FEA TURES

• Connect to remote computers over an
Ethernet network.

• Single-, dual-, and quad-user versions.

• Up to 1280 x 1024 @ 85 Hz resolution.

• Local port for KVM control station
connection.

• Display four server screens in quad­screen format.

• Scale screen images automatically.

• Easy to install and operate.

• Autosense network connection speed.

• Compatible with many KVM switches.

• Include brackets for rackmounting.

View servers from a remote location using a TCP/IP network connection.

OVERVIEW

For the ultimate in remote computer server management,

order a ServSwitch

™

Ultra Remote or ServSwitch Remote.
These compact, rackmountable devices bring remote server
connectivity to you in the form of an Ethernet LAN/WAN
connection, giving you computer CPU access anywhere in the
world.

By extending a KVM switch’s user port for operation from
a remote workstation or location, the ServSwitch Ultra
Remote or ServSwitch Remote lets you tap into a network
server from home or another office.

In addition to an RJ-45 Ethernet port for a remote connection,
the Single-User ServSwitch Ultra Remote and ServSwitch Ultra
units provide an integrated switched analog KVM port for the
local side. Use this port to attach a keyboard, monitor, and mouse
and gain direct access to the unit.

For port density up to two or four remote users, order
a Dual-User or Quad-User Ultra Remote. The dual and quad
models contain two or four independent ServSwitch Ultra
Remote units in a single rackmountable chassis. They enable
multiple users to have remote access to servers by connecting
to the KVM inputs on the Dual-User or Quad-User Ultra
Remote units.

The Single-User ServSwitch Ultra Remote (ACR9000A)
differs from the other models in that it’s designed for future
connections and long-term use. It includes dual USB Type A
connectors that are reserved for future applications and will
soon support connections via a dialup modem.

If you need a single-access model and don’t think you’ll
need these type of connectors in the future, you can get the
job done with our low-cost ServSwitch Remote (ACR9005A).

All ServSwitch Ultra Remote and ServSwitch Remote units

also include a pair of DB9 connectors for future use.

The ServSwitch Ultra Remote and ServSwitch Remote are
fully embedded products with no hard drives or complicated
operating systems, so they’re highly reliable and available.
Tobegin configuring the Ultra Remote for connection to your
network and set password information, just access the analog
KVM port(s) on the local side.

Advanced viewing options.

With the included remote-access client Viewer software
installed on your workstation, you can see up to four
connected servers in your data center (as long as the Ultra
Remote/Remote is attached to a compatible KVM switch)
in real time.

For easy viewing, the client interface displays these four
remote computers simultaneously within a split-screen format
in color, shades of gray, or black and white. A computer­selection box for each quadrant of the screen appears on the
software’s toolbar.

You can also use a single-screen view, in which the video
image from only one remote computer is shown in the display
area.

An advanced scaling function even resizes the video image
to fit your window and allows you to reposition video images
of any size image anywhere on your monitor‘s screen. This
helps you monitor the connected servers while you tend to
other tasks. Place a scaled image of your server in the corner
of your monitor screen or work with it at full resolution.

What’s more, because the scaling function requires less
data to transmit images, you’re able to obtain video updates
quickly over slower links. There’s also reduced demand on
network bandwidth.

ServSwitch Ultra Remote

(ACR9000A)

Servers

LAN PC with Remote

Viewer Software Installed

Local Monitor,

Keyboard and Mouse

Compatible KVM

Switch

LAN Connection over

UTP Cable
