Page 1
BC100B
Baby Safety Seat
User Instruction
◎
Universal
◎Applicable for 0-13kg baby
Read the instruction carefully before using the baby car seat.
Keep this instruction well for future reading.
This corporate is certificated by ISO9001:2008.
Page 2
Add：No.88 Yugong Road,Economic and TechnicalDevelopment
Zone,Zhengzhou,Henan,China PR.
Tel ：0371-8533 5555
Fax：0371-6689 9399+1863
Homepage：www.biucobaby.com
Please read this instruction and the relative part of your vehicle
manual. Please follow this instruction when installiing and using this
baby car seat. Not following this instruction may lead to a severe
injury or death to your child. Please keep this instruction in safety
place in case of future reading.
Content
1 Application scope 02-03
2 Important notes 03-04
3 Vehicle related notes 05-06
4 Assembly indicator 07
5 Baby safety seat user guide 08-15
Thanks for buying BIUCO BC100B baby safety seat！
1.This is a “universal” children restraint system (CRS) which is approved to
ECE Regulation No. 44, 04 series of amendments and GB27887-2011, for general use
in vehicles and it will fit most, but not all, car seats.
2.A correct fit is likely if the vehicle manufacturer has declared in the vehicle
handbook that the vehicle is capable of accepting a "Universal" child restraint for this
age group.
3. This child restraint has been classified as "Universal" under more stringent
conditions than those which applied to earlier designs which do not carry this notice.
4. Only suitable if the approved vehicles are fitted with 3 point safety-belts
approved to UN/ECE Regulation No. 16 or GB 14166 or other equivalent standards.
5.If in doubt, consult either the child restraint manufacturer or the retailer.
0126
BIUCO Car Seat BC100B User Instruction
400-659-6563
HOTLINE
Warranty Card
Name：
City：
Email：
Model：
Color：
Purchasing time：
Phone：
Post Code：
Address：
Type：
Retailer：
Signature：
Retailer
Stampe
Page 3
5.1 Handle adjustment 08
5.2 Seat cushion 09
5.3 Canopy and Canopy bracket 09
5.4 Baby fixation and notes 10-13
5.4.1 Y-shaped belt adjustment 10-11
5.4.2 Baby fixation 12-13
5.5 Installation in vehicle 13-15
5.6 Check the belt and make sure its route goes on correctly 15
6 Maintenance 16-24
6.1 Attention 16
6.2 Cover cleaning 16
6.3 Remove the canopy and cover 17-21
6.4 Installation of canopy and cover 22-24
7 Warranty condition and warranty card 25-26
Certification
●This baby safety seat is designed and tested with the European
Children Ristraint System standard (ECE R44/04) and the Chinese
Children Ristraint System standard (GB27887-2011). The certification
stamp E mark (in the round circle) with approval number and the
CCC mark (in the ellipse circle) can be found on the labels (in the
bottom side of this seat)
●Any modification of this seat by you will lead to invalidity of the
certification. Nobody is authorized to modify baby safety seat unless
the baby safety seat manufacturer.
1.Application scope
Certificated by ECE R44/04 and GB27887-2011, this baby safety
seat is applicable for Group 0+ infants.
BIUCO Baby safety seat
BC100B
Group
0+
Range of baby weight
0-13kg
2.Important notes
To protect the baby
●Important!Due to problem at birth, some baby might be
underweight, please confirm with the doctor before using this seat.
●Important!Do not use any accessory which is not shown in this
instruction.
●Important!Do not fix this seat in ways that are not shown in this
instruction.
●Do not leave your baby alone in this baby safety seat in your car.
●Do not remove the labels , important information contained.
●Do not modify this seat in any form.
●Do not disassemble this seat unless following the instruction.
BC100B User Instruction
0302
BIUCO Car Seat
Page 4
Danger
To protect passengers on board
●All heavy or sharp items must be fixed well.
●All passengers must fasten their seat belts.
●Make sure the baby safety always fixs well even no baby inside.
BC100B User Instruction
0504
BIUCO Car Seat
●Do not use borken or abrasive baby safety seats or seat belts.
●Do not use a post-accident baby safety seat. Invisible damage
might be made to the baby safety seat after crash.
●Check the baby safety seat and belts to make sure every part
functions well.
●No twine or twisting of the belts.
●Fasten the baby safety seat’s 3-point belt when baby inside.
●Every time using this seat, make sure its handle is locked
in“ carrier position”.
●Empyrosis possibility！Cover this seat when the car is exposed in
sunshine. The safety seat parts might be overheated and burn your
baby’s skin. Check the temperature before using the seat.Sunshine
can also lead to a cover fading.
●Rear-facing installation of this seat ONLY.
●Do not place the seat near edges of high, uneven or soft-surface
places. The seat may fall from there and your baby may get hurt.
●Do not use the product in seating positions where an active frontal
airbag is installed.
●Do not use any load bearing contact points other than those
described in the instructions and marked in the child restraint.
3.Vehicle related notes
●Use 2-point car belt to fix your baby safety seat may lead to
severe injury or death to your child if crash happened.
●By placing the bay car seat on it, abrasive marks might be found on
car seats made of sensitive materials such as silk and leather .
●Do not use this seat on side-facing or rear-facing car seats ( 1a
1b in drawing below). Only applicable for front-facing car seats.
Crash statistic shows that children are safer in back row seats.
Page 5
4.Assembly indicator
shoulder strap slot
buckle
belt route guider
seat cushion
canopy
handle
adjuster strap
crotch strap
shoulder strap
handle adjustment button
central adjuster
BC100B User Instruction
0706
BIUCO Car Seat
? optional：Only applicable for seat with no airbags（1d）.
?? optional：Only applicable for seats with adult 3-point safety belt (1d).
●Make sure the baby car seat is not stuck by foldable or movable
seat and door.
●Put the car belt into lowest position if its height is adjustable.
●Always fix this seat even if no baby inside. Unfastened baby safety
seat may injure the passengers on board. Check other objects like
luggage or books due to simillar reason.
●The belt must be certificated by ECE R16/GB14166 or
equivelant(please check the label with letter“ e” or“ CCC” on seat
belts).
●Do not let the child adjust or play with this seat. Check the belt
fasten status every time when using this seat.
●Do not use the same car belt together with your child.
Page 6
B
2
D
1
5.Baby safety seat user guide
5.1 Handle adjustment
Level description（ Figure 1 ）：
A.Balance position⸺balance the seat
on the ground.
B.Cradle position⸺function as a cradle.
C.Carrier position⸺installation in cars
or function as a baby carrier.
Level adjustment：
●Push the handle adjustment button
on both sides ( Figure 2 D ) at the
same time.Then rotate the handle
towards the wanted position.Release
the button when near the ideal
position,adjust the handle slightly until
you hear the click.
45°
3
E
5.2 Seat cushion
●The Seat cushion support and
protect your baby’s head and back.
The waist cushion ( Figure 3 E behind
the head and back cushion ) can
reduce the pressure on baby’s waist
( After your baby grows up, the
cushions can be removed to provide
more inner space ).
5.3 Canopy and canopy bracketCanopy
The canopy is for preventing
direct sunshine to your baby’s face.
The use of canopy is optional.
1）When not using the canopy, simply
press the buttons in D on both sides, then
turn the handle from position C to position
B or A and fold the cloth well( Figure 4 ).
2）When using the canopy: 1. When the
handle is in cradle position, simply press
the buttons in D (figure 4) on both sides
and turn the handle from position B to C;
2. When the handle is in balance position,
press the buttons in D on both sides and
turn the handle from position A to C. If
the handle were stuck when passing
position B, slightly pull it up( Figure 5 ).
BC100B User Instruction
0908
BIUCO Car Seat
4
B
D
5
B
C
Page 7
2）Belt position standard:
●Keep the shoulder strap even or a
little bit lower than your baby’s
shoulder ( Figure 9 ）.
3）Y-shaped belt removement：
●loosen the straps as long as
possible.
●remove shoudler straps from the
metal splitter plate ( Figure 8 ).
●pull the shoulder straps from the
shoulder belt slots ( Figure 10 ).
9
4）Y-shaped belt installation：
●Pull the shoulder straps out of the
slots and reconnect with the metal
splitter plate ( Figure 11 ).
Note：Make sure both shoulder straps can
go through the slots fully and no belt
should be twisted。
11
10
Position adjustment
1）Position adjustment
●As your baby grows up, the shoulder
straps can be removed from the metal
splitter plate G ( on the bottom side of
this seat ) and relocated from slot J to
slot F ( Figure 8 ).
8
J
H
G
5.4 Baby fixation and notes
5.4.1 Y-shaped belt adjustment
Length adjustment
●Release---push and hold the central
adjuster button( Figure 6 E ) , then lift
up the shoulder straps ( Figure 6 F ).
Note：Do bot pull the shoulder pad.
●Fasten---pull the adjuster strap
( Figure 7 ).
BC100B User Instruction
1110
BIUCO Car Seat
shoulder strap
6
E
F
7
Page 8
●To lock the straps, place the two
buckle tongues together properly,
then plug it into the buckle slot. A“
click”sound can be heard as a sign of
locked（ Figure 14 ）.
Note：the proper loaction of the buckle
is near your baby’s crotch not his/her
belly.
●Pull the adjuster strap through the
arrow direction ( Figure 15 ) to fasten
the Y-shaped belt. The proper tightness
is a two-finger space between the
shoudler strap and your baby’s chest.
5.5 Installation in vehicle
1）Switch the seat handle to “carrier
position”,then place this seat onto the
back row car seat near the vertical
cushion. The seat should be opposite
to the driving direction ( Figure 16 ).
15
16
2）Baby fixation
●Put your baby into the baby safety
seat,then put shoulder strap onto
baby’s shoulder gentely ( Figure 13 ).
Note：Do not twist or cross the shoulder
straps.
5.4.2 Baby fixation
1）Release the Y-shaped belt
●Place the seat on an even
surface,then adjust the handle to the“
balance position” （Page 8 Figure 1，
handle in position A）.
●loosen the shoulder strap as long
as possible ( Page 10 Figure 6 ).
●Push the red button on buckle to
release the belts.
●Put aside the buckle tongues
seperately ( Figure 12 ).
12
13
BC100B User Instruction
1312
BIUCO Car Seat
14
1
3
2
Page 9
4）Fasten the car belt (Figure 19)
●push the baby seat to the car seat.
●pull the lap belt horizontally to
fasten it.
●Pull the upper shoulder belt to
fasten the rest parts and the whole
car belt.
Note：Make sure the baby safety seat is
fixed well.
19
3）Drag the shoulder belt over the
baby seat.put the shoulder belt into
the blue belt route guider (Figure 18
K ).
Note：No twisting or slipping of the car
belts.
2）Pull out the car belt as long as
poosible. Place the lap belt over this
seat and lock the car belt. Then put the
lap belt into the belt route guider
(Figure 17).
Note：No twisting or slipping of the car
belts.
BC100B User Instruction
1514
BIUCO Car Seat
17
18
K
shoulder belt
waist belt
K
5.6 Check the belt and make sure its route
goes on correctly
●Do not place your baby car seat too close to the car seat belt buckles
( Figure 20,21 ).
20 21
Page 10
6.Maintainance
6.1 Attention
●Accidents happened when the car speed higher than
10km/h,may cause invisible damage to the baby safety
seat.Please change your baby safety seat after crash accident.
●Check all important parts regularly, make sure all mechanism
functions properly.
●To avoid damage, make sure no part of this baby seat is stuck by
car door , foldable car seat or any other objects.
●Do not lubricate any part with lubricants.
●Store your baby car seat in safe place if not use. Avoid heavy
objects, direct sunshine or direct heat on it.
●The cover can be removed. Clean the cover in warm water ( lower
than 30 ℃ ) with mild detergent, dry naturally. No drying.
●Plastic parts can be cleaned with soap water. Do not use strong
detergent ( for example, dissolvant ).
●straps and tethers can be cleaned in soap water.
●Shoulder pad can be removed and cleaned in soap water.
6.2 Cover cleaning
Baby safety seat must not be used without cover.
BC100B User Instruction
1716
BIUCO Car Seat
6.3 Remove the canopy and cover
Remove the canopy
●
The non-removable canopy bracket
is used for storing the canopy. To
remove or install the canopy, the
bracket can be pulled out for a short
dictance ( Figure 22 L ).
22
L
pull this way
●
Release the two snap fasteners on
top of the canopy ( Figure 23 M ).
snap
M
23
Page 11
●lift up the canopy ( Figure 25 ) cloth
along the top gap ( Page 17 Figure
22 ). Pull out the canopy from the
seat.
25
clamp slot
●Switch the handle to position C ( Page
8 Figure 1 ) . Find the clamp slot,
release the canopy along the arrow’s
direction ( Figure 24 N ).
N
24
BC100B User Instruction
1918
BIUCO Car Seat
Remove cover：
●Push the red button on the buckle to
release the straps ( Figure 26 ).
26
●Remove the seat cushion ( Figure
28 ).
●Remove the shoulder pad ( Figure
27 ).
27
28
Page 12
32
●lift up the cover （ arrow deriction ）
to remove the cover from the central
adjuster completely ( Figure 32 ).
31
●Pull out the cover from both
sides.Hold the seat with one hand,
and pull the cover according to the
arrow’s direcction until you see a
small gap between the central
adjuster and the cover ( Figure 31 ).
●Drag the bolt Q out of the slot R,and
then lift up the cover （ arrow deriction ）
to remove it ( Figure 33 ).
33
R
Q
BC100B User Instruction
2120
BIUCO Car Seat
●Switch the handle to position C ( Page
8 Figure 1 ) . Find the clamp slot, release
the cover along the arrow’s direction
( Figure 29 ).
29
●Pull down the cover along the
arrow’s deriction ( O ). Release the
cover hook ( Figure 30 ).
Note：For safety reason,frequent removement
is not recommended.
elastic band
30
O
P
O
Page 13
6.4 Installation of canopy and cover
35
Cover installation：
●Put the cover onto the shell. Let the
crotch strap passes through the crotch
pad ( Figure 34 ).
●Let the shoulder straps pass through
corresponding shoulder pad ( Figure
35 ).
●Hold the seat with one hand. Push
the cover into the small gap under
the central adjuster with the other
hand. Then make the cover tidy and
even ( Figure 36 ).
34
36
Press
●Hold the seat back side with one
hand, draw and fix the cover to the
edge of seat ( Figure 37 ).
37
38
●Take similar action from the other
side, and push the bracker pin into
slot to fix the cover ( Figure 38 ).
39
●Set the handle to position A ( Page 8
Figure 1 ), put pins into corresponding
slot on both sides ( Figure 39 ).
BC100B User Instruction
2322
BIUCO Car Seat
Page 14
8.Warranty condition
The warranty covers manufacturing defects in material or
workmanship for a period of one (1) years from the date of original
purchase. Keep the warranty card and other sales documents during
the warranty period.
Once quality problem is found,please send back the product
with warranty card.The return product must be kept tidy. The quality
problem is restricted to product defects.
Exclusive：
●Natural phenomenon or demage s caused by overload.
●Damages caused by incorrect or improper use.
●Damages caused by traffic accidents.
Inclusive：
Fabric：except fabric clor fading due to the ultraviolet radiation.
Buckle：except glitches result from dust and dirt.
Once quality problem is found, please contact the local retailer
directly.When making a claim, the depreciation rate will be taken into
account
●Draw and fix the canopy to the
handle with two snap fasteners ( Figure
43 ).
43
●After whole canopy is sliped into the
bracket, then fix the elastic band into
clamp slot ( Figure 42 ).
42
Canopy installation
●
Fix the canopy onto the seat and put
it into the space between bracket and
seat ( Figure 41 ).
41
●Set the handle to position C ( Page 8
Figure 1 ), draw the elastic band and
fix it onto corresponding hook on both
sides of the seat ( Figure 40 ).
40
BC100B User Instruction
2524
BIUCO Car Seat
Loading...
