot partition, 4-30 channel port

Channel Port Status screen, 4-9 monitoring the status, 4-9

channels

Channels Configuration screen, 4-23 configuring, 4-23 up-links, 4-23

circuit boards, 1-3 clearance

front panel, 2-2 rear panel, 2-2

Configuration menu, 4-13 configuring, 4-1

channels, 4-23 control port, 4-20 Ethernet port, 4-21 physical ports, 4-21 redundancy, 4-13 up-links, 4-23

connections, 2-6

AC/DC power supply, 2-8 alarm relays, 2-7 DC power, 2-8 fiber optic, 2-2

—D—

DC connections, 2-8 depth, 1-8 device

resetting, 4-21

device information

Device Info menu, 4-16 setting, 4-16

diagnostics, 1-5, 4-24, 5-1

Diagnostics menu, 4-24 tests, 5-4

displaying

loop status, 4-26 physical port alarms, 4-12 system alarms, 4-11 system log file, 4-10

downloading

software, 4-27 software using X-Modem protocol, 4-29 software via TFTP protocol, 4-27

—E—

entering the terminal session, 4-2 environment specifications, 1-9 equipment, 2-2 Ethernet port

configuring, 4-21 monitoring the status, 4-8

events, 4-11, 5-3, 5-4

I-1

Index MT1000A Installation and Operation Manual

—F—

factory defaults

Factory Default menu, 4-21 resetting, 4-21

features, 1-1 fiber optic

connections, 2-2, 2-7 interface, 1-3 local loopback, 5-6 redundancy, 1-4 remote loopback, 5-8 specifications, 1-7

file system

File System menu, 4-29 viewing information, 4-29

File Utilities menu, 4-27 front panel

clearance, 2-2 connectors, 3-1 controls, 3-1 indicators, 3-1

—G—

grounding, 2-7

connection, 2-7

—H—

hardware

viewing updates, 4-27

height, 1-8 Host IP List menu, 4-17 Host IP menu, 4-17 humidity, 1-9, 2-2

—I—

indications, 1-5

normal, 3-3

indicators

specifications, 1-7

installation, 2-1, 2-3

equipment needed, 2-2

interface, 2-6

fiber optic, 1-3, 1-7, 2-2, 2-7 specifications, A-1 tributary, 1-4, 1-7, 2-1, 2-6, A-1

—J—

jumpers

internal, 2-3 main board, 2-5 setting internal, 2-3, 2-4 settings, 2-5

—L—

Local Device Loops menu, 4-25 local loopback, 5-4, 5-5

fiber optic, 5-6

setting, 4-25 setting timeout, 4-24 T1, 5-5

Local Physical Port Status menu, 4-8 Local Physical Ports Configuration screen, 4-22 Local Redundancy menu, 4-14 Local System Alarms screen, 4-11 local system status

monitoring, 4-5 values, 4-6

local system statusLocal System Status screen, 4-5,

4-27 log file, 4-10, 4-11 login screen, 4-2 loop status

displaying, 4-26

Loops Setting screen, 4-25, 4-26

—M—

Main menu, 4-2 management, 1-6 management access

setting, 4-18

Management Ethernet Status Screen, 4-8 Management Information Base, B-1 Management menu, 4-16 management port

specifications, 1-8

Management Port Configuration screen, 4-22 Manager Access menu, 4-18 manager list

Manager List screen, 4-18

setting, 4-18

menus

Baud Rate, 4-20

Change Access, 4-20

Configuration, 4-13

Control Port, 4-19

Device Info menu, 4-16

Diagnostics, 4-24

Factory Default, 4-21

File System, 4-29

File Utilities, 4-27

Host IP, 4-17

Host IP List, 4-17

Local Device Loops, 4-25

Local Physical Port Status, 4-8

Local Redundancy, 4-14

Main, 4-2

Management, 4-16

Manager Access, 4-18

map, 4-3

Monitoring, 4-4, 4-27

Physical Port Alarms, 4-12

Physical Port Monitoring, 4-4, 4-7

Physical Ports Configuration, 4-21

Redundancy, 4-14

Redundancy Mode, 4-15

I-2

MT1000A Installation and Operation Manual Index

Remote Device Loops, 4-25, 4-26 Remote Physical Port Status, 4-8 S/W & File Transfer, 4-27 System Configuration, 4-14 System Monitoring, 4-4, 4-27 Telnet, 4-19 Via TFTP, 4-28

monitoring, 1-6

channel port status, 4-9 Ethernet port status, 4-8 local system status, 4-5 physical port, 4-4 physical ports, 4-7 remote system status, 4-7 system, 4-4 up-link status, 4-9

Monitoring menu, 4-4, 4-27

—N—

network parameters

setting, 4-17

normal indications, 3-3

—O—

operating, 3-1

instructions, 3-1 turning off, 3-3 turning on, 3-1

—P—

package contents, 2-2 password

setting, 4-19

physical

characteristics, 1-2 specifications, 1-8

physical port

configuring, 4-21 monitoring, 4-4, 4-7 Physical Port Monitoring menu, 4-4, 4-7, 4-8 Physical Ports Configuration menu, 4-21

physical port alarms

displaying, 4-12 Physical Port Alarms menu, 4-12

port alarms, 5-3

Port Alarms screen, 4-12

power supply

AC/DC, 1-6, 1-8, 2-1, 2-8 connection, 2-7 DC, 1-6, 1-8, 2-1, 2-8 grounding, 2-7 redundant, 1-6 requirements, 1-6 specifications, 1-8

prerequisites, 2-1 product features, 1-1

—R—

rear panel, 2-6

clearance, 2-2

redundancy

configuring, 4-13

fiber optic, 1-4

power supply, 1-6

Redundancy menu, 4-14

Redundancy Mode menu, 4-15

Remote Device Loops menu, 4-25, 4-26 remote loopback, 5-4, 5-7

fiber optic, 5-8

setting, 4-26

setting timeout, 4-25

T1, 5-7

Remote Physical Port Status menu, 4-8 Remote Physical Ports Configuration screen, 4-22 Remote System Alarms screen, 4-11 remote system status

monitoring, 4-7

Remote System Status screen, 4-7

requirements, 2-1 resetting

device, 4-21

factory defaults, 4-21

—S—

S/W & File Transfer menu, 4-27 screens

Channel Port Status, 4-9

Channels Configuration, 4-23

Local Physical Ports Configuration, 4-22

Local System Alarms, 4-11

Local System Status, 4-5, 4-27

Loops Settings, 4-25, 4-26

Management Ethernet Status, 4-8

Management Port Configuration, 4-22

Manager List, 4-18

Port Alarms screen, 4-12

Remote Physical Ports Configuration, 4-22

Remote System Status, 4-7

SW Files, 4-29

System Log File, 4-10

Up Link Alarms screen, 4-12

Up-Link Configuration, 4-23

Up-link Status, 4-9

setting

device information, 4-16

local loopback, 4-25

local loopback timeout, 4-24

management access, 4-18

manager list, 4-18

network parameters, 4-17

password, 4-19

remote loopback, 4-26

remote loopback timeout, 4-25

terminal communication parameters, 4-1

user name, 4-19

I-3

Index MT1000A Installation and Operation Manual

setup, 2-1, 2-3 site

prerequisites, 2-1 requirements, 2-1

software

boot partition, 4-30 downloading, 4-27 downloading using X-Modem protocol, 4-29 downloading via TFTP protocol, 4-27 viewing updates, 4-27

specifications, 1-7

alarm connector, 1-8 control DTE supervisory port, 1-8 environment, 1-9 fiber optic, 1-7 indicators, 1-7 interface, A-1 management port, 1-8 physical characteristics, 1-8 power supply, 1-8 T1 tributary interface, 1-7

status

channel port, 4-9 Ethernet port, 4-8 local physical ports, 4-8 local system, 4-5 loops, 4-26 remote physical ports, 4-8 remote system, 4-7 up-link, 4-9

SW Files screen, 4-29 switches

internal, 2-3 main board, 2-5 setting internal, 2-3, 2-4 settings, 2-5

switching

automatic, 1-4

system

alarms, 4-11, 5-3 log file, 4-10, 4-11 monitoring, 4-4

System Configuration menu, 4-14 system log file

clearing, 4-11 displaying, 4-10 System Log File screen, 4-10

System Monitoring menu, 4-4, 4-27

—T—

local loopback, 5-5

remote loopback, 5-7

technical information, 1-7 Telnet menu, 4-19 temperature, 1-9, 2-2 terminal

entering the session, 4-2

management modes, 4-1

setting communication parameters, 4-1

testing, 1-5, 5-1 TFTP protocol, 4-27 tributary interface, 1-4, A-1

connecting channels, 2-6

connections, 2-1

troubleshooting, 5-1 turning the unit

off, 3-3

on, 3-1

—U—

updates

hardware, 4-27

software, 4-27

Up-link

alarms, 5-3

monitoring the status, 4-9

Up Link Alarms screen, 4-12

Up-Link Configuration screen, 4-23

Up-link Status screen, 4-9

user name

setting, 4-19

—V—

Via TFTP menu, 4-28 viewing

file system information, 4-29

hardware updates, 4-27

software updates, 4-27

—W—

weight, 1-8 width, 1-8

—X—

X-Modem protocol, 4-29

I-4

DC Power Supply Connection – Terminal Block Connector

Note: Ignore this supplement if the unit is

AC-powered.

Certain DC-powered units are equipped with a plastic 3-pin VDC-IN power input connector, located on the unit rear panel. Different variations of the connector are shown in Figure 1. All are functionally identical.

Supplied with such units is a kit including a mating Terminal Block (TB) type connector plug for attaching to your power supply cable.

Connect the wires of your power supply cable to the TB plug, according to the voltage polarity and assembly instructions provided below.

Caution: Prepare all connections to the TB plug before inserting it into the unit’s VDC-IN connector.

Preparing and Connecting the Power Supply Cable with the TB Plug

Refer to Figure 2 for assistance.

1. Strip the insulation of your power supply wires according to the dimensions shown.

2. Place each wire lead into the appropriate TB plug terminal according to the voltage polarity mapping shown in Figure 4. (If a terminal is not already open, loosen its screw). Afterwards, tighten close the three terminal screws.

3. Pull a nylon cable tie (supplied) around the power supply cable to secure it firmly to the TB plug grip, passing the tie through the holes on the grip.

4. Isolate the exposed terminal screws/wire leads using a plastic sleeve or insulating tape, to prevent the possibility of short-circuit.

5. Connect the assembled power supply cable to the unit by inserting the TB plug into the unit’s VDC-IN connector until it snaps into place.

Typical DC Power

Input Connector

(on unit panel)

Figure 1. TB DC Input Connectors Types

Appearin

on Unit Panels

Terminal screws

Mating

TB Connector

Plug

Figure 2. TB Plug Assembly

BCA

20 mm

5 mm

Wire stripping

dimensions

See following page

for wire mapping

Nylon cabl e tie

TB plug grip

DC power

cable

SUP-221-03/03

Note: Certain TB plugs are equipped with captive screws for securing the assembled cable’s TB plug to the unit’s VDC-IN connector (C and E types only). To secure the plug, tighten the two screws on the plug into the corresponding holes on the sides of the input connector as shown in Figure 3.

Captive screws

Figure 3. TB Plug with Captive Screws (optional)

DC Power Supply Wire Voltage Polarity

Refer to Figure 4 for proper mapping of the power supply wire leads to the TB plug’s three terminals.

Warning:

• Reversing the wire voltage polarity can cause damage to the unit!

• Always connect a ground (earth) wire to the TB plug’s Chassis (frame) Ground terminal. Connecting the unit without a protective ground, or interruption of the grounding (for example, by using an extension power cord without a grounding conductor) can cause harm to the unit or to the equipment connected to it!

TB Connector Plug

0 -48

Chassis (frame)

Ground

Positive pole

Figure 4. Power Supply Wire Mapping

24/48VDC

to TB Plug

( )

-24

Negative pole

Black Box MT1000A-13-R3, MT1000A-85-R3 Quick Start Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
