bioscrypt VENC, VTENC, VNENC Installation Manual

V-ENC Enclosure Installation Guide

Veri-Series Outdoor Enclosure (Models VENC, VTENC, VNENC)

March 23, 2005

Page 1

Introduction

The Bioscrypt Veri-Series fingerprint readers are manufactured for indoor use, and if placed outdoors must be installed within a complete Bioscrypt certified enclosure to protect the reader against direct contact with the elements, including rain, sun, snow, or excessive moisture. Failure to place any reader installed outdoors within such an enclosure shall void the warranty on the fingerprint reader. The Veri-Series product line includes:

 V-Prox  V-Flex  V-Pass  V-Smart (MIFARE and iCLASS models)  V-Station (Base, Searching, Prox, MIFARE, and iCLASS models)

The V-ENC Enclosure Installation Guide provides you with general information on installing the new Bioscrypt Veri-Series Outdoor Enclosure. Please refer to the Veri- Series Installation Guide for further information on the installation of your Bioscrypt Veri-Series fingerprint reader. If there are any questions about information provided in this document please contact Bioscrypt Technical Support.

Page 2

Disclaimer

The instructions in this document have been carefully checked for accuracy and are presumed to be reliable. Bioscrypt, Inc. and its writers assume no responsibility for inaccuracies and reserve the right to modify and revise this document without notice.

It is always our goal at Bioscrypt, Inc. to supply accurate and reliable documentation. If you discover a discrepancy in this document, please e-mail your comments to

support@bioscrypt.com, or contact Bioscrypt Technical Support at the telephone

number listed below. Bioscrypt accepts no liability for the misuse of third-party hardware mentioned in this

document. In no case shall Bioscrypt be liable for damage to a reader resulting from the misuse of such hardware.

No part of this publication may be placed in a retrieval system, transmitted, or reproduced in any way, including, but not limited to, photograph, photocopy, computer disk or other record, without prior agreement and written permission from:

Bioscrypt Inc. 5805 Sepulveda Blvd., Suite 750 Van Nuys, CA 91411 Phone 818.304.7150 Toll Free 888.982.4643

http://www.bioscrypt.com

Page 3

Bioscrypt One Year Limited Warranty Policy

Bioscrypt warrants to the original consumer purchaser (“Customer”) that new Bioscrypt products will be free from defects in material and workmanship for one year from the date the product was shipped from Bioscrypt. For replacement products the warranty on the replacement unit is the remainder of the warranty on the original product or ninety (90) days, whichever is longer. The Customer is responsible for making any claims for shipment damage (evident or concealed) with the freight carrier. Bioscrypt must be notified within thirty days of shipment of incorr ect mate rials.

If a defect is discovered, Bioscrypt's sole obligation shall be to repair or replace the Bioscrypt product(s) at its sole discretion at no charge, provided it is returned to Bioscrypt during the warranty period and is shipped freight and insurance prepaid. Merchandise must be properly packaged to prevent damage during shipping. Before returning a Bioscrypt product, contact Bioscrypt Technical Support to obtain a Return Material Authorization (RMA) number. No product may be returned whether in warranty or out of warranty without first obtaining approval from Bioscrypt. The model number, invoice number, and serial number may be required for warranty service.

This warranty shall not apply to any product or any part of a product, which in the judgment of Bioscrypt, has been subjected to misuse, negligence, alteration, accident, improper maintenance, or damage by excessive physical or electrical stresses. Tampering, such as opening the housing of a biometric reader or replacing parts will void this warranty. The warranty is void if the serial number of the Bioscrypt product has been defaced, altered, or removed or if the product has been modified. Repair and replacement parts will be furnished on an exchange basis and may be either reconditioned or new. All replaced parts or products become the property of Bioscrypt. This warranty may also be voided for failure to comply with Bioscrypt’s return policy.

The warranty is not applicable to:

 Abnormal wear and tear  Damage caused during installation  Damage caused by the equipment or system with which the biometric reader is

used

 Damage caused by modification or repairs not made or authorized by Bioscrypt  Damage caused by improper packaging  Damage caused by lack of ESD protection  Merchandise that is determined to be stolen

Page 4

All Veri-Series units have an operating temperature range of 0°-60° Celsius (32°-140° Fahrenheit). In addition, the Veri-Series product line has a relative humidity operating range of 0-95% non-condensing. Any device used outside that temperature or humidity range requires an enclosure with thermal or humidity control that can maintain a consistent environment within the stated operating ranges.

The newest Bioscrypt Veri-Series products are designed to be weather resistant but no sensor technology exists today that can work in all weather environments. If a Bioscrypt Veri-Series product is not used in a completely indoor environment, then a protective enclosure is required to shield the unit from moisture, dust, other contaminants and temperatures outside stated operating range. Product failures resulting from exposure to these conditions are not covered under the product warranty.

For outdoor installations, Bioscrypt does offer an enclosure to protect the device from exposure to moisture, dust, other contaminants and temperatures outside stated operating range. When used properly, this enclosure will protect Veri-Series devices in most environments, but not all. The Customer is responsible for determining whether the offered enclosure will appropriately shield Veri-Series devices in their specific installation. Product failures resulting from exposure to moisture, dust, oth er contaminants and temperatures outside stated operating range, even if an enclosure is used, are not covered under the product warranty.

This warranty is exclusive and in lieu of all others, whether oral or written, expressed or implied. Bioscrypt specifically disclaims any and all implied warranties, including without limitation, warranties of merchantability and fitness for any particular purpose. No Bioscrypt dealer, agent, or employee is authorized to make any modification, extension or addition to this warranty.
