MDS931AE-10BT
MDSL Standalone 2.3 Mbit/s Modem
USER MANUAL
Version 1.0
Revision 18. Nov. 2002
© Copyright ©2002 by BLACK BOX Network Services AG. The contents of this publication may not
be reproduced in any part or as a whole, transcribed, stored in a retrieval system, translated into any
language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical,
chemical, photocopying, manual, or otherwise, without the prior written permission of BLACK BOX
Network Services AG. All rights reserved.
User Manual
VERSION CONTROL ........................................................................................................................4
1 INTRODUCTION ......................................................................................................................5
2 GENERAL INFORMATION......................................................................................................6
3 DESCRIPTION OF THE DEVICE.............................................................................................7
3.1 Exterior design ................................................................................................................7
3.2 Functions of switches ......................................................................................................9
3.3 Rules of connection settings .........................................................................................10
4 RULES OF SWITCHING ........................................................................................................11
4.1 The delivery set .............................................................................................................11
4.2 Connection rules ...........................................................................................................11
4.3 Communication parameters of the terminal configuration.............................................11
5 THE COMMAND SYSTEM.....................................................................................................13
5.1 Basic rules.....................................................................................................................13
5.2 The main menu .............................................................................................................13
5.3 Performance management submenu ............................................................................14
5.3.1 TRACETIME command ...................................................................................14
5.3.2 LINE command................................................................................................15
5.3.3 ETH command.................................................................................................15
5.3.4 MAC command................................................................................................16
5.3.5 RESET command............................................................................................16
5.4 Fault and maintenance management submenu ............................................................17
5.4.1 TRACETIME command ...................................................................................17
5.4.2 SQ command...................................................................................................18
5.4.3 STATUS command..........................................................................................18
5.4.4 ALARM command ...........................................................................................19
5.5 Configuration management submenu ...........................................................................19
5.5.1 TRACETIME command ...................................................................................19
5.5.2 CONFIG command..........................................................................................20
5.5.3 RESET command............................................................................................20
5.5.4 MASTER command.........................................................................................20
5.5.5 LINERATE command ......................................................................................21
5.5.6 ADAPTIVE command ......................................................................................21
Page 2 of 30
User Manual
5.5.7 ESPEED command .........................................................................................22
5.5.8 EMODE command...........................................................................................23
5.6 Security management submenu....................................................................................23
6 TECHNICAL SPECIFICATIONS............................................................................................24
7 STORAGE CONDITIONS ......................................................................................................25
8 GUARANTEE .........................................................................................................................26
9 TERMS TO TRANSPORT......................................................................................................27
10 CONNECTOR’S DESCRIPTION............................................................................................28
10.1 DSL Connector..............................................................................................................28
10.2 Monitor Connector.........................................................................................................28
10.3 PC and Hub Connectors ...............................................................................................29
11 DESCRIPTION OF INTERFACE CABLES............................................................................30
Page 3 of 30
User Manual
VERSION CONTROL
Version Date Major changes to previous version
0.0 31.12.2001 Initial version of the manual corresponding to version 1.31 of the
device micro program
0.1 7.02.2002 Information about relays is changed
0.3 1.07.2002 The version of micro program 1.32 is changed
1.0 1.11.2002 The official version, corresponding to Software version 1.41
Page 4 of 30
User Manual
1 INTRODUCTION
The Black BoxDSL Discovery is targeted at the organization of high-rate Black Box to Internet or at
the integration of LANs. The 2B1Q line code is used to transmit information over a twisted pair. The
Black BoxDSL Discovery ensures organization of communication over one twisted pair. The device
provides transmission rates in the range from 192 Kbit/s to 2320 Kbit/s. The parameters of the
device can be set both using switches or stored in the NVRAM with the help of a PC. The
10/100Base-T interface is used as a user’s interface. The device can operate in the transparent
bridge mode with the dynamic accumulation of MAC addresses.
The device is designed to organize a digital channel on the customer premises side and to connect
this channel with the Black BoxDSL Discovery rack-mount unit installed at the central office side. It
is also possible to interconnect two stand-alone modems, for example, for the organization of
communication between LANs.
The modems support uploading of new firmware versions using the Monitor port.
Page 5 of 30
User Manual
2 GENERAL INFORMATION
High-speed symmetrical data transmission over one physical copper twisted pair with the 135
Ohm impedance according to ETSI TS 101 135.
•
•
•
•
•
•
•
•
•
•
•
•
•
2B1Q line encoding.
Line rate in the range from 192 Kbit/s to 2320 Kbit/s.
Manual or automatic mode of line-speed adjustment.
Ethernet 10/100Base-T interface, Full/Half duplex.
Transmission of VLAN packet (IEEE-802.1q).
Dynamic table formation of MAC addresses.
Accumulation of up to 1024 MAC addresses.
Granting of 95% of the digital channel band to the user.
In-built functions of diagnostics and self-testing.
Low power consumption, easy-to-use applications.
Console port for the local management.
220 V power feeding.
Page 6 of 30
User Manual
3 DESCRIPTION OF THE DEVICE
3.1 Exterior design
Exterior design is introduced at the picture
The front panel of the device has five LEDs:
Page 7 of 30
User Manual
LOCAL informs the user about the status of the local device. The following four statuses are
possible
«blinking red» informs the user about malfunctioning of the modem’s hardware and
software. In this case, the modem is out of order and should be
submitted to the service center for being repaired.
«red» informs the user about an urgent alarm. An abruption of the
connection, the correspondence of the signal-to-noise ratio, which
does not allow to transmit information and a great number of errored
blocks, can cause an urgent alarm. See the “Command menu”
chapter for detail.
«amber» informs the user about non-urgent alarms. An abruption of connection
over the user’s interface can cause non-urgent alarms.
«green» absence of alarms. Normal functioning of the device.
REMOTE informs the user about the status of the remote device. At the time being the remote
configuring of modems is not provided.
LINK The LED is lit upon an incorrect connection to the LAN.
ACT The LED is lit on upon the detection of packets in the segment of the current LAN.
10/100 The LED is lit upon the connection to the LAN at 100 Mbit/s.
The back panel of the modem has:
the grounding bolt of the modem (option); •
•
•
•
•
•
The “AC12V” power connector. The connection of the modem to the 220 V power supply is
implemented using an external power supply unit;
the “Monitor” connector to control the modem and store statistics;
switches to set operation modes of the modem in “field” conditions;
“PC” and “HUB” connectors to connect the modem to the LAN using a straight Patch Cord (to
the PC or HUB, respectively);
the “DSL” connector to connect the modem to the leased physical line.
Page 8 of 30
User Manual
3.2 Functions of switches
The switches are used to configure the modem and their position has the following applications:
Number Meaning Effect
OFF Uploading of the modem parameters from the NVRAM 1
ОN Setting of the parameters of the modem with switches
ON The «MASTER» mode is enabled. This mode is usually set on the
provider or the central filter side
2
OFF The «MASTER» mode is disabled
3 OFF The «ADAPTIVE» mode of the automatic speed adjustment is
enabled
ON The «ADAPTIVE» mode is disabled
4,5,6 OFF, OFF, OFF 192 Kbit/s
OFF, OFF, ON 272 Kbit/s
OFF, ON, OFF 400 Kbit/s
OFF, ON, ON 784 Kbit/s
ON, OFF, OFF 1040 Kbit/s
ON, OFF, ON 1552 Kbit/s
ON, ON, OFF 2064 Kbit/s
ON, ON, ON 2320 Kbit/s
7,8 OFF, OFF The Ethernet parameters are set automatically
OFF, ON 10 Mbit/s, half duplex
ON, OFF 100 Mbit/s, half duplex
ON, ON Reserved
Page 9 of 30
User Manual
3.3 Rules of connection settings
It is necessary to stick to the following rules while configuring the modems:
One modem should be set in the “MASTER” mode and the other should have this mode
disabled. Usually the “MASTER” mode is enabled on the provider or central office side because
in this mode the modem can affect the connection parameters.
•
•
•
•
The “ADAPTIVE” mode should be either enabled or disabled on both modems.
In case when the “ADAPTIVE” mode is disabled, the line rates on both modems should be set
equal.
The time of connections in ADAPTIVE mode depends on the current line conditional and can be
up to 5 minutes.
Examples of the modem configuration.
Parameters Modem 1 Modem 2
MASTER ON OFF
ADAPTIVE ON ON
LINERATE 2320 Any
The connection is established at a speed of 2320 Kbit/s.
Parameters Modem 1 Modem 2
MASTER ON OFF
ADAPTIVE OFF OFF
LINERATE 192 192
The connection is established at a speed of 192 Kbit/s.
Page 10 of 30
User Manual
4 RULES OF SWITCHING
Open the package and make sure that the delivery set is complete.
4.1 The delivery set
The delivery set includes:
the subscriber Black Box device (a modem); •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
the power supply source (an AC adapter);
the cable for the connection to the line;
operating manual.
If any problems occur, address to the vendor.
4.2 Connection rules
During the connection of the modem stick to the following rules:
connect the modem using the “straight” Patch Cord cable to the hub through the HUB connector
or to the PC through the PC connector. Only one device can be connected to the modem jack at
the same time;
connect the modem, if necessary, to the serial port of the PC through the “MONITOR” connector
using the “straight” modem cable;
connect the modem to the line using the “DSL” connector;
connect the power supply unit to the AC power system;
connect the modem to the power adapter using the “AC 12V” connector;
launch the hyper-terminal operation program on the PC.
4.3 Communication parameters of the terminal configuration
It is necessary to set the following parameters to monitor the modem:
transmission rate – 9600;
data bits – 8;
parity – none;
number of stop bits – 1;
flow control – XON/XOFF.
Page 11 of 30
User Manual
To update the information on the screen use the “Enter” key. The following menu will appear on the
screen.
MDSL
Ethernet Monitor V1.41
+------------------------+
| Main Menu |
+------------------------+
1. Performance management (PM)
2. Fault and maintenance management (FMM)
3. Configuration management (CM)
4. Security management (SM)
NTU> Select [1..4]:
The modem is ready to be configured.
Page 12 of 30
User Manual
5 THE COMMAND SYSTEM
5.1 Basic rules
After the command is typed, press <enter>.
The <Backspace> key is used to edit commands.
Some commands have the parameter <C> to update the information on the screen. This mode
starts acting after the command is entered. To exit from the mode press any key.
Each command has the (H)elp command to help the user and the (M)ain command to return to the
main menu.
5.2 The main menu
The main menu is the following:
MDSL
Ethernet Monitor V1.41
+------------------------+
| Main Menu |
+------------------------+
1. Performance management (PM)
2. Fault and maintenance management (FMM)
3. Configuration management (CM)
4. Security management (SM)
NTU> Select [1..4]:
The menu consists of four submenus. To choose the needed submenu, it is necessary to type its
number and press “Enter”. The main menu also contains information about the current version of the
firmware. It is important that you inform the service center about it when being consulted.
Page 13 of 30
User Manual
5.3 Performance management submenu
Upon activation of the performance management submenu the following message will be displayed.
00:28:10 Performance management activated
Enter <M> to return to MAIN, or <H> for HELP information
NTU_PM>
Press <H> to see all available commands with their brief description.
00:28:10 Performance management activated
Enter <M> to return to MAIN, or <H> for HELP information
NTU_PM>H
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
LINE Display Line statistic
LINE C Display Line statistic continuously
ETH Display Ethernet statistic
ETH C Display Ethernet statistic continuously
MAC Display MAC table
RESET A Reset All statistics
RESET L Reset Line statistics
RESET E Reset Ethernet statistics
RESET M Reset MAC table statistics
TRACETIME [5..20] Change trace time (5..20 seconds)
M(AIN) Return to main menu
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_PM>
5.3.1 TRACETIME command
The TRACETIME command allows the user to change the time interval of updating the information
on the screen (5…20 seconds):
NTU_PM>TRACETIME 10
NTU_PM>
Page 14 of 30
User Manual
5.3.2 LINE command
The LINE command informs the user about the status of the connection over the physical line. Upon
entering the <C> parameter, the updating of the information on the screen will occur automatically
with the interval of 5…20 seconds according to the parameter set by the TRACETIME command:
Line Port Statistics
LOCAL REMOTE
------------------------------------------------------------------------ 5 sec Total 5 sec Total
Transmit Packets 10 15 9 27
Receive Packets 12 25 5 15
Receive Error Packets 0 0 0 0
Error Packet Rate, % 0.00 0.00 0.00 0.00
Receive Bytes 449 3418 1272 1992
Transmit Bytes 1 1993 1536 3101
Average Speed, kBps 0 0 1 0
------------------------------------------------------------------------Software Version 1.41 1.4
Link Up
Line Speed, kBps 656
Signal Level, dBm 16.0 16.0
Far-End Level, dBm 0.0 0.0
Noise Level, dBm 15.5 15.5
NTU_PM>
5.3.3 ETH command
The ETH command informs the user about the status of the connection over the Ethernet port. Upon
entering the <C> parameter, the updating of the information on the screen will occur automatically
with the interval of 5…20 seconds according to the parameter set by the TRACETIME command:
Ethernet Port Statistics
Speed 100M Duplex Mode Full
Link State Link Up
Input Output
5 sec Total 5 sec Total
Octets 64 9775 1110 19746
Ucast Packets 0 0 0 10
NUcast Packets 0 20 14 224
Discards Pckts 1 74 0 0
Errors 0 0 0 0
NTU_PM>
Page 15 of 30
User Manual
5.3.4 MAC command
The MAC command displays the table of MAC addresses on the screen
LOCAL
00:90:27:1c:78:70 00:09:b7:02:66:91 00:c0:26:31:5d:61 00:60:08:76:62:08
00:60:52:0b:f8:01 XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX
NTU_PM>
5.3.5 RESET command
The modem continuously stores statistics about its operation. The RESET command is used to reset
all the statistics. The following parameters are available:
“A” to reset all the statistics; •
•
•
•
“L” to reset the line statistics;
“E” to reset the Ethernet port statistics;
“M” to reset the MAC table statistics.
NTU_PM>RESET A
01:23:57 All modem statistics cleared
NTU_PM>RESET L
01:24:07 Line statistics cleared
NTU_PM>RESET E
01:24:15 Ethernet port statistics cleared
NTU_PM>RESET M
01:24:22 MAC table statistics cleared
NTU_PM>
Page 16 of 30
User Manual
5.4 Fault and maintenance management submenu
Upon activation of the fault and maintenance management submenu the following message will be
displayed.
01:37:30 Fault and maintenance management activated
Enter <M> to return to MAIN, or <H> for HELP information
NTU_FMM>
Press <H> to see all available commands with their brief description.
01:37:30 Fault and maintenance management activated
Enter <M> to return to MAIN, or <H> for HELP information
NTU_FMM>H
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
SQ Display Signal Quality
SQ C Display Signal Quality continuously
STATUS Display System Status
STATUS C Display System Status continuously
ALARM Display Alarm
ALARM C Display Alarm continuously
TRACETIME [5..20] Change trace time (5..20 seconds)
M(AIN) Return to main menu
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_FMM>
5.4.1 TRACETIME command
The TRACETIME command allows the user to change the time interval of updating the information
on the screen (5…20 seconds):
NTU_FMM>TRACETIME 10
NTU_FMM>
Page 17 of 30
User Manual
5.4.2 SQ command
The SQ command informs the user about the status of the connection over the physical line. Upon
entering the <C> parameter, the updating of the information on the screen will occur automatically
with the interval of 5…20 seconds according to the parameter set by the TRACETIME command. It
is very convenient to create a text file about the connection status for further analysis.
NTU_FMM>SQ
-----Levels, dBm -------------------------------------------------------Time Signal FarEnd Noise R.Pckts T.Pckts E.Pckts EPR%
------------------------------------------------------------------------01:39:13 49.0 50.0 -16.0 0 0 0 0.00
NTU_FMM>
Use this command to store the information about the quality of the connection in log files.
NTU_FMM>SQ C
-----Levels, dBm -------------------------------------------------------------Time Signal FarEnd Noise R.Pckts T.Pckts E.Pckts EPR%
------------------------------------------------------------------------------00:06:35 17.0 0.0 15.5 6 0 0 0.00
00:06:40 16.0 0.0 15.5 8 0 0 0.00
00:06:45 16.0 0.0 15.5 11 1 0 0.00
00:06:50 17.0 0.0 15.5 27 0 0 0.00
00:06:55 16.0 0.0 15.5 13 0 0 0.00
NTU_FMM>
5.4.3 STATUS command
The STATUS command informs the user about the modem status. Upon entering the <C>
parameter, the updating of the information on the screen will occur automatically with the interval of
5…20 seconds according to the parameter set by the TRACETIME command:
Modem Status
Startup time 441 sec ( 0 days 00:07:21)
Line Ethernet
Link Up Link Up
Master OFF Duplex Full
Speed, kBps 656 Speed, Mbps 100
Unavailable time 60 Unavailable time 3
Available time 382 Available time 439
Statistic time 442 Statistic time 442
Link Loss 1
NTU_FMM>
Page 18 of 30
User Manual
5.4.4 ALARM command
The ALARM command informs the user about urgent and non-urgent alarms. Upon entering the
<C> parameter, the updating of the information on the screen will occur automatically with the
interval of 5…20 seconds according to the parameter set by the TRACETIME command:
Alarm Status
Urgent: LossSync – ON HiEPR - OFF
Not-urgent: Link – OFF LoEPR - OFF SQ - OFF
NTU_FMM>
5.5 Configuration management submenu
Upon activation of the configuration management submenu the following message will be displayed.
01:47:50 Configuration management activated
Enter <M> to return to MAIN, or <H> for HELP information
NTU_CM>
Press <H> to see all available commands with their brief description.
01:47:50 Configuration management activated
Enter <M> to return to MAIN, or <H> for HELP information
NTU_CM>H
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
CONFIG Display local configuration
RESET System Reset
MASTER ON|OFF Set xDSL master/slave mode (similar to CO/RT)
LINERATE [1..8] Select line rate
ADAPTIVE ON|OFF Set adaptive mode to ON/OFF ( only for slave mode)
DEFAULT [0..1] Set default configuration
ESPEED [AUTO|10|100] Set speed of Ethernet port
EMODE [AUTO|HALF|FULL] Set Duplex mode of Ethernet port
TRACETIME [5..20] Change trace time (5..20 seconds)
M(AIN) Return to main menu
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>
5.5.1 TRACETIME command
The TRACETIME command allows the user to change the time interval of updating the information
on the screen (5…20 seconds):
NTU_CM>TRACETIME 10
NTU_CM>
Page 19 of 30
User Manual
5.5.2 CONFIG command
The CONFIG command informs the user about the configured parameters.
NTU_CM>CONFIG
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2320
Master/Slave: Master
Adaptive mode: ON
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>
5.5.3 RESET command
The RESET command restarts the modem.
NTU_CM>RESET
01:55:02 system reset
5.5.4 MASTER command
The MASTER command sets the modem either in the maser or slave modes.
NTU_CM>MASTER ON
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2320
Master/Slave: Master
Adaptive mode: ON
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>MASTER OFF
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2320
Master/Slave: Slave
Adaptive mode: ON
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>
Page 20 of 30
User Manual
5.5.5 LINERATE command
The LINERATE command determines the modem connection rate over the line. The number
parameters from 1 to 16 determine the connection rate.
NTU_CM>LINERATE 1
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 192
Master/Slave: Slave
Adaptive mode: ON
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>LINERATE 16
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2320
Master/Slave: Slave
Adaptive mode: ON
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>
5.5.6 ADAPTIVE command
The ADAPTIVE command adjusts the line rate of the slave modem to the line rate of the master
modem. The line rates should be set equal on both modems.
NTU_CM>ADAPTIVE ON
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2064
Master/Slave: Slave
Adaptive mode: ON
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>ADAPTIVE OFF
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2064
Master/Slave: Slave
Adaptive mode: OFF
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Page 21 of 30
User Manual
NTU_CM>
5.5.7 ESPEED command
The ESPEED command determines the operating speed over the Ethernet port.
NTU_CM>ESPEED AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2064
Master/Slave: Slave
Adaptive mode: OFF
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>ESPEED 10
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2064
Master/Slave: Slave
Adaptive mode: OFF
Ethernet
Speed: 10
Duplex mode: HALF
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>ESPEED 100
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2064
Master/Slave: Slave
Adaptive mode: OFF
Ethernet
Speed: 100
Duplex mode: HALF
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>
Page 22 of 30
User Manual
5.5.8 EMODE command
The EMODE command sets the operation mode over the Ethernet port.
NTU_CM>EMODE AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2064
Master/Slave: Slave
Adaptive mode: OFF
Ethernet
Speed: AUTO
Duplex mode: AUTO
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>EMODE HALF
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2064
Master/Slave: Slave
Adaptive mode: OFF
Ethernet
Speed: 100
Duplex mode: HALF
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>EMODE FULL
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
xDSL
Line Rate,kbit/s: 2064
Master/Slave: Slave
Adaptive mode: OFF
Ethernet
Speed: 100
Duplex mode: FULL
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_CM>
5.6 Security management submenu
Upon activation of the security management submenu the following message will be displayed.
00:18:02 Security management activated
Enter <M> to return to MAIN, or <H> for HELP information
NTU_SM>
It is reserved for further developments.
Page 23 of 30
User Manual
6 TECHNICAL SPECIFICATIONS
The main technical specifications of modems of the Black Box family are presented below in the
table.
Line interface.
Standard ETSI 101 135
Number of pairs 1
Line rate 192 – 2320 Kbit/s
Communication range for cables
with the wire diameter of
144 Kbit/s
2320 Kbit/s
0.5 mm:
7.7 km
3.4 km
1.2 mm:
31 km
13.7 km
Line code 2B1Q
Input impedance of the physical line 135 Ohm
Output signal level 7.8 – 14.8 dBm
Transmission spectrum from 0…96 kHz to 0…1160 kHz
User’s interface
Standard: IEEE-802.3
IEE-802.1q
Interface type: Ethernet 10/100Base-T, Full/Half Duplex
Connector: RJ-45
Management
Monitoring VT100
Power supply
Supply voltage:
~220 V ± 10%; 50 Hz
Power consumption: No more than 5 W
Grounding resistance No more than 10 Ohm
Protection Conforms to the requirements of the GOST (State Standard)
12.2007.0-85, GOST 7153-85,
GOST Р.50033-92 and Norm 9-93
Climatic conditions
Temperature range -5о С ….+45о С
Relative humidity of air 5%…85%
Page 24 of 30
User Manual
7 STORAGE CONDITIONS
The equipment of the Black Box family while being packed should withstand all means of transport
at a temperature in the range form -50
о
С to +50о С and the relative humidity of air up to 100% at 25
о
С. The equipment can also withstand air-transport at a low air pressure of 12 kPa (90 Torr) at -50о С.
The packed equipment of the Black Box family can be stored within 12 months (from the date of
transshipment including transporting time) in storage rooms without heating at -50
о
С - +50о С and
the mean monthly value of the air humidity of 80% at 20
о
С; short-term increases of air humidity up
to 98% (no more than a month a year) at a temperature not exceeding 25
о
С without moisture
condensation is admissible.
The equipment should be stored in storage buildings, which protect the devices from atmospheric
precipitations. The equipment should be kept on shelves or in factory packages in the absence of
vapors of acids, alkali and other atmospheric impurities.
Page 25 of 30
User Manual
8 GUARANTEE
The mean time before failure is no less 30000 hours.
The manufacturer guarantees that the equipment are in all respects in accordance with the
requirements of technical conditions when the customer follows the rules and conditions of
storage, transporting and maintenance.
The guarantee period (no less than 12 months after putting the equipment into operation) is
specified upon drawing the Contract for the sale of the equipment.
Should the equipment prove defective during the guarantee period, the manufacturer
undertakes to remedy the defects or replace the faulty equipment. If the defects appear due
to incompetent storage, maintenance and transporting, the guarantee does not cover such
defects.
After the guarantee period expires, the manufacture provides paid delivery of spare parts.
The list of spare parts and terms of their delivery during the operating lifetime of the
equipment should be specified in the Contract.
Page 26 of 30
User Manual
9 TERMS TO TRANSPORT
The equipment of the Black Box family should be packed and transported by:
motor transport with an enclosed truck body; •
•
•
•
•
•
•
•
•
•
•
enclosed railroad cars;
unpressurized airplanes and helicopters (up to 10000 m at an air pressure of 170 Torr);
river transport (in holds).
The Black Box family equipment should withstand transportation when being packed under the
following conditions:
temperature from -50
о
С to +50о С;
relative air humidity up to 100% at 25
о
С (within 10 days).
The equipment of the Black Box family should be packed and withstand transportation by:
motor transport with the number of transshipments no more than four:
along the asphalt-concrete and cement-concrete roads at a distance of 200 – 1000 km;
earth roads at a distance of 50 – 250 km at a speed of 40 km/hour;
different means of transport (airplanes, railway transport in combination with motor transport
along the asphalt-concrete and cement-concrete roads at a distance of 200 km) with the number
of transshipments from three to four;
water transport (excluding sea transport) in combination with motor transport along the asphaltconcrete and cement-concrete roads at a distance of 200 km with the number of transshipments
no more than four.
During transportation the packages with the equipment should be fixed so that to exclude their
moving, collision and collision against the transport bodies.
Page 27 of 30
User Manual
10 CONNECTOR’S DESCRIPTION
10.1 DSL Connector
Type: RJ-11, 4 pin
Number Signal Assignment
1 NC -
2 LA,a tip
3 LA,b ring
4 NC -
RJ-11
1
4
10.2 Monitor Connector
Type: Sub-D9, female
Number Signal Assignment
1 NC -
2 TXD Transmit data
3 RXD Receive data
4 DTR Data terminal ready
5 SGND Signal ground
6 NC -
7 NC -
8 NC -
9 NC -
DB9
female
1
5
6
9
Page 28 of 30
User Manual
10.3 PC and Hub Connectors
Type: RJ-45 Number PC assignment HUB assignment
1 Tx+ Rx+
2 Tx- Rx-
3 Rx+ Tx+
4 NC NC
5 NC NC
6 Rx- Tx-
7 NC NC
8 NC NC
18
............
RJ-45
Page 29 of 30
User Manual
Page 30 of 30
11 DESCRIPTION OF INTERFACE CABLES
«Straight» Ethernet cable
Side А Color of wire Side B
1 white/green 1
2 green/white 2
3 white/orange 3
4 blue/white 4
5 white/blue 5
6 orange/white 6
7 white/brown. 7
8 brown/white 8
«Straight» modem cable
The device side The PC side
DB9M DB9F DB25F
2 2 3
3 3 2
5 5 7
4 4 20
Loading...
