Bio-Blaze BBD1I Assembly Guide
Algemene Handleiding
Bio-Blaze
WWW.
BIO-BLAZE.COM
Conditions Générales d’utilisation
Safety and Assembly Instructions
DIAMOND I & DIAMOND II
ENGLISH ENGLISH
TECHNICAL DETAILS
Product Name
Product Dimensions
Weight
Material
Available Colors
Burner
Duration of Combustion
Heating Capacity
Included
Patent & Tested
Minimum Room surface
Advised air exchange
Product Name
Product Dimensions
Weight
Material
Available Colors
Burner
Duration of Combustion
Heating Capacity
Included
Patent & Tested
Minimum Room surface
Advised air exchange
Diamond I
790 x 625 x 200 mm - 31.1’’ x 24.6’’ x 7.87’’
22 kg - 49 lbs
Stainless Steel - Power Coated Steel
Stainless Steel/ Black/ Sliver
3 x 0.33l - 3 x 11 oz - round burners with reducers
+/- 3 hours - 0.11 l/h - 3.7 oz/h
2 KW - 6824 BTU
3 round burners/ 3 reducers/ Tool to extinguish/ Hanging
system/ Funnel/ Lighter/ Marble Stones/ Manuel
Yes
49 m³- 1730 ft³ (roof 2.45 m - 8 ft)
Every one hour for rooms < 110 m³- 3884 ft³
Diamond II
790 x 625 x 200 mm - 31.1’’ x 24.6’’ x 7.87’’
22 kg - 49 lbs
Stainless Steel - Power Coated Steel
Stainless Steel/ Black/ Sliver
Max 1.2 L - Max 40 oz - adjustable flame
+/- 3 hours - 0.4 l/h - 13.5 oz/h
2 KW - 6824 BTU
Burner/ Lever/ Hanging system/ Funnel/ Marble
Stones/ Lighter/ Manuel
Yes
49 m³ - 1730 ft³ (roof 2.45 m - 8 ft)
Every one hour for rooms < 110 m³- 3884 ft³
SECURITY AND ASSEMBLY INSTRUCTIONS
Please read carefully the instructions before using a Bio-Blaze® fireplace. The non
compliance of the safety rules can cause serious burns, or even a fire.
Do not allow children or any other person who has not been instructed to use the Bio
Fireplace Bio-Blaze
competent and who have read and understood the security and assembly instructions.
Keep children and pets away from the Bio Fireplace. Do not cover the fireplace; do not
place any flammable materials or clothing on the fireplace.
Do not place the Bio Fireplace underneath or on top of a window sill to avoid drafts.
Do not use the Bio Fireplace Bio-Blaze
Do not use the Bio Fireplace Bio-Blaze
Never leave the fire unattended.
Use the Bio Fireplace Bio-Blaze
(see table installation conditions)
We do not recommend placing the Bio Fireplace in a bedroom or a bathroom.
The Bio Fireplace Bio-Blaze
®
. The Bio-Blaze® fireplaces can only be used by people of age, who are
®
in caravans, boats, or in vehicles.
®
in non-ventilated rooms.
®
in rooms that comply to the below listed specifications
®
is a decorative fireplace item and not a heating system.
ENGLISH ENGLISH
USING THE BIO FIREPLACE BIO-BLAZE® INSTALLATION
Step 1
The hanging system is integrated in the back of the fireplace. First mount the top wall bracket, using
good quality plugs and screws that suits your type of wall, then lift the fireplace up ensuring that
the rear ledge of the fireplace engages the top wall bracket and is sitting centrally positioned on the
bracket.
Ensure that the fireplace is well attached to the wall. The Bio-Blaze
®
fireplace can only be hung on
walls without any flammable materials.
Make sure that there are no electric cables or wiring located behind your fireplace.
Ensure that flammable products (curtains, furniture or other flammable materials) are not nearby the
fireplace.
Keep a safety distance of at least 1 meter or 3 foot (on the left-, right- and front side) for objects.
Keep a safety distance of at least 1 meter or 3 foot between fireplace and ceiling.
Step 2
The Bio Fireplace Bio-Blaze® burns exclusively with bio-ethanol liquid. This bio-ethanol requires
caution; use only after reading all the security instructions.
Carefully pour in the bio-ethanol into the burner(s). Use the provided.
The burner(s) can be lled up to ¾ level.
Make sure that the liquid does not spilled outside the burner. If it
is the case, wait several minutes until it evaporates before lighting
it.
USE ONLY BIO-ETHANOL as of 95% ethanol, suitable for the fireplace
Bio-Blaze
®
.
Do not use gel or any petrol products: spirits, essence …
Do not mix the bio ethanol with other fuels; the Bio-ethanol is a (highly) inflammable product.
Avoid contact with the eyes and skin.
Do not stock the bio ethanol nearby a Bio Fireplace.
Do not use the Bio Fireplace Bio-Blaze
Do not use the Bio Fireplace Bio-Blaze
®
and its burner to cook food, to heat water or to grill meat.
®
and its burner if ammable gas is in the room.
Persons who have breathing problems needs to be advised by their doctors before use.
Step 2 - Lightning
To light the fire use a long lighter provided in the kit, or a long match. With a normal lighter, you may
risk burning injuries.
Do not place anything on the fire. Logs and stones should be
around the flame, not on the flame.
The bio-ethanol should be at room temperature when being
used.
Do not smoke while lighting the burners of the Bio Fireplace.
Place the burner(s) in the insert/ opening.
Only for Diamond I version: The flame reducers are to be placed on the top of the cylindrical burner.
Do not take out the reducers while burning. You may get injured
Step 3
Wash the heat resistant stones before using them with water and soap. Let them dry. Now the stones
are ready to be used.
If you are using any other type of decorative log set or ceramic stones make sure that they are heat
resistant.
Make sure that stones or log sets are not placed in to the flame, the closing and opening space of
the burner needs to be clear and accessible.
Step 1 - Fuel
The burner is made from stainless steel, it will get hot; avoid
contact with the stainless steel element.
Never take the burner in your hands while it’s burning or if it is hot.
Never put your head above the burner while lighting it.
Never leave the bio-ethanol bottle open next to a fireplace.
Never add bio ethanol while the fireplace is burning.
Never leave the Bio Fireplace without surveillance. Put out the fire in case you would like to leave
home or go to bed.
In case of burning injuries, call your nearest doctor or hospital service. Do not apply any treatment on
the burn. See a doctor for a treatment.
Respect the law of your city in terms of the fire security. It is not recommended to burn a Bio-Blaze
near a tree or any flammable vegetation.
Never move the fireplace while it is burning.
Step 3 - Extinguishing the replace
®
