Biolight Meditech WT1 Users manual
WT1/WT2 Electronic Thermometer
User’s Manual
Guangdong Biolight Meditech Co., Ltd.
Product Information
Product Model: WT1/WT2
Product Name: Electronic Thermometer
Manufacturer Name: Guangdong Biolight Meditech Co.,Ltd.
After Service Contact Information:
Address: No.2 Innovation First Road, Technical Innovation Coast, Hi-tech
Zone, Zhuhai, P.R. China
Fax: +86-756-3399919
Post code: 519085
Toll-free consultation hot line: +86-400-8818-233
Revision History
This manual has a revision number. This revision number changes whenever the
manual is updated due to software or technical specification change. Contents of this
manual are subject to change without prior notice.
Document No.:
Revision number: V1.0
Release time: July, 2014
Copyright © 2014 Guangdong Biolight Meditech Co., Ltd. All rights reserved.
Statement
Manufacturer holds the copyright of this manual, and we are also entitled to deal
with this manual as confidential files. This manual is only used for operation,
maintenance and service of product, someone else can not publish the manual.
This manual contains exclusive information protected by copyright laws and we
reserve its copyright. Without written approval of manufacturer no parts of this
manual shall be photocopied, Xeroxed or translated into other languages.
The contents contained in this manual are subject to amendments without
notification.
1
Manufacturer's Responsibility
Only under the following circumstances will manufacturer be responsible for the
safety, reliability and performance of the instrument:
All the installation, expansion, readjustment, renovation or repairs are conducted
by the personnel certified by manufacturer.
The storage condition, operation condition and electrical status of the instrument
conform to the product specification.
The instrument is used in accordance with the user’s manual.
About this manual
This manual contains the instructions necessary to operate the product safely and
in accordance with its function and intended use. Observance of this manual is a
prerequisite for proper product performance and correct operation.
This manual is based on the maximum configuration and therefore some contents
may not apply to your product. If you have any question, please contact us.
This manual is an integral part of the product. It should always be kept close to the
equipment so that it can be obtained conveniently when needed.
Illustrations are for reference only. They may be not in conformity with your
products.
Signs in this manual：：：：
Warning: Indicates a potential hazard or unsafe practice that, if
not avoided, will result in death or serious injury.
Caution: Indicates a potential hazard or unsafe practice that, if not
avoided, could result in minor personal injury or product/property
damage.
Note: Provides application tips or other useful information to ensure that you
get the most from your product.
2
Contents
1. Intended Use ............................................................................................................................. 1
2. Application ................................................................................................................................ 1
3. Safety Information .................................................................................................................... 1
4. Appearance ............................................................................................................................... 3
5. Download And Install The Software ......................................................................................... 4
6. Battery Installation Steps .......................................................................................................... 4
7. Using Steps ............................................................................................................................... 5
8. Normal Body Temperature ........................................................................................................ 8
9. Maintenance and Cleaning ........................................................................................................ 9
10. Accessory and Specifications ................................................................................................ 9
11. Troubleshooting .................................................................................................................. 11
12. Equipment Symbols ............................................................................................................ 12
Appendix A Guidance and Manufacturer’s Declaration of EMC ................................................... 13
I
1. Intended Use
The device is intended to be used for measuring and monitoring human
temperature continuously via wireless signal transmission of the measuring result.
2. Application
The device is reusable and intended for measuring human temperature for
persons over two years old. It can be used in hospital and at home.
3. Safety Information
Warning：：：：
Any form of modification to this device is forbidden;
Don’t used the device together with MRI or CT equipment;
Explosion danger: don’t use the device in flammable anesthetic gas;
Don’t squeeze the device. If the housing is broken, please stop using the
device.
Caution：：：：
Please check device regularly to make sure that it contacts skin tightly;
otherwise the data may be inaccurate.
The device is for indoor use only;
Please pay attention to the operation temperature and humidity. Using the
device in a condition that does not satisfy the requirement may lead
measurement error;
The effective wireless transmission distance is 15m in a barrier-free
environment. If more than this distance, the product might not work. Please
use this product within effective wireless transmission distance;
Muscle and fat affect wireless transmission, so the transmission range would
be weaken when adult or obese child use the device.
Magnetic and electrical fields are capable of interfering with the proper
1
performance of the device. For this reason make sure that all external
equipments operated in the vicinity of the device comply with the relevant
EMC requirements. Mobile phone, X-ray equipment or MRI devices are a
possible source of interference as they may emit higher levels of
electromagnetic radiation.
Caution：：：：
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference;
(2) This device must accept any interference received, including interference
that may cause undesired operation.
The user is cautioned that changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to operate
the equipment
FCC STATEMENT:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
2
FCC RADIATION EXPOSURE STATEMENT:
2
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Note：：：：
The device is not sterile;
Doctor should make diagnosis on clinical manifestation and symptoms, only
with using the device as subsidiary;
This product has been calibrated. No other routine maintenance and
calibration is needed in addition to the replacement battery;
If the system upgrade, please update the program;
It is impossible that the application is incompatible with other application on
your receiver. Please contact us if you meet this kind of matters;
If you have questions concerning setting up, using, maintaining of the device
or any unexpected events, please contact manufacturer or its representatives.
When the patient is the operator, please use and maintain the device
according to this manual.
4. Appearance
WT1：：：：
Front View: Rear View:
WT2：：：：
Front View: Rear View:
3
