Page 1
Send your video where it needs
to go at the touch of a button.
Send your video where it needs
to go at the touch of a button.
ServSwitch Brand Matrix Video Switches
© 2007. All rights reserved. Black Box Corporation.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com
Page 2
2 of 3
6/15/2007
#24758
724-746-5500 blackbox.com
FEA TURES
• 4 x 4 or 8 x 2 video switching.
• Enough bandwidth to handle
1600 x 1280 resolution at 85 Hz.
• Just press a button to switch any
input to any output.
• Has universal power supply—can be
used almost anywhere.
• Designed for VGA, but can support
almost any kind of video with the
right cabling.
• Can drive video as far as 300 ft. (90 m).
• Front-panel LEDs make it easy to figure
out where video is going.
Direct any of your video output to different locations
for display , recording, broadcasting—you name it!
OVERVIEW
If you have several sources of video that you’d like to
display at different places at different times, here are a
few things not to do:
1. Don’t settle for static, expensive dedicated video feeds.
2. Don’t swap video cables by hand.
3. Don’t subject your video devices to ugly and potentially
damaging mechanical video switching.
4. Don’t pay for extra switching (keyboard, mouse, etc.)
that you don’t need.
What should you do? Consider ServSwitch
™
Brand Matrix
Video Switches. Y ou can use them to electronically switch
video signals from four source devices among video screens
or to switch from eight source devices to two video screens.
In the standard application, computer CPUs will be the
sources and computer monitors will be the destinations. But
with the proper cabling and signal conversion (and as long as
the destination devices can handle it), almost any video device
can be involved—TVs, VCRs, cameras, projectors, DVD players,
etc.
This is because the switches can handle almost any kind
of video synchronization: RGBHV (as used in VGA, SVGA, and
other types of computer video), RGBS (as used in NTSC and
PAL TV signals), and RGsB (“sync on green”). They have a vast
amount of bandwidth—enough to carry video at resolutions
up to 1600 x 1280 at refresh rates up to 85 Hz. All inputs and
outputs are buffered, so you always get the sharpest possible
images.
The 4 x 4 switch can drive signals up to 150 ft. (45 m);
the 8 x 2 switch can drive signals up to 300 ft. (90 m).
ServSwitch Brand Matrix Video Switches can be controlled
in either of two ways. For one, it can be controlled with a
standard serial numeric keypad, powered by the Switch, that
plugs into the Switch’s rear panel. Press the keypad buttons in
the sequence output–decimal point–input–Enter key to make
a switch. For example, press [3][.][1][Enter] to switch the input
from CPU #1 to output to monitor #3. If you press zero for the
input number, the output channel will be blanked (the Switch
won’t send it any video signal). If you press the asterisk key for
the output number, the input channelwill be broadcast to all
outputs. LEDs show you which output channel is receiving
which input.
The keypad’s cable is 6 ft. (1.8 m) long, but you can use
DB9 extension cable (not included) to extend your “roaming
radius” out to RS-232’s maximum distance of 50 ft. (15 m).
The 4 x 4 model includes one keypad; the 8 x 2 model includes
two keypads.
The other way to control a switch is by attaching a PC or
other serial device that can send the Switch the ASCII characters
or hex codes equivalent to the keypad keypresses. In this way,
switching can be automatically controlled for displays, demos,
and so on.
Each switch has a universal power supply; with the proper
input cord, you can plug it in just about anywhere in the world.
Control
Keypad
Monitors
ServSwitch Brand Matrix
Video Switch (ACL0404A)
Computer
CPUs
Monitors
Video Converter Video Projector
Video Converter
VCR
Page 3
3 of 3
6/15/2007
#24758
724-746-5500 blackbox.com
ACL0404A
TECH SPECS
Cable Required — To attach a computer as a video source: Video-
extension cable such as our EVNPS05-XXXX-MF
Compliance — CE; FCC Part 15 Subpart B Class A, ICClass/classe A
Standards — VGA, SVGA, XGA, orXGA-2 video
Interfaces — Video: VGA;
Keypads: Proprietary serial
Supported Video Types —RGBHV (VGA, SVGA, XGA, or XGA-2), RGBS, or
RGsB (“sync on green”)
Resolution and Refresh Rate — Up to 1600 x 1280 noninterlaced at up to
85 Hz
Video Coupling — DC
Video Level — 0.7 volts peak-to-peak
Video Gain — 1-to-1 (buffered)
Maximum Distance — ACL0404A:
Up to 150 ft. (45.7 m) of total cable length from attached
CPU/input device to attached monitor/output device;
ACL0802A: Up to 300 ft. (91 m) of total cable length from any
attached CPU or other input device to any attached monitor
or other output device
User Controls —
ACL0404A: (1) Front-mounted rocker switch for power;
Switching commands (ASCII “make” and “break” codes
from PC or included serial keypad);
ACL0802A: (2) 10-button switching keypads, (1) for each user;
(2) rear-mounted 8-position DIP switches—(1) for each user
port—for distance compensation
Indicators — ACL0404A: (16) Front-mounted LEDs to show video
connections;
ACL0802A: (16) Rear-mounted LEDs, (2) for each video-source port;
(10) LEDs on each keypad
Connectors —
ACL040A: On Switch itself:
(8) HD15 female for video:
(4) to CPUs’ video ports (or other sources),
(4) to monitors (or other destinations);
(1) DB9 male for serial;
(1) 5-pin DIN female for power;
On power-supply transformer: (1) IEC male inlet for power;
ACL0802A: Front-mounted: (8) HD15 female for video input;
Rear-mounted: (2) HD15 female for video output, (1) for each
user port;
(2) DB9 female for keypad input, (1) for each user port;
(1) 5-pin DIN female power inlet
Maximum Altitude — 10,000 ft. (3048 m)
Temperatur e Tolerance —
Operating: 32 to 122˚F (0 to 50˚C);
Storage: -40 to +185˚F (-40 to +85˚C)
Humidity Tolerance —Up to 95% noncondensing
✦
The ServSwitch Brand Matrix Video Switch
✦
ACL0404A: (1) 18-button serial keypad
ACL0802A: (2) 10-button serial keypads
✦
Its autosensing power supply
✦
Its manual
WHA T‘S INCLUDED
Item Code
ServSwitch™Brand Matrix Video Switches
4 x 4 ACL0404A
8 x 2 ACL0802A
You might also need…
CAUTION: If you use adapters or converters to attach non-VGA
equipment, all destination devices must be capable of handling
the video signals from all source devices. For example, driving
high-end workstation video to a monitor whose maximum refresh
rate is too low could result in oversyncing and damaging the
monitor.
VGA Video-Extension Cable (HD15 male to HD15 female,
specify length) EVNPS05-XXXX-MF
Video to VGA Portable (converts NTSC/PAL to VGA
up to 1280 x 1024 at 60 Hz) AC328A
VGA to Video Portable II (converts VGA up to 1024 x 768
at 75 Hz to NTSC/PAL) AC325A-R2
Mac®to VGA Video Adapter (DB15 male to HD15 female)
EVMA22
Sun®to VGA Video Adapter (13W3 male to HD15 female)
FA8500SUN
SGI™to VGA Video Adapter (13W3 male to HD15 female)
FA8500SGI
Universal Generic Video Adapter (five BNC male to HD15
female, handles any sync arrangement) EYRGBS4-0006
DB9 Extension Cable (DB9 male to DB9 female, specify length)
EDN12H-XXXX-MF
DB9 RS-232 Data-Line Surge Protector SP361A-R2
Call us about UPSes and AC-power surge protection; we’ll help
you determine the best equipment for your application.
Enclosure — Steel
MTBF — 300,000 hours (calculated estimate)
Power — From utility-power (mains) outlet, through included detachable
output cord and external universal power supply:
Input: 100 to 250 VAC at 50 to 60 Hz (autosensing);
Output: +5 VDC at 1 A, +12 VDC at 0.5 A, and -12 VDC at 0.5 A;
Consumption: 5 VA (5 watts) maximum
Size — ACL040A: 2.3"H x 8.3"W x 5.3"D (5.8 x 21.1 x 13.5 cm);
ACL0802A: 1.5"H x 12.1"W x 4.1"D (3.8 x 30.7 x 10.4 cm); mounting
ears protrude an additional 0.9" (2.2 cm) wide on each side
Weight —
ACL040A: Net:
Switch itself: 2.2 lb. (1 kg);
Keypad: 1 lb. (0.5 kg);
Power supply: 3 lb. (1.4 kg);
Shipping: 7 lb. (3.2 kg);
ACL0802A: Net:
Switch itself: 2.3 lb. (1 kg);
Keypads: 1 lb. (0.5 kg) each;
Power supply: 1.3 lb. (0.6 kg);
Shipping: 6.7 lb. (3 kg)
