Bio-Blaze BBDT Assembly Guide
Algemene Handleiding
Bio-Blaze
WWW.
BIO-BLAZE.COM
Conditions Générales d’utilisation
Safety and Assembly Instructions
DESIGN TABLE
ENGLISH ENGLISH
TECHNICAL DETAILS
Product Name
Product Dimensions
Weight
Material
Available Color
Burner
Duration of Combustion
Heating Capacity
Included
Patent & Tested
Minimum Room surface
Advised air exchange
Design Table
545 x 300 x 230 mm - 21.4’’ x 11.8’’ x 9’’
10 kg - 22 lbs
Power Coated Steel
Black
Max 1.5 L - Max 50 oz - adjustable flame
+/- 6 hours - 0.25 l/h - 5.4 oz/h
2.8 KW - 9553 BTU
Heat resistant glass/ Burner/ Lever/ Funnel/
Lighter/ Manual
Yes
54 m³ - 1906 ft³ (roof 2.45 m - 8 ft)
Every one hour for rooms < 110 m³ - 3884 ft³
SECURITY AND ASSEMBLY INSTRUCTIONS
Please read carefully the instructions before using a Bio-Blaze® fireplace. The non
compliance of the safety rules can cause serious burns, or even a fire.
Do not allow children or any other person who has not been instructed to use the Bio
Fireplace Bio-Blaze
competent and who have read and understood the security and assembly instructions.
Keep children and pets away from the Bio Fireplace. Do not cover the fireplace; do not
place any flammable materials or clothing on the fireplace.
Do not place the Bio Fireplace underneath or on top of a windowsill to avoid drafts
Do not use the Bio Fireplace Bio-Blaze
Do not use the Bio Fireplace Bio-Blaze
Never leave the fire unattended.
Use the Bio Fireplace Bio-Blaze
technical details)
We do not recommend placing the Bio Fireplace in a bedroom or a bathroom.
The Bio Fireplace Bio-Blaze
®
. The Bio-Blaze® fireplaces can only be used by people of age, who are
®
in caravans, boats, or in vehicles.
®
in non-ventilated rooms.
®
in rooms that comply to the minimum room surface (see
®
is a decorative fireplace item and not a heating system.
ENGLISH ENGLISH
USING THE BIO FIREPLACE BIO-BLAZE® INSTALLATION
Step 1
To use as an insert for a traditional existing fireplace.
Install the Bio Fireplace inside your existing fireplace on a flat, horizontal and firm floor.
Make sure not to expose the product to intense movements. Never install the product in a draught.
Ensure that flammable products (curtains, furniture or other flammable materials) are not nearby the
fireplace.
Close the damper in your chimney.
Step 2
Place the burner(s) in the insert/ opening.
Step 3
Step 1 - Fuel
The Bio Fireplace Bio-Blaze
®
burns exclusively with bio-ethanol
liquid. This bio-ethanol requires caution; use only after reading all
the security instructions.
Carefully pour in the bio-ethanol into the burner(s). Use the provided.
The burner(s) can be lled up to ¾ level.
Make sure that the liquid does not spilled outside the burner. If it
is the case, wait several minutes until it evaporates before lighting
it.
USE ONLY BIO-ETHANOL as of 95% ethanol, suitable for the fireplace Bio-Blaze
®
.
Do not use gel or any petrol products: spirits, essence …
Do not mix the bio ethanol with other fuels; the Bio-ethanol is a (highly) inflammable product.
Avoid contact with the eyes and skin.
Do not stock the bio ethanol nearby a Bio Fireplace.
Do not use the Bio Fireplace Bio-Blaze
Do not use the Bio Fireplace Bio-Blaze
®
and its burner to cook food, to heat water or to grill meat.
®
and its burner if ammable gas is in the room.
Persons who have breathing problems needs to be advised by their doctors before use.
Step 2 - Lightning
To light the fire use a long lighter provided in the kit, or a long
match. With a normal lighter, you may risk burning injuries.
Do not place anything on the fire. Logs and stones should be
around the flame, not on the flame.
The bio-ethanol should be at room temperature when being
used.
Do not smoke while lighting the burners of the Bio Fireplace.
Slide the heat resistant glasses in the slots.
Step 4
If you are using decorative log set or ceramic stones make sure that they are heat resistant.
Make sure that stones or log sets are not placed in to the flame, the closing and opening space of
the burner needs to be clear and accessible.
If you are using the Bio-Blaze
®
stones, you need to wash the stones before using them with water
and soap. Let them dry. Now they are ready to be used.
The burner is made from stainless steel, it will get hot; avoid contact with the stainless steel
element.
Never take the burner in your hands while it’s burning or if it is hot.
Never put your head above the burner while lighting it.
Never leave the bio ethanol bottle open next to a fireplace.
Never add bio ethanol while the fireplace is burning.
Never leave the Fireplace without surveillance. Put out the fire in case you would like to leave home
or go to bed.
In case of burning injuries, call your nearest doctor or hospital service. Do not apply any treatment on
the burn. See a doctor for a treatment.
Respect the law of your city in terms of the fire security. It is not recommended to burn a Bio-Blaze
near a tree or any flammable vegetation.
Never move the fireplace while it is burning.
®
