User’s Guide
REMOTE TRAINING SYSTEM
Model: SCOUTTRAINER100
The features described in this User's Guide are subject to modifications without prior notice.
Welcome...
to your new Motorola Remote Training System!
Thank you for purchasing the Motorola Remote Training System. Your new
Remote Training System will provide a quick and effective means of solving
common problem behaviors and reinforcing basic obedience commands
your dog already knows. You can choose from three different training modes
- warning tone only, gentle vibration or 15 levels of static correction from
gentle to firm, or give verbal commands through the Pet Collar Unit with the
digital walkie-talkie function.
Please retain your original dated sales receipt for your records.
For warranty service of your Motorola product, you will need to provide a
copy of your dated sales receipt to confirm warra nty status. Registration is
not required for warranty coverage.
For product related questions, please call:
US and Canada 1-888-331-3383
Email: support@motorolamonitors.com
This User's Guide provides you with all the information you need to get the
most from the product.
Please read and follow the instructions in this User’s Guide along with the
Safety Instructions on page 8 before you using this product.
Got everything?
• 1 x Pet Collar Unit
• 1 x Power Adapter (for Pet Collar Unit)
• 1 x Collar Strap
• 1 x Remote Control Unit
• 1 x Test Light for Metal Contacts
• 2 pairs of Collar Metal Contacts (Long and Short)
In multi-collar packs, you will find one or more additional Pet Collar Units
with power adapter units.
Overview of the Pet Collar Unit
1 2
3
7
5 6
4
1. Pair Key
2. Power Key
Press and hold to power ON.
The Indicator LED lights up in green
for 5 seconds when powered on.
Press and hold to power OFF.
3. Metal Contacts
4. Power Ada pter Socket
5. Indicator LED
Lights up in green for 5 seconds
when powered on and flashes
slowly during standby.
Lights up in red when battery is low.
Flashes alternately in green and red
when delivering static correction.
6. Charging LED
Lights up in blue when charging.
7. Speaker
Delivers tone or voice sent from the
Remote Control Unit.
Overview of the Remote Control Unit
2
3
6
7
8
1
4
5
9
11
10
12
13
14
OK
1. Display (LCD screen)
2. OK Key
Press to select the desired option
and lock the setting.
3. Menu Key
Press to pair or unpair with the Pet
Collar Unit. You can pair it with up to
4 Pet Collar Units.
4. Up Key
Correction Mode: Increase level
Menu Mode: Move up
5. Down Key
Correction Mode: Decrease level
Menu Mode: Move down
6. Tone Key
Press to send a tone to the Pet Collar
Unit.
7. Vibra tion Key
Press to vibrate the Pet Collar Unit.
8. Static Correction Key
Press and hold to deliver static
correction to the Pet Collar Unit.
9. Microphone
10. Antenna
11. Tal k k ey
Press and hold to give verbal
commands through the Pet Collar
Unit.
12. Power Key
Press and hold to power ON/OFF.
13. Battery Cover
14. Leash Clip
Symbols on the Remote Control Unit
RF signal strength of the Remote Control against the Pet Collar Unit.
Displays when you enter Menu mode.
Alert indication on Collar 3 (battery low, out of range, etc).
Battery level on Remote Control Unit.
Pet Collar Number.
Select to REMOVE collar.
Select to PAIR collar.
Displays the selected STATIC CORRECTION LEVEL (Level 0 to 15).
When 0 is displayed, only tone and vibration alerts are sent to the Pet
Collar Unit.
Displays when TALK KEY is pressed.
Displays when VIBRATION KEY is pressed.
Displays when TONE KEY is pressed.
How the Remote Training System works
The Remote Training System comes with a Remote Control Unit that is paired
with the Pet Collar Unit. At th e push of the STATIC CORRECTION KEY on
the Remote Control Unit, a signal is sent to the Pet Collar Unit, which delivers
static correction to your dog to assist you with shaping and modifying its
behavior.
The Remote Control Unit is also designed with a TONE KEY and a
VIBRATION KEY . At the push of any one of these keys, a tone or vibration
signal is sent to the Pet Collar Unit, which delivers a tone or vibration to your dog.
The tone function is good for giving your dog an oppo rtunity to respond to your
commands prior to pressing the
vibration function can be used in many ways. However, it is best suited as a
secondary reinforcement for rewards.
STATIC CORRECTION KEY . The
Important guidelines when using the Remote Training System
• Included in the Remote Training System are Metal Contacts in three
different lengths (short, medium and long) that deliver static correction to
your dog. Choose the appropriate length for your dog’s hair coat. The Pet
Collar Unit was shipped with medium Metal Contacts that are suitable for
dogs with medium hair coats. If your dog has dense coats or undercoats, use
one of the longer Metal Contacts included with the product.
• Proper fit of the Pet Collar Unit is critical to the performance and
effectiveness of the Remote Training System. If the fit is too loose, the collar
will not be able to get sufficient contact with the skin to deliver static
correction. If the fit is too tight, it will irritate your dog’s skin.
• Tighten the collar high on your dog’s neck, tight enough that you can get
two fingers between the collar strap and your dog. It should not be able to
rotate around the neck.
• Do not make your dog wear the Pet Collar Unit for more than 12 hours
continuously to avoid skin irritation.
• Do not connect a leash to the Pet Collar Unit as this might pull the Metal
Contacts too tight against your dog’s neck.
• When connecting a separate collar for the leash, make sure that it does not
add pressure on the Pet Collar Unit.
• Check the contact area on your dog’s neck for signs of irritation. If there is a
rash or sore, discontinue use until the skin is completely healed. See a
veterinarian if the condition persists.
Table of contents
1. Safety Instructions.................................................................................... 8
2. Getting Started ......................................................................................... 9
2.1 Remote Control Unit Battery Installation ................................................... 9
2.2 Attach the Adjustable Strap to the Pet Collar Unit ..................................10
2.3 Charging the Pet Collar Unit ....................................................................10
2.4 Fit the Pet Collar Unit on your Dog’s Neck ..............................................11
2.5 Trim Away Excess Strap Length .............................................................. 12
2.6 Change Metal Contacts ...........................................................................13
2.7 Using the Test Light ..................................................................................14
3. Using the Pet Collar Unit ........................................................................15
3.1 Powering On/Off the Pet Collar Unit ......................................................15
3.2 Pairing with the Remote Control Unit ......................................................15
4. Training Your Dog with the Remote Training System ...........................16
4.1 Powering On/Off the Remote Control Unit ............................................16
4.2 Select a Pet Collar Unit (if you have 2 or more Pet Collar Units) ............. 16
4.3 Deliver Static Correction ......................................................................... 16
4.4 Determine the TRAINING LEVEL for your dog .......................................17
4.5 When to Increase Level of Static Correction .......................................... 17
4.6 Walkie-Talkie Function............................................................................. 18
4.7 Tone Key ...................................................................................................18
4.8 The Vibration Key .....................................................................................18
5. Training Tips ...........................................................................................19
6. Disposal of the Device (Environment) ................................................... 21
7. Cleaning and Care .................................................................................. 22
8. Frequently Asked Questions ..................................................................23
9. Troubleshooting .....................................................................................25
10. General Information ...............................................................................26
ENGLISH
7
1. Safety Instructions
WARNING:
DO NOT USE ON AGGRESSIVE DOGS - This product is not for use on
ag gres sive dogs . If y ou ar e no t sur e if t his prod uct i s su itab le fo r you r do g,
please consult a certified trainer or your veterinarian.
RISK OF SKIN DAMAGE
• Determine a proper fit of the Pet Collar Unit on your dog’s neck. If worn
for too long or the fit is too tight, it may cause skin damage.
• Check your dog’s neck area daily for signs of skin irritation.
• Discontinue use immediately if a rash or sore is found on the neck area.
• AVOID wearing for more than 12 continuous hours a day.
• Clean your dog’s neck area and the Metal Contacts on the Pet Collar
Unit with a soft damp cloth weekly.
WARNING
The Remote Training System is suitable for use on healthy, non-aggressive dogs
to correct their behavior when used as describe d in this User's Guide. Therefore,
always read the instructions in this User's Guide carefully before using the
product.
• This product is not a toy. Do not allow children to play with it.
• This product is not a substitute for responsible supervision of your dog.
• Test this product and all its functions so that you are familiar with it prior to
actual use.Remote Training System
• Only use batteries of the same type. The Remote Control Unit uses 2x 1.5V
AAA-sized alkaline batteries.
• Keep this User's Guide for future reference.
CAUTION
There is danger of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to their instructions.
8 Safety Instructions
2. Getting Started
Small cross-head
or flat end
screwdriver.
+
+
2.1 Remote Control Unit Battery Installation
The Remote Control Unit uses 2x AAA-sized alkaline batteries.
1. Use a small cross-head or flat end screwdriver to unscrew the battery
compartment cover as shown above.
2. Fit the batteries into the compartment in the correct polarity as shown
below.
3. Close the battery compartment cover and gently tighten the screw in a
clockwise direction using a small cross-head or flat end screwdriver.
4. Press and hold the POWER KEY to power the Remote Control Unit
on or off.
ENGLISH
Getting Started 9
2.2 Attach the Adjustable Strap to the Pet Collar Unit
Slot
Slot
Metal Contacts
IMPORTANT
Power off the Pet Collar Unit before attaching the strap.
1. Set the Pet Collar Unit facing down with the Metal Contacts facing up.
2. With the front side of the buckle facing down, thread the strap through the
first slot, moving it towards the second slot.
3. Continue to thread through the second slot.
2.3 Charging the Pet Collar Unit
1. Connect the small plug of the power adapter to the Pet Collar Unit and the
other end into the electrical outlet.
2. The Charging LED will light up in blue to indicate charging.
NOTE
Only use the enclosed power adapter (6V DC / 450mA).
The battery pack will take approximately 16 hours to charge. The Power LED
will light up in red when battery is low. To conserve battery life, press and hold
the POWER KEY to power off the Pet Collar Unit when it is not in use.
10 Getting Started
