Binatone Electronics T25T User Manual

User’s Guide

REMOTE TRAINING SYSTEM

Model: SCOUTTRAINER25

The features described in this User's Guide are subject to modifications without prior notice.

Welcome...

to your new Motorola Remote Training System!

Thank you for purchasing the Motorola SCOUTTRAINER25. Your new
Remote Training System will provide a quick and effective means of solving
common problem behaviors and reinforcing basic obedience commands
your pet already knows. You can choose from two training modes - warning
tone only or 9 levels of static correction from gentle to firm.

Please retain your original dated sales receipt for your records.
For warranty service of your Motorola product, you will need to provide a
copy of your dated sales receipt to confirm warra nty status. Registration is
not required for warranty coverage.

For product related questions, please call:

US and Canada 1-888-331-3383
Email: [e-mail]

This User's Guide provides you with all the information you need to get the
most from the product.

Please read and follow the instructions in this User’s Guide along with the
Safety Instructions on page 8 before you using this product.

Got everything?

• 1 x Pet Collar Unit

• 1 x Collar Strap

• 1 x Remote Control Unit

• 1 x Test Light for Collar Contacts

• 2 Pairs of Collar Contacts - Long & Short (For Pet Collar Unit)

In multi-collar packs, you will find one or more additional Pet Collar Units
with power adapter units.

Overview of the Pet Collar Unit

1 2 3

5

4

1. Pair Key

2. Indicator LED

Lights up in green for 3 seconds
when the unit is powered on and
flashes slowly during standby.
Lights up in red when battery is low.
Flashes quickly in green and red
when delivering static correction.

3. Power Key

Press once to power the unit On/
Off.
Indicator LED lights up in green for
3 seconds when the unit is powered
on.

4. Battery Cover

5. Collar Contacts

Overview of the Remote Control Unit

1

2
3

4

5

6

7

8

9

1. Display (LCD screen)

2. Up Key

Correction Mode: Increase level
Menu Mode: Move up

3. Down Key

Correction Mode: Decrease level
Menu Mode: Move down

4. Tone Key

Press to send a tone to the Pet Collar
Unit.
Press to confirm and pair with the
Pet Collar Unit.

5. Static Correction Key

Press and hold to deliver static
correction to the Pet Collar Unit.

6. Antenna

7. Power Key

Press and hold to power ON/OFF.

8. Battery Cover

9. Leash Clip

Symbols on the Remote Control Unit

Battery level on Remote Control Unit.

Pet Collar Number.

Displays the selected STATIC CORRECTION LEVEL (Level 0 to 9).
When 0 is displayed, only tone alerts are sent to the Pet Collar Unit.

Displays when TONE KEY is pressed.

How the Remote Training System works

The Training System comes with a Remote Control Unit that is paired with the
Pet Collar Unit. At the push of the STATIC CORRECTION KEY on the
Remote Control Unit, a signal is sent to the Pet Collar Unit, which delivers static
correction to your dog to assist you with shaping and modifying its behavior.

The Remote Control Unit is also designed with a TONE KEY . At the push
of the key, a tone is sent to the Pet Collar Unit. The tone function is good for
giving your dog an opportunity to respond to your commands prior to pressing
the

STATIC CORRECTION KEY .

Important guidelines when using the Remote Training System

• Included in the Training System are Collar Contacts in three different
lengths (short, medium and long) that deliver static correction to your dog.
Choose the appropriate length for your dog’s hair coat. The Pet Collar Unit
was shipped with medium Collar Contacts that are suitable for dogs with
medium hair coats. If your dog has dense coats or undercoats, use one of the
longer Collar Contacts included with the product.

• Proper fit of the Pet Collar Unit is critical to the performance and
effectiveness of the Training System. If the fit is too loose, the collar will not
be able to get sufficient contact with the skin to deliver static correction. If
the fit is too tight, it will irritate your dog’s skin.

• Tighten the collar high on your dog’s neck, tight enough that you can get
two fingers between the collar strap and your dog. It should not be able to
rotate around the neck.

• Do not make your dog wear the Pet Collar Unit for more than 12 hours
continuously to avoid skin irritation.

• Do not connect a leash to the Pet Collar Unit as this might pull the Collar
Contacts too tight against your dog’s neck.

• When connecting a separate collar for the leash, make sure that it does not
add pressure on the Pet Collar Unit.

• Check the contact area on your dog’s neck for signs of irritation. If there is a
rash or sore, discontinue use until the skin is completely healed. See a
veterinarian if the condition persists.

Table of contents

1. Safety Instructions ....................................................................................8

2. Getting Started......................................................................................... 9

2.1 Insert Batteries on the Remote Control Unit ..............................................9

2.2 Attach the Adjustable Strap to the Pet Collar Unit ..................................10

2.3 Insert and Remove Battery on the Pet Collar Unit ...................................10

2.4 Fit the Pet Collar Unit on your Dog’s Neck ..............................................12

2.5 Trim Away Excess Strap Length ...............................................................13

2.6 Change Collar Contacts ..........................................................................14

2.7 Using the Test Light.................................................................................. 15

3. Using the Pet Collar Unit ........................................................................16

3.1 Powering On/Off the Pet Collar Unit ......................................................16

3.2 Pairing with the Remote Control Unit ......................................................16

4. Training Your Dog with the Remote Training System ...........................17

4.1 Powering On/Off the Remote Control Unit ............................................17

4.2 Select a Pet Collar Unit (if you more than 1 Pet Collar Units) ..................17

4.3 Deliver Static Correction ..........................................................................18

4.4 Determine the TRAINING LEVEL for your dog .......................................18

4.5 When to Increase Level of Static Correction ..........................................19

4.6 Tone Key ...................................................................................................19

5. Training Tips ...........................................................................................20

6. Disposal of the Device (Environment) ................................................... 22

7. Cleaning and Care .................................................................................. 23

8. Frequently Asked Questions ................................................................. 24

9. Troubleshooting .....................................................................................26

10. General Information ............................................................................... 27

ENGLISH

7

1. Safety Instructions

WARNING:

As with any electrical device, supervision of your pet’s usage should be
exercised until your pet is acclimated to the product.
If you r p et i s p ron e t o ch ew ing , w e st ro ngl y r eco mm end yo u ke ep t hi s an d
all other electrical devices out of its reach.

RISK OF SKIN DAMAGE

• Determine a proper fit of the Pet Collar Unit on your dog’s neck. If worn
for too long or the fit is too tight, it may cause skin damage.

• Check your dog’s neck area daily for signs of skin irritation.

• Discontinue use immediately if a rash or sore is found on the neck area.

• AVOID wearing for more than 12 continuous hours a day.

• Clean your dog’s neck area and the Collar Contacts on the Pet Collar
Unit with a soft damp cloth weekly.

WARNING

The Remote Training System is suitable for use on healthy, non-aggressive dogs
to correct their behavior when used as describe d in this User's Guide. Therefore,
always read the instructions in this User's Guide carefully before using the
product.

• DO NOT USE ON AGGRESSIVE DOGS - This product is not for use on

aggressive dogs. If you are not sure if this product is suitable for your dog, please
consult a certified trainer or your veterinarian.

• This product is not a toy. Do not allow children to play with it.

• This product is not a substitute for responsible supervision of your dog.

• Test this product and all its functions so that you are familiar with it prior to

actual use.

• Only use batteries of the same type. The Remote Control Unit uses 2x 1.5V

AAA-sized alkaline batteries.

• Keep this User's Guide for future reference.

CAUTION

There is danger of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to their instructions.

8 Safety Instructions

2. Getting Started

Small cross-head
or flat end
screwdriver.

+

+

2.1 Insert Batteries on the Remote Control Unit

The Remote Control Unit uses 2x AAA-sized alkaline batteries.

1. Use a small cross-head or flat end screwdriver to unscrew the battery
compartment cover as shown above.

2. Fit the batteries into the compartment in the correct polarity as shown
below.

3. Close the battery compartment cover and gently tighten the screw in a
clockwise direction using a small cross-head or flat end screwdriver.

4. Press and hold the POWER KEY to power the Remote Control Unit
on or off.

ENGLISH

Getting Started 9

2.2 Attach the Adjustable Strap to the Pet Collar Unit

Slot

Slot

Collar Contacts

Small cross-head or
Flat end screwdriver.

IMPORTANT
Power off the Pet Collar Unit before attaching the strap.

1. Set the Pet Collar Unit facing down with the Collar Contacts facing up.

2. With the front side of the buckle facing down, thread the strap through the

first slot, moving it towards the second slot.

3. Continue to thread through the second slot.

2.3 Insert and Remove Battery on the Pet Collar Unit

IMPORTANT

Do not install the battery while the Pet Collar Unit is strapped to your dog.

The Pet Collar Unit uses a replaceable battery (CR2450).

1. Use a small cross-head or flat end screwdriver to unscrew the battery
compartment cover as shown above.

2. Place the battery with negative pole (-) facing upwards in the
compartment.

10 Getting Started
