USER MANUAL
LBH120A-H SERIES AND LMC270A-XX-XX S ERIES
INDUSTRIAL
SWITCH/
CONVERTER
24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.CO M
LINK/
ACT
PWR
1
2
3
4
100
LINK/
ACT
5
100
100
LINK/
ACT
PWR
1
2
3
4
LINK/
ACT
X
100
LINK/
ACT
PWR
1
LINK/
ACT
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TABLE OF CONTENTS
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
1. SPECIFICATIONS ........................................................................................................................................................................... 3
2. OVERVIE W ...................................................................................................................................................................................... 5
2.1 Introduction ...............................................................................................................................................................................................5
2.2 Available Models ...................................................................................................................................................................................... 5
2.2.1 Industrial Switches ............................................................................................................................................................................................. 5
2.2.2 Industrial Media Converters ............................................................................................................................................................................ 5
2.3 Features .................................................................................................................................................................................................... 5
2.4 What’s Included ........................................................................................................................................................................................6
2.5 Hardware Description ..............................................................................................................................................................................6
3. I NSTALLATION .............................................................................................................................................................................. 8
3.1 Preparing the Installation Site ................................................................................................................................................................. 8
3.2 Installation Steps .....................................................................................................................................................................................8
4. OPERATION .................................................................................................................................................................................. 11
APPENDIX A. REGULATORY INFORMATION ................................................................................................................................ 12
A.1 FCC Statement ....................................................................................................................................................................................... 12
A.2 NOM Statement ..................................................................................................................................................................................... 13
APPENDIX B. TRADEMARKS/DISCLAIMER .................................................................................................................................. 14
B.1 Trademarks Used in this Manual ..........................................................................................................................................................14
B.2 Disclaimer ............................................................................................................................................................................................... 14
2
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
CHAPTER 1: SPECIFICATIONS
SPECIFICATIONS
Approvals
ISO Manufactured in an ISO 9001 facility
Safety UL 62368
EMI FCC Part 15B, Class A ,
VCCI Class A ,
EN 61000-6-4,
EN 61000-3-2,
EN 61000-3-3
EMS EN 61000-6-2 ,
EN 61000-4-2 (ESD Standards) ,
EN 61000-4-3 (Radiated RFI Standards) ,
EN 61000-4-4 (Burst Standards) ,
EN 61000-4-5 (Surge Standards),
Signal ports: ±4kV line-to-ground,
EN 61000-4-6 (Induced RFI Standards),
EN 61000-4-8 (Magnetic Field Standards)
Environmental Test Compliance IEC 60068-2-6 Fc (Vibration),
IEC 60068-2-27 Ea (Shock),
FED STD 101C Method 5007.1 (Free fall w/ package)
Technology
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
Standards IEEE 802.3u 100BASE-TX/FX,
IEEE 802.3x full-duplex flow control,
IEEE 802.3az Energy Efficient Ethernet,
IEEE 802.1p Quality of Service (QoS)
Forwarding and Filtering Rate 10 Mbps: 14,880 pps,
100 Mbps: 148,810 pps
Packet Buffer Memory 448 KB
Processing Type Store-and-Forward,
Half-duplex back-pressure and IEEE802.3x full-duplex flow control,
Auto Negotiation,
Auto MDI/MDIX
Address Table Size 1K MAC addresses
Power
Power Input 12–48 VDC
Power Consumption 1.82 W Max. 0.14A @ 12 VDC,
0.07A @ 24 VDC, 0.038A @ 48 VDC
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
3
CHAPTER 1: SPECIFICATIONS
SPECIFICATIONS (CONTINUED)
Mechanical
Connectors LBH120A-H: (4) RJ-45 device ports, (1) RJ-45 uplink port;
LBH120A-H-SC, LBH120A-H-20K-SC, LBH120A-H-40K-SC, LBH120A-H-75K-SC:
(4) RJ-45 device ports, (1) pair of SC fiber ports for uplink;
LBH120A-H-ST: (4) RJ-45 device ports, (1) pair of ST fiber ports for uplink;
LMC270A-MM-SC, LMC270A-SM-20K-SC, LMC270A-SM-40K-SC, LMC270A-SM-75K-SC:
(1) RJ-45 port, (1) pair of SC fiber ports;
LMC270A-MM-ST, LMC270A-SM-ST: (1) RJ-45 port, (1) pair of ST fiber ports
Indicators Per RJ-45 port: (1) Link/Activity LED, (1) Speed LED;
Per SC or ST fiber port: (1) Link/Activity LED, (1) Speed LED
Enclosure Plastic IP30
Mounting DIN rail, top hat type 35-mm
Dimensions Each unit: 4.33"H x 1.02"W x 2.76"D (11 x 2.6 x 7 cm)
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
Weight 0.44 lb. (0.2 kg)
Environment
Operating Temperature 14 to 140° F (10 to 60° C);
Tested at -4 to +158° F (-20 to +70° C)
Storage Temperature -40 to +185° F (-40 to +85° C)
Ambient Relative Humidity 5 to 95%, noncondensing
4
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 2: OVERVIEW
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
2.1 OVE RVIEW
The Industrial Switches and Industrial Media Converters operate at temperature extremes of 14 to 140° F (-10 to +60* C). These units are
ideal for harsh environments constrained by space.
The switches provide four twisted-pair device ports and one twisted-pair or fiber uplink port. The media converters link twisted-pair
segments or devices to fiber segments or devices.
2.2 AVAILABLE MODELS
The models listed below are available.
2.2.1 INDUSTRIAL SWITCHES
LBH120A-H (four RJ-45 twisted-pair device connectors, and one RJ-45 twisted-pair uplink connector)
LBH120A-H-SC (four RJ-45 twisted-pair device connectors, and one pair of SC fiber uplink connectors)
LBH120AH-ST (four RJ-45 twisted-pair device connectors, and one pair of ST fiber uplink connectors)
LBH120A-H-20K-SC (four RJ-45 twisted-pair device connectors, and one pair of SC fiber uplink connectors, 20 km distance)
LBH120A-H-40K-SC (four RJ-45 twisted-pair device connectors, and one pair of SC fiber uplink connectors, 40 km distance)
LBH120A-H-75K-SC (four RJ-45 twisted-pair device connectors, and one pair of SC fiber uplink connectors, 75 km distance)
2.2.2 INDUSTRIAL MEDIA CONVERTERS
LMC270A-MM-SC (one RJ-45 twisted-pair connector and one pair of SC multimode fiber connectors)
LMC270A-MM-ST(one RJ-45 twisted-pair connector and one pair of ST multimode fiber connectors)
LMC270A-SM-20K-SC (one RJ-45 twisted-pair connector and one pair of SC single-mode fiber connectors, 20 km distance)
LMC270A-SM-40K-SC (one RJ-45 twisted-pair connector and one pair of SC single-mode fiber connectors, 40 km distance)
LMC270A-SM-75K-SC (one RJ-45 twisted-pair connector and one pair of SC single-mode fiber connectors, 75 km distance)
LMC270A-SM-20K-ST (one RJ-45 twisted-pair connector and one pair of ST single-mode fiber connectors, 20 km distance)
2.3 FEATURES
Complies with EN61000-6-2 & EN61000-6-4 EMC Generic standard immunity for industrial environment.
Supports IEEE 802.3az 10BASE-TE only. 10BASE-T is not supported. 10BASE-TE is fully interoperable with 10BASE-T over 328 feet
(100 meters) of class D (Category 5) or better cabling as specified in ISO/IEC 11801:1995.
Supports 802.3az/802.3u/802.3x. Auto-negotiation: 10/100Mbps, Full/Half-duplex. Auto MDI/MDIX.
100BASE-FX: Multi mode SC or ST type, Single mode SC or ST type.
100BASE-BX: WDM Multi mode or Single mode SC type.
Supports 1024 MAC addresses, 448K bits buffer memory.
IEEE802.3x Flow control for Full-duplex, Back pressure for Half-duplex.
Non-blocking architecture and full wire-speed forwarding rate.
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
5
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 2: OVERVIEW
Supports IEEE802.1p QoS with two priority queues.
Supports IEEE802.3az Energy Efficient Ethernet (EEE).
Supports Max. length of frame up to 1552 Bytes.
Power Consumption: 1.82 W Max. 0.14 A @ 12 VDC, 0.07 A @ 24 VDC, 0.038 A @ 48 VDC.
Power Supply: DC Terminal Block power input, 12-48 VDC.
Operating temperature ranges from 14 to 140° F (-10 to +60° C).
2.4 WHAT’S INCLUDED
Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support
at 877-877-2269 or INFO@BLACKBOX.COM.
(1) Industrial Ethernet Switch or (1) Industrial Ethernet Media Converter
(1) Quick Start Guide
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
2.5 HARDWARE DESCRIPTION
Figure 2-1 shows three available models. Table 2-1 describes their components. Models not pictured have the same components as
shown in the diagram, but have different fiber optic port speeds. For a complete list of available models and their port descriptions, see
Table 2-2.
1
2
3
4
5, 6
7
LBH120A-H LBH120A-H-SC LMC270A-MM-SC
FIGURE 2-1. LBH120A-H, LBH120A-H-SC AND LMC270A-MM-SC MODELS
6
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
CHAPTER 2: OVERVIEW
TABLE 2-1. LBH120A-H, LBH120A-H-SC AND LMC270A-MM-SC COMPONENTS
NUMBER IN FIGU RE 2-1 COMPONENT DESCRIPTION
1 (4) RJ-45 connectors Links to RJ-45 devices
2 (1) RJ-45 connector Links twisted-pair uplink
3 (1) Link/Activity LED Lights when there is activity on the link
4 (1) Speed LED on RJ-45 connector Lights when data is being transmitted at 100 Mbps
5 (1) Link/Activity LED on RJ-45 connector Lights when there is activity on the link
6 (1) Speed LED on SFP port Lights when data is being transmitted at 100 Mbps
7 (1) pair of SC or ST connectors
Links to fiber optic cable, uplink port on the LBH120A-H-SC
and device port on the LMC270A-MM-SC
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
TABLE 2-2. PORTS ON THE SWITCHES AND MEDIA CONVERTERS
PRODUCT CODE NUMBER OF RJ-45 PORTS NUMBER OF FIBER PORTS
SWITCHES
LB H12 0A- H 5 (4 device, 1 uplink) None
LBH120A-H-SC 4 (1) SC
LB H12 0A- H-ST 4 (1) ST
LBH120A-H-20K-SC 4 (1) SC, 20 km distance
LBH120A-H-40K-S C 4 (1) SC, 40 km distance
LBH120A-H-75K-SC 4 (1) SC, 75 km distance
MEDIA CONVERTERS
LMC270A-MM-SC 1 (1) SC
LMC270A-MM-ST 1 (1) ST
LMC270A-SM-20K-SC 1 (1) SC, 20 km distance
LMC270A-SM-40K-SC 1 (1) SC, 40 km distance
LMC270A-SM-75K-SC 1 (1) SC, 75 km distance
LMC270A-SM-20K-ST 1 (1) ST, 20 km distance
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
7
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CH AP TE R 3: INSTA LL AT IO N
3.1 PREPARING THE INSTALLATION SITE
Before you install the device, be sure your operating environment meets the operating environment requirements listed below.
Power source:
Provide a power source within 6 feet (1.8 meters) of the installation location. Power specifications for the Hardened Unmanaged
Switch are shown in Chapter 1, Specifications.
Environment:
Install the Hardened Unmanaged Switch in a dry area, with ambient temperature between -14 and +140º F (-10 and +60° C).
The installation location should have a maximum relative humidity of 95%, non-condensing.
Do not restrict airflow by covering or obstructing the top and side panels of the Hardened Unmanaged Switch. Keep at least 2 inches
(5.08 centimeters) free on all sides for cooling.
3.2 INSTALLATION STEPS
ST E P 1: Install the unit on the DIN rail. Place the switch on the DIN rail from above using the slot. Push the front of the switch
toward the mounting surface until it audibly snaps into place.
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
FIGURE 3-1. INSTALLING THE UNIT ON A DIN RAIL
8
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
CH AP TE R 3: INSTA LL AT IO N
STEP 2: Connect 10/100BASE-TX.
The table below lists the pinouts of the 10/100BASE-TX ports.The picture shows the connector pinout.
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
TABLE 3-1. 10/100BASE-TX PINOUTS
PIN REGULAR PORTS UPLINK PORT
1 Input Receive Data + Output Transmit Data +
2 Input Receive Data - Output Transmit Data 3 Output Transmit Data + Input Receive Data +
4 Not connected Not connected
5 Not connected Not connected
6 Output Transmit Data - Input Receive Data 7 Not connected Not connected
8 Not connected Not connected
PIN 8
PIN 7
PIN 6
PIN 5
PIN 4
PIN 3
PIN 2
PIN 1
FIGURE 3-2. RJ-45 CONNECTOR
STEP 3: Connect 100BASE-FX
The Tx (transmit) port of device 1 is connected to the Rx (receive) port of device 2, and the Rx (receive) port of device 1 to the Tx
(transmit) port of device 2. The fiber connector is shown below.
FIGURE 3-3. FIBER CONNECTOR
STEP 4: Connect the switch to your network.
Cable Type and Length
Follow the cable specifications below when connecting the switch to your network. Use the appropriate cables that meet your speed
and cabling requirements.
TABLE 3-2. CABLE SPECIFICATIONS
SPEED CONNECTOR PORT SPEED HALF/FULL DUPLEX CABLE MAX
10BASE-TE RJ-45 10/20 Mbps 2-pair UTP/STP CAT5 328 ft. (100 m)
100BASE-TX RJ-45 100/200 Mbps 2-pair UTP/STP CAT5 328 ft. (100 m)
100BASE-FX SC, ST 200 Mbps MMF (50 or 62.5 µm) 1.2 mi. (2 km)
100BASE-FX SC, ST 200 Mbps SMF (9 or 10 µm) 12.4 or 24.8 mi. (20 or 40 km)
100BASE-BX SC 200 Mbps MMF (50 or 62.5 µm) 1.2 or 3.1 mi. (2 or 5 km)
100BASE-BX SC 200 Mbps SMF (9 or 10 µm) 12.4 or 24.8 mi. (20 or 40 km)
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
9
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CH AP TE R 3: INSTA LL AT IO N
STEP 5: Grounding the Unit
CAUTION: This equipment is designed to permit the connection of the grounded conductor of the DC supply circuit to the grounding
conductor at the equipment.
For power connection, the following conditions must be met:
• This equipment must be connected directly to the DC supply system grounding electrode conductor or to a bonding jumper from a
grounding terminal bar or bus to which the DC supply system grounding electrode conductor is connected.
• This equipment must be located in the same immediate area (such as, adjacent cabinets) as any other equipment that has a
connection between the grounded conductor of the same DC supply circuit and the grounding conductor, and also the point of
grounding of the DC system. The DC system should not be
grounded elsewhere.
• The DC supply source must be located within
the same premises as the equipment.
• Switching or disconnecting devices will not be in the grounded circuit conductor between the DC source and the point of
connection of the grounding electrode conductor.
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
PWR
12–4 8 V D C
POWER INPUT
GND
POWER GROUND
FIGURE 3-4. GROUNDING THE UNIT
Before you apply power:
1. Inspect the equipment thoroughly.
2. Verify that all cables are installed correctly.
3. Check cable routing to make sure cables are not damaged or create a safety hazard.
4. Be sure that all equipment is mounted properly and securely.
STEP 5: Apply power.
Connect the 12–48 VDC power supply voltage to start up the switch via the terminal block.
GROUND
10
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
CHAPTER 4: OPERATION
TABLE 4-1. LED INDICATORS
LED S TATE DESSCRIPTION
Link/Act
100
Steady Network connection established
Flashing Transmitting or receiving data
Steady Transfer at 100 Mbps
Off Transfer at 10 Mbps
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
11
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
APPENDIX A: REGULATORY INFORMATION
A.1 FCC STATEMENT
This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used
properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has
been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart
B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a residential area is likely to cause interference, in which
case the user at his own expense will be required to take whatever measures may be necessary to correct
the interference.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio
Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de
la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
12
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
APPENDIX A: REGULATORY INFORMATION
A.2 NOM STATEMENT
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca
de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de operación.
Todo otro servicio deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato eléctrico
sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en libreros o gabinetes que
impidan el flujo de aire por los orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros
aparatos (incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como
se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados
sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato;o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
13
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
APPENDIX B: DISCLAIMER/TRADEMARKS
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
B.1 DISCLAIMER
Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover
damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation
may revise this document at any time without notice.
B.2 TRADEMARKS USED IN THIS MANUAL
Black Box and the Black Box logo type and mark are registered trademarks of Black Box Corporation.
Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
14
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
NOTES
________________________________________________________________________________________________
__
________________________________________________________________________________________________
__
________________________________________________________________________________________________
__
________________________________________________________________________________________________
__
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 6 9
________________________________________________________________________________________________
__
________________________________________________________________________________________________
__
________________________________________________________________________________________________
__
_
________________________________________________________________________________________________
_
________________________________________________________________________________________________
__
________________________________________________________________________________________________
_ _\
________________________________________________________________________________________________
__
________________________________________________________________________________________________
__
________________________________________________________________________________________________
1. 8 7 7. 8 7 7. 2 2 6 9 BL ACK BOX .COM
15
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.87 7. 8 7 7. 2 269
© COPYRIGHT 2018 BLACK BOX CORPORATION. ALL RIGHTS RESERVED.
Loading...
