MARCH 2000
IC142C
IC190C
8-Port Serial Host Adapter PCI
1
FCC AND IC STATEMENTS
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are designed to
provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct
the interference.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital
apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.
This product is approved.
2
8-PORT SERIAL HOST ADAPTER PCI
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de
que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.
3
NOM STATEMENT
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen del
aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.
4
8-PORT SERIAL HOST ADAPTER PCI
TRADEMARKS
The trademarks mentioned in this manual are the sole property of their owners.
5
TABLE OF CONTENTS
CONTENTS
1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 What’s Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3. Card Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 Clock Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Baud Rates and Divisors for the “Div1” mode . . . . . . . . . . . . . . . . 9
3.3 Address and IRQ selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1 Setting Up the Operating System . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.1 Windows 3.1x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.2 Windows 95/98. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.3 Windows NT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.4 DOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.5 Other Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2 Installing the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5. Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.1 Interrupts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.2 Why Use an ISP? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6. Connector Pin Assignments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.1 DB25 (RS-232 DTE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.2 DB78 Connector Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . 14
Appendix A: Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
A.1 Using the Serial Utility Diskettes. . . . . . . . . . . . . . . . . . . . . . . . . . . 15
A.2 Calling for Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Appendix B : Electrical Interface (RS-232) . . . . . . . . . . . . . . . . . . . . . . . 16
Appendix C: Asynchronous Communications . . . . . . . . . . . . . . . . . . . . . 17
Appendix D: Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Appendix E: Compliance Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
E.1 Federal Communications Commission Statement (see page 1). . 20
E.2 EMC Directive Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6
8-PORT SERIAL HOST ADAPTER PCI
1. Specifications
Communications Chip — IC142C: 16554 UART; IC190C: 16950 UART
Maximum Distance — 50 ft. (15.2 m)
Operation — RS-232
Protocol — Asynchronous
Speed —I C142C: Up to 460.8 kbps;
IC190C: 460.8 kbps and above
CE Approval — Yes
Temperature — Operating: 32 to 122 °F (0 to 50 °C);
Storage: -4 to 158 °F (-20 to 70 °C)
Humidity — 10 to 90% noncondensing
Connectors — (1) DB78 female on card, (1) DB78 male and (8) DB25 male on
included octopus cable
Cable Length — 36" (91.4 cm)
Power — From the interface: +5 V @ 250 mA; +12 V @ 60 mA; -12 V @ 100 mA
Size — Half-card
7
CHAPTER 2: Introduction
2. Introduction
2.1 Overview
The 8-Port Serial Host Adapter PCI provides the PC with eight RS-232
asynchronous ports. The Adapter allows for connection to any device using the
RS-232 electrical interface, such as modems, data-entry terminals, and plotters.
2.2 What’s Included
The Serial Host Adapter PCI is shipped with the following items:
• 8-Port Serial Host Adapter PCI
• DB78 to eight DB25 Octopus Cable
• (2) Serial Utility Software Diskettes
• User Manual
If any of these items is missing or damaged, contact Black Box immediately
at 724-746-5500.
8
8-PORT SERIAL HOST ADAPTER PCI
3. Card Setup
3.1 Clock Modes
The Adapter employs a unique clocking option that allows the end user to select
from divide-by-4 and divide-by-1 clocking modes. This mode is selected at J1.
To select the baud rates commonly associated with COM ports (2400, 4800, 9600,
19.2, … 115.2 kbps), place the jumper in the divide-by-4 position (marked DIV4).
Figure 3-1. Clocking Mode “Divide By 4.”
To select the maximum data rate (460.8 kbps), place the jumper in the divide-
by-1 position (marked DIV1).
Figure 3-2. Clocking Mode “Divide By 1.”
DIV1
DIV4
DIV1
DIV4
9
CHAPTER 3: Card Setup
3.2 Baud Rates and Divisors for the “Div1” mode
The following table shows some common data rates and the rates you should
choose to match them if using the adapter in the “Div1” mode.
Table 3-1. Baud Rates for the “Div1” Mode.
For this Data Rate Choose this Data Rate
1200 bps 300 bps
2400 bps 600 bps
4800 bps 1200 bps
9600 bps 2400 bps
19.2 kbps 4800 bps
57.6 kbps 14.4 kbps
115.2 kbps 28.8 kbps
230.4 kbps 57.6 kbps
460.8 kbps 115.2 kbps
If your communications package allows the use of baud-rate divisors, choose the
appropriate divisor from the following table:
Table 3-2. Baud-Rate Divisors for the “Div1” Mode.
For this Data Rate Choose this Divisor
1200 bps 384
2400 bps 192
4800 bps 96
9600 bps 48
19.2 kbps 24
38.4 kbps 12
57.6 kbps 8
115.2 kbps 4
230.4 kbps 2
460.8 kbps 1
10
8-PORT SERIAL HOST ADAPTER PCI
3.3 Address and IRQ selection
The Adapter is automatically assigned I/O addresses and IRQs by your
motherboard BIOS. Only the I/O address may be modified by the user.
Adding or removing other hardware may change the assignment of I/O
addresses and IRQs.
11
CHAPTER 4: Installation
4. Installation
IMPORTANT
You MUST set up the operating system BEFORE you physically install
the Card.
4.1 Setting Up the Operating System
If you are installing the PCI adapter in DOS, OS/2®, or QNX, please refer to the
appropriate directory on one of the Serial Utilities Disks for instructions.
4.1.1 W
INDOWS
3.1
X
Refer to the Win3x.hlp file in the \Win31 directory on Disk 1 of the Serial Utilities
software.
4.1.2 W
INDOWS
95/98 U
SERS
If you are installing the PCI card in Windows 95/98, run setup on disk two of the
Serial Utilities Diskettes before installing the card. Power down the computer and
install the adapter. The resources are automatically configured for the PCI card.
Refer to the appropriate help file in the Black Box folder located in the Start,
Programs menu for changing those resources.
4.1.3 W
INDOWS
NT
If you are installing a PCI card in Windows NT, run setup on disk two of the Serial
Utilities Diskettes before installing the card. After the software installation is
complete, power down the computer, install the card, then power up. Since
resource allocation is automatic, the installation is now complete.
4.1.4 DOS
Refer to the Readme.txt file found in the \DOS directory on Disk 1 of the Serial
Utilities software.
4.1.5 O
THEROPERATINGSYSTEMS
Refer to the appropriate directory on Disk 1 of the Serial Utilities software.
12
8-PORT SERIAL HOST ADAPTER PCI
4.2 Installing the Hardware
You can install the Serial Host Adapter in any of the PCI expansion slots. It
contains several jumper straps for each port that you must set for proper
operation.
1. Power off the PC. Disconnect the power cord.
2. Remove the PC cover.
3. Locate an available PCI slot and remove the blank metal slot cover.
4. Gently insert the Adapter into the slot. Make sure that it is seated properly.
5. Connect the DB78 male connector end of the octopus cable to the DB78
female connector on the card.
6. Replace the screw.
7. Replace the cover.
8. Connect the power cord.
13
CHAPTER 5: Technical Description
5. Technical Description
5.1 Interrupts
A good analogy of a PC interrupt is a telephone ringing. The phone bell is a
request for us to stop what we are currently doing and take up another task (speak
to the person on the other end of the line). This is the same process the PC uses to
alert the CPU that a task must be performed. The CPU, upon receiving an
interrupt, makes a record of what the processor was doing at the time and stores
this information on the “stack”; this allows the processor to resume its predefined
duties after the interrupt is handled, exactly where it left off. Every main sub-system
in the PC has its own interrupt, frequently called an IRQ (short for Interrupt
ReQuest).
5.2 Why Use an ISP?
The Interrupt Status Port (ISP) is a read-only 8-bit register that sets a
corresponding bit when an interrupt is pending. Port 1 interrupt line corresponds
with Bit D0 of the status port, Port 2 with D1, etc. The use of this port means that
the software designer now only has to poll a single port to determine if an
interrupt is pending.
The ISP is at Base+7 on each port (example: Base=280 hex, Status Port=287,
28F...etc.). The Adapter will allow any one of the available locations to be read
to obtain the value in the status register. Both status ports on the Adapter are
identical, so either one can be read. Example: This indicates that Channel 2 has
an interrupt pending.
Bit Position: 76543210
Value Read: 00000010
14
8-PORT SERIAL HOST ADAPTER PCI
6. Connector Pin Assignments
6.1 DB25 (RS-232 DTE)
Signal Name Pin # Mode
GND Ground 7
TD Transmit Data 2 Output
RTS Request to Send 4 Output
DTR Data Terminal Ready 20 Output
RD Receive Data 3 Input
CTS Clear to Send 5 Input
DSR Data Set Ready 6 Input
DCD Data Carrier Detect 8 Input
RI Ring Indicator 22 Input
6.2 DB78 Connector Pin Assignments
Port #12345678
TD 36 12 27 3 75 51 66 42
RD 37 11 28 2 76 50 67 41
RTS 17318 2256704761
CTS 16327 2355714662
DTR 35 13 26 4 74 52 65 43
DSR 18309 2157694860
DCD 38 10 29 1 77 49 68 40
RI 15336 2454724563
GND 34 14 25 5 73 53 64 44
15
APPENDIX A: Troubleshooting
Appendix A: Troubleshooting
A.1 Using the Serial Utility Diskettes
A Serial Utility diskette comes with the Serial Host Adapter for use in
troubleshooting. If you still cannot solve a problem after reading this chapter,
call for technical support.
1. Identify all I/O adapters currently installed in your system, including your
on-board serial ports, controller cards, sound cards, etc. Identify the I/O
addresses used by these adapters, as well as the IRQ (if any).
2. Configure your Serial Host Adapter so that there is no conflict with currently
installed adapters. No two adapters can occupy the same I/O address.
3. Make sure the Adapter is using a unique IRQ. While this Adapter does allow
the sharing of IRQs, many other adapters (such as SCSI adapters and onboard serial ports) do not. The IRQ is typically selected via an on-board
header block. Refer to Chapter 3 for help in choosing an I/O address
and IRQ.
4. Make sure the Adapter is securely installed in a motherboard slot.
5. For Windows 95/98 and Windows NT, the diagnostic tool “WinSSD” is
installed in the Adapter folder on the Start Menu during the startup process.
First find the ports using the Device Manager, then use “WinSSD” to verify
that the ports are working.
6. When running DOS, Windows 3.x or other operating systems, refer to Serial
Utilities Disk 1 and this manual to verify that the Adapter is configured
correctly. The supplied software contains a diagnostic program “SSD” that
runs under DOS and will verify if an adapter is configured properly. This
diagnostic program is easy to use. Refer to the README.txt file on the
supplied diskette for detailed instructions on using “SSD.”
A.2 Calling for Technical Support
If the procedures described in Section A.1 do not solve your problem, call Black
Box Technical Support at 724-746-5500. Have the following information ready
when you call:
1. Current adapter settings. If possible, have the Adapter installed in a computer
ready to run diagnostics.
2. This user manual for reference.
16
8-PORT SERIAL HOST ADAPTER PCI
Appendix B: RS-232 Electrical
Interface
The most widely used communication standard is RS-232. It’s been defined and
revised several times and is sometimes also called EIA/TIA-232. The IBM AT
computer defined the RS-232 port on a DB9 connector, and subsequently the
EIA/TIA approved this implementation as the EIA/TIA-574 standard, which is
defined as the “9-Position Non-Synchronous Interface between Data Terminal
Equipment and Data Circuit-Terminating Equipment Employing Serial Binary
Data Interchange.”
RS-232 can operate at data rates of up to 20 kbps at distances less than 50 ft.
(15.2 m). The absolute maximum data rate may vary depending on line conditions
and cable lengths. RS-232 is a single-ended or unbalanced interface, meaning that
a single electrical signal is compared to a common signal (ground) to determine
binary logical states. The RS-232 and the EIA/TIA-574 specification define two
types of interface circuits, Data Terminal Equipment (DTE) and Data CircuitTerminating Equipment (DCE). The Serial Host Adapter is a DTE device.
17
APPENDIX C: Asynchronous Communication
Appendix C: Asynchronous
Communication
In serial data communication, individual bits of a character are transmitted
consecutively to a receiver that assembles the bits back into a character. Data rate,
error checking, handshaking, and character framing (start/stop bits) are predefined and must correspond at both the transmitting and receiving ends.
Asynchronous communication is the standard means of serial data
communication for PC and compatible computers. The original PC was equipped
with a communication or COM port that was designed around an 8250 Universal
Asynchronous Receiver Transmitter (UART), which allows asynchronous serial
data to be transferred through a simple and straightforward programming device.
The Serial Host Adapter (IC142C) uses a much newer 16554 UART that also
features buffering.
Asynchronous communication works this way: A start bit, followed by a predefined number of data bits (5, 6, 7, or 8) defines character boundaries for
asynchronous communication. The end of the character is defined by the
transmission of a pre-defined number of stop bits (usually 1, 1.5, or 2).
Figure C-1. Asynchronous Communication Bit Diagram.
Odd
Idle State
of
Line
1
0
5 to 8 Data Bits
Even
or
Unused
Parity
Bit
1
1.5
2
Stop Bits
Remain Idle
or
Next Start Bit
18
8-PORT SERIAL HOST ADAPTER PCI
An extra bit used for error detection is often appended before the stop bits.
This special bit is called the parity bit. Parity is a simple way to determine if a data
bit has been lost or corrupted during transmission. There are several methods for
implementing a parity check to guard against data corruption. Common methods
are called [E]ven Parity or [O]dd Parity. Sometimes parity is not used to detect
errors on the data stream (this is called [N]o Parity). Because each bit in
asynchronous communication is sent consecutively, it is wrapped (framed) by
pre-defined bits to mark the beginning and end of the serial transmission of the
character. The data rate and communication parameters for asynchronous
communication have to be the same at both the transmitting and receiving ends.
The communication parameters are baud rate, parity, number of data bits per
character, and stop bits—for example, 9600, N, 8, 1.
19
APPENDIX D: Board Layout
Appendix D: Board Layout
Figure D-1. Board Layout.
P2
U11
P1
C19
R8
75232
75232
C11
C17
XC9536-7801
+
C22
C4
C9
U4
U8
C10R1
PC19050
C21
C3
U3
75232
C8
U7
75232
U10
DIV4=Clock Divide by 4
Standard Clock=DIV4
93CS4S
C16
U13
C18
C2
U2
75232
C7
U6
75232
J1=Clock Divide Select
DIV1=Clock Divide by 1
X2
C12
C14
C15R2 R3 R4 R5 R6 R7
X3
J1
DIV1
DIV4
U14 U15
C20 R9
74LS74
74LS04
C6
X1
X4
75232
75232
Y1
C1
U1
C5
U5
16C554 U9
C13
16C554 U12
20
8-PORT SERIAL HOST ADAPTER PCI
Appendix E: Compliance Notices
E.1 Federal Communications Commission Statement
See page 1.
E.2 EMC Directive Statement
Products bearing the CE Label fulfill the requirements of the EMC directive
(89/336/EEC) and of the low-voltage directive (73/23/EEC) issued by the
European Commission.
To obey these directives, the following European standards must be met:
• EN55022 Class A - “Limits and methods of measurement of radio interference
characteristics of information technology equipment”
• EN50082-1 - “Electromagnetic compatibility - Generic immunity standard” Part
1: Residential, commercial and light industry
• EN60950 (IEC950) - “Safety of information technology equipment, including
electrical business equipment”
Always use cabling provided with this product if possible. If no cable is provided
or if an alternate cable is required, use high-quality shielded cabling to maintain
compliance with FCC/EMC directives.
1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746
© Copyright 2000. Black Box Corporation. All rights reserved.
Loading...
