Take your PCMCIA cards on the road and have
the cable you need to plug into a phone jack.
Take your PCMCIA cards on the road and have
the cable you need to plug into a phone jack.
PCMCIA Storage Cases • Mobile RJ-11 Retractable Cables
© 2007. All rights reserved. Black Box Corporation.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com
2 of 3
7/13/2007
#13473
724-746-5500 blackbox.com
FEA TURES
• PCMCIA Storage Cases protect Types I, II,
and III PCMCIAcards from harmful dust
and debris.
• Made of durable vinyl and polypropylene.
• Mobile RJ-11 cables extend and retract
easily, like a tape measure, into cases
that are smaller than cassettes.
• Plug the RJ-11 connector into a phone
jack, pull out as much cable as you need,
then plug the other end into your
laptop’s modem port.
OVERVIEW
Are you one of those road warriors attached to the laptop
to your mobile computer? Are you always in contact with the
home office, sending and receiving files? Then you need our
PCMCIA Storage Cases and Mobile RJ-11 Retractable Cables.
The pocket-sized SingleStore (AC103) protects Type I and
II PCMCIA cards. Molded from durable vinyl, the SingleStore
enables easy storage and portability and offers an economical
solution to your mobile data storage requirements. It features
a molded inner lip that holds the memory card securely in
place.
Our SecureStore (AC109) provides the ultimate in shock
protection for rotating memory cards. A SecureStore case
protects Type III cards inside molded durable polypropylene
cases. A thermoplastic rubber tray provides superior shock
absorption. Perimeter connection of the tray to the base
forms an air- and water-tight gasket. A state-of-the-art snap
lock ensures positive closure.
SecureStore cases are designed to meet stringent industry
drop standards. Properly store your cards—and eliminate the
risk of losing valuable data—with SecureStore.
To plug your computer into a data port when you’re on
the road, opt for one of our Mobile RJ-11 Retractable Cables
(TE101A-R2 or AC108-R2). They easily extend and retract for
convenient storage and use.
Item Code
PCMCIA Storage Cases
SingleStore, Black AC103
SecureStore, Green AC109
Mobile RJ-11 Retractable Cables
Rectangle, 10-ft. (3-m) TE101A-R2
Oval, 8-ft. (2.4-m) AC108-R2
Mobile RJ-11 Retractable Cables offer an efficient
alternative to loose and tangled cables. They’re designed to
share the same footprint as a standard PCMCIA card to
provide ease of use and efficiency.
The reel component on these cables features a molded
finger recess for smooth, easy winding. It’s molded from
durable acetal, providing frictionless action. The RJ-11
connector retracts easily into its original position after use.
Choose from two models—the rectangle-case TE101A-R2
with 10 feet (3 m) of cable or the oval-case AC108-R2, with
8 feet (2.4 m) of cable.
Our PCMCIA Storage Cases and the Mobile RJ-11
Retractable Cables are guaranteed for life!
Recognize any of these situations?
• You wait more than 30 minutes to get through
to a vendor’s tech support.
• The so-called “tech” can’t help you or gives you
the wrong answer.
• You don’t have a purchase order number and the
tech refuses to help you.
• It’s 9 p. m. and you need help, but your vendor’s
tech support line is closed.
According to a survey by Data Communications
magazine, 90% of network managers surveyed say
that getting the technical support they need is extremely
important when choosing a vendor. But even though
network managers pay anywhere from 10 to 20% of their
overall purchase price for a basic service and support
contract, the technical support and service they receive falls
far short of their expectations—and certainly isn’t worth
what they paid.
At Black Box, we guarantee the best value and the
best support. You can even consult our Technical Support
Experts before you buy if you need help selecting just
the right component for your application.
Don’t waste time and money—call Black Box today.
Why Buy From Black Box? Exceptional V alue.
Exceptional Tech Support. Period.
3 of 3
7/13/2007
#13473
724-746-5500 blackbox.com
The Personal Computer Memory Card International
Association (PCMCIA) is an organization that is chartered with
establishing, marketing, and maintaining a series of hardware
and software standards for credit card-sized, integrated-circuit
PC cards.
PCMCIA cards are your laptop’s mobile link to the outside
world. You can use them to send last-minute data files from
the airport to the office. Then you can link your laptop to
connect to a branch office’s Ethernet port.
The PCMCIA standard specifies a removable device measuring 2.126" x 3.37" (5.4 x 8.6 cm)—basically the size of three
stacked credit cards. PCMCIA cards have 68 pins and interface
with both 8- and 16-bit buses. They also support physical
access of up to 64 MB of memory.
PCMCIA cards provide universal expansion capability for
laptop computers and personal digital assistants (PDAs). These
tiny cards can support a wide variety of functions including
faxmodem capabilities, mass storage, and memory extension
for host machines.
PCMCIA enables you to choose the memory and I/O devices
(LAN adapters, faxmodems, disk drives, etc.) that you need
most. You are not restricted to using cards that work with only
a specific computer make or model.
The three types of PCMCIA slots are defined by the thickness
of the card that fits in them. All card types are backward
compatible.
T ype Icards are 3.3-mm thick. They’re used primarily in PD
As as RAM, flash memory, electrically erasable programmable
read-only memory (EEPROM), and one-time programmable
memory (OTP).
T ype IIcards are 5-mm thick and are fully I/O-capable. You
can use them for memory enhancements or for I/O features in
modems, LAN connections, and host communications.
T ype IIIcards measure 10.5-mm thick. They’re designed
primarily for removable hard drives and radio communication
devices that require a larger size. They can also be used for
memory enhancements.
Technically Speaking
T ype I and II extended cards are identical to the regular
cards except they’re 50 mm longer. These cards are used in
applications that need components outside of the systems
or that simply need more room for internal components.
Plug PCMCIA cards into a host socket/adapter on the
computer’s motherboard or connect them to its expansion
bus. The socket side has the standard 68-pin interface for the
card. The adapter side translates the PCMCIA interface signals
to match the computer’s bus standards.
Socket Services 2.0 is the software interface between
the card in the socket and the adapter to the computer’s bus.
The standard Socket Services interface is what permits the use
of any PCMCIA card on any PC equipped with a socket/adapter.
The programming interface for PCMCIA is called Card
Services 2.0. It sends the signals to link Socket Services to the
PC’s operating system and hardware.
Card Information Structure (CIS) contains information
about how the card functions, its size, its electrical requirements, and so on. On card insertion, the card passes this
identifying information to the host system.
The system software reads the CIS data on insertion, installs
the appropriate drivers, notifies relevant system resources,
and initializes the card to make it available for use by the
host.
There have been three major PCMCIA releases since the
inception of the PCMCIA organization in 1989. PCMCIA
Release 1.0 set the specification for a PC card, offering
memory capabilities for mobile computing. Release 2.0
broadened the spec to include mass storage, modem, LAN,
cellular and radio frequency communications peripherals.
Release 2.1 enhanced the Card and Socket Services specs, and
made improvements to the CIS. All standards are backward
compatible.
