B&K AVR 707, AVR-705 User Manual
14472 102808
ii
SBIMPLY ETTER!
BK&
© 2008 B&K Components Ltd. All rights reserved.
QUICK START GUIDE - AVR 707 & AVR 705
The information in this manual is copyright protected. No part of this manual may be copied or reproduced in any form
without prior written consent from B&K Components, Ltd.
B&K Components Ltd. SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL
ERRORS/OMISSIONS MADE IN THIS MANUAL. The information in this manual may be subject to change
without prior notice.
Accessories Included
1 - SR10.1 Remote Control
1 - AM Antenna
1 - FM Dipole Antenna
1 - Information CD
1 - Warranty Card
1 - Serial to RJ-45 Adapter
1 - Power Cord
1 - S-Video to RCA Adapter
Limited Warranty
B&K Components Ltd., referred to herein as B&K, warrants your B&K equipment (excluding remote control) against all defects in material and workmanship for a period of five years from the date of purchase. The remote control is under warranty for a period of one year. This warranty applies only
to the original purchaser and only to equipment in normal residential use and service. Defective equipment must be returned to B&K, prepaid, accompanied by proof of purchase and sufficient payment to cover the cost of return shipping and handling, and will be repaired or replaced at the discretion
of B&K whose decision as to the method of reparation will be final.
This warranty shall not apply to any equipment which is found to have been improperly installed, incorrectly fused, misused, abused, or subjected to
harmful elements, used in any way not in accordance with instructions supplied with the unit, or to have been modified, repaired or altered in any way
without the expressed, written consent of B&K. This warranty does not apply to the cabinet or appearance items such as the faceplate or control buttons, nor does it cover any expenses incurred in shipping the unit to and from the manufacturer's service department.
This warranty on B&K Components, Ltd. products is NOT VALID if the products have been purchased from an unauthorized dealer or an E-tailer or if
the original factory serial number has been removed, defaced or replaced in any way. B&K Components, Ltd. sells its products through authorized dealers in order to insure that consumers obtain proper dealer service and support. Buying from an authorized B&K Components, Ltd. dealer insures that
you have a FACTORY WARRANTY on your B&K Components, Ltd. product. If you have any questions concerning your Factory Warranty call
B&K Components, Ltd. at 716-656-0026.
Upgradability: B&K is one the first manufacturers in the audio/video industry to consistently offer software and hardware upgrades to its processing of
audio signals. Through upgrades B&K delivers exceptional value to its customers. But what is "Upgradability"? Upgradability is not a guarantee; we
define it as a philosophy of designing and manufacturing products so that as audio technology evolves, B&K can provide enhancements and improvements to its products that are economically viable.
THE EXPRESS FACTORY WARRANTY HEREIN CONTAINED IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OF MERCHANTABILITY, UPGRADABILITY OR OF FITNESS FOR ANY PARTICULAR PURPOSE. B&K COMPONENTS, LTD. SHALL NOT UNDER ANY CIRCUMSTANCES BE LIABLE FOR DAMAGES, INCLUDING SPECIAL, INCIDENTAL, EXEMPLARY, PUNITIVE OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH THE PURCHASE, USE OR PERFORMANCE OF ANY B&K
PRODUCT.
This warranty gives you specific legal rights. Your may also have other rights which vary from State to State. Some States do not allow the exclusion or
limitation of incidental or consequential damages and the foregoing exclusions may not apply to you.
No agent, representative, dealer or employee of B&K has the authority to increase or alter the obligations or terms of this warranty.
Returning Equipment
No equipment may be returned to B&K Components Ltd. without a RETURN AUTHORIZATION (RA). Should you find it necessary to return equipment
to B&K, for any reason, a RETURN AUTHORIZATION (RA) number must be issued by B&K in respect of the equipment being returned. You may
request an RA number by calling B&K at the numbers below. We will need the following information to issue your RA number. Please have it ready
before you call.
Your call will be referred to a Technical Service Representative who will work with you to resolve the problem. If it is determined that the unit must be
returned for repair, an RA number will be issued.
SIMPLYBETTER! is a copyright of B&K Components, Ltd. All other brand or product names are trademarks or registered trademarks of their respective companies or organizations.
1. Your name, address, and phone number.
2. The model and serial number of the equipment being returned.
3. A description of the problem being experienced.
4. Your sales receipt.
2100 Old Union Road Buffalo, NY 14227 1-800-543-5252 In NY: 716-656-0026 fax: 716-656-1291
e-mail: info@bkcomp.com Web Site: www.bkcomp.com
Table of Contents
FRONT AND REAR PANEL ...............................................................................................2
CONNECTION OVERVIEW...............................................................................................4
VIDEO INPUT / OUTPUT CONNECTIONS .......................................................................5
Video Input Connection - HDMI...............................................................................5
Video Input Connection - Component Video...........................................................5
Video Input Connection - S-Video...........................................................................5
Video Input Connection - Composite Video.............................................................5
Video Output and Scaling........................................................................................5
AUDIO INPUT CONNECTIONS.........................................................................................6
Audio Input Connection - HDMI...............................................................................6
Audio Input Connection - Optical Digital..................................................................6
Audio Input Connection - Coax Digital.....................................................................6
Audio Input Connection - StereoAnalog..................................................................6
Audio Input Connection - Multi-channel Analog 5.1 or 7.1......................................6
1
AUDIO OUTPUT CONNECTIONS.....................................................................................7
Audio Output Connection.........................................................................................7
Audio Output Connection - Speakers......................................................................7
CONFIGURATION AND CONTROL...................................................................................8
GUI On-Screen Overlay Interface............................................................................8
Ethernet Communication .........................................................................................8
RS-232 Communication...........................................................................................8
SAFETY PRECAUTIONS...................................................................................................9
SPECIFICATIONS ..............................................................................................................10
Product Information
Date of Purchase:
Model #:
Serial #:
Purchased From:
Address:
Phone #:
2
FRONT AND REAR PANEL
1
6
7
8
2
5
9
10
11
12
13
3
4
14
15
24
1 Left Hand Knob - The left selector knob is a rotary encoder with the primary purpose of A/V input source selection. The knob serves
multiple functions. Pushing in on the the knob will scroll through the options to control or select Input Source, AM/FM Tuning,AM/FM
Station,Audio Preference or Video Preference. Rotating the knob will change the highlighted function.
2 Display - The receiver contains a 16 character by 2 row display.It will display current status of the receiver and any changes being
performed.
3 Right Hand Knob - The right selector knob is a rotary encoder with the primary purpose of audio volume adjustment. The knob
serves multiple functions. Pushing in on the the knob will scroll through the options to control Master Volume, Bass, Treble, Center
Volume or Subwoofer Volume. Rotating the knob allows changing of the highlighted function.
4 Main power switch - Removes all power to the receiver. Normal operation of the receiver requires the power switch to remain on.
Use the SLEEP button for daily on and off of the receiver. SLEEP places the unit in standby mode, which allows turning
back on with the remote control. Turn the receiver off using the Main Power switch when the receiver is not used for extended periods of time.
5 Front panel buttons - Front panel buttons serve the following functions:
21
20
Sleep - Toggles the unit in and out of standby mode (ON or OFF).
Mute - Toggles the unit in and out of a mute state (ON or OFF).
Menu - Enters into and out of the on-screen menu system.
Save - Save the selected setting such as a Preference or Menu option.
Enter - Selection button for the desired preference.
Arrows - Navigate through the menu.
19
18
17
16
22
23
