Our toughest, most versatile

media conversion system.

Our toughest, most versatile

media conversion system.

Dynamic Fiber Conversion System

© 2007. All rights reserved. Black Box Corporation.

FREE 24-hour Tech Support: 724-746-5500

blackbox.com

2 of 8

5/22/2007
#10841

724-746-5500 blackbox.com

FEATURES

• Dynamic modular system grows with
your network.

• More module choices than any other
media converter system.

• Tough construction for hard use: Most
modules are NEBS Level 3 certified.

• Use with or without management.

• Hot-swappable modules.

• Four different powered chassis to
choose from.

OVERVIEW

The Dynamic Fiber Conversion System is without a doubt
the most robust media conversion system we’ve ever
evaluated.

The system is suited for fiber-based carrier-class or
enterprise networks. It withstands harder use than most
media conversion systems and offers a wider choice of
modules—including autosensing 10/100/1000 Ethernet media
converters and switches—than any other system. Plus, it’s fully
SNMP manageable. You just aren’t going to find a harder­working, more-versatile system anywhere.

Tough as nails

Most components of the Dynamic Fiber Conversion System
are NEBS Level 3 certified (See “What is NEBS Level 3?” on
page 5), and the rest are in the process of being certified.
The system is suitable for the most demanding carrier-class
applications in telco central offices (COs). The heavy-duty
chassis stand up to hard use and each module screws solidly
into place.

Fully manageable

The Dynamic Fiber Conversion System is completely SNMP
manageable with the installation of one SNMP Management
Module in each chassis. You can manage a stack of up to 16
chassis in one location as a single IP address.

The SNMP Management Module features a 32-bit, high­performance RISC processor. It has a serial port for initial
configuration, a frontplane or backplane Ethernet
management port, and a pair of multichassis management
ports.

The SNMP Management Module polls all converters and
power supplies in its domain every second, collecting status
and module information. It reports this information to the
management software.

Use any standard SNMP management software to manage
the system using in-band or out-of-band SNMP and Telnet.

Optional Management Software is customized to work
with the Dynamic Fiber Conversion System. It can operate as
a standalone application in Windows

®

9x/Me/XP, Windows

2000, or Windows NT

®

. Or you can integrate it into a

management program such as HP

®

OpenView®.

Management Software features an intuitive GUI interface,
which provides real-time monitoring, configuration, alarms,
and event/trap management.

The software monitors chassis power, voltage, current,
and temperature. It enables you to remotely and selectively
monitor and configure the chassis, modules, and ports.
Settings, such as speed, are switch selectable at the module
but can be overridden through the Management Software.
(See Management Features on page 4.)

You can group the modules together for mass
configuration, and they maintain settings even if there’s a
power outage.

Backplane links

Many modules—in particular, the Switch Module— can be
linked to other modules in the chassis through the backplane,
enabling multiple modules to act as one. The backplane link
can be made through a DIP switch on the module or through
the management software.

Modules that support backplane links are the Switch
Module (LMC3050C), some Gigabit modules (LMC3058C–
LMC3063C), and some copper/fiber converters (LMC3033C–
3042C).

Choose from four different powered chassis

The 19-Slot Power Chassis holds up to 19 converter
modules or 18 converter modules plus a management
module. For extra power redundancy, it holds up to three
AC or DC power supplies in any combination, each cooled
with an integral fan. The chassis occupies 2U (3.5") of rack
space and comes complete with rackmount ears.

The 5-Slot Power Chassis enables you to put five modules
into only 1U (1.75") of rack space. It accommodates one or
two AC or DC power supplies.

The 2-Slot Power Chassis is intended for desktop use and
has one AC or DC power supply.

The 19-, 5-, and 2-Slot Chassis are manageable with the
addition of SNMP Management modules. The chassis report
the voltage, current, and temperature of each power supply.

Use the unmanaged 1-Slot Power Chassis in non-critical
remote locations. It’s intended for desktop use and is available
only with an AC power supply.

Many hot-swappable modules to choose from

The Dynamic Fiber Conversion System gives you more
module choices than any other we offer, including multimode
fiber, single-mode fiber, single-strand fiber, 10/100/1000
Ethernet, Gigabit Ethernet, a 4-port switch module, ATM,
and T1/E1.

All modules are hot swappable and manageable.

UTP to Coax Module

This module converts Ethernet from 10BASE-T to 10BASE2
cable. It works at a speed of 10 Mbps.

UTP ports detect and correct wiring polarity reversals.
The module has a crossover switch that enables you to use a
straight-through cable to connect to a workstation or hub.

The coax port has a BNC connector and supports 50-ohm
cable at distances of up to 606 feet (184.7 m).

3 of 8

5/22/2007
#10841

UTP to Multimode Duplex Fiber Modules

These modules convert Ethernet from twisted-pair
to standard duplex multimode fiber optic cable. They’re
available in 10-Mbps, 100-Mbps, and 1000-Mbps, as well as
autosensing 10-/100-Mbps and 10-/100-/1000-Mbps modules.

UTP ports are autosensing for half- or full-duplex. An
MDI/MDI-X switch eliminates the need for crossover cable.
Plus, the modules feature Link Propagation, which passes
on link disconnection information from the fiber side to
the copper side, and vice-versa.

UTP to Single-Mode Duplex Fiber Modules

Single-mode fiber optic cable is the preferred choice for
long-distance applications, and the Dynamic Fiber Conversion
System offers many single-mode fiber choices, supporting
ranges of up to 80 kilometers (that’s about 50 miles!).

10-/100-Mbps and 10-/100-/1000-Mbps modules are auto­sensing for speed on the UTP side. UTP ports on all modules
are autosensing for half- or full duplex. All modules have
switch-selectable MDI/MDI-X and a Link Propagation feature
for communicating link disconnection information from the
copper to fiber side, or the fiber to copper side.

UTP to Single-Mode Single-Strand Modules

These modules enable you to save on cabling costs by
transmitting and receiving over one single-mode fiber strand.
(See the ”Single-strand fiber WDM” box on page 4.) Like
our UTP to Single-Mode Duplex Fiber Modules, single-fiber
modules are autosensing for speed on 10-/100-Mbps and
10-/100-/1000-Mbps modules and are autosensing for half- or
full-duplex. They also have switch-selectable MDI/MDI-X and
a Link Propagation feature.

Mode Converters

Mode Converters enable you to interconnect multimode
and single-mode fiber optic cable. All have a Link Propagation
feature for remote troubleshooting.

Redundant Modules

These modules convert a single 100BASE-TX UTP link to
dual 100-Mbps fiber optic or dual 10-/100-Mbps copper links.
They provide hot backup for your vital connections, switching
to the redundant link within 100 microseconds if the primary
link goes down.

All ports support full or half-duplex operation; UTP ports
autonegotiate duplex, and fiber ports can only be set
manually. All UTP ports support MDI/MDI-X, eliminating the
need for crossover cables. All ports support Link Loss Carry
Forward (Link Propagation).

Switch Module

Not a converter, but a welcome addition to the Dynamic
Fiber Conversion System, the Switch Module features four

10-/100-Mbps Ethernet ports. The switch is autosensing for
both speed and duplex with hardware control available for
two ports and software control available for all four ports.

The switch supports MDI/MDI-X crossover. Port 1 has a
manual crossover switch; Ports 2, 3, and 4 feature automatic
crossover detection.

ATM OC3 Modules

These modules support OC3 over ATM or SONET and
convert duplex multimode fiber optic cable to duplex single­mode fiber optic cable. They enable you to use single-mode
cable to add up to 28 kilometers (17.4 mi.) of distance to your
OC3 network. Plus, you get another 5 kilometers (3.1 miles)
of distance on the multimode side.

For fault detection, the modules feature Line Propagate,
Link Segment, and Remote Fault Detection modes.

T1/E1 Modules

Convert copper T1 lines with RJ-48 connectors to single­or multimode fiber for long-range transmission. The modules
support AMI or B8ZX/HDB3 modes. A DCE/DTE switch
eliminates the need for crossover cable when connecting
to devices such as PBXs and CSUs. Test modes include Local
Loopback, Force 1s to Copper, Force 1s to Fiber, and Fiber Test.

Modules with VLAN Tagging

Multimode and single-mode modules are also available
with VLAN tagging.

The modules provide UTP to fiber conversion as well as
rate conversion between 10BASE-T or 100BASE-TX and
100BASE-FX fiber.

The modules support IEEE 802.1Q Tag VLAN packet
tagging and untagging including double-tagging (1Q1A
double-stacking) as well as PortVLAN. VLAN tagging provides
a secure way to keep track of data packets as they are
transported across a LAN or WAN. It also enables users
to tunnel enterprise VLAN networks transparently through
the service provider’s network.

Like the versions without VLAN tagging, these modules are
available with different fiber port options such as multimode,
single-mode, and single-fiber. They support ST, SC, MT-RJ, and
LC connectors.

Desktop or Wallmount Managed Media Converters
for the Dynamic Fiber Conversion System

These remote managed media converters fit neatly on
a desktop or mount on a wall. Models are available with
110-VAC, 220-VAC, or 8–16-VDC power supplies. They convert
10BASE-T/100BASE-TX to 100BASE-FX. The converters work
with all components of the Dynamic Fiber Conversion System.
(See the ordering information on pages 6–8.) Management
software (LMC3003A) is also available.

724-746-5500 blackbox.com

4 of 8

5/22/2007
#10841

724-746-5500 blackbox.com

Single-strand fiber WDM.

Traditional fiber optic media converters perform a useful
function but don’t really reduce the amount of cable needed
to send data on a fiber segment. They still require two strands
of glass to send transmit and receive signals for fiber media
communications. Wouldn’t it be better to combine these two
logical communication paths within one strand?

That’s exactly what single-strand fiber conversion does. It
compresses the transmit and receive wavelengths into one
single-mode fiber strand.

The conversion is done with Wave Division Multiplexing
(WDM) technology. WDM increases the information-carrying
capacity of optical fiber by transmitting two signals
simultaneously at different wavelengths on the same fiber.
The way it usually works is that one unit transmits at 1550 nm
and receives at 1310 nm. The other unit transmits at 1310 nm
and receives at 1550 nm. The two wavelengths operate
independently and don’t interfere with each other. This
bidirectional traffic flow effectively converts a single fiber
into a pair of “virtual fibers,“ each driven independently
at different wavelengths.

WDM on single-strand fiber is most often used for point­to-point links on a long-distance network. It’s also used to
increase network capacity or relieve network congestion.

Chassis Information

• Part Number

• Serial Number

• Revision

• Description

Chassis Status

• Power Status

• Power Output Voltage

• Chassis Temperature

• Chassis Reset

Port Information

• Name

• Type

• Speed

• Slot Occupied

• Port Number

Port Status

• Administrative

• Operational

•Link

Module Status

• Module Power

• Link Status

• Activity

• Active Port

• Diagnostic Status

• Management

• Redundancy

• Media Converter Type

• Slot Occupied

• Part Number

• Serial Number

• Configuration

• Revision

• Ports on Module

Alarms

• Cold Start

• Warm Start

• Link Up

• Link Down

• Authentication Failure

• Configuration Change

• Backplane Failure

• Temperature Out of
Range

• Power Supply On/Off

• Power Supply Inserted

• Power Supply Removed

• Chassis Reset

• Module Reset

• Port Reset

• Module Insertion

• Module Removal

• Module Unknown

• Module Failure

• Port Link State Change

• Redundant Switchover

Active Control

• Link Propagate

• Remote Fault Detection

• Port Name

• Module Name

• Chassis Name and
Location

• IP Address

• Disable Management
Port

• Alarm Threshold Setting

• Download Software via
FTP

• Reset Chassis

• Subnet Mask

• Default Gateway

• Telnet to Console
Commands

Management Module

Statistics

• In Bytes

• Out Bytes

• In Errors

• Out Errors

• In Discards

• Out Discards

MANAGEMENT FEATURES

Technically Speaking

1310 nm

1550 nm

5 of 8

5/22/2007
#10841

724-746-5500 blackbox.com

What is NEBS Level 3?

Network Equipment Building System (NEBS) standards
set requirements for telco equipment. The standards are
maintained by Telcordia Technologies, Inc., formerly Bellcore.
Bellcore Special Report, SR-3580 defines three distinct
functional levels of NEBS compliance. The third of these
levels, NEBS Level 3, is the most stringent, certifying carrier­class equipment intended for long-term use in variable
environments.

NEBS Level 3 certifies that a piece of equipment can be
safely used in an extreme environment. To become certified
at NEBS Level 3, a device must meet strict physical, electrical,
and environmental requirements to prove it will operate
safely and reliably in extreme conditions. It must pass a series
of tests that include extreme heat, humidity, fire, earthquakes
(Zone 4), light, and noise.

Technically Speaking

TECH SPECS for Chassis

Power — LMC3004A–LMC3005A, LMC3010A, LMC3080A,

LMC3014A: 110–230 VAC, 50 –60 Hz, autosensing, internal;

LMC3007A–LMC3008A, LMC3012A, LMC3081A –LMC3082A:

± 48 VDC, internal;

LMC3015A: 110 VAC, 60 Hz, external (220-VAC power supply

available on request)

Size — 19-Slot Chassis: 3.5"H (2U) x 17.2"W x 14"D (8.9 x 43.7 x 35.6 cm);

5-Slot Chassis: 1.75"H (1U) x 17.2"W x 9"D (4.4 x 43.7 x 22.9 cm);
2-Slot Chassis: 1.9"H x 6.7"W x 5.5"D (4.8 x 17 x 14 cm);
1-Slot Chassis: 1"H x 3.8"W x 5.5"D (2.5 x 9.7 x 14 cm)

Weight —

19-Slot Chassis: Single power supply: 16 lb. (7.3 kg);

Dual power supplies: 18.5 lb. (8.4 kg);

5-Slot Chassis: Single power supply: 7.5 lb. (3.4 kg);

Dual power supplies: 9 lb. (4.1 kg);
2-Slot Chassis: 2.5 lb. (1.1 kg);
1-Slot Chassis: 1.5 lb. (0.7 kg)

TECH SPECS for Modules

Connectors — LMC3000A: (1) DB9 serial, (2) RJ-45 Ethernet,

(2) proprietary multichassis management ports;

Converter Modules: See ordering information on pages 6– 7

Indicators — LEDs:

LMC3000A: (1) Power, (3) Power Supply, (1) UTP Link, (1) Master,

(1) Slave, (1) Management Poll;
LMC3018C-R2–LMC3022C-R2: (1) Power, (1) Fiber Link, (1) UTP Link;
LMC3023C–LMC3032C: (1) Power, (1) Fiber Link, (1) UTP Link, (1) Auto,

(1) Half-/Full-Duplex;
LMC3033C–LMC3042C, LMC3084C–LMC3095C: (1) Power, (1) Fiber Link,

(1) UTP Link, (1) Auto, (1) UTP Half-/Full-Duplex, (1) Fiber Half-/Full-

Duplex, (1) 10/100;
LMC3051C–LMC3052C, LMC3054C–LMC3057C: (1) Power, (1) Fiber Link,

(1) UTP Link, (1) Fiber Half-/Full-Duplex;
LMC3058C–LMC3063C: (1) Power, (1) Fiber Optic Link, (1) Auto,

(1) Fiber, (1) Half-/Full-Duplex, (1) 10/100/1000;
LMC3064C–LMC3073C: (1) Power, (2) Fiber Optic Link;
LMC3045C–LMC3049C: (1) Power, (1) Fiber Optic Link, (1) UTP Link,

(1) Select, (1) Auto, (1) Half-/Full-Duplex;
LMC3043C: (1) Power, (1) UTP Link, (2) 10/100;
LMC3050C: (1) Power, (4) UTP Link, (4) 10/100;
LMC3074C–LMC3075C: (1) Power, (2) Fiber Optic Link;
LMC3076C–LMC3079C: (1) Power, (1) Test, (1) RJ-45/RJ-48 Link,

(1) Fiber Optic Link;
LMC3083C: (1) Power, (1) RJ-45 Link, (1) BNC Link;
LMC3100C–LMC3107C: (1) Power, (3) Power Supply, (1) Fiber Optic Link

(FO), (1) Master/Slave (BP), (1) 10 UTP, (1) 100 UTP, (1) FDX

Power — From the interface
Size — 2.8"H x 0.9"W x 4.5"D (7.1 x 2.3 x 11.4 cm)
Weight — 0.5 lb. (0.2 kg)

TECH SPECS for Managed Desktop
and Wallmount Models

Connectors — See ordering information on page 8
Indicators — (1) Power, (3) Power Supply, (1) Fiber Optic Link (FO),

(1) Master/Slave (BP), (1) 10 UTP, (1) 100 UTP, (1) FDX

Power — LMC3100A–LMC3115A: 110 VAC, 60 Hz, external;

LMC3100AE– LMC3115AE: 220 VAC, 50 Hz, external;
LMC3100A-DC–LMC3115A-DC: 8–16 VDC

Size — 1"H x 3.8"W x 5.5"D (2.5 x 9.7 x 14 cm)
Weight — 1.5 lb. (0.7 kg)

6 of 8

5/22/2007
#10841

724-746-5500 blackbox.com

Item Code

Dynamic Fiber Conversion System

First, order the chassis…

19-Slot Power Chassis (Managed, Rackmount)

with (1) AC Power Supply LMC3004A
with (2) AC Power Supplies LMC3005A
with (1) DC Power Supply LMC3007A
with (2) DC Power Supplies LMC3008A

5-Slot Power Chassis (Managed, Rackmount)

with (1) AC Power Supply LMC3010A
with (2) AC Power Supplies LMC3080A
with (1) DC Power Supply LMC3012A
with (2) DC Power Supplies LMC3081A

2-Slot Power Chassis (Managed, for Desktop Use)

with (1) AC Power Supply LMC3014A
with (1) DC Power Supply LMC3082A

1-Slot Power Chassis (Unmanaged, for Desktop Use)

with (1) AC Power Supply LMC3015A

…then you may need some of these chassis accessories…

NMM Cascade Cable, 3-ft. (0.9-m) LMC3001A
Blank Panels for Unused Slots LMC3002A
Wallmounting Kit for 1-Slot Chassis LMC3017C
Spare Power Supplies

for 19-Slot Chassis (Holds up to Three Power Supplies)

AC LMC3006P
DC LMC3009P

for 5-Slot Chassis (Holds up to Two Power Supplies)

AC LMC3011P
DC LMC3013P

If you want to manage your system, order a management
module…

SNMP Management Module LMC3000A

…then software.

Management Software LMC3003A

Next order converter modules.

UTP to Coax Modules

10BASE-T to 10BASE2 LMC3083C

UTP to Multimode Duplex Fiber Modules

10BASE-T/10BASE-FL

850-nm, 2 km

ST

®

LMC3018C-R2

SC LMC3021C-R2

1310-nm, 5 km

ST LMC3019C-R2

1310-nm, 30 km

ST LMC3020C-R2
SC LMC3022C-R2

100BASE-TX to 100BASE-FX

1310-nm, 5 km

ST LMC3023C
SC LMC3026C

1310-nm, 30 km

ST LMC3024C
SC LMC3027C

1310-nm, 60 km

ST LMC3025C
SC LMC3028C

Item Code

10BASE-T/100BASE-TX to 100BASE-FX

1310-nm, 5 km

ST LMC3033C
SC LMC3036C

1000BASE-T to 1000BASE-SX

850-nm, 220 m

SC LMC3051C
MT-RJ LMC3054C

10BASE-T/100BASE-TX/1000BASE-T to 1000BASE-SX

850-nm, 220 m

SC LMC3058C

UTP to Single-Mode Duplex Fiber Modules

10BASE-T/100BASE-TX to 100BASE-FX

1310-nm

30 km, ST LMC3034C
30 km, SC LMC3037C
60 km, ST LMC3035C
60 km, SC LMC3038C

1000BASE-TX to 1000BASE-LX

1310-nm

12 km, SC LMC3052C
12 km, MT-RJ LMC3055C

10BASE-T/100BASE-TX/1000BASE-T to 1000BASE-LX

1310-nm

12 km, SC LMC3059C
34 km, SC LMC3060C

1550-nm

80 km, SC LMC3061C

10BASE-T/100BASE-TX to 100BASE-FX with VLAN Tagging

Multimode, 1310-nm/5 km

ST LMC3084C
SC LMC3087C
MT-RJ LMC3091C

Single-Mode, 1310-nm/30 km

ST LMC3085C
SC LMC3088C
MT-RJ LMC3092C
LC LMC3093C

Single-Mode, 1310-nm/60 km

ST LMC3086C
SC LMC3089C
LC LMC3094C

Single-Mode, 1550-nm/120 km

SC LMC3090C
LC LMC3095C

LMC3004A: shown with modules

7 of 8

5/22/2007
#10841

724-746-5500 blackbox.com

Item Code

UTP to Single-Mode Single Fiber

100BASE-TX to 100BASE-FX

1310-nm TX/1550-nm RX

20 km, SC LMC3029C
40 km, SC LMC3030C

1550-nm TX/1310-nm RX

20 km, SC LMC3031C
40 km, SC LMC3032C

10BASE-T/100BASE-TX to 100BASE-FX

1310-nm TX/1550-nm RX

20 km, SC LMC3039C
40 km, SC LMC3040C

1550-nm TX/1310-nm RX

20 km, SC LMC3041C
40 km, SC LMC3042C

1000BASE-TX to 1000BASE-X

1310-nm TX/1550-nm RX

20 km, SC LMC3056C

1550-nm TX/1310-nm RX

20 km, SC LMC3057C

10BASE-T/100BASE-TX/1000BASE-T to 1000BASE-X

1310-nm TX/1550-nm RX

20 km, SC LMC3062C

1550-nm TX/1310-nm RX

20 km, SC LMC3063C

Mode Converters

100BASE-FX Multimode Duplex to 100BASE-FX
Single-Mode Duplex

1310-nm/1310-nm, Multimode, 5 km/Single-Mode

20 km, ST LMC3064C
20 km, SC LMC3066C
60 km, ST LMC3065C
60 km, SC LMC3067C

120 km, SC LMC3068C
1000BASE-SX Multimode Duplex to 1000BASE-LX
Single-Mode Duplex

850-nm/1310-nm, Multimode, 220 m/Single-Mode

12 km, SC LMC3069C
34 km, SC LMC3070C

80 km, SC LMC3071C
1000BASE-X Multimode Duplex to 1000BASE-X
Single-Mode Single-Strand

220 m/20 km, SC

1310-nm TX/1550-nm RX LMC3072C

1550-nm TX/1310-nm RX LMC3073C

Item Code

Redundant Modules

UTP to Dual Multimode Duplex Fiber

(1) 100BASE-TX to (2) 100BASE-FX, 1310-nm

5 km, SC LMC3047C

UTP to Dual Single-Mode Duplex Fiber

(1) 100BASE-TX to (2) 100BASE-FX, 1310-nm

30 km, ST LMC3045C
30 km, SC LMC3048C
60 km, ST LMC3046C
60 km, SC LMC3049C

UTP to Dual UTP

(1) 100BASE-TX to (2) 10/100BASE-T,

100 m, RJ-45 LMC3043C

Switch Module

4-Port 10/100 Ethernet Switch, (4) RJ-45 LMC3050C

ATM OC3 Modules

Duplex Multimode to Duplex
Single-Mode, 1310-nm/1310-nm

5 km/28 km

ST LMC3074C
SC LMC3075C

T1/E1 Copper to 1310-nm Multimode Duplex Fiber Modules

5 km

ST LMC3076C
SC LMC3078C

30 km

ST LMC3077C

SC LMC3079C
Managed Media Converter Modules for the Dynamic Fiber
Conversion System

10BASE-T/100BASE-TX to 100BASE-FX, 1310-nm

Multimode

5 km, ST LMC3100C

5 km, SC LMC3102C

Single-Mode

30 km, ST LMC3101C

30 km, SC LMC3103C

Single-Mode, Single-Strand, 20 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3104C

1550-nm TX/1310-nm RX, SC LMC3106C

Single-Mode, Single-Strand, 40 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3105C

1550-nm TX/1310-nm RX, SC LMC3107C

LMC3032C

8 of 8

5/22/2007
#10841

724-746-5500 blackbox.com

Item Code

Desktop Managed Media Converters for the Dynamic Fiber
Conversion System, 110 VAC

10BASE-T/100BASE-TX to 100BASE-FX

Multimode, 5 km

5 km, ST LMC3100A
5 km, SC LMC3102A

Single-Mode, 1310-nm, 30 km

30 km, ST LMC3101A
30-km, SC LMC3103A

Single-Mode, Single-Strand, 20 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3104A
1550-nm TX/1310-nm RX, SC LMC3106A

Single-Mode, Single-Strand, 40 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3105A

1550-nm TX/1310-nm RX, SC LMC3107A
Desktop Managed Media Converters for the Dynamic Fiber
Conversion System, 220 VAC

10BASE-T/100BASE-TX to 100BASE-FX

Multimode, 5 km

ST LMC3100AE

SC LMC3102AE

Single-Mode, 1310-nm, 30 km

ST LMC3101AE

SC LMC3103AE

Single-Mode, Single-Strand, 20 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3104AE

1550-nm TX/1310-nm RX, SC LMC3106AE

Single-Mode, Single-Strand, 40 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3105AE

1550-nm TX/1310-nm RX, SC LMC3107AE
Desktop Managed Media Converters for the Dynamic Fiber
Conversion System, 8–16 VDC

10BASE-T/100BASE-TX to 100BASE-FX

Multimode, 5 km

ST LMC3100A-DC

SC LMC3102A-DC

Single-Mode, 1310-nm, 30 km

ST LMC3101A-DC

SC LMC3103A-DC

Single-Mode, Single-Strand, 20 km (Order one of each.)

1310-nm TX/1550-nm RX, SC LMC3104A-DC

1550-nm TX/1310-nm RX, SC LMC3106A-DC

Single-Mode, Single-Strand, 40 km (Order one of each.)

1310-nm TX/1550-nm RX, SC LMC3105A-DC

1550-nm TX/1310-nm RX, SC LMC3107A-DC

Item Code

Wallmount Managed Media Converters for the Dynamic Fiber
Conversion System, 110 VAC

10BASE-T/100BASE-TX to 100BASE-FX

Multimode, 5 km

ST LMC3108A
SC LMC3110A

Single-Mode, 5 km

ST LMC3109A
SC LMC3111A

Single-Mode, Single-Strand, 20 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3112A
1550-nm TX/1310-nm RX, SC LMC3114A

Single-Mode, Single-Strand, 40 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3113A

1550-nm TX/1310-nm RX, SC LMC3115A
Wallmount Managed Media Converters for the Dynamic Fiber
Conversion System, 220 VAC

10BASE-T/100BASE-TX to 100BASE-FX

Multimode, 5 km

ST LMC3108AE

SC LMC3110AE

Single-Mode, 5 km

ST LMC3109AE

SC LMC3111AE

Single-Mode, Single-Strand, 20 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3112AE

1550-nm TX/1310-nm RX, SC LMC3114AE

Single-Mode, Single-Strand, 40 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3113AE

1550-nm TX/1310-nm RX, SC LMC3115AE
Wallmount Managed Media Converters for the Dynamic Fiber
Conversion System, 8–16 VDC

10BASE-T/100BASE-TX to 100BASE-FX

Multimode, 5 km

ST LMC3108A-DC

SC LMC3110A-DC

Single-Mode, 5 km

ST LMC3109A-DC

SC LMC3111A-DC

Single-Mode, Single-Strand, 20 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3112A-DC

1550-nm TX/1310-nm RX, SC LMC3114A-DC

Single-Mode, Single-Strand, 40 km (Order One of Each.)

1310-nm TX/1550-nm RX, SC LMC3113A-DC

1550-nm TX/1310-nm RX, SC LMC3115A-DC

LMC3108A
