Biogents CO2 Timer User Manual

Mosquito Control
Table of contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product components . . . . . . . . . . . . . . . . . . . 4
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Attaching to CO2 tubes . . . . . . . . . . . . . . . . . 14
Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
2
Introduction
The Biogents CO2 Timer lets you to control when CO2 is released by establis-
hing specic start and stop times. It enables you to set up two start and end
times for CO2 releases per day. The BG-CO2 timer is placed between the CO2 tank and the mosquito trap with CO2 connecting tubes.
3
Product components
The BG-CO2 Timer consists of a body with a display and buttons to set up the release times, two connections to the CO2 tubes and a 9V battery.
Connection to CO2 tube to CO2 source
Buttons to set up release times
Display
4
Connection to CO2 tube to trap
Battery
The 9V battery to run the timer is located in the back of the body and inclu­ded, but not connected. To run the timer remove the screws from the back of the body. Insert the battery and connect the connection plate to the battery. The timer is now switched on. Then replace the screws and tighten. The status of the battery is shown in the display. The battery should last at least 9 months.
5
Opened back of the body
6
Battery status
9V battery
Connection plate
Functions
A
5
4
4
Down Arrow indicates CO2 emission.
5
“A“ indicates that the timer function is switched o.
Button to increase time /
1
switch on CO2 permanently Button to decrease time /
2
switch o CO
Button to switch on display/
3
Set-up of time frames
permanently
2
7
Switch on / Set current time
Switch on the display by pressing button 3.
3
short
To start set-up of the current time press button 3 for two seconds.
To adjust the current time use button 1 to increase and but­ton 2 to decrease the time.
8
2 sec.
3
1
2
Start time 1
1
S1
Increase time
Decrease time
2
Start set-up of
3
start time 1
After setting up the current time press button 3. „S1“ (Start time 1) appears in the display.
Set the rst start time with buttons 1 and 2 as described
above.
3
2
1
9
End time 1
1
Increase time
2
Decrease time
E1
Start set-up of
3
end time 1
After setting up the rst start time press button 3. „E1“ (End
time 1) appears in the display.
Set the end time with buttons 1 and 2 as described above.
10
3
2
1
Start and end time 2
To set up a second start and end time, press button 3 after setting up the
rst end time. ”S2“ (Start time 2) appears in the display. Set the time with
buttons 1 and 2 as described before. To set the second end time press but-
ton 3. “E2“ will appear in the display. Set time with buttons 1 and 2. After
the second end time is entered, press button 3. Now the timer is running, shown by a „R“ in the display. NOTE: if a second start/end time cycle is not required, set both the second start and end time to one minute after the
end of the rst cycle above.
S2
E2
11
R
Option 1: Permanent CO
Switch on
1
CO2 permanently
2
A
To run the CO2 continuously and not use the timer, change the mode to “Always CO2“. Press button 1 for two seconds. With an audible click, “A“ will appear in the display along with a down arrow showing that CO2 is now emitted continuously.
To cancel the “Always CO2” mode, press button 1 again.
12
1
2 sec.
1
short
Option 2:
Switch o CO
Switch o CO
2
2
A
permanently
2
To switch o the CO2 permanently, press button 2 for two se-
conds. An “A“ without down arrow will appear in the display to show that CO2 ow is switched o permanently.
To switch back to the timer mode press button 2 again.
2
2 sec.
short
2
13
Attaching to CO2 tubes
Install the BG-CO2 timer between the CO2 source and the mosquito trap. The tube coming from the CO2 source should be attached to connection Attach the sinter plugs with the tube going to the trap to connection .
14
2
1
1
2
CO2 source
Mosquito trap
Sinter plugs
15
Inhaltsverzeichnis
Einführung . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Produktkomponenten . . . . . . . . . . . . . . . . . 18
Batterie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Funktionen . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Anschließen an CO2Schläuche . . . . . . . . . 28
Kontakt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
16
Einführung
Biogents CO2 Timer ermöglicht eine regulierte Abgabe von CO2 zu von Ih­nen bestimmten Zeiten, wobei Sie zwei verschiedene Zeitfenster pro Tag einstellen können. Der BG-CO2 Timer wird zwischen der CO2 Quelle und der
Mückenfalle mit CO2 Schläuchen angebracht.
17
Produktkomponenten
Der BG-CO2 Timer besteht aus einem Korpus mit Display, Knöpfen zum Einstel-
len der Zeitfenster, zwei Anschlüssen an CO2 Schläuche und eine 9V Batterie.
Anschluss an CO2 Schlauch zur CO2 Quelle
Knöpfe zum Einstellen der Zeitfenster
Display
18
Anschluss an CO2 Schlauch zur Mückenfalle
Batterie
Um den Timer zu betreiben, benötigen Sie eine 9V Batterie, die im Liefer­umfang enthalten, aber noch nicht angeschlossen ist. Um den Timer anzu-
schalten, entfernen Sie die Rückseite des Timers, indem Sie die Schrauben
lösen. Legen Sie die Batterie ein und verbinden sie dann die Batterie mit der Batterieverbindungsplatte. Der Timer ist nun eingeschaltet. Schrauben
Sie dann die Rückseite des Korpus wieder an. Der Batteriestatus wird im Display angezeigt. Die Batterie sollte für mind. 9 Monate reichen.
19
Geönete Rückseite des Timers
20
Batteriestatus
9V Batterie
Batterieverbindungsplatte
Funktionen
A
4
5
4
Pfeil nach unten zeigt an, dass CO2 abgegeben wird.
„A“ zeigt an, dass die Timer-Funktion ausgeschaltet ist.
5
Knopf zum Erhöhem der Uhrzeit /
1
für dauerhafte CO2 Abgabe
Knopf zum Verringern der Uhrzeit /
2
dauerhaft CO
Knopf zum Anschalten des Displays/
3
Einstellen der Zeitfenster
ausschalten
2
21
Display anschalten / Aktuelle Uhrzeit einstellen
Schalten Sie das Display ein, indem Sie Knopf 3 drücken.
3
kurz
Um die aktuelle Uhrzeit einzustellen, drücken Sie 2 Sekun­den lang Knopf 3.
Passen Sie die Zeit mit Knopf 1 und 2 an, wobei Knopf 1 die Uhrzeit erhöht und Knopf 2 die Uhrzeit verringert.
22
3
2 Sek.
1
2
Startzeit 1
1
S1
Erhöhen der Uhrzeit
Verringern der Uhrzeit
2
Einstellen der
3
Startzeit 1
Nach dem Einstellen der aktuellen Uhrzeit drücken Sie Knopf 3. Ein „S1“ für „Startzeit 1“ erscheint im Display.
Passen Sie die Startzeit 1 mit den Knöpfen 1 und 2 wie vor­her beschrieben an.
3
2
1
23
Endzeit 1
Erhöhen der Uhrzeit
1
Verringern der Uhrzeit
2
E1
Einstellen der
3
Endzeit 1
Nach dem Einstellen der ersten Startzeit drücken Sie Knopf
3. Ein „E1“ für „Endzeit 1“ erscheint im Display.
Passen Sie die Uhrzeit wie oben beschrieben mit den Knöp­fen 1 und 2 an.
24
3
2
1
Start- und Endzeit 2
Um eine zweite Start- und Endzeit einzustellen, drücken Sie, nachdem Sie die Endzeit 1 festgesetzt haben, Knopf 3. Ein „S2“ für Startzeit 2 erscheint
im Display. Stellen Sie die Uhrzeit wie zuvor beschrieben ein. Legen Sie die
zweite Endzeit fest, indem Sie Knopf 3 drücken und dann die Uhrzeit ein­stellen. Drücken Sie danach Knopf 3. Ein „R“ zeigt an, dass der Timer läuft. Wenn eine zweite Start/Endzeit nicht benötigt wird, stellen Sie Start- und Endzeit 2 beide auf 1 Minute nach Endzeit 1 ein.
S2
E2
25
R
Dauerhafte CO2Abgabe
Option 1: Dauerhaft CO
Um dauerhafte CO2 Abgabe einzustellen und die Timer­Funktion auszuschalten, drücken Sie Knopf 1 für 2 Sekun­den. Mit einem hörbaren „Klick“ erscheint ein „A“ und ein Pfeil im Display, die die dauerhafte Abgabe von CO2 anzei­gen. Um den „Always CO2“ Modus abzuschalten, drücken sie nochmals Knopf 1.
2
A
1
26
2 Sek.
1
kurz
1
Option 2: Ausschalten der CO2 Abgabe
Um die CO2 Abgabe dauerhaft auszuschalten, drücken Sie
Knopf 2 für 2 Sekunden. Ein „A“ ohne Pfeil im Display zeigt
an, dass das CO2 dauerhaft ausgeschaltet wurde.
A
Ausschalten der CO
2
Abgabe
2
2
2 Sek.
Um zurück in den Timer-Modus zu schalten, drücken Sie
nochmals Knopf 2.
2
kurz
27
Anschließen an CO2 Schläuche
Installieren Sie den BG-CO2 Timer zwischen die CO2 Quelle und die Mü­ckenfalle mit CO2 Schläuchen. Der von der CO2 Quelle kommende Schlauch sollte an den Anschluss angebracht werden. Die Sinterelemente mit
dem zur Mückenfalle führenden CO2 Schlauch werden an Anschluss an-
gebracht.
28
1
2
1
2
CO2 Quelle
Mückenfalle
Sinterelemente
29
Table des matières
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Composition du produit . . . . . . . . . . . . . . . . . . . . . . . 32
Pile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Fonctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Raccordement aux conduits de CO2 . . . . . . . . . . . 42
Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
30
Introduction
Le Biogents CO2 Timer vous permet de règler les horaires de début et de
n d’émission du CO2. Vous disposez de deux plages horaires maximum par
jour. Grâce à deux conduits, le Biogents CO2 Timer est relié à la source de CO2 d’un coté et au piège à moustiques de l’autre.
31
Composition du produit
Le BG-CO2 Timer est composé d’un boîtier avec écran, de touches de réglage
des horaires d’émission de CO2, de deux raccordements pour les conduits de
CO2 ainsi que d’une pile de 9V.
Raccordement à la source de CO
Touches de réglage des plages horaires
Écran d’achage
2
32
Raccordement au piège à moustiques
Pile
Pour mettre l’appareil en service, il vous faut tout d’abord brancher la pile de 9V (fournie). Pour se faire, dévisser le cache au dos de l’appareil, insérer la pile et la brancher avec le raccord. L’appareil est désormais en service. Refermer la face arrière de l’appareil avec les vis. L’état de chargement de la pile est aché sur l’écran. La pile a en général une durée de vie d’au
moins 9 mois.
33
Face arrière ouverte du boîtier
34
Etat de la pile
Pile plate 9V
Raccord de pile
Fonctions
A
4
5
4
La èche vers le bas indique une émission de CO2.
“A” indique que l’appareil n’est plus en mode “minuterie”.
5
Touche pour avancer l’heure / mode
1
d’émission continue de CO Touche pour reculer l’heure / stopper
2
l’émission de CO Touche de mise en marche de l’écran /
3
Réglage des plages horaires
2
2
35
Allumage de l’écran / Réglage de l’heure
Allumer l’écran en appuyant sur la touche 3.
3
bref
Pour le réglage de l’heure actuelle, rester appuyer 2 secon­des sur la touche 3.
Ajuster l’heure avec la touche 1 pour l’avancer et 2 pour la
reculer.
36
3
2 sec.
1
2
Heure de début 1
1
S1
Avancer l’heure
Reculer l’heure
2
Réglage de l’horaire
3
de début 1
Après avoir régler l’heure, appuyer sur la touche 3. „S1“ (Start time 1) s’ache à l’écran.
Ajuster l’horaire de départ avec les touches 1 et 2 comme
décrit précédemment.
3
2
1
37
Heure de n 1
Avancer l’heure
1
Reculer l’heure
2
E1
Réglage de l’ho-
3
raire de n 1
Après avoir régler l’heure, appuyer sur la touche 3. „E1“ (End time 1) s’ache à l’écran.
Ajuster l’heure de n avec les touches 1 et 2 comme
décrit précédemment.
38
3
2
1
Heure de début
et de n 2
An de programmer une seconde plage horaire, appuyer sur la touche 3 (après avoir programmer une première plage). “S2” apparait sur l’écran.
Ajuster les horaires souhaités comme décrit précédemment. Régler la
seconde heure de n (E2) en appuyant sur la touche 3. “E2” apparait sur l’écran. Une fois terminé, appuyer sur la touche 3. L’appareil fonctionne et la lettre “R” s’ache sur l’écran. N.B: Si vous ne souhaitez utiliser qu’une seule plage horaire, régler S2 et E2 1 minute après E1.
S2
E2
R
39
Emission continue
1
Option 1: CO2 en continu
Pour pouvoir émettre du CO2 en continu, appuyer sur la
touche 1 pendant 2 secondes jusqu’à entendre un bip. Sur l’écran s’ache un „A“ et une èche vers le bas qui indique l’émission de CO2. Pour arrêter l’emission continue, appuyer de nouveau sur la
touche 1.
A
de CO2
40
2 sec.
1
bref
1
Option 2: Couper l’émission de CO
2
Pour couper l’émission de CO2 de façon durable, appuyer sur la touche 2 pendant 2 secondes. Sur l’écran s’ache un “A” (sans èche), qui indique que l’émission de CO2 est
interrompue.
A
Arrêter durable-
2
ment l’émission
de CO
2
2
2 sec.
Pour sortir de ce mode, appuyer de nouveau sur la touche 2.
2
bref
41
Raccordement aux conduits de CO
Installer le BG-CO2 Timer entre la source de CO2 et le piège à moustiques. Le conduit provenant de la source de CO2 doit se brancher avec la sortie Le conduit de CO2 possédant l’embout avec le ltre (bleu ou rouge) et menant au piège doit se brancher sur la sortie .
2
2
42
1
Source de CO
2
1
Piège à moustiques
2
Filtres
43
Indice
Introduzione . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Componenti del prodotto . . . . . . . . . . . . . . . . . . . . . . 46
Batteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Funzioni . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Collegamento tubi per la CO2 . . . . . . . . . . . . . . . . . . 28
Contatto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
44
Introduzione
Il Biogents CO2 Timer consente di programmare l’erogazione della CO2 a
orari da Lei pressi. Si possono impostare due tempi di inizio e di ne al
giorno. Il BG-CO2 Timer viene montato fra la fonte di CO2 e la trappola, alla quale sono già applicati i tubi per la CO2.
45
Componenti del prodotto
Il Biogents CO2 Timer consiste di un corpo di plastica con display, pulsanti per programmare i tempi di erogazione della CO2, due attacchi per tubi di raccordo e una batteria da 9V.
46
Attacco per il tubo di raccordo che porta alla fonte di CO Pulsanti per programmare i tempi di ero­gazione.
Display
Attacco per il tubo che porta la CO2 alla trappola
2
Batteria
Per far funzionare il Timer occorre una batteria da 9V come quella inclusa nella confezione. Per attivare il Timer, la batteria va collegata. Quindi svitare
il retro del Timer. Inserire la batteria e ssarla sul pezzo di raccordo. Ora il
Timer è in funzione. Riavvitare il retro del Timer. Lo stato di carica della batteria viene indicato sul display. La batteria dovrebbe assicurare la funzio nalità del Timer per almeno 9 mesi.
47
Il retro del Timer aperto
48
Stato di carica della batteria
Batteria da 9V
Pezzo di raccordo
Funzioni
A
4
5
4
La freccia verso il basso indica che la CO2 viene rilasciata.
“A” segnala che la funzione Timer è spenta.
5
Pulsante per aumentare il tempo/
1
per l’erogazione continua di CO
Pulsante per diminuire il tempo/
2
disattivare l’erogazione della CO
Pulsante per accendere il display/
3
per programmare i tempi di erogazione
2
2
49
Accendere il display / Impostare l’ora
Accendere il display premendo il pulsante 3.
Per impostare l’ora premere il pulsante 3 per due secondi.
Per aggiustare l’ora, premere il pulsante 1 per aumentarla e
il pulsante 2 per diminuirla.
50
3
breve
3
2 sec.
1
2
Inizio tempo 1
1
S1
Aumentare l’ora di inizio
Diminuire l’ora di inizio
2
Programmare
3
l’ora di inizio 1
Dopo aver impostato l’ora attuale premere il pulsante 3. Sul display si leggerà „S1“ per “orario di inizio primo tempo”
(tempo 1). Aggiustare l’orario di inizio 1 con i pulsanti 1 e 2 come de­scritto sopra.
3
2
1
51
Fine tempo 1
Aumentare l‘ora
1
Diminuire l’ora
2
E1
Programmare la
3
ne del tempo 1
Dopo aver programmato l’ora di inizio 1, premere il pulsante
3. Sul display apparirà “E1” (Fine tempo 1).
Aggiustare la ne del tempo 1 con i pulsanti 1 e 2 come de-
scritto sopra.
52
3
2
1
Inizio e ne del
tempo 2
Per programmare l’inizio e la ne di un secondo tempo, premere il pulsante 3 dopo aver programmato la ne del primo tempo. Sul display apparirà “S2”. Programmare l’ora con i pulsanti 1 e 2 come descritto sopra. Program­mare la ne del secondo tempo premendo il pulsante 3 e impostando poi l’ora. Premere poi il pulsante 3. Sul display apparirà “R”. Ciò inidica che il Timer è in funzione. Nota bene: se non si vuole programmare un secondo tempo, impostare l’inizio e la ne del tempo 2 un minuto dopo la ne del
primo tempo (tempo 1).
S2
E2
53
R
Erogazione continuata
1
Opzione 1: CO2 continuata
Per programmare l’erogazione continuata della CO2 e per
disattivare la funzione Timer premere il pulsante 1 per 2
secondi. Si udirà un ‘clic’ e sul display apparirà contempo­raneamente “A” per “Always CO2”. Una freccia verso il basso indicherà l’erogazione continua della CO2. Per disattivare la
funzione “Always CO2” premere nuovamente il pulsante 1.
A
di CO2
54
2 sec.
1
breve
1
Opzione 2: Disattivare l’ero­gazione di CO
Per disattivare permanentemente la funzione di erogazione della CO2 premere il pulsante 2 per 2 secondi. “A” per “Al-
ways o” sul display indicherà che la funzione di erogazione
della CO2 è stata permanentemente disattivata. Per riattivare la funzione Timer premere nuovamente il pul­sante 2.
2
A
Disattivare la funzione
2
di erogazione continuata di CO
2
2
2 sec.
2
breve
55
Collegamento tubi per la CO
Montare il BG-CO2-Timer fra la fonte di CO2 e la trappola per zanzare. Il
tubo proveniente dalla fonte di CO2 va montato all’attacco . Montare il ltro sinter e il tubo che porta verso la trappola all’attacco .
2
1
2
56
Fonte di CO
2
1
Trappola Biogents
Filtro sinter
2
57
Contact / Kontakt / Contact / Contatto
Biogents AG Weißenburgstr. 22 93055 Regensburg Germany www.biogents.com
Email: biogents@biogents.com
58
Loading...
