Binatone Electronics SM320 Users Manual

USER GUIDE
US
MOBILE
TELEPHONE
SM320
2
CONTENTS
1 BOX CONTENT ................................................... 3
2 GETTING TO KNOW YOUR PHONE .................... 4
3 MENU OPERATION ............................................. 8
4 INSTALLATION AND SETUP ................................ 9
3

1 BOX CONTENT

In the box you will find:
• 1 mobile handset
• 1 charging cradle
• 1 power adapter
• 1 handset back cover
• 1 user guide
• 1 USB cable Keep the packing materials in a safe place in case you later need to transport the device.
Warning
The torch uses a high-brightness LED. Do not shine directly into eyes, or view with optical instruments.
IMPORTANT
Your handset is not supplied with a SIM card, you will need to insert a SIM card for the handset to work correctly.
BECAUSE WE CARE
Thank you for purchasing this product. This product has been designed and assembled with utmost care for you and the environment. This is why we supply this product with a quick installation guide to reduce the number of paper (pages) and therefore save trees to be cut for making this paper. Thank you for supporting us to protect our environment.
4

2 GETTING TO KNOW YOUR PHONE

2.1 Keys and parts
7
9
8
1
4
6 6
11
2
5 3
10
12
# Meaning
1
2
Left Soft
Key
Right
Soft Key
Performs the function of displayed text above: Menu / OK
Performs the function of text above: Contacts / Back
• Press to browse menu
Up and
3
Down
Key
• Press to move cursor up or down while editing
• Press to manually change the frequency in FM interface
• Press for + and - in the Calculator
14
13
4 Talk key
End key
5
M1/M2
6
key
Power
7
key
SOS
8
key
Keypad
9
lock key
5
• Press to answer a call during ringing
• Press to enter the calls log in standby
• Press to dial a number
• Press to end a call
• Press to return to the Home Screen / Standby mode
• Direct memory keys for storing a telephone number you often use, long press to dial out M1/M2
• Press to search channel in the FM interface
• Press to switch left/right in menu
• Press for X and / in the Calculator
• Press and hold to switch the phone on or off
• Press to Light the screen
• Long press to start SOS procedure : SOS alarm /dial out the 5 pre-stored memo­ry numbers/send SOS SMS
• Push up to lock the Keypad
• Push down to unlock the Keypad
6
Number
10
11 * Key
12 # Key
13
14
key
Volume control
buttons
Torch
key
• Press to input telephone number.
• In edit mode : press to input numbers or letters.
• Press to input */
+/ P/ W symbols.
• Press to input “#”.
• In edit mode : press to change input method.
• Long press to active silent mode
• Ring volume in standby or speaker volume in call.
• Volume in FM radio
• Long press to switch torch LED ON/OFF
2.2 Display icons and symbols
The standby screen shows the following information:
Meaning
Radio link
On with signal strength when linked. with mobile network.
Battery charge level
Internal segments cycle during battery charging.
Alarm
On if alarm is set.
Ring and Vibrate off
Ringer and vibration is off.
Ring on
On if only the ringer is enabled.
Vibrate on
On if only vibration is enabled.
Vibrate and ring on
On if both are enabled.
Vibrate then ring
On if vibrate then ring is enabled.
New SMS
Indicates you have new text messages.
Lock
On when the keypad is locked.
FM radio
On when FM is active.
Bluetooth
On when bluetooth is active.
Earphone
On when earphone plugged in.
7
8

3 MENU OPERATION

Menu lists are used for set up and operation. The left and right soft key functions initially are Menu and Names.
• Press Menu to display Messaging the rst entry in the main Menu list.
Use Up or Down to scroll the menu list. The
display changes and soft keys become OK and Back.
• Press Ok/ Back for the next/ previous display.
When writing text, use the # key to Switch input method between (ABC), (abc) , (Abc) and numerals (123). Use Up / Down key and M1/M2 to move the cursor, right soft key to delete letters and the * key for symbols or punctuation .

4 INSTALLATION AND SETUP

Before operating, a SIM card must be installed. Keep the SIM card out of reach of small children. The SIM card and its contacts can be damaged easily by scratches or bending, so handle the card carefully.
4.1 Install the SIM card and battery
• Switch off the phone, disconnect the power adaptor.
• To remove the back cover, lift the cover off from the gap at left side.
• Remove the battery.
• Carefully slide the SIM card into the holder with the gold connectors face down ( as shown 1).
• Replace the battery by aligning the gold connectors on the battery with those on the phone and push the end of the battery down until it clicks into place (as shown 2).
• Replace the back cover by placing it at on the back of the handset and pushing down until it clicks into place.
1. 2.
9
10
4.2 Charge the battery
Warning:
Use only the supplied/approved batteries and chargers. Using others may be dangerous and will invalidate warranty. A battery must be tted. Do not charge with the back cover removed.
• Connect the charger lead rmly into the USB socket in the right of the handset, or place the handset directly in the charging cradle.
• Plug the mains power adapter into an AC mains socket. If the handset is turned on, “Charger connected” displays for a few seconds and the battery symbol bars scroll to indicate that charging has started.
• If “Charger connected“ does not display, disconnect and retry.
If charging still fails, contact the helpline.
• The battery is fully charged when the bars within the battery symbol are continuously on. Disconnect the charger from the phone and the AC outlet. “Charger removed” displays for a few seconds to indicate the charging has stopped.
Note:
The battery can also be charged if the handset is connected to a computer USB port.
11
4.3 Switching on and off
To switch the phone on and off:
• To switch off, press and hold Power key until the display turns off.
• To switch back on, press and hold Power key until the display turns on.
Warning:
Do not switch on when mobile phone use is prohibited or if it may cause interference or danger.
12

5 MAKING AND ANSWERING CALLS

5.1 To make a call
Ensure the phone is switched on and in service.
• Key in the telephone number including area code. (To add prefix “+” press the * key
twice repeat)
• Press Talk to dial the number on the display.
• To end calls press the End Call button.
5.2 Last number redial
• In idle mode, press Talk to see the All calls list – a list of the last dialled, received and missed calls.
• Press Up/Down to go to the number you want.
• Press Talk to dial the number.
5.3 To answer a call
• When the phone rings, press Talk to answer it.
• During a call, press Volume control buttons to change the volume.
The volume level is displayed and stays for future calls.
5.4 To switch to speakerphone
• During a call, press H-Free to turn Loudspeaker on and press H-Held to turn Loudspeaker off.
• To end the call press the End Call button.
5.5 To mute the microphone
• During a call, press Left Soft Key for Option then On /Off Mute .
13

6 USING THE PHONEBOOK

You can store names and phone numbers in the Internal phone book (up to 300) and in the SIM phone book (SIM dependant, but a maximum of 250).
6.1 To access the phonebook
In idle mode:
• Press RSK or Menu then Down to Phonebook, OK.
Note:
Indicates entries on the SIM card
Indicates entries in the Internal phone book.
6.2 Add a new phonebook entry
• Press Menu, then Down to Phonebook, press OK to open the phonebook menu.
• Select Add new contact , and press Options, then press Select to SIM / to Phone ,then OK.
• Enter the Name then press Down and then enter the telephone number.
• Press Options then Save the new contact.
Note:
When writing the name, use # to switch
between (ABC), (abc) ,(Abc) and Numerals (123).
6.3 To call a phonebook number
• In the idle, Press Right soft key to open the phonebook.
• Press Up/Down to nd the name you want to, Press Talk key to dial the number.
14
6.4 To edit a phonebook entry
• Press Right soft key to open the phonebook,
then Up/Down to nd the entry you want to change.
• Press Options then Up/Down to select Edit, then modify the name ,and then Press Down and modify the Number.
• Press Options then Save the change(s).
6.5 To delete a phonebook entry
• Press Right soft key to open the phonebook,
then Up/Down to nd the entry you want to delete.
• Press Options then Up/Down to select Delete,
then Yes to conrm the Delete.
6.6 To copy an entry to the phone or SIM card
• Press Right soft key to open the phonebook,
then Up/Down to nd the entry you want to copy.
• Press Options then Up/Down to select Copy, then press the LSK to select copy to Phone or
to SIM.
6.7 To add an entry to Blacklist
• Press Right soft key to open the phonebook,
then Up/Down to nd the entry you want to add to Blacklist.
• Press Options then Up/Down to select add to Blacklist, then Yes to conrm.
