Biro 3334SS-4003 Specifications

SPECIFICATIONS

MODEL 3334SS-4003

ELECTRICAL 3 HP, (2.2 kW), 220 Volts, 60 Hz, 3 phase; 1 phase and 50 Hz optional (see table below)

ELECTRICAL Totally enclosed high humidity motor, watertight magnetic switch system with thermal COMPONENTS overload protection

CONSTRUCTION Heavy duty stainless steel base, legs, and tables with 25% larger front easy flow

moving carriage. Cast aluminum head and door structure.

DRIVE SYSTEM Double V belt and pulleys with tapered roller bearings on drive shaft

BLADE Hard tooth .022 inch (.5 mm) thick, 3 teeth per inch (8.5 mm between teeth),

5/8 inch (16 mm) wide, 124 inches (3150 mm) long

BLADE SPEED 4000 feet (1219 m) per minute

OPTIONS

CERTIFICATIONS USDA, UL, NSF, CSA

WEIGHT Uncrated 510 pounds (231 kg) approximate

(Extra cost) Cord and plug, double flange wheels, lower removable wheels, split rear platter,

stainless steel head

(No Charge)

Narrow blade guides (.018 inch/.46 mm), 5000 (1524m) and 6000 (1829m) feet per minute blade speed

Crated 575 pounds (261 kg) approximate

HP TYPE VOLTS AMPS CYCLE PH STATUS

3 TE 220/440 8.6/4.3 60 3 STD 3 TE 380/415 4.3 50 3 STD 3 TE 208/230 14.0 60 1 EC 3 TE 220 12.5 50 1 EC 3 TE 550 3.6 60 3 EC

THE BIRO MANUFACTURING COMPANY

MOTORS

1114 WEST MAIN STREET

MARBLEHEAD, OH 43440-2099 U.S.A.

Phone: (419) 798-4451

Fax: (419) 798-9106

http://www.birosaw.com

sales@birosaw.com

ITEM NO.: LIT 3334-4003-308

FORM NO.: Md 3334-4003-308-4-06-7-ENG-MARK

Service is available from over 245 locations worldwide
