Wallmount Patch Panel Brackets
Mount directly to the wall
or on any 19" EIA standard rack.
JPM080-R4 holds equipment occupying up to 4U of vertical space.
JPM082-R4 holds equipment up to 2U high.
JPM080-R4
JPM082-R4
MT1000A-85-R4
Specifications
Mounting: 16" on center
Size: JPM080-R4: 7"H (4U) x 19"W x 8"D
(17.8 x 48.3 x 20.3 cm);
JPM082-R4: 3.5"H (2U) x 19"W x 8"D (8.9 x 48.3 x 20.3 cm)
Weight: JPM080-R4: 6 lb. (2.7 kg);
JPM082-R4: 4 lb. (1.8 kg)
Overview
The Wallmount Patch Panel Bracket-4 (JPM080-R4) and the
Wallmount Patch Panel Bracket-2 (JPM082-R4) can be mounted
directly to the wall. JPM080-R4 holds equipment occupying up
to 4 rack units (4U) of vertical space, and JPM082-R4 holds
equipment up to 2U high.
Customer
Support
Information
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: w ww.blackbox.com • E-mail : [email protected]
What’s Included
Your package should contain the following items. If anything
is missing or damaged, contact Black Box Technical Support
at 724 -746 -550 0.
• (1) Wallmount Patch Panel Bracket with hinged lip
• (8) M5 cage nuts
• (8) M5 screws with clear plastic washers
• (4) 2" hex head bolts for mounting to wooden studs
• This user’s manual
For installation instructions, turn this page over…
Page 2
Installation
To mount the bracket on the wall:
Determine the appropriate mounting location for the bracket.
Insert the included 2" hex head bolts through the keyholes in the rear panel of the bracket and fasten the bolts securely.
NOTE: Use the included M5 cage nuts and screws to mount equipment.
