HSS
Hot Self Serve
Multi-Tier Merchandiser with
Heated Air Curtain
Heated Shelves With Independent
Temperature Control
Stainless Steel Shelf Top With
Marine Edge Retains Spills
24” (620 mm), 36” (914 mm) & 48”
(1220 mm) Widths
Ambient Barrier With Heated Air
Curtain Maintains Temperature &
Freshness of Pre-Packaged Foods
At Ambient Temperatures As Low
As 60°F (15°C)
Slanted Shelves For Better Product
Presentation
Pricing Tag Rails
Fluorescent Lamp Above Each
Shelf
Durable Tempered Glass End
Panels
Mechanical Specifications:
Unit Dimensions
Model Width Depth
HSS2
HSS3
HSS4
24 13/16 in
[630 mm]
24 3/16 in
(615 mm)
36 3/16 in
(920 mm)
48 3/16 in
(1224 mm)
36 13/16 in
[934 mm]
38 in
(965 mm)
38 in
(965 mm)
38 in
(965 mm)
48 13/16 in
[1239 mm]
Shelf
Config.
-2 49 15/32 in (1257 mm)
-3 & -4S 69 11/16 in (1770 mm)
-4T & -5 79 3/16 in (2011 mm)
-2 49 15/32 in (1257 mm)
-3 & -4S 69 11/16 in (1770 mm)
-4T & -5 79 3/16 in (2011 mm)
-2 49 15/32 in (1257 mm)
-3 & -4S 69 11/16 in (1770 mm)
-4T & -5 79 3/16 in (2011 mm)
Height
24 3/16 in
[615 mm]
HSS2 HSS3 HSS4
36 3/16 in
[920 mm]
48 3/16 in
[1224 mm]
Crated Dimensions:
Unit Dimensions
Model Width Depth Shelf Config. Height Weight
-2 62 in (1575 mm) 460 lbs. (209 kg)
-3 & -4S 80 in (2032 mm) 535 lbs. (243 kg)
-4T & -5 89 in (2261 mm) 560 lbs. (254 kg)
-2 62 in (1575 mm) 524 lbs. (238 kg)
-3 & -4S 80 in (2032 mm) 607 lbs. (275 kg)
-4T & -5 89 in (2261 mm) 640 lbs. (290 kg)
-2 62 in (1575 mm) 570 lbs. (259 kg)
-3 & -4S 80 in (2032 mm) 670 lbs. (304 kg)
-4T & -5 89 in (2261 mm) 720 lbs. (327 kg)
HSS2
HSS3
HSS4
32 1/2 in
(826 mm)
44 1/2 in
(1130 mm)
56 1/2 in
(1435 mm)
46 in
(1168 mm)
46 in
(1168 mm)
46 in
(1168 mm)
Electrical Specifications:
Model HSS2 HSS3 HSS4
Shelf
Config.
-2
-3
-4S
-4T
-5
Volts Phase Cycles Wires Watts Amps Watts Amps Watts Amps
208 1 50/60 Hz 2 + G 2183 10.5 3452 16.6 4326 20.8
220 1 50/60 Hz 2 + G 2320 10.5 3678 16.7 4595 20.9
230 1 50/60 Hz 2 + G 2536 11.0 4020 17.5 5022 21.8
240 1 50/60 Hz
208 1 50/60 Hz 2 + G 2483 11.9 3902 18.8 4926 23.7
220 1 50/60 Hz 2 + G 2595 11.8 4090 18.6 5144 23.4
230 1 50/60 Hz 2 + G 2836 12.3 4470 19.4 5622 24.4
240 1 50/60 Hz
208 1 50/60 Hz 2 + G 2784 13.4 4352 20.9 5526 26.6
220 1 50/60 Hz 2 + G 2870 13.0 4502 20.5 5693 25.9
230 1 50/60 Hz 2 + G 3136 13.6 4920 21.4 6222 27.1
240 1 50/60 Hz
208 1 50/60 Hz 2 + G 3084 14.8 4802 23.1 6126 29.5
220 1 50/60 Hz 2 + G 3144 14.3 4913 22.3 6242 28.4
230 1 50/60 Hz 2 + G 3436 14.9 5370 23.3 6822 29.7
240 1 50/60 Hz
2 + G 2761 11.5 4377 18.2 5468 22.8
2 + G 3088 12.9 4867 20.3 6122 25.5
2 + G 3415 14.2 5357 22.3 6775 28.2
2 + G 3741 15.6 5847 24.4 7428 31.0
Capacities:
Model Width Depth Area
HSS2
HSS3
HSS4
23 in
(584 mm)
35 in
(889 mm)
47 in
(1194 mm)
Capacity per Shelf Total Capacity
21 1/2 in
(546 mm)
21 1/2 in
(546 mm)
21 1/2 in
(546 mm)
3.43 sq ft
(22.1 sq cm)
5.22 sq ft
(33.7 sq cm)
7.02 sq ft
(45.3 sq cm)
Chicken
Domes
6 12 18 24 30
8 16 24 32 40
12 24 36 48 60
-2 -3
-4S/
-4T
-5
Agency Approvals:
BKI North America BKI Europe
PO Box 80400 Theale Technology Centre
Simpsonville, SC 29680-0400 USA Station Road – Theale
Telephone: (864) 963-3471 Reading – West Berkshire – RG7 4AA
Toll Free: (800) 927-6887 Telephone: 0870 9904242
Fax: 0870 9904243
