Bitatek IT7000PDT User Manual

3.2.3.3 China Postage

□ Enable

□ Length

□ Fixed Length

□ Check Digit

Verify

□ Checksum
Default

Enable China Postage
Disable China Postage

Min Length can be set from 2 to 80
Max Length can be set from 2 to 80

Fixed Length 1 2-80
Fixed Length 2 2-80
Fixed Length 3 2-80

Check Digit transmit
Check Digit doesn’t transmit

Enabled
Disabled
Tap the “Default” tab to return back to
default setting

P3-9

3.2.3.4 Code93

Code93 is a variable length, continuous
symbology that uses four element
widths.

□ Enable

□ Concatenation

Default

Enable Code93
Disable Code93
Enable Concatenation
Disable Concatenation
Tap the “Default” tab to return back to
default setting

P3-10

3.2.3.5 Matrix 2 of 5

□ Enable

□ Length

□ Fixed Length

□ Check Digit

Verify

□ Checksum
Default

Enable Matrix 2 of 5
Disable Matrix 2 of 5

Min Length can be set from 2 to 80
Max Length can be set from 2 to 80

Fixed Length 1 2-80
Fixed Length 2 2-80
Fixed Length 3 2-80

Check Digit transmit
Check Digit doesn’t transmit

Enabled
Disabled
Tap the “Default” tab to return back to
default setting

P3-11

3.2.3.6 IATA

□ Enable

Default

Enable IATA
Disable IATA
Tap the “Default” tab to return back to
default setting

P3-12

3.2.3.7 Code128

□ Enable

Default

Enable Code128
Disable Code128
Tap the “Default” tab to return back to
default setting

P3-13

3.2.3.7 Code11

□ Enable

□ Check Digit

Default

Enable Code11
Disable Code11
Check Digit Transmit
Check digit verification can select “ 1
Digit” or “2 Digits”
Check Digit doesn’t transmit
Tap the “Default” tab to return back to
default setting

P3-14

3.2.3.8 MSI/PLESSEY

□ Enable

□ Check Digit

Check Mode

Default

Enable MSI/PLESSEY
Disable MSI/PLESSEY
Check Digit transmit
Check digit verification can select “ 1
Digit” or “2 Digits”
Check Digit doesn’t transmit
One of “Mode10”, “Mode10-10” and
“Mode11-10” can be selected from the
pull-down list.
Tap the “Default” tab to return back to
default setting

P3-15

3.2.3.9 UPC-A

□ Enable

Format

Check Digit

Default

Enable UPC-A
Disable UPC-A
Only one of the “Without Truncation”,
“Truncate Leading Zero”, “Truncate

Leading Digit” and “Truncate Leading
Zero and Digit” can be selected from the

pull-down list.
Check Digit transmit
Check Digit doesn’t transmit
Tap the “Default” tab to return back to
default setting

P3-16

3.2.3.10 EAN-13

□ Enable

Format

Check Digit

Default

Enable EAN-13
Disable EAN-13
Only one of the “Without Truncation”,
“Truncate Leading Zero”, “Truncate

Leading Digit” and “Truncate Leading
Zero and Digit” can be selected from the

pull-down list.
Check Digit transmit
Check Digit doesn’t transmit
Tap the “Default” tab to return back to
default setting

P3-17

3.2.3.11 UPC-E/UCC EAN-128

□ Enable

Format

Check Digit

Enable UCC EAN-128

Enable UPC-E
Convert to UPC-A
Default

Enable UPC-E/UCC EAN-128
Disable UPC-E/UCC EAN-128
Only one of the “Without Truncation”
and “Truncate Leading Zero” can be
selected from the pull-down list.
Check Digit transmit
Check Digit doesn’t transmit
Enable UCC EAN-128
Disable UCC EAN-128
Enable UPC-E Convert to UPC-A
Disable UPC-E Convert to UPC-A
Tap the “Default” tab to return back to
default setting

P3-18

3.2.3.12 Interleaved 2 of 5

□ Enable

□ Length

□ Fixed Length

□ Check Digit

Verify

□ Checksum
Default

Enable Interleaved 2 of 5
Disable Interleaved 2 of 5

Min Length can be set from 2 to 96
Max Length can be set from 2 to 96

Fixed Length 1 2-96
Fixed Length 2 2-96
Fixed Length 3 2-96

Check Digit transmit
Check Digit doesn’t transmit
Enabled
Disabled
Tap the “Default” tab to return back to
default setting

P3-19

3.2.3.13 Codabar/NW7

□ Enable

□ Start/Stop

□ Checksum

Verify

□ Checksum
Default

Enable Codabar/NW7
Disable Codabar/NW7

Start/Stop transmit
Start/Stop doesn’t transmit

?????

Checksum transmit
Checksum doesn’t transmit
Enabled
Disabled
Tap the “Default” tab to return back to
default setting

P3-20

3.2.3.14 EAN-8/JAN-8

□ Enable

Format

□ Check Digit

Verify

□ Checksum
□ Enable EAN-8

Convert to EAN-13
Transmit 5 zeros

Default

Enable EAN-8/JAN-8
Disable EAN-8/JAN-8
Only one format of “Without

Truncation” and “Truncate Leading
Zero” can be selected from the pull-down

list.
Check Digit transmit
Check Digit doesn’t transmit
Enabled
Disabled
Enable EAN-8 Convert to EAN-13
Disable EAN-8 Convert to EAN-13
One kind of “Before BarCode” and
“After 3 Digits” is selected from the
pull-down list.
Tap the “Default” tab to return back to
default setting

P3-21

3.2.3.15 Code4

□ Enable

Default

Enable Code4
Disable Code4
Tap the “Default” tab to return back to
default setting

P3-22

3.2.3.16 ISBN

□ Enable

Default

Enable ISBN
Disable ISBN
Tap the “Default” tab to return back to
default setting

P3-23

3.2.3.17 Korea Code 3 of 5

□ Enable

Default

Enable Korea Code 3 of 5
Disable Korea Code 3 of 5
Tap the “Default” tab to return back to
default setting

P3-24

3.2.3.18 GTIN

□ Enable

Default

Enable GTIN
Disable GTIN
Tap the “Default” tab to return back to
default setting

P3-25

3.2.3.19 UOC-EAN Add on 2/5

□ Enable

Default

Enable UPC-EAN Add on 2/5
Disable UPC-EAN Add on 2/5
Tap the “Default” tab to return back to
default setting

P3-26

3.2.4 Brightness

Table 3-3 Brightness

ICON ITEM & FUNCTION

Brightness

 “Brightness Control” Applet ( Figure 3-4-1) :

 Control the LCD brightness and KEYPAD Brightness
 Tap the “LCD brightness” Tab, and then tune the LCD

brightness by tapping right-arrow & left-arrow. Can also tune
the LCD brightness by pressing right-direction key or
left-direction key.

 Tap the “KEYPAD Brightness” Tab, and then tune the Keypad

brightness by tapping right-arrow & left-arrow. Can also tune
the Keypad brightness by pressing right-direction key or
left-direction key.

 “Backlight Timeout” Applet( Figure 3-4-2~ Figure 3-4-5):

 Select one power source from the pull-down list, “ AC power” &

“Battery” of Power Scheme.

 Select the timeout duration from another pull-down list of “Turn off

backlight after” Tab.
< Never, 15 seconds, 30 seconds, 1 minutes, 2 minutes, 5 minutes>

 The Backlight will be turned off after the selected timeout value
 □ Dim backlight after 20 seconds of idleness

ITEM Function

The brightness of backlight keep the same brightness even
though system is already idle.
The brightness of backlight will change to a little dark during
system idle situation after 20 seconds when the system isn’t
running any action.

P3-27

Figure 3-4-1 Figure 3-4-2

Figure 3-4-3 Figure 3-4-4

P3-28

Figure 3-4-5

3.2.5 Certificates

Certificates are used by some applications for establishing trust and for secure

communications.
Certificates are signed and issued by certificate authorities and are valid for a
prescribed period of time. Windows CE manages multiple certificate stores.

Table 3-4 Certificates(A)

ICON

Certificates

ITEM & FUNCTION

 “Store” Tab ( Figure 3-5-1) :
 In the Stores tab, select the certificate store you wish to view or

modify from the drop-down list (Figure 3-5-2).



The “T rusted Authorities “store lists the top-level certificates
for authorities you trust.( Figure 3-5-2 , Figure 3-5-3)



The “My Certificates “store contains your personal certificates,
which you use to identify yourself.



Intermediate certificate authorities that help establish a chain of
trust are stored in the “Other Authorities” store.

P3-29

Table 3-4 Certificates(B)

ICON ITEM & FUNCTION

Certificates

 “Store” Tab :
 To add a certificate or associated private key to the selected

store, select “Import” (Figure 3-5-4).



To view more details of the selected certificate, such as the
expanded name or expiration date, choose “View”.



To delete the selected certificate from the store, choose
“Remove”.

Figure 3-5-1 Figure 3-5-2

P3-30

Figure 3-5-3 Figure 3-5-4

Figure 3-5-5

P3-31

3.2.6 CPU Speed

Table 3-5 CPU Speed

ICON ITEM & FUNCTION

CPU Speed

 “CPU Speed” Tab :( Figure 3-6)
 Provide the information of current CPU Speed.



To change the CPU Speed , select the desired CPU speed you
want.

< 100 MHz, 200MHz, 300MHz, 400MHz >

Figure 3-6

P3-32

3.2.7 Date/Time

Table 3-6 Date/Time

ICON ITEM & FUNCTION

Date/Time

 “Date/Time” Tab :( Figure 3-6)
 Please see the detail information of 2.5.1 Setting Time and

Date on P2-22

3.2.8 Dialing Properties

Table 3-7 Dialing properties(A)

ICON ITEM & FUNCTION

Dialing
Properties

 “Dialing Properties” Tab :( Figure 3-7-1)
 In the When dialing from list, select the “Location” where you

want to change settings.(Figure 3-7-2)



To create a new location, select “New”. Enter the name of the
location, and then select “OK”.(Figure 3-7-3)



Enter or edit the area code and local country code as needed.
In Dial using, select “Tone dialing” or “Pulse dialing”. Most



phone lines are tone.



To automatically disable call waiting, select “□ Disable call

waiting by dialing＂, select the appropriate number sequence in the
list, or enter a new sequence.

 Editing dialing patterns (Figure 3-7-4)

Using the codes listed in the topic, revise the dialing patterns as



needed.

Notes:

 If you need to use character other than the ones listed here,

use manual dialing.



Hyphens and spaces in dialing strings are ignored.



Some modems may not respond to the following characters,
even though your device lets you add them to the dial
string.

P3-33

Figure 3-7-1 Figure 3-7-2

Figure 3-7-3 Figure 3-7-4

P3-34

3.2.9 Display Properties

Table 3-8 Display properties(A)

ICON ITEM & FUNCTION

Display

 “Background” Tab :( Figure 3-8-1)
 From the “Image” list, select an image you want as the

background of the desktop.(Figure 3-8-2)



To locate an image in another folder, select “Browse”.(Figure
3-8-3)



To have the image cover the entire background, select “ □Tile
image on background”

 “Appearance” Tab(Figure 3-8-4)
 Change the color scheme :( Figure 3-8-5)



From the” Scheme” list, select a scheme.



View your choice in the preview box. If you like the
scheme, select “Apply”.



Create a custom color scheme:

From the “Item” list, select a display item.





From the “Basic colors” list, select a color, and select
“OK”.



View your color selection(s) in the Preview box.
To save the scheme, select “Save”.





In the “Save this color scheme as” box, enter a name
for the scheme, and select “OK”.



Select “Apply”.

P3-35

Figure 3-8-1 Figure 3-8-2

Figure 3-8-3 Figure 3-8-4

P3-36

3.2.10 Fkey Settings

Figure 3-8-5

Table 3-9 FKey (A)

ICON ITEM & FUNCTION

 “Hot keys” Tab :( Figure 3-9-1)

FKey
Setting

 Assign your hot keys to wakeup system after it goes into sleep

mode.
To select which key(s) that can wakeup system, then, tap “OK”.



< F1 key, F2 key, F3 key, F4 key and Scanner Buttons>

 “AP Settings” Tab(Figure 3-9-2)
 To assign your favorite application program to F1,F2,F3 and F4 hot

keys.
Choose one of F1, F2, F3 and F4 from pull-down list.(Figure



3-9-3)



To tap “ Open” inside “Assign program” applet.



Select one application program you want from program list, Then,
choose “OK”. (Figure 3-9-4)



To tap Default tab to return back to default setting. (Figure 3-9-2)

P3-37

Table 3-9 FKey (B)

ICON ITEM & FUNCTION

 “AP Settings” Tab(Figure 3-9-2)

FKey

 The default setting for F1~F4:

Setting

F Key Name of Application Program
F1 Internet Explorer
F2 WordPad
F3 Inbox
F4 My Computer

Figure 3-9-1 Figure 3-9-2

P3-38

Figure 3-9-3 Figure 3-9-4

3.2.11 Information

Table 3-10 Information

ICON ITEM & FUNCTION

 “Information” Tab :

Information

 Provide hardware version, Software version, ROM size, RAM

size, Serial No. and Configuration No.

3.2.12 Input Panel

Table 3-11 Display properties(A)
ICON

Input Panel

ITEM & FUNCTION

 “Input panel” Tab :( Figure 3-10-1)
 Select the input method you want to change.

To change the Soft Keyboard Options , tap “Option” (Figure



3-10-2)

.

P3-39

Table 3-11 Display properties(B)

ICON ITEM & FUNCTION

Input Panel

 “Input panel” Tab :
 Change the soft keyboard options as desired, selecting from:



Large or small keys



Using gestures for space, black-space shift, and enter.

To exit the soft keyboard Options, press “OK” on the control



bar, or press the <Enter> key on the keypad.



To exit the Input Panel, press “OK” on the control bar, or press
the <Enter> key on the keypad.

.

Figure 3-10-1 Figure 3-10-2

3.2.13 Internet Options

Table 3-12 Internet Options(A)

ICON ITEM & FUNCTION

Internet
Settings

 “General” Tab :( Figure 3-11-1)
 Type in the URL of desired start page and the desired search

engine. You also change the Cache Size, clear the Cache and
Clear the History..

P3-40

Table 3-12 Internet Options(B)

ICON ITEM & FUNCTION

Internet
Settings

 “Connection” Tab :( Figure 3-11-2)
 Modify the network access setting as desired.

 “Security” Tab (Figure 3-11-3)

 Modify the security settings as desired. You can enable any of

the following by tapping the checkbox:



Allow cookies



Allow TLS 1.0 security



Allow SSL 2.0 security



Allow SSL 3.0 security

 Warm when switching across secure and insecure areas.

 “Advanced” Tab (Figure 3-11-4)

 Modify the security settings as desired. You can enable any of

the following by tapping the checkbox:



Display Image in pages



Play sounds in pages



Enable scripting



Display a notification about every script error



Underline links-

○

Never

○ Always
○ Hover

P3-41

Figure 3-11-1 Figure 3-11-2

Figure 3-11-3 Figure 3-11-4

P3-42

3.2.14 Keyboard

Table 3-13 Keyboard(A)

ICON ITEM & FUNCTION

Keyboard

 “Repeat” Tab :( Figure 3-12)
 To change the amount of time between depressions before

repetition starts, adjust the Repeat delay slider



To change the repeat rate, adjust the Repeat rate slider.



Test your new setting.
Tap “ OK” to exit the “Keyboard” Tab.



Figure 3-12

P3-43

3.2.15 Mouse

Table 3-14 Mouse(A)

ICON ITEM & FUNCTION

Mouse

 “Double-Click” Tab :( Figure 3-13-1,Figure 3-13-2)
 Double-click the checkerboard grid at comfortable speed



Double-click the Test icon to test your setting.



The function is OK if the figures are changed from Figure
3-13-1 to Figure 3-13-2.
To tap “OK” to exit the Mouse tab.



Figure 3-13-1 Figure 3-13-2

P3-44

3.2.16 Network and Dial-up Connections

Table 3-15(A) Network and Dial-up Connections

ICON ITEM & FUNCTION

Network
and Dial-up
Connections

 “Connection” Tab :

 To create a “Dial-up Connection”:



Double-tap the “Make New connection”.



In the “Make New Connection” dialog box, enter a name for
the connection.
Select “Dial-Up Connection”.





Select the “Next” button.



Select the modem you want use.
Select “Configure”





Under “Connection Reference”, use the default settings
provided. If you can’t connect using these settings, see your
ISP or network administrator for specific information. If you
want to always enter a phone number before connecting,
Select “Manual Dial”. Select “OK”.



Select “TCP/IP Settings”. In the “General” tab, ensure “Use
Server-assigned IP address” is selected. In the “Name
Servers” tab, ensure “Use Server-assigned addresses” is

selected, and select “OK”. If you are unable to connect with
these default settings, see your ISP or network administrator
for specific TCP/IP information.
Select the “Next” button and type the telephone number.





Select the “Finish” button.
The connection you just created appears as an icon in the “Network
and Dial-up Connections” folder.



Set up a point-to-Point Protocol(PPP) account with an ISP and
obtain the following information:



Access telephone number



User name



Password

P3-45

Table 3-15(A) Network and Dial-up Connections

ICON ITEM & FUNCTION

Network
and Dial-up
Connections

Once you have established an account, create a new connection on
your device. When creating this connection, you should be able to use
all of the default TCP/IP settings provided in the Make New
Connection Wizard. If you can’t connect using the default settings,
contact your ISP or access your ISP’s Web site for specific TCP/IP
information as well as primary and secondary DNS address.

 Modify connection setting



Select Start > Settings > Network and Dialup Connections



Select the icon for connection settings you want to modify.

Select File > Properties, or double- tap the appropriate icon.





Select desired options. There may be additional settings that

depend on the connection. To modify, select the icon and

select the icon and select Advanced Settings… from the

menu.

P3-46

P3-47

P3-48

P3-49

3.2.17 Owner

Table 3-16 Owner

ICON ITEM & FUNCTION

Owner

 “Identification” Tab : (Figure 3-15-1)
 Fill in or edit the data as desired.



To have this information displayed when you start your device,
select “Display Owner Identification” at Power On.



To set up identification for remote networks, see Setting up
identification for remote networks.

 “Network ID” Tab: (Figure 3-15-2)
 Enter the user name, password, and domain name you use to log

on to remote network.

Figure 3-15-1 Figure 3-15-2

P3-50

3.2.18 Password

Table 3-17 Password

ICON ITEM & FUNCTION

Password

 “Password Setting” Tab : (Figure 3-16)
 Enter the password

In the “Confirm password “box, enter the password again.





To require the password on startup, select “Enable password
protection at power- on“. and/or select “Enable password
protection for screen saver”



To exit the Password control panel, press “OK” from the
control bar, or press the <Enter> key on the keypad.

Figure 3-16

P3-51

3.2.19 PC Connection

Table 3-18 PC Connection

ICON ITEM & FUNCTION

PC
Connection

 “PC Connection” Tab : (Figure 3-17-1)
 Select the first checkbox to enable direct connections to the

desktop computer. (Figure 3-17-1)



Tap the “Change Connection…” button to modify the
connection method from USB, IrDA, or Serial. (Figure 3-17-2)



To exit the “Change Connection” dialog, press “OK” from the
control bar, or press the <Enter> key on the keypad.



To exit the “PC Connection” properties control panel, press
“OK” from the control bar, or press the <Enter> key on the
keypad.

Figure 3-17-1 Figure 3-17-2

P3-52

3.2.20 Power

Table 3-19 Power

ICON ITEM & FUNCTION

Power

 “Battery” Tab : (Figure 3-18-1)
 Provide change level indicators for Main battery and Backup

battery.



To exit Battery control panel, press “OK” from the command
bar, or press <Enter> key on keypad.

 “ Schemes” Tab: (Figure 3-18-2)
 The Scheme Tab allows you to determine the time to switch

state to Suspend mode when using either Battery Power or AC
Power.



Select Battery Power or AC Power as the power scheme from
the pull-down list.( Figure 3-18-2)

 Select the time to suspend mode from the pull-down list.

( Figure 3-18-3)

 “Device Status” Tab: ( Figure 3-18-4)

Provide power level of device – The power level ranges from
“ High(D0)” which means the device is at the highest power level to
“Off(D4)” which means the device is at the lowest power level.

Figure 3-18-1 Figure 3-18-2

P3-53

Figure 3-18-3 Figure 3-18-4

3.2.21 Regional Settings

Table 3-20 Regional Settings

ICON ITEM & FUNCTION

Regional
Settings

 “Region” Tab : (Figure 3-19-1)
 Select the desired location/language.

Review the Appearance samples in the bottom half of the



screen.



Select the Tab at the top for any settings you wish to change,
Options to modify include Number, Currency, Time, and Date.
( Figure 3-19-3 ~ Figure 3-19-9)

P3-54

Figure 3-19-1 Figure 3-19-2

Figure 3-19-3 Figure 3-19-4

P3-55

Figure 3-19-5 Figure 3-19-6

Figure 3-19-7 Figure 3-19-8

P3-56

Figure 3-19-9

3.2.22 Remove Programs

Table 3-21 Remove Programs

ICON ITEM & FUNCTION

Remove
Programs

 “Remove Programs” Tab :
 Only user installed programs can be removed.



Select the program you wish to remove from the list and press
“remove” button.

3.2.23 Storage Manager

Table 3-22 Storage Manager(A)

ICON ITEM & FUNCTION

 “Storage Manager” Tab : (Figure 3-20)

Storage
manager

 To change Storage properties control panel default settings:

Insert. Compact Flash(CF) or Secure digital (SD) storage card into

the unit.

 Select Start > Settings > Control Panel > Storage Properties

P3-57

Table 3-22 Storage Manager(B)

ICON ITEM & FUNCTION

 “Storage Manager” Tab : (Figure 3-20)
 From the “Storage Info” pull-down list, select the desired

Storage
manager

storage device.



You can also format, dismount, and create partitions on storage
devices using this control panel.
To save and exit the Storage Properties control panel, press



“OK” from the control bar, or press the <Enter> key on the
keypad.

Caution: Dismounting or formatting the DiskOnChip will

erase all files and program stored in Flash Memory

Figure 3-20

P3-58

3.2.24 Stylus

Table 3-23 Stylus(A)

ICON ITEM & FUNCTION

Stylus

 “Double-Tap” Tab : (Figure 3-21-1,Figure 3-21-2)
 Double-tap the checkerboard grip at a comfortable speed.



Double-tap clapboard to test your settings



The function is OK if the figures are changed from Figure
3-21-1 to Figure 3-21-2.
To tap “OK” to exit the Stylus Properties.



 “Calibration”: (Figure 3-21-3)
 In the Welcome Wizard, you tapped a target with the stylus to set

the amount of pressure needed for the screen to respond to your
stylus taps.



Please also see 2.4.3: Calibration of the touch Screen

Figure 3-21-1 Figure 3-21-2

P3-59

Figure 3-21-3

3.2.25 System

Table 3-24 System(A)

ICON ITEM & FUNCTION

System

 “General” Tab : (Figure 3-22-1)
 To show:



Firmware information



Information about Processor type, Memory size, Expansion
card

 “Memory”: (Figure 3-22-2)
 Move the slider to adjust memory allocation. Default storage

memory is normally is normally set to about 8MB with the
reminder assigned to Program memory.
Press the “OK” key on the Keypad.



Note: the difference is occupied by OS between the RAM size in
Information properties and total memory size of storage memory
and program memory

P3-60

Table 3-24 System(B)

ICON ITEM & FUNCTION

System

 “Device Name” Tab : (Figure 3-22-3)
 Your device uses this information to identify itself to other

computers.



The input panel will open to facilitate data entry.
To close the Device Name, press the “OK” button, or press the



<Enter> key on keypad.

 “Copyrights” Tab: (Figur e3-22-4)
 Refer to this tab for specific copyright data. As a user, you are

responsible to read this statement.

Figure 3-22-1 Figure 3-22-2

P3-61

Figure 3-22-3 Figure 3-22-4

3.2.26 Volume & Sounds Properties

Table 3-25 Volume & Sound

ICON ITEM & FUNCTION

Volume &
Sound

 “Volume” Tab : (Figure 3-23-1)
 The factory default for Volume is the forth level. You can adjust

the volume to your environment and comfort.

 Set the volume by adjusting the slider from Soft to Loud,

or press Right or Left edge of Navigation keys

 “Sounds ” Tab: (Figure3-23-2)
 Enable the desired sounds for key clicks, screen taps,

notifications, and applications.

P3-62

Figure 3-23-1 Figure 3-22-2

3.3 Taskbar and Start Menu

Table 3-26 Taskbar and Start menu

ICON ITEM & FUNCTION

Taskbar and
Start Menu

 “General” Tab :
 In this tab, You can change the position of the Taskbar and Start

menu

Is always on top or not





Auto hide or not



Show Clock or not

 “Advanced ” Tab:
 Tap the “Clear” button to remove the contents of the Documents

Menu.



Enable “□ Expand Control Panel＂ to list all icons of Control

Panel from top to bottom.

P3-63

Chapter 4

Communication

4.1 Installing & Setting Up Microsoft ActiveSync

4.1.1 Installing Microsoft ActiveSync on the Host PC

Microsoft ActiveSync is a file transfer tool to synchronize the files on a PC with the
files on your PDA.
To install Microsoft ActiveSync, complete the following steps on the PC:

1. Go to the Microsoft Windows CE.NET website and download the most current
version of ActiveSync:

http://www.microsoft.com/mobile/pockeypc/downloads/ .

2. Install the most version of Microsoft ActiveSync on the host PC.

3. Open ActiveSync.

4. Select File > Communication Settings from AtiveSync’s menu bar.

5. Go to “Using ActiveSync” on page X.X to continue using ActiveSync.

4.1.2 Connecting PDA to Host PC

1. You can use either the USB/Serial(RS232) port of Single Dock or a
USB/Serial(RS232) cable to connect the PDA to the Host PC.

 To use the dock, you must first insert the PDA into the slot, making sure that the

unit is firmly seated the dock.



To use the cable, connect the USB/Serial cable to the PDA.

2. Connect the USB/Serial dock or cable to the Host PC’s serial port or USB port.

3. Connect the dock or PDA to the power adapter and power source.

4.2 Using ActiveSync

Use ActiveSync to transfer and synchronize files between the PDA and the Host PC.

4.2.1 Setting up a Partnership

During the Microsoft ActiveSync installation, you were prompted to create a

P4-1

partnership with your mobile device. When you set up a partnership, you select
synchronization and file conversation settings, which are contained in a file on your
desktop computer. This file enables your desktop computer to recognize your device.
Only devices that have a partnership with a desktop computer can synchronize
information between the two computers.
For more information on partnerships, please refer to your Microsoft ActiveSync
documentation or help file.

Transferring Files:

To transfer files, complete the
following steps on the host PC:

 Select Start> Programs

>Communication >(IrDA,

Serial, or USB) Activesync.



Double-click on the selected
ActiveSync icon



After you have established a
connection with PDA, tap the
“Explore” button at the top of
the ActiveSync window ( or

 Navigate to the target directory on your PDA and copy the desired file by using

select Explore from the File
menu).

the Copy/paste method or dragging and dropping the desired file(s) into the
folder.

4.2.2 ActiveSync File Synchronization

ActiveSync files synchronization requires an ActiveSync partnership between the
PDA and the Host PC. Refer to “Setting up a Partnership”, above:



Select the files in the synchronization configuration for the PDA partnership.
Select Tools > Options from the ActiveSync command bar to configure the



synchronization options.
Place the file to be synchronized in the Synchronization folder created you’re



My Documents directory. Defaults to the desktop. During the ActiveSync
connection, all files in the Synchronization folder will be synchronized to the
\My Documents directory on the PDA.

P4-2

4.2 Networking

Please see the 3.2.17 Owner, Table 3-16 Owner on page 3-50 for setting up the
network ID. And see the 2.5.6 Initiating a Network Connection to setup the

802.11b Wireless LAN for RF connecting.

P4-3
