AYSU ARSLAN
General Information
Storage
Product is provided as an off-white solid in a prefilled cartridge of 3 ml. Solid Inx
should be stored at 4˚C. Protect it from light. Expiry date of the product is indicated
on the sealed pouch. The product can be stored for a maximum of 3 months after
opening and should be consumed before the expiry date.
Intended Use
Research use only. This product is not intended for use in diagnostic or therapeutic
procedures.
Safety Information
For more information, please refer to the material safety data sheet.
User Guidelines
Preparation
SOLID INX can be prepared according to the instructions below. The use of a
temperature controlled printhead with a metal nozzle heat conductor is required.
03
240105
1
Page 3
AYSU ARSLAN
Processing
Recommended printing parameters for two different nozzle sizes:
Nozzle size 22G 25G
Nozzle Geometry conical conical
Printhead temperature 60 ± 1 °C 60 ± 1 °C
Printbed temperature 12 ± 2 °C 12 ± 2 °C
Pressure 50 ± 10 kPa 80 ± 10 kPa
Infill speed 6 ± 1 mm/s 6 ± 1 mm/s
Layer height 0.18 ± 0.01 mm 0.14 ± 0.01 mm
Use of rectilinear infill pattern is recommended.
Photo-crosslinking: During printing, structure should be irradiated
with light (λ: 365 nm or 405 nm, Dose: 70 mJ/cm2) after every layer. This
step is required for partial crosslinking of the structure for a better shape
retention. After completion of printing, the final structure should be
placed under UV light for complete crosslinking.
(Recommended parameters for post-printing photo-crosslinking:
λ: 365 or 405 nm, Dose: 10000 mJ/cm2)
The printing parameters have been validated for printing a cube with
dimensions 15 x 15 mm (W x L) using 3 ml cartridges.
