FS1
SERIE S
FS
the underside of their thighs. BioFit footrests can maximize worker comfort and productivity –
especially when combined with one of our superior ergonomic chair products.
FS ergonomic footrests feature rectangular steel frames, are available in two platform widths,
and adjust from 3 to 11 inches in height.
FOOTRESTS
Ergonomic footrests promote comfort from head-to-toe.
Free-standing adjustable footrests provide workers foot
support when their chairs cannot, relieving stress on
FOOTREST OVERVIEW STANDARD FEATURES
Adj. Range Platform Size Mfg. #
3"-11" 20" wide x
11" deep
3"-11" 12" wide x
11" deep
FS-1
FS-2
Footrest Frame: All-welded frame is
manufactured of 1" x 1" x 14 ga. steel tubing.
Footrest Platform: Adjustable platform of 14
ga. sheet steel features trouble-free rack and pin
adjustment which can be set in 1" increments
from 3" to 11" above the floor. Platform includes
a non-skid tread.
FS2
PERFORMANCE PACKAGE
Static Control
Metal Parts: FS footrests are standard in
06 Black powder-coated finish or a chromeplated finish when specified with a C option
code or K for static control performance
package.
© 2009. All rights reserved. BioFit Engineered Products. 09/09
