OPeraTING POINTers & TrOUBLesHOOTING
Optical Fiber:
The RGBHV with Stereo Audio ber optic transmission system is designed to operate
with most multimode (MM) and single mode (SM) optical bers.
Remember to check the attenuation and bandwidth of the ber optic cable. The
system will only operate properly if these specications fall within the range of the
system’s loss budget.
Troubleshooting:
Multimode ber optic cable contains an optical ber with a light carrying “core” that
is only .0025 inches (62.5 microns) in diameter. Single mode ber optic cable has an
even smaller “core”, only 00032 to .0004 inches (8-10 microns). This is smaller than
a human hair! Therefore, any minute particles of dirt or dust can easily block the ber
from accepting or radiating light. To prevent this from happening, always use the
provided dust caps whenever optical connectors are exposed to air. It is also a good
idea to gently clean the tip of an optical connector with a lint-free cloth moistened
with alcohol whenever dust is suspected.
The status of the VIDEO and AUDIO indicator LEDs should provide the rst clue as
to the origin of an operational failure. If these are off, it usually means that the ber is
broken or has too much attenuation. Next, be certain that the input and output signal
connections are correct.
If, after reviewing the above possibilities, the system is still not operating, please
contact the Black Box Tech Support for further assistance
Maintenance:
The only maintenance of the AC1020A system that can be provided by the user is to
ascertain that the optical connectors are free of dust or dirt that could interfere with light
transmission and that electrical connections are secure and accurate. DANGER! Always
disconnect the transmitter power before removing the optical ber from the unit! For
assistance with all other repairs, please contact Black Box technical support.
2
11
AC1020A/AC1021A-XMIT/ AC1021A-REC
NOm sTaTemeNT
descrito en el instructivo de operación, o como se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra sica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean
pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo
particular atención a los contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomen-
daciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u oricios de ventilación.
18. Servicio por personal calicado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
10
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.
Ce INFOrmaTION
Standards to which conformity is declared: EN 55103-1:1997 EN
55103-2:1997
3
AC1020A/AC1021A-XMIT/ AC1021A-REC
INsTaLLaTION
Indicator LEDs:
The transmitter and receiver units in the A1020A system each have three integral indicator LEDs that are used to monitor the state of the unit. Their status is as follows:
TRANSMITTER and RECEIVER:
Power: (Green) Indicates that correct power has been applied.
TRANSMITTER:
Video: OFF: Indicates no video detected on the input.
BLINKING GREEN: Indicates either H or V sync detected at the input
but not on both.
STEADY GREEN: Indicates both H and V sync detected on the input.
Audio: OFF: Indicates no audio detected on the transmitter unit.
BLINKING: Indicates audio detected on the transmitter unit.
RECEIVER:
Video: OFF: Indicates no video detected over ber and, as a result, no
video present on output.
BLINKING GREEN: Indicates either H or V sync detected over the
ber but not both.
STEADY GREEN: Indicates both H and V sync detected over the ber
and, as a result, video present on the output.
Audio: OFF: Indicates no audio detected over ber and, as a result, no active
audio detected by the receiver unit.
BLINKING: Indicates audio detected over fiber and, as a result,
active audio detected by the receiver unit.
4
9
AC1020A/AC1021A-XMIT/ AC1021A-REC
AC1020A/AC1021A-XMIT/ AC1021A-REC
INsTaLLaTION
4. Connect the audio input signals to the transmitter stereo jack and the audio
output to the receiver stereo jack.
5. Apply power to both units. Refer to Figure 1.
6. When power is applied, the green POWER
LED will light, indicating the presence of
operating power. The VIDEO LED will give
an indication as described on Page 9.
7. The green AUDIO LED will give an indication as stated on Page 9.
System Connections:
The input and output connections for the AC1020A are as follows:
Audio Connector (Transmitter and Receiver): 3.5mm stereo jack
Video Connector (Transmitter and Receiver): HD-15F connector
Video Pin Out: Transmitter: Receiver:
1 Red Red
2 Green Green
3 Blue Blue
4 N/C N/C
5 Ground Ground
6 Ground Ground
7 Ground Ground
8 Ground Ground
9 N/C N/C
10 Ground Ground
11 N/C N/C
12 N/C N/C
13 Hor. Sync In Hor. Sync Out
14 Vert. Sync In Vert. Sync Out
15 N/C N/C
ITems INCLUded
Depending on which product you ordered, you should have received:
AC1021A-XMIT:
Qty Description
1 AC1021A-XMIT Transmitter
1 Power Supply
1 AC line cord
1 User Manual
1 HD15M - HD15M VGA cable, 6 ft.
1 3.5mm plug to 2xRCA(M) stereo audio cable, 6 ft.
1 3.5mm plug to 3.5mm plug stereo audio cable, 6 ft.
AC1021A-REC :
Qty Description
1 AC1021A-REC Receiver
1 Power Supply
1 AC line cord
1 User Manual
1 HD15M - HD15M VGA cable, 6 ft.
1 3.5mm plug to 2xRCA(M) stereo audio cable, 6 ft.
1 3.5mm plug to 3.5mm plug stereo audio cable, 6 ft.
AC1020A:
Qty Description
1 AC1021A-XMIT Transmitter
1 AC1021A-REC Receiver
2 Power Supplies
2 AC line cords
2 User Manuals
2 HD15M - HD15M VGA cables, 6 ft. each
2 3.5mm plug to 2xRCA(M) stereo audio cables, 6 ft. each
2 3.5mm plug to 3.5mm plug stereo audio cables, 6 ft. each
8
5
AC1020A/AC1021A-XMIT/ AC1021A-REC
AC1020A/AC1021A-XMIT/ AC1021A-REC
GeNeraL INFOrmaTION
Introduction:
The RGBHV Video with Stereo Audio Fiber Optic Transmission System (AC1020A V/A System) is a transmitter/receiver pair that transmits a single channel of RGBHV
and two audio channels over one single mode or multimode ber.
The system’s all digital encoding delivers noise-free transmissions that retain all of
their initial parameters, regardless of ber optic cable attenuation. System operation
may be easily monitored using integral indicator LEDs on each unit that continuously
signify the presence of baseband video and audio signals.
Specications:
Video:
Input Impedance ...................................RGB: 75 ohms; H&V: Hi-Z
Input Level ...........................................RGB: 714 mV p-p; H&V: 3 to 5 V p-p
H Sync Frequency Range .....................15 to 60 kHz
V Sync Frequency Range .....................30 to 85 Hz
Number of Video Channels ..................1 RGBHV
RGB Format Supported .......................RGB with separate H and V
Signal Connectors ................................HD-15F
RGB Processing ...................................24 bits, no compression or scaling
Audio:
Number of Audio Channels .................. 2, unbalanced
Frequency Response ............................. +0/-0.5 dB, 20 Hz to 20 kHz
Input Impedance .................................... >24 kOhms
Output Impedance ................................. <1 Ohm
Maximum Audio Level ......................... +10 dBu
THD+N ................................................. 0.005%; 20 Hz to 20 kHz
SNR (A-Weighted) ................................ 95 dB
Channel Phase Differential ................... +/-0.1
Crosstalk ............................................... Min. 95 dB (1kHz)
Signal Connectors ................................. 3.5mm Stereo jack
Audio to Video Diff. Delay (skew) ....... <300 uS
6
o
GeNeraL INFOrmaTION
Optical:
Operating Wavelength ..........................1310 nm; MM or SM
Optical Fiber ........................................50 - 62.5/125microns MM or
8-10/125 microns SM
Optical Connectors ...............................ST
Wavelength Loss Budget (in dB) Distance* (in km)
1310 MM 0-15 0-0.75
1310 SM 0-15 0-35
*Note: Distance specications are only approximate and are not guaranteed. Operating loss budget must not be exceeded.
Misc:
Operating Temperature Range .............-20 to +60 degrees C
Operating Power ..................................9 to 24 Volts AC or DC @ 5 watts (max)
CAUTION! The transmitting element in the AC1021A-XMIT transmitter is a solidstate Laser Diode located in the optical connector on the unit. This device emits
invisible infrared electromagnetic radiation which can be harmful to human eyes.
The radiation from this optical connector, if viewed at close range without a ber
optic cable connected to the optical connector, may be of sufcient intensity to
cause instantaneous damage to the retina of the eye. Direct viewing of this
radiation should be avoided at all times.
INsTaLLaTION
Installation Procedure:
The AC1020A ber optic transmission system for RGBHV with Stereo Audio is delivered ready for immediate use. There are indicator LEDs on the units for monitoring
purposes. The following instructions describe the typical installation procedure and
the function of the LED indicators.
1. Connect the video source to the video input HD-15F connector on the transmitter unit.
2. Connect the video output on the receiver unit to the HD-15F connector.
3. Connect the ber optic cable between the transmitter and receiver unit.
7
Loading...
