Black Box HDMI Matrix Switch, RS-232 User Manual

VSW-HDMI8X8-B
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
Switch (8) source devices with HDMI and IR to (8) displays with HDMI.
Supports 1080p 3D HDMI or DVI formats + IR with RS-232 or IR remote control.
Customer
Support
Information
Web site: w ww.blackbox.com • E-mail: info @blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
RS-232 Protocol and Command
RS-232 Cable Pin Lines
Matrix Switch RS-232 pins out, PC RS-232 pins, DB9 female connector DB9 male connector
Not connected 1 ----------------------------------------------------------------------------- 1 Not connected
TX 2 ----------------------------------------------------------------------------- 2 RX
RX 3 -----------------------------------------------------------------------------3 TX
Not connected 4 ----------------------------------------------------------------------------- 4 Not connected
GND 5 ----------------------------------------------------------------------------- 5 GND
Not connected 6 ----------------------------------------------------------------------------- 6 Not connected
Not connected 7 ----------------------------------------------------------------------------- 7 Not connected
Not connected 8 ----------------------------------------------------------------------------- 8 Not connected
Not connected 9 ----------------------------------------------------------------------------- 9 Not connected
1. Transmission rate: 9600 bps
2. Data format: 8 data bits, no parity, 1 start bit, and 1 stop bit
3. Flow control: None
Also known as 9600, 8, n, 1.
Data String Format
The Data String contains four elements:
[Command][ ][Data][;]
The format is:
1. Command
2. Space
3. Data
4. ;
There is a single space after the Command and before the Data string. The data string must conclude with a semicolon “;” (without the quotes). All text is full ASCII Code and is NOT case sensitive. You can use either capital letters or lower-case letters and get the same result.
The LINK command must be sent first. This establishes a communications link between an external controller or computer and the device you want to control. When you have an established link, communication via the IR port is disabled. The front panel remains operational.
Page 2
724-746-5500 | blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
The format is:
LINK 01; This will establish the link.
LINK 00; This will terminate the link.
Devices that are firmware version x.x or higher will return a status. This status is command dependent.
For example: Response [SKU][ ][Status][;]
The Status is a two-digit numerical code. See page 4 in this document for specific details.
Commands
NOTE: Not all commands are supported on all devices.
Commands
Item Command Description
1 Link Establish or disable the data link between the controller and the device.
2 Power Set/check the status of power.
3 Output [d] Set/check the status of single outputs.
4 ActiveSource Check the status of an input for a signal present.
5 OutputAll Set/check the status of all outputs.
6 Recall Recall a saved matrix configuration from memory.
7 Recall [mm] Check the memory address data.
8 Memory Save the current matrix.
9 Lock Set/check the status of lock.
10 EDID Set/check EDID (HDMI only).
11 Signal Format Sets V + A, A only.
1. Link
Function Command Response Description
Leave Link 00; VSWHDMI8X8B 00; Leave
VSWHDMI8X8B 01; Command not recognized
Link Link 01; VSWHDMI8X8B 00; Link
VSWHDMI8X8B 01; Command not recognized
Check Link Condition Link ?; Link 00;
Link 01;
2. Power
Function Command Response Description
Power OFF Power 00; VSWHDMI8X8B 00; Power off
VSWHDMI8X8B 01; Command not recognized
Power ON Power 01; VSWHDMI8X8B 00; Power on
VSWHDMI8X8B 01; Command not recognized
Check Power Status Power ?; Power 00;
Power 01;
System Leave System Link
Power off Power on
Page 3
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
3. Output [dd]
Function Command Response Description
OFF source OUTPUT01 00; VSWHDMI8X8B 00; Output 1 is off
VSWHDMI8X8B 01; Command not recognized
OUTPUT02 00; VSWHDMI8X8B 00; Output 2 is off
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 00; VSWHDMI8X8B 00; Output 3 is off
VSWHDMI8X8B 01; Command not recognized
OUTPUT04 00; VSWHDMI8X8B 00; Output 4 is off
VSWHDMI8X8B 01; Command not recognized
OUTPUT05 00; VSWHDMI8X8B 00; Output 5 is off
VSWHDMI8X8B 01; Command not recognized
OUTPUT06 00; VSWHDMI8X8B 00; Output 6 is off
VSWHDMI8X8B 01; Command not recognized
OUTPUT07 00; VSWHDMI8X8B 00; Output 7 is off
VSWHDMI8X8B 01; Command not recognized
OUTPUT08 00; VSWHDMI8X8B 00; Output 8 is off
VSWHDMI8X8B 01; Command not recognized
Set channel status OUTPUT01 01; VSWHDMI8X8B 00; Set output 1 to input 1
VSWHDMI8X8B 01; Command not recognized
OUTPUT01 02; VSWHDMI8X8B 00; Set output 1 to input 2
VSWHDMI8X8B 01; Command not recognized
OUTPUT01 03; VSWHDMI8X8B 00; Set output 1 to input 3
VSWHDMI8X8B 01; Command not recognized
OUTPUT01 04; VSWHDMI8X8B 00; Set output 1 to input 4
VSWHDMI8X8B 01; Command not recognized
OUTPUT01 05; VSWHDMI8X8B 00; Set output 1 to input 5
VSWHDMI8X8B 01; Command not recognized
OUTPUT01 06; VSWHDMI8X8B 00; Set output 1 to input 6
VSWHDMI8X8B 01; Command not recognized
OUTPUT01 07; VSWHDMI8X8B 00; Set output 1 to input 7
VSWHDMI8X8B 01; Command not recognized
OUTPUT01 08; VSWHDMI8X8B 00; Set output 1 to input 8
VSWHDMI8X8B 01; Command not recognized
Set channel status OUTPUT02 01; VSWHDMI8X8B 00; Set output 2 to input 1
VSWHDMI8X8B 01; Command not recognized
OUTPUT02 02; VSWHDMI8X8B 00; Set output 2 to input 2
VSWHDMI8X8B 01; Command not recognized
OUTPUT02 03; VSWHDMI8X8B 00; Set output 2 to input 3
VSWHDMI8X8B 01; Command not recognized
OUTPUT02 04; VSWHDMI8X8B 00; Set output 2 to input 4
VSWHDMI8X8B 01; Command not recognized
OUTPUT02 05; VSWHDMI8X8B 00; Set output 2 to input 5
VSWHDMI8X8B 01; Command not recognized
Page 4
724-746-5500 | blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
3. Output [dd] (continued)
Function Command Response Description
Set channel status OUTPUT02 06; VSWHDMI8X8B 00; Set output 2 to input 6
VSWHDMI8X8B 01; Command not recognized
OUTPUT02 07; VSWHDMI8X8B 00; Set output 2 to input 7
VSWHDMI8X8B 01; Command not recognized
OUTPUT02 08; VSWHDMI8X8B 00; Set output 2 to input 8
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 01; VSWHDMI8X8B 00; Set output 3 to input 1
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 02; VSWHDMI8X8B 00; Set output 3 to input 2
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 03; VSWHDMI8X8B 00; Set output 3 to input 3
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 04; VSWHDMI8X8B 00; Set output 3 to input 4
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 05; VSWHDMI8X8B 00; Set output 3 to input 5
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 06; VSWHDMI8X8B 00; Set output 3 to input 6
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 07; VSWHDMI8X8B 00; Set output 3 to input 7
VSWHDMI8X8B 01; Command not recognized
OUTPUT03 08; VSWHDMI8X8B 00; Set output 3 to input 8
VSWHDMI8X8B 01; Command not recognized
Set channel status OUTPUT04 01; VSWHDMI8X8B 00; Set output 4 to input 1
VSWHDMI8X8B 01; Command not recognized
OUTPUT04 02; VSWHDMI8X8B 00; Set output 4 to input 2
VSWHDMI8X8B 01; Command not recognized
OUTPUT04 03; VSWHDMI8X8B 00; Set output 4 to input 3
VSWHDMI8X8B 01; Command not recognized
OUTPUT04 04; VSWHDMI8X8B 00; Set output 4 to input 4
VSWHDMI8X8B 01; Command not recognized
OUTPUT04 05; VSWHDMI8X8B 00; Set output 4 to input 5
VSWHDMI8X8B 01; Command not recognized
OUTPUT04 06; VSWHDMI8X8B 00; Set output 4 to input 6
VSWHDMI8X8B 01; Command not recognized
OUTPUT04 07; VSWHDMI8X8B 00; Set output 4 to input 7
VSWHDMI8X8B 01; Command not recognized
OUTPUT04 08; VSWHDMI8X8B 00; Set output 4 to input 8
VSWHDMI8X8B 01; Command not recognized
Set Channel Status OUTPUT05 01; VSWHDMI8X8B 00; Set output 5 to input 1
VSWHDMI8X8B 01; Command not recognized
Page 5
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
3. Output [dd] (continued)
Function Command Response Description
OUTPUT05 02; VSWHDMI8X8B 00; Set output 5 to input 2
VSWHDMI8X8B 01; Command not recognized
OUTPUT05 03; VSWHDMI8X8B 00; Set output 5 to input 3
VSWHDMI8X8B 01; Command not recognized
OUTPUT05 04; VSWHDMI8X8B 00; Set output 5 to input 4
VSWHDMI8X8B 01; Command not recognized
OUTPUT05 05; VSWHDMI8X8B 00; Set output 5 to input 5
VSWHDMI8X8B 01; Command not recognized
OUTPUT05 06; VSWHDMI8X8B 00; Set output 5 to input 6
VSWHDMI8X8B 01; Command not recognized
OUTPUT05 07; VSWHDMI8X8B 00; Set output 5 to input 7
VSWHDMI8X8B 01; Command not recognized
OUTPUT05 08; VSWHDMI8X8B 00; Set output 5 to input 8
VSWHDMI8X8B 01; Command not recognized
Set Channel Status OUTPUT06 01; VSWHDMI8X8B 00; Set output 6 to input 1
VSWHDMI8X8B 01; Command not recognized
OUTPUT06 02; VSWHDMI8X8B 00; Set output 6 to input 2
VSWHDMI8X8B 01; Command not recognized
OUTPUT06 03; VSWHDMI8X8B 00; Set output 6 to input 3
VSWHDMI8X8B 01; Command not recognized
OUTPUT06 04; VSWHDMI8X8B 00; Set output 6 to input 4
VSWHDMI8X8B 01; Command not recognized
OUTPUT06 05; VSWHDMI8X8B 00; Set output 6 to input 5
VSWHDMI8X8B 01; Command not recognized
OUTPUT06 06; VSWHDMI8X8B 00; Set output 6 to input 6
VSWHDMI8X8B 01; Command not recognized
OUTPUT06 07; VSWHDMI8X8B 00; Set output 6 to input 7
VSWHDMI8X8B 01; Command not recognized
OUTPUT06 08; VSWHDMI8X8B 00; Set output 6 to input 8
VSWHDMI8X8B 01; Command not recognized
Set Channel Status OUTPUT07 01; VSWHDMI8X8B 00; Set output 7 to input 1
VSWHDMI8X8B 01; Command not recognized
OUTPUT07 02; VSWHDMI8X8B 00; Set output 7 to input 2
VSWHDMI8X8B 01; Command not recognized
OUTPUT07 03; VSWHDMI8X8B 00; Set output 7 to input 3
VSWHDMI8X8B 01; Command not recognized
OUTPUT07 04; VSWHDMI8X8B 00; Set output 7 to input 4
VSWHDMI8X8B 01; Command not recognized
OUTPUT07 05; VSWHDMI8X8B 00; Set output 7 to input 5
VSWHDMI8X8B 01; Command not recognized
Page 6
724-746-5500 | blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
3. Output [dd] (continued)
Function Command Response Description
Set Channel Status OUTPUT07 06; VSWHDMI8X8B 00; Set output 7 to input 6
VSWHDMI8X8B 01; Command not recognized
OUTPUT07 07; VSWHDMI8X8B 00; Set output 7 to input 7
VSWHDMI8X8B 01; Command not recognized
OUTPUT07 08; VSWHDMI8X8B 00; Set output 7 to input 8
VSWHDMI8X8B 01; Command not recognized
Set Channel Status OUTPUT08 01; VSWHDMI8X8B 00; Set output 8 to input 1
VSWHDMI8X8B 01; Command not recognized
OUTPUT08 02; VSWHDMI8X8B 00; Set output 8 to input 2
VSWHDMI8X8B 01; Command not recognized
OUTPUT08 03; VSWHDMI8X8B 00; Set output 8 to input 3
VSWHDMI8X8B 01; Command not recognized
OUTPUT08 04; VSWHDMI8X8B 00; Set output 8 to input 4
VSWHDMI8X8B 01; Command not recognized
OUTPUT08 05; VSWHDMI8X8B 00; Set output 8 to input 5
VSWHDMI8X8B 01; Command not recognized
OUTPUT08 06; VSWHDMI8X8B 00; Set output 8 to input 6
VSWHDMI8X8B 01; Command not recognized
OUTPUT08 07; VSWHDMI8X8B 00; Set output 8 to input 7
VSWHDMI8X8B 01; Command not recognized
OUTPUT08 08; VSWHDMI8X8B 00; Set output 8 to input 8
VSWHDMI8X8B 01; Command not recognized
Check output status OUTPUT 01 ?; Output01 01; Output 1 to input 1
Output01 02; Output 1 to input 2
Output 01 03; Output 1 to input 3
Output 01 04; Output 1 to input 4
Output01 05; Output 1 to input 5
Output01 06; Output 1 to input 6
Output 01 07; Output 1 to input 7
Output 01 08; Output 1 to input 8
OUTPUT 02 ?; Output02 01; Output 2 to input 1
Output02 02; Output 2 to input 2
Output02 03; Output 2 to input 3
Output02 04; Output 2 to input 4
Output02 05; Output 2 to input 5
Output02 06; Output 2 to input 6
Output 02 07; Output 2 to input 7
Output 02 08; Output 2 to input 8
Page 7
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
3. Output [dd] (continued)
Function Command Response Description
Check output status OUTPUT 03 ?; Output03 01; Output 3 to input 1
Output03 02; Output 3 to input 2
Output 03 03; Output 3 to input 3
Output 03 04; Output 3 to input 4
Output03 05; Output 3 to input 5
Output03 06; Output 3 to input 6
Output 03 07; Output 3 to input 7
Output 03 08; Output 3 to input 8
OUTPUT 04 ?; Output04 01; Output 4 to input 1
Output04 02; Output 4 to input 2
Output04 03; Output 4 to input 3
Output04 04; Output 4 to input 4
Output04 05; Output 4 to input 5
Output04 06; Output 4 to input 6
Output 04 07; Output 4 to input 7
Output 04 08; Output 4 to input 8
OUTPUT 05 ?; Output05 01; Output 5 to input 1
Output05 02; Output 5 to input 2
Output05 03; Output 5 to input 3
Output05 04; Output 5 to input 4
Output05 05; Output 5 to input 5
Output05 06; Output 5 to input 6
Output05 07; Output 5 to input 7
Output05 08; Output 5 to input 8
OUTPUT 06 ?; Output06 01; Output 6 to input 1
Output06 02; Output 6 to input 2
Output06 03; Output 6 to input 3
Output06 04; Output 6 to input 4
Output06 05; Output 6 to input 5
Output06 06; Output 6 to input 6
Output06 07; Output 6 to input 7
Output06 08; Output 6 to input 8
OUTPUT 07 ?; Output07 01; Output 7 to input 1
Output07 02; Output 7 to input 2
Output07 03; Output 7 to input 3
Output07 04; Output 7 to input 4
Output07 05; Output 7 to input 5
Output07 06; Output 7 to input 6
Output07 07; Output 7 to input 7
Output08 08; Output 7 to input 8
Page 8
724-746-5500 | blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
3. Output [dd] (continued)
Function Command Response Description
Check output status OUTPUT 08 ?; Output08 01; Output 8 to input 1
Output08 02; Output 8 to input 2
Output 08 03; Output 8 to input 3
Output 08 04; Output 8 to input 4
Output08 05; Output 8 to input 5
Output08 06; Output 8 to input 6
Output08 07; Output 8 to input 7
Output08 08; Output 8 to input 8
4. Active Source
Function Command Response Description
Check the status of a signal on an input port ACTIVESOURCE ?; ActiveSource 0100; Input 1 = 01 so the signal is active.
Input 2 = 00 so the signal is inactive.
ActiveSource 0101; Input 1 = 01 so the signal is active.
Input 2 = 01 so the signal is inactive.
ActiveSource 0000; Input 1 = 00 so the signal is active.
Input 2 = 00 so the signal is inactive.
NOTE: This does not validate if the signal is within proper format (ex. 1VPP Video), only that one is present and active.
Page 9
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
5. OutputAll
Function Command Response Description
Switch all outputs off OUTPUTALL 00; VSWHDMI8X8B 00; Unlock
VSWHDMI8X8B 01; Command not recognized
Set all outputs to one source OUTPUTALL 01; VSWHDMI8X8B 00; Set all outputs to Source 1
VSWHDMI8X8B 01; Command not recognized
OUTPUTALL 02; VSWHDMI8X8B 00; Set all outputs to Source 2
VSWHDMI8X8B 01; Command not recognized
OUTPUTALL 03; VSWHDMI8X8B 00; Set all outputs to Source 3
VSWHDMI8X8B 01; Command not recognized
OUTPUTALL 04; VSWHDMI8X8B 00; Set all outputs to Source 4
VSWHDMI8X8B 01; Command not recognized
OUTPUTALL 05; VSWHDMI8X8B 00; Set all outputs to Source 5
VSWHDMI8X8B 01; Command not recognized
OUTPUTALL 06; VSWHDMI8X8B 00; Set all outputs to Source 6
VSWHDMI8X8B 01; Command not recognized
OUTPUTALL 07; VSWHDMI8X8B 00; Set all outputs to Source 7
VSWHDMI8X8B 01; Command not recognized
OUTPUTALL 08; VSWHDMI8X8B 00; Set all outputs to Source 8
VSWHDMI8X8B 01; Command not recognized
Check the status of all outputs OUTPUTALL
01020304
Response all outputs status
Output1=01, output 1 to input 1
Output2=-02, output2 to input2
Output3=03, output3 to input 3
Output4=04, output 4 to input 4
Output4=05, output 5 to input 5
Output4=06, output 4 to input 6
Output4=07; output 4 to input 7
Output4=08, output 4 to input 8
Page 10
724-746-5500 | blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
6. Recall
Function Command Response Description
Recall a saved configuration from memory RECALL 00; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 01; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 02; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 03; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 04; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 05; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 06; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 07; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 08; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 09; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 0A; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 0B; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 0C; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 0D; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 0E; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 0F; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
RECALL 10; VSWHDMI8X8B 00;
VSWHDMI8X8B 01;
Recall from memory00 Command not recognized
Recall from memory01 Command not recognized
Recall from memory02 Command not recognized
Recall from memory03 Command not recognized
Recall from memory04 Command not recognized
Recall from memory05 Command not recognized
Recall from memory06 Command not recognized
Recall from memory07 Command not recognized
Recall from memory08 Command not recognized
Recall from memory09 Command not recognized
Recall from memory10 Command not recognized
Recall from memory11 Command not recognized
Recall from memory12 Command not recognized
Recall from memory13 Command not recognized
Recall from memory14 Command not recognized
Recall from memory15 Command not recognized
Recall from memory16 Command not recognized
Page 11
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
7. Recall [mm]
Function Command Response Description
Check the memory address data
RECALL 00?; RECALL00 0102030405060708
NOTE: “RECALL00” means recall from memory address 1. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 01?; RECALL01 0102030405060708
NOTE: “RECALL01” means recall from memory address 2. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 02?; RECALL01 0102030405060708
NOTE: “RECALL02” means recall from memory address 3. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 03?; RECALL03 0102030405060708
NOTE: “RECALL03” means recall from memory address 4. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 04?; RECALL04 0102030405060708
NOTE: “RECALL04” means recall from memory address 5. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 05?; RECALL05 0102030405060708
NOTE: “RECALL05” means recall from memory address 6. 0102030405060708 are the input numbers connected to outputs 1–8.
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Page 12
724-746-5500 | blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
7. Recall [mm]
Function Command Response Description
Check the memory address data
RECALL 06?; RECALL06 0102030405060708
NOTE: “RECALL06” means recall from memory address 7. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 07?; RECALL07 0102030405060708
NOTE: “RECALL07” means recall from memory address 8. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 08?; RECALL08 0102030405060708
NOTE: “RECALL08” means recall from memory address 9. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 09?; RECALL09 0102030405060708
NOTE: “RECALL09” means recall from memory address 10. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 0A?; RECALL0A 0102030405060708
NOTE: “RECALL0A means recall from memory address 11. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 0B?; RECALL0B 0102030405060708
NOTE: “RECALL0B” means recall from memory address 12. 0102030405060708 are the input numbers connected to outputs 1–8.
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Page 13
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
7. Recall [mm] (continued)
Function Command Response Description
Check the memory address data
RECALL 0C?; RECALL0C 0102030405060708
NOTE: “RECALL0C” means recall from memory address 13. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 0D?; RECALL0D 0102030405060708
NOTE: “RECALL0D” means recall from memory address 14. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 0E?; RECALL0E 0102030405060708
NOTE: “RECALL0E” means recall from memory address 15. 0102030405060708 are the input numbers connected to outputs 1–8.
RECALL 0F?; RECALL0F 0102030405060708
NOTE: “RECALL0F” means recall from memory address 16. 0102030405060708 are the input numbers connected to outputs 1–8.
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Output1= 01, output 1 to input1 Output2= 02, output 2 to input2 Output3= 03, output 3 to input3 Output4=04, output 4 to input4 Output5= 05, output 5 to input 5 Output6 = 06, output 6 to input 6 Output7 = 07, output 7 to input 7 Output8 = 08, output 8 to input 8
Page 14
724-746-5500 | blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
8. Memory
Function Command Response Description
Save current matrix configuration to memory address
MEMORY 00; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 01; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 02; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 03; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 04; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 05; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 06; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 07; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 08; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 09; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 0A; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 0B; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 0C; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 0D; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 0E; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
MEMORY 0F; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
Save at memory address 00 Command not recognized
Save at memory address 01 Command not recognized
Save at memory address 02 Command not recognized
Save at memory address 03 Command not recognized
Save at memory address 04 Command not recognized
Save at memory address 05 Command not recognized
Save at memory address 06 Command not recognized
Save at memory address 07 Command not recognized
Save at memory address 08 Command not recognized
Save at memory address 09 Command not recognized
Save at memory address 10 Command not recognized
Save at memory address 11 Command not recognized
Save at memory address 12 Command not recognized
Save at memory address 13 Command not recognized
Save at memory address 14 Command not recognized
Save at memory address 15 Command not recognized
Page 15
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
9. Lock
Function Command Response Description
Unlock LOCK 00; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
Lock LOCK 01; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
Check the status of lock
10. EDID
Function Command Response Description
Set EDID EDID00; VSWHDMI8X8B 00;
LOCK?; Lock 00;
Lock 01;
VSWHDMI8X8B 01
EDID01; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
EDID02; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
EDID03; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
EDID04; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
EDID05; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
EDID06; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
EDID07; VSWHDMI8X8B 00;
VSWHDMI8X8B 01
Unlock Command not recognized
Lock Command not recognized
System Unlock System Lock
Set EDID to FSS Command not recognized
Set EDID to H24-3D Command not recognized
Set EDID to H24-3D Command not recognized
Set EDID to H36-No 3D Command not recognized
Set EDID to H36M-No 3D Command not recognized
Set EDID to H36-3D Command not recognized
Set EDID to H36-No 3DF Command not recognized
Set EDID to Auto Command not recognized
Page 16
724-746-5500 | blackbox.com
8 x 8 HDMI Matrix Switch RS-232 Protocol Manual
Hex/Decimal Equivalents
Hex Decimal Hex Decimal Hex Decimal Hex Decimal Hex Decimal Hex Decimal Hex Decimal
00 0 10 16 20 32 30 48 40 64 50 80 60 96
01 1 11 17 21 33 31 49 41 65 51 81 61 97
02 2 12 18 22 34 32 50 52 66 52 82 62 98
03 3 13 19 23 35 33 51 43 67 53 83 63 99
04 4 14 20 24 36 34 52 44 68 54 84 64 100
05 5 15 21 25 37 35 53 45 69 55 85
06 6 16 22 26 38 30 54 46 70 56 86
07 7 17 23 27 39 37 55 47 71 57 87
08 8 18 24 28 40 38 56 48 72 58 88
09 9 19 25 29 41 39 57 49 73 59 89
0A 10 1A 26 2A 42 3A 58 4A 74 5A 90
0B 11 1B 27 2B 43 3B 59 4B 75 5B 91
0C 12 1C 28 2C 44 3C 60 4C 76 5C 92
0D 13 1D 29 2D 45 3D 61 4D 77 5D 93
0E 14 1E 30 2E 46 3E 62 4E 78 5E 94
0F 15 1F 31 2F 47 3F 63 4F 79 5F 95
Page 17
NOTES
Page 18
724-746-5500 | blackbox.com
NOTES
Page 19
Black Box Tech Support: FREE! Live. 24/7.
Tech support the way it should be.
Great tech support is just 30 seconds away at 724-746-5500 or blackbox.com.
About Black Box
Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 30 seconds or less.
© Copyright 2013. Black Box Corporation. All rights reserved. Black Box® and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Any third-party trademarks appearing in this manual are acknowledged to be the property of their respective owners.
VSW-HDMI8X8 -B, RS-232 Protocol Manual, version 1
724-746-5500 | blackbox.com
Loading...
